Genaray Radiance User manual

USER MANUAL
Radiance
230-WATT DAYLIGHT LED MONOLIGHT

Radiance 230-Watt Daylight LED Monolight - USER MANUAL
2
THANK YOU FOR CHOOSING GENARAY
The Genaray 230-watt Radiance monolight features
an advanced chip-on-board (COB) array that outputs
a substantial 23,000 lux for a powerful, flicker-free
5600 K light source. Extremely quiet cooling fans make the
Radiance a great a choice for film, broadcast, and video
projects, as well as photo sessions. The Radiance runs
on AC power or two V-mount batteries that will provide
enough power for lengthy location shoots.
The fixture’s natural-looking light is dimmable from
100% to 0%, and it boasts a CRI and TLCI of over 95 for
exceptionally accurate color rendering. A 2.4 GHz receiver
is integrated into the unit for wireless operation of one or
more Radiance fixtures with a dedicated remote control.
Radiance
INTRODUCTION

Radiance 230-Watt Daylight LED Monolight - USER MANUAL 3
· Please read and follow these
instructions, and keep this
manual in a safe place.
· Keep this unit away from water and
any flammable gases or liquids.
· Make sure the unit is powered off
when plugging it into a power source.
· Use only the correct,
recommended voltage.
· Handle the unit with care.
· Do not attempt to disassemble or
repair the equipment. Doing so will
void the warranty, and Genaray will
not be responsible for any damage.
· Do not stare directly at the
light when it’s powered on.
· Clean the unit with only
a soft, dry cloth.
· Images are for illustrative
purposes only.
PRECAUTIONS
Precautions

Radiance 230-Watt Daylight LED Monolight - USER MANUAL
4
PRODUCT
OVERVIEW
COB LED array
Light Fixture - Front
Bowens mount
release
Locking button
Reflector

Radiance 230-Watt Daylight LED Monolight - USER MANUAL 5
Product overview
Tilt adjustment knob
Locking knob
Yoke
5/8 in. mount
Light Fixture - Back

Radiance 230-Watt Daylight LED Monolight - USER MANUAL
6
Product overview
Power Supply - Top
Dimmer knob
LCD screen
V-mount
battery slots
Channel/DMX ID
Channel/ID
adjustment buttons
BrightnessColor temperature
Brightness up/down
buttons
Color temperature up/down buttons
(bicolor fixtures only)

Radiance 230-Watt Daylight LED Monolight - USER MANUAL 7
Product overview
Color temperature
Brightness
Channel/DMX ID
Brightness up/down
buttons
Power button
Battery power and
charging indicators
Antenna port
Power socket
DMX in and out ports
Power switch
I - DC power
O - Off
II - AC power
DC power cable
Power Supply - Right Side Remote

Radiance 230-Watt Daylight LED Monolight - USER MANUAL
8
MOUNTING THE
RADIANCECONTENTS INCLUDE
· LED with yoke
· AC power supply
· AC power cord
· Remote
· Antenna
· Reflector
· Carry case
· User manual
Mount the Radiance on any heavy-duty
light stand with a 5/8-inch baby pin.
1. Loosen the locking knob, and press the
locking button to fit the 5/8-inch mount
on the light stand’s mounting stud.
2. Make sure the mount is properly
seated on the light stand, and turn
the locking knob until secure.
contents

Radiance 230-Watt Daylight LED Monolight - USER MANUAL 9
POWERING THE
RADIANCE
ATTACHING THE
REFLECTOR
AC POWER
Important
The Radiance is a multivoltage fixture
capable of running on 100–240 V, 50/60 Hz.
The included cable has a 120 V, 50 Hz plug.
To use this fixture with other voltages, you
must use a plug adapter (sold separately).
Connect the AC power adapter to
the Radiance with the 9-pin cable,
and use the power cable to connect
the adapter to an outlet.
Warning
The Radiance is a very powerful
light. Do not look directly into the
light while it’s being switched on.
Turn the power supply switch to the
(=) position. The LCD screen will
illuminate, and the Radiance will
power on to the last settings.
The Radiance is outfitted with a
Bowens mount that’s compatible with
most Bowens-mount accessories.
1. Align the mounting studs on the reflector
with the mounting slots on the fixture.
2. Insert the reflector, and turn it
clockwise until it clicks into place.
To remove the reflector, push and hold
the Bowens-mount release, and turn
the reflector counterclockwise.
instructions

Radiance 230-Watt Daylight LED Monolight - USER MANUAL
10
The power supply has two sets of
rubber feet that allow you to stand
the unit horizontally or vertically.
BATTERY POWER
The Radiance can be powered
by two V-mount batteries.
Important
Both V-mount batteries must be attached
to operate the Radiance on battery power.
When attaching the batteries, make sure the
power switch is in the off (O) position, and
the fixture is not plugged into a wall outlet.
To turn on the fixture, move the power
switch to the DC (–) position.
ADJUSTING THE
BRIGHTNESS
The dimmer knob controls the brightness
from 100% to 0% in 1% increments.
Press the dimmer knob to enter sleep
mode. This turns off the light without
powering down. Press the dimmer
knob again to resume operation.
The brightness up/down buttons on the LCD
screen can also adjust the light’s brightness.
· Touch to adjust the brightness
in 1% increments.
· Touch and hold to rapidly
scroll up or down.
instructions

