USER MANUAL
PortaBright
100 W BI-COLOR MONOLIGHT
MLACDCB

PortaBright 100 W Bi-Color Monolight - USER MANUAL
2
THANK YOU FOR CHOOSING GENARAY
Genaray’s versatile and powerful PortaBright offers
soft yet bright light that’s perfect for photographers and
videographers on the go. The PortaBright runs on AC
power or an integrated rechargeable lithium-ion battery
that serves up enough power to illuminate your subjects
with an extremely high degree of color accuracy.
The COB LED delivers bright, flicker-free light that
eliminates the strobing effect that’s often seen in slow-
motion video. And thanks to the PortaBright’s circular
COB array, it also provides a natural-looking catch light.
For extra directionality or texture, the integrated Bowens
accessory mount is compatible with a host of easy-to-
attach accessories.
The PortaBright is outfitted with Genaray’s 2.4 GHz
Lightseeker remote system, which adds the capability
of selecting between 16 channels and five groups. The
Lightseeker remote is available separately, and it allows
you to control multiple Lightseeker-equipped Genaray
lights from up to 300 feet away.
PortaBright
INTRODUCTION

PortaBright 100 W Bi-Color Monolight - USER MANUAL 3
· Please read and follow these
instructions, and keep this manual in
a safe place.
· Keep this unit away from water and
any flammable gases or liquids.
· Make sure the unit is powered off
when plugging it into a power source.
· Use only the correct, recommended
voltage.
· Do not attempt to disassemble or
repair the equipment—doing so will
void the warranty, and Genaray will not
be responsible for any damage.
· Handle the unit with care.
· Do not stare directly at the lights when
they are powered on.
· Clean the unit with only a soft, dry
cloth.
· Keep this unit away from children.
· Use only parts provided by the
manufacturer.
· Make sure the item is intact and that
there are no missing parts.
· All images are for illustrative purposes
only.
PRECAUTIONS
Precautions

PortaBright 100 W Bi-Color Monolight - USER MANUAL
4
PRODUCT
OVERVIEW
Light Fixture - Front
Umbrella hole
COB LED array
Bowens mount
Bowens mount
release button
Light stand mount
5/8 in. receiver
Locking knob
Locking button
Tilt lock
Umbrella locking screw

PortaBright 100 W Bi-Color Monolight - USER MANUAL 5
Product overview
Light Fixture - Back
Power switch
3-pin power socket
Release button
Dimming/Color
adjustment
knob
Group button
Channel button
Display
Battery status
Channel indicator
Color temperature
Brightness
Group indicator

PortaBright 100 W Bi-Color Monolight - USER MANUAL
6
Product overview
Light Fixture - Top
Battery compartment
Battery contacts

PortaBright 100 W Bi-Color Monolight - USER MANUAL 7
Product overview
Umbrella mount
Battery - Top
Battery - Bottom
Reflector
Power input
Battery terminals
Battery release
buttons

PortaBright 100 W Bi-Color Monolight - USER MANUAL
8
CHARGING AND
INSTALLING THE BATTERYCONTENTS INCLUDE
· Monolight fixture
· Reflector
· Battery
· Battery charger and cable
· AC adapter and cable
· Padded carry case
· Shoulder strap
The PortaBright includes a multivoltage
100–240 V AC, 50/60 Hz charger for
the rechargeable Li-ion battery.
1. Plug the battery charger into the battery,
and plug the AC cable into an outlet. The
indicator light on the charger will glow
red when the battery is charging, and
green when the battery is charged.
2. Align the battery terminals
with the contacts in the battery
compartment. Then slide the battery
into the battery compartment.
contents

PortaBright 100 W Bi-Color Monolight - USER MANUAL 9
PREPARING FOR USE
MOUNTING ON A LIGHT STAND
Important!
Always support the PortaBright
with one hand when mounting or
adjusting the angle until all locks and
connections are tight and secure.
1. Loosen the locking knob.
2. Press the locking button, and
set the PortaBright on the
light stand’s 5/8 in. stud.
3. Press the battery into place
until it clicks shut.
To remove the battery, press the
release buttons and lift the battery
out of the compartment.
When not in use, the battery loses
approximately 3% to 14% of its charge
per month. Genaray recommends
recharging the battery every 2 to 3
months, even if it’s not in use.
instructions

PortaBright 100 W Bi-Color Monolight - USER MANUAL
10
3. Release the locking button, and
hold the PortaBright with one
hand while tightening the locking
knob until the light is secure.
To adjust the angle of the light, loosen
the tilt lock while supporting the
light with one hand. Adjust the light’s
angle, and retighten until secure.
ATTACHING THE REFLECTOR
The PortaBright features an integrated
Bowens mount that accommodates most
Bowens-compatible accessories such as
reflectors, softboxes, grids, and snoots.
To attach the included 7 in. reflector:
1. Insert the accessory mounting pegs
on the reflector into the accessory
slots on the PortaBright.
2. Turn the reflector clockwise until it clicks.
instructions

PortaBright 100 W Bi-Color Monolight - USER MANUAL 11
To remove the reflector, push the Bowens-
mount release button and turn the reflector
counterclockwise to slide it out of the mount.
ATTACHING AN UMBRELLA
The mounting handle has an
integrated umbrella mount. To attach
an umbrella, follow these steps:
1. Loosen the umbrella locking screw
on the light stand mount.
2. Insert the umbrella shaft through
the reflector and into the umbrella
mount, and tighten the locking screw.
POWERING THE
PORTABRIGHT
USING THE PORTABRIGHT
WITH AC POWER
Connect the AC power adapter to the
PortaBright with the included 3-pin cable,
and plug the power cable into an outlet.
To turn on the fixture, press the
power switch to the AC position.
instructions

