Genaray Mini Moon RSF-11 User manual

USER MANUAL
Mini Moon
11 IN. ROUND BI-COLOR SOFT LED
RSF-11

Mini Moon 11 in. Bi-Color LED Light - USER MANUAL
2
THANK YOU FOR CHOOSING GENARAY
The Genaray Mini Moon LED light is a thin and portable
xture that provides photographers and videographers
with a natural and soft continuous light source with
broad coverage. This 600-LED xture casts a bright
beam for a xture in this size class, and an integrated
diffuser furnishes a soft wraparound-quality and single-
shadow beam.
The Mini Moon operates on either on AC or battery
power and will accept either NP-F or V-mount
batteries. It features icker-free dimming from 100%
to 10%. The Mini Moon supports DMX-512, so the
light’s settings can be remotely controlled from a DMX
console. It has 512 selectable channels and a DMX
output jack to daisy-chain other DMX-compatible lights.
Mini Moon
INTRODUCTION

Mini Moon 11 in. Bi-Color LED Light - USER MANUAL 3
· Please read and follow these
instructions, and keep this
manual in a safe place.
· Keep this unit away from water and
any ammable gases or liquids.
· Make sure the unit is powered off
when plugging it into a power source.
· Do not use 26-volt V-Mount
batteries with this xture. Doing
so will damage the unit and void
the warranty. Use only the correct,
recommended voltage posted on the
battery plate and in this manual.
· Handle the unit with care.
· Do not attempt to disassemble or
repair the equipment—doing so will
void the warranty, and Genaray will
not be responsible for any damage.
· Do not stare directly at the lights
when they are powered on.
· Clean the unit with only
a soft, dry cloth.
· Images are for illustrative
purposes only.
PRECAUTIONS
Precautions

Mini Moon 11 in. Bi-Color LED Light - USER MANUAL
4
PRODUCT
OVERVIEW
1/4-20 threading
mounting socket
2-way 5/8 in.
mount
Tilt
Adjustment
Knobs
Diffuser
Accessory shoe mount
Yoke
Locking knob

Mini Moon 11 in. Bi-Color LED Light - USER MANUAL 5
Product overview
V-mount
release button
V-mount
battery plate
DMX selector button
Channel selector
button
Color temperature
knob
Color temperature
quick adjust (+ or -400 K)
DMX output port
DMX input port
NP-F battery
plates
Power socket
Dimmer/channel knob
LCD screen
Power switch
Battery status
Channel/
DMX address
Brightness
Color temperature
D-tap connector

Mini Moon 11 in. Bi-Color LED Light - USER MANUAL
6
POWERING THE
MINI MOON
MOUNTING THE
MINI MOON
CONTENTS INCLUDE
· LED with yoke
· AC adapter
· Power cord
· User manual
· Carry case
Mount the Mini Moon on any light
stand with a 5/8-inch stud, and turn
the locking knob until secure.
If the yoke is removed, the Mini Moon
can also be mounted on a tripod via
the 1/4-20 socket on the bottom of the
xture. Screw the Mini Moon onto the
1/4-20 mounting post until secure.
The Mini Moon can be powered
directly from an AC outlet, two NP-F
batteries, or one V-Mount battery.
USING THE MINI MOON WITH AC POWER
Connect the AC power adapter to the Mini
Moon with the included 2-pin cable, and
plug the power cable into an outlet.
To turn on the xture, move the
power switch to the AC position.
USING THE MINI MOON
WITH BATTERY POWER
The Mini Moon can be powered by two
NP-F batteries or one V-mount battery.
contents

Mini Moon 11 in. Bi-Color LED Light - USER MANUAL 7
Important
Use only V-mount batteries with a
maximum of 14.8 volts per battery.
Two NP-F batteries must be attached
to the Mini Moon to power the light.
When attaching batteries, make sure the
power switch is in the off position and the
xture is not plugged into a wall outlet.
INSTALLING A V-MOUNT BATTERY
Align the battery with the battery terminals,
and slide the battery onto the plate until
it clicks into place. To remove the battery,
press the release button to unlock the
battery and slide it off the plate.
INSTALLING NP-F BATTERIES
Align the batteries with the battery
terminals on the battery plates. Place the
batteries down into the plates, and slide
them toward the terminals until secure.
To turn on the xture, move the
power switch to the DC position.
The battery status indicator on the LCD
screen displays the remaining battery power.
4/4 100% to 75%
3/4 75% to 50%
2/4 50% to 25%
1/4 25% to 10% (light will not operate 10%)
instructions