Radiance 230-Watt Daylight LED Monolight - USER MANUAL 11
SETTING THE CHANNEL
AND DMX ID
Use the same steps to set the channel
and DMX address numbers.
To set the channel or DMX number:
1. Touch the on-screen menu button.
The first digit will blink.
2. Touch the Enter button to change
the number in increments of 1.
3. Follow steps 1 and 2 to set the
second and third digits.
4. After setting all three digits, press the
Menu button to accept your selection.
Important
DMX addresses range from 0 to 512.
If the DMX ID is set to a value greater
than 512, the DMX controller will not
communicate with the Radiance.
REMOTE OPERATION
POWERING ON/CHARGING THE REMOTE
Press the power button to turn on the
remote. The LCD screen will illuminate.
To recharge the remote, use a USB cable
with a Micro-B connector to plug into an
outlet or a powered USB port on a computer.
The charging indicator will glow red
to indicate charging is in progress.
When the green indicator lights up,
the remote is fully charged.
instructions

Radiance 230-Watt Daylight LED Monolight - USER MANUAL
12
SETTING THE CHANNEL ID
The remote and the Radiance must
be set to the same channel in order
to operate the light via the remote.
To set the channel number,
follow these steps:
1. Touch the on-screen channel ID
button. The first digit will blink.
2. Touch the on-screen up/down
buttons to make a selection.
3. Follow steps 1 and 2 to set the
second and third digits.
After three seconds, the digit will stop
blinking, and the selection will be set.
ADJUSTING BRIGHTNESS
To adjust the brightness via the remote:
1. Power on the remote by
pressing the power button.
2. Touch the brightness button on the
screen. The brightness value will blink.
3. Tap the on-screen up/down
buttons to fine-tune the brightness
in 1% increments, or touch
and hold to adjust rapidly.
USING THE ANTENNA
To increase the operating range of the
remote from 100 to 165 feet (30 to 50 m),
screw the antenna into the antenna port
on the rear of the power adapter.
instructions

Radiance 230-Watt Daylight LED Monolight - USER MANUAL 13
The Radiance supports DMX-512,
so a DMX console can remotely
control the the light’s settings.
Note
When the Radiance is connected to a
DMX console, the remote is disabled.
To set up DMX operation on the
Radiance, follow these steps:
1. Use a Cat 5e or Cat6 cable with RJ45
connectors to attach a DMX controller to
either one of the RJ45 ports. The other
port will automatically become the
output port.
Note: DMX XLR to RJ45 adapters
are available separately.
2. Use the other RJ45 port to
connect multiple lights.
3. Refer to the DMX console’s user manual
to set the DMX address on the controller.
Set the DMX ID on the Radiance by
following the instructions in Setting
the Channel and DMX ID above.
Important
Make sure the DMX ID on the Radiance
matches the DMX console’s address.
USING DMX
instructions

Radiance 230-Watt Daylight LED Monolight - USER MANUAL
14
PRODUCT
SPECIFICATIONS
LIGHT FIXTURE
LED Chip Type: COB
Output Power: 230 W
Beam Angle: 46° without reflector
64° with reflector
Color Temperature: 5600 K
Color Accuracy Standard: CRI 95
TLCI 95
Cooling System: Fans on light and power adapter
Dimming: Yes, 100% to 0%
Display: LCD
Housing Material: Metal
Photometrics: 19,240 lx at 1 m
2,130 lx at 3 m
769 lx at 5 m
Expected Lamp Life: 50,000 Hr.
Dimensions (H×W×D):
Light: 11.5 × 8.5 × 14 in.
(29.2 × 21.6 × 35.6 cm)
Power adapter: 11.25 × 4.6 × 4.75 in.
(28.6 × 11.7 × 12.1 cm)
Weight:
Light: 6.5 lb. (2.9 kg)
Power adapter: 6.3 lb. (2.9 kg)
YOKE
Yoke Material: Metal
Yoke Type: U bracket yoke
Tilt: 180°
sPecifications

Radiance 230-Watt Daylight LED Monolight - USER MANUAL 15
CONNECTORS
Battery Plate: V-mount (×2)
Power Input Connector: 9 pin
DMX Connector: RJ45
Service Connector: No
MOUNTING
Fixture Mount: 5/8 in. receiver
REMOTE OPERATION
Remote Control Type: 2.4 GHz, DMX 512
Number of Channels: 999
Number of DMX Channel Modes: 512
Wireless Range : 100 ft. (30 m)
164 ft. (50 m) with antenna
POWER
AC Input Power: 100 to 240 V AC, 50/60 Hz
DC Input Power: 24 V, 15 A DC
Power Source: AC Adapter, 9-Pin XLR,
V-mount battery
Max Power Consumption: 230 W
Power Pass-Thru: None
PHYSICAL
Certifications: CE, RoHS
sPecifications