PortaBright 100 W Bi-Color Monolight - USER MANUAL
12
USING THE PORTABRIGHT
WITH BATTERY POWER
Make sure the power switch is in
the off position, and the fixture is
not plugged into a wall outlet.
Install the battery (see Charging and
Installing the Battery above).
To turn on the fixture, press the
power switch to the DC position.
The battery status indicator on the LCD
screen displays the remaining battery power.
4/4 100% to 75%
3/4 75% to 50%
2/4 50% to 25%
1/4 25% to 10% (light will not operate 10%)
OPERATING THE LIGHT
SETTING THE BRIGHTNESS
When it’s powered on, the PortaBright
defaults to brightness mode.
Use the adjustment dial to change
the brightness from 100% to
0% in 10% increments.
If the channel or group buttons are pressed,
the PortaBright returns to brightness mode
after 5 seconds if the value isn’t changed.
SETTING THE COLOR TEMPERATURE
The MLACDCB has a color temperature
range of 3200 to 6500 K. To adjust the
color temperature, follow these steps:
1. Press the adjustment dial. The color
temperature (CCT) will be highlighted.
2. Adjust the color temperature in 100 K
increments.
3. Press the adjustment dial to set
instructions

PortaBright 100 W Bi-Color Monolight - USER MANUAL 13
the temperature and return to
brightness mode. If the adjustment
dial isn’t pressed to set the color
temperature, the PortaBright returns
to brightness mode in 5 seconds.
SELECTING CHANNELS
When shooting with a multi-light setup,
assigning a channel to each fixture lets you
set the brightness and color temperature
of each light with a remote. This allows you
to adjust the ratio and color temperature
that’s perfect for your exposure without
having to manually adjust each light.
Make sure the PortaBright and the wireless
remote are set to the same channel.
1. Press the channel button to highlight
the channel number on the screen.
2. Use the adjustment dial to select
a channel from 1 to 16.
3. Press the channel button to set the
channel and return to brightness mode.
SELECTING GROUPS
In multiple-light setups, assigning groups
offers the flexibility to individually adjust
and control lights or groups of lights.
Make sure the lights that are meant to be
controlled together are set to the same
group, and make sure the remote is set to
the correct group when adjusting them.
1. Press the group button to highlight
the group selection on the screen.
2. Use the adjustment dial to
select a group from A to E.
3. Press the group button to set the group
and return to brightness mode.
instructions

PortaBright 100 W Bi-Color Monolight - USER MANUAL
14
PRODUCT
SPECIFICATIONS
LIGHT FIXTURE
LED Chip Type: COB
Output Power: 100 W
Beam Angle: 120° without reflector
45° with reflector
Color Temperature: 3200 to 6500 K
Color Accuracy Standard:
CRI 96.4 (5600 K), 96.4 (4400 K), 97.3 (3200 K)
TLCI 97.2 (5600 K), 98.4 (4400 K), 98 (3200 K)
Dimming: Yes, 100% to 0% in 10% increments
Display: LCD
Housing Material: Metal
Light Intensity @ 3 ft.:
11,900 lx (5600 K),
12,159 lx (4400 K), 6151 lx (3200 K)
Expected Lamp Life: 50,000 hr.
Dimensions:
Length: 8.5 in. (21.6 cm) without reflector
Diameter: 4.75 in. (12.1 cm) without reflector
Weight: 4.5 lb. (2 kg) with battery
CONNECTORS
Battery Plate: Integrated battery compartment
Power Input Connector: 3-pin XLR
MOUNTING
Fixture Mount: 5/8 in. receiver
sPecifications

PortaBright 100 W Bi-Color Monolight - USER MANUAL 15
REMOTE OPERATION
Remote Control Type: 2.4 GHz
Number of Channels: 16
Number of Groups: 5
Wireless Range : 100 ft. (30 m)
POWER
AC Input Power: 100 to 240 V AC, 50/60 Hz
DC Input Power: 11.1 V, 6600 mAh DC
Power Source: AC adapter, 3-pin XLR
Max Power Consumption: 100 W
Power Pass-Through: None
RECYCLING LITHIUM-ION
BATTERIES
Lithium-ion batteries are recyclable. You can
help preserve the environment by returning
your used rechargeable batteries to a
collection and recycling location near you.
For more information about recycling
rechargeable batteries, call the
Call2Recycle helpline at 1-877-723-1297,
or visit www.call2recycle.org.
sPecifications

ONE-YEAR LIMITED WARRANTY
This Genaray product is warranted to the original purchaser to be free from defects in materials and
workmanship under normal consumer use for a period of one (1) year from the original purchase date
or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect
to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of
any product that fails during normal use of this product in its intended manner and in its intended
environment. Inoperability of the product or part(s) shall be determined by Genaray. If the product
has been discontinued, Genaray reserves the right to replace it with a model of equivalent quality and
function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse,
improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, GENARAY MAKES NEITHER
ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This
warranty provides you with specific legal rights, and you may also have additional rights that vary from
state to state.
To obtain warranty coverage, contact the Genaray Customer Service Department to obtain a return
merchandise authorization (“RMA”) number, and return the defective product to Genaray along with
the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own
risk and expense.
For more information, or to arrange service, visit www.genaray.com or contact us at [e-mail].
© 2019 Genaray. All Rights Reserved.
GG1