Mini Moon 11 in. Bi-Color LED Light - USER MANUAL
8
The MB-WRT Wireless Transmitter (sold
separately) facilitates color temperature
adjustment from 3200 to 5600 K as well as
brightness adjustment from 100% to 10%.
The MB -WRT can operate the Mini Moon, as
well as Genaray’s Full Moon LED and other
light xtures, from up to 98 feet (30 m) away.
You can also control color temperature
or brightness on multiple lights that are
all set at different values. This makes
the MB-WRT a convenient tool for use
in a sophisticated lighting setup.
To set the receiving channel on the
Mini Moon, follow these steps:
1. Press the channel select button.
The channel icon will blink.
2. While the channel icon is blinking,
use the dimmer/channel knob to set
the receiving channel from 1 to 99.
USING THE MB-WRT
WIRELESS TRANSMITTER
ADJUSTING BRIGHTNESS AND
COLOR TEMPERATURE
Power the Mini Moon on. The LCD screen
will show the last setting that was used.
After powering on the Mini Moon, set
the brightness and color temperature by
rotating the knobs on the back of the xture.
Color temperature is adjustable from
3200 to 5600 K in 100 K increments.
For rapid color adjustment, use the
400K + and – buttons to change the color
temperature in 400 K increments.
Brightness is adjustable from 100%
to 10% in 1% increments.
OPERATING THE
MINI MOON
instructions

Mini Moon 11 in. Bi-Color LED Light - USER MANUAL 9
The Mini Moon supports DMX-512 so
the light’s settings can be remotely
controlled from a DMX console.
Note
When the Mini Moon is in DMX mode,
the adjustment knobs are disabled.
Adjust the brightness and color
temperature via the DMX console.
To set up DMX operation on the
Mini Moon, follow these steps:
1. Use a DMX cable to connect a DMX
controller to the DMX input port.
The Mini Moon has RJ45 DMX ports.
If your DMX controller has XLR
ports, you will need XLR to RJ45
adapters (available separately).
2. Use the DMX output port to connect
multiple lights.
USING DMX
3. Press the channel select button
to set the channel. The channel
icon will stop blinking.
Refer to the MB-WRT user manual to
set the channel on the transmitter.
Important
Make sure the channel on the Mini Moon
matches the MB-WRT.
Refer to the MB-WRT user manual to
operate the Mini Moon remotely.
instructions

Mini Moon 11 in. Bi-Color LED Light - USER MANUAL
10
PRODUCT
SPECIFICATIONS
To set the DMX address on the Mini Moon:
· Press the DMX selector button to
switch to DMX mode. The DMX
icon will appear onscreen.
· Press the channel select button.
The channel icon will blink.
· While the channel icon is blinking, use
the dimmer/channel knob to select
a DMX channel from 01 to 512.
· Press the channel select button
to set the channel selection. The
channel icon will stop blinking
Important
Make sure the DMX address on the Mini
Moon matches the DMX console.
LED Count: 600
Color Temperature: 3200 to 5600 K
Luminance: 1900 lx @3 ft.
Coverage: 120°
CRI: 97
TLCI: 97
Output Power: 60 W
Working Voltage: AC: 100–240 V
DC: 15–19 V
Battery Type: NP-F750/950 (×2)
V-mount (14.8 V max)
Mount: 5/8 in. receiver
1/4-20 threaded socket
Cable Length: AC Adapter Cord: 12.5 ft. (3.8 m)
Power Cord: 16 ft. (4.9 m)
Dimensions (with yoke): 14.75 × 14.25 × 2.25 in.
(37.5 × 36.2 × 5.7 cm)
Weight (without battery): 3.1 lb. (1.4 kg)
sPecifications

ONE-YEAR LIMITED WARRANTY
This Genaray product is warranted to the original purchaser to be free from defects in materials and
workmanship under normal consumer use for a period of one (1) year from the original purchase date
or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect
to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of
any product that fails during normal use of this product in its intended manner and in its intended
environment. Inoperability of the product or part(s) shall be determined by Genaray. If the product
has been discontinued, Genaray reserves the right to replace it with a model of equivalent quality and
function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse,
improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, GENARAY MAKES NEITHER
ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This
warranty provides you with specic legal rights, and you may also have additional rights that vary from
state to state.
To obtain warranty coverage, contact the Genaray Customer Service Department to obtain a return
merchandise authorization (“RMA”) number, and return the defective product to Genaray along with
the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own
risk and expense.
For more information, or to arrange service, visit www.genaray.com or contact us at [e-mail].
