Genaray LED-5700T User manual

USER MANUAL
LED-5700T
240 LAMP VARIABLE COLOR LED ON-CAMERA LIGHT

LED-5700T - USER MANUAL
2LED-5700T - USER MANUAL 3
Thank you for choosing the Genaray LED-5700T
On-Camera Light. This product will provide you with
powerful, portable and dependable illumination that
can be used in a variety of settings. Featuring a
super-bright 240 LED lamp count, 3200K-5400K
variable color temperature, flicker-free dimmable
features and the acceptance of multiple battery types,
the Genaray LED-5700T On-Camera Light proves to be
the perfect choice for photographers
and videographers alike.
LED-5700T
INTRODUCTION

LED-5700T - USER MANUAL
2LED-5700T - USER MANUAL 3
· Lightweight Design With Powerful 240
Lamp Count
· Compact Profile For Easy Transport
& Storage
· Removable Slide-In Diffuser &
Magenta Filter
· Built-In Battery Level Indicator
· 240 LED Light
· Slide-In Diffuser
· Slide-In Magenta Filter
· Panasonic Li-Ion Battery Adapter
· AA Battery Adapter
· Ball Head Mount
· Manual
KEY
FEATURES
PRODUCT
CONTENTS
Features

LED-5700T - USER MANUAL
4LED-5700T - USER MANUAL 5
SAFETY
WARNINGS
· Do not attempt to disassemble,
repair or perform any unauthorized
modifications on this device
· Do not handle with wet hands,
immerse in liquids or expose to water
and rain; electric shock or fire may
result
· Device contains small parts which
may pose a choking hazard; keep out
of reach of children
· Do not operate device in presence of
flammable gas or vapors
· Do not use product if it emits smoke
or a strange odor and disconnect
power source immediately to avoid
personal injury and contact place of
purchase
· Observe caution when handling
batteries; only use batteries approved
by the manufacturer of this product
· Batteries are prone to leakage when
fully discharged; to avoid damaging
product be sure to remove batteries
when leaving product unattended
saFety Warnings

LED-5700T - USER MANUAL
4LED-5700T - USER MANUAL 5
· Do not intentionally stare or gaze at
LED light panel for prolonged periods
while device is on
· Do not cover the ventilation grille
found at the rear of device when in
operation and ensure light is cool
before storing
· Do not use or leave device in
conditions of extreme heat, severe
cold or high humidity
· Unit will display a decrease in
brightness when the battery runs
low; be sure to replace battery when
necessary to avoid affecting recording
quality
· When cleaning the device, use only a
mild detergent solution and quickly
wipe dry with a soft cloth
· Please dispose of used batteries,
packaging and old devices in
accordance with appropriate
environmental regulations
saFety Warnings

LED-5700T - USER MANUAL
6LED-5700T - USER MANUAL 7
PRODUCT
OVERVIEW
Filter
Insertion
Clasps
Included
Ball Head Mount
Cold Shoe Mount
1/4 20
Threading Mount

LED-5700T - USER MANUAL
6LED-5700T - USER MANUAL 7
Battery
Level
Indicator
Battery
Mounting
Area
Dimming
Wheel
Color
Variation
Wheel
Power
Switch
PrODuCt OvervieW

LED-5700T - USER MANUAL
8LED-5700T - USER MANUAL 9
MOUNTING
LIGHT ON CAMERA
OR TRIPOD
MOUNTING LIGHT
ON ROTATING BALL
HEAD MOUNT
· Optional ball head mount is designed to provide
user with a 180° tilt or 360° rotating angle feature
that can be used on both cameras and other
devices featuring a cold shoe
· For cold shoe mounting, ensure that shoe found
on bottom of ball head mount is of adequate
height by twisting it counterclockwise as needed.
Verify that locking ring above shoe is tightened;
then slide entire shoe into cold shoe of camera to
lock in place securely
· When attaching light device to ball head mount,
insert 1/4 20 screw found atop ball head mount
into the 1/4 20 threading found on bottom of light
unit and tighten
· Verify that ball head mount locking knob is fully
loosened by twisting counterclockwise and rotate
ball head mount to desired angle. Twist locking
knob clockwise to lock light unit firmly in position
· Begin by positioning light directly over a
tripod bearing a 1/4 20 screw
· Insert 1/4 20 screw found on tripod head
into the 1/4 20 threading mount found on
bottom of unit, then tighten securely
Light can also be fastened
to included ball head mount,
which can then be installed on
cold shoe found on cameras
or similar devices; see ball
head mounting instructions
below
Note
instruCtiOns
MOUNTING
LIGHT ON CAMERA
OR TRIPOD

LED-5700T - USER MANUAL
8LED-5700T - USER MANUAL 9
· Lift the twin clasps to open the battery
chamber door
· Insert six AA batteries according to the
orientations indicated in the battery
chamber
· Close the battery chamber door so it clicks
into place
· Mount the adapter according to the
instructions in Mounting a Battery or
Battery Adapter
· The LED-5700T features two built-in battery
mounts, an outer one and an inner one, to
accommodate Sony batteries. The outer
mount also accommodates the included
Panasonic and AA battery adapters. For a
full list of compatible batteries, refer to the
Battery Compatibility Chart on page 10 of
this manual
· With the contacts aligned, seat the battery or
battery adapter in the battery mount
· Push the battery or battery adapter toward
the contacts in the mount until you hear it
click into place
· To remove the battery or battery adapter,
push it in the opposite direction of the
contacts
instruCtiOns
MOUNTING A BATTERY
OR BATTERY ADAPTER
AA BATTERY
ADAPTER

LED-5700T - USER MANUAL
10 LED-5700T - USER MANUAL 11
POWERING
THE DEvICE
Sony Panasonic AA
Outer
Mount
Inner
Mount
Battery
Adapter
Battery
Adapter
NP-F
NP-FM
NP-FH
NP-FP
NP-FV
NP-QM
CGA-D54
CGP-D28
CGR-D08
CGR-D16
CGR-D28
CGR-D53
CGR-D54
CGR-D815
Alkaline
Lithium
NiMH
· Slide the power switch to ON position, then
twist the dimming switch clockwise to turn
LED lights on
· Press the built-in battery level indicator
button to instantly view the power
remaining in the battery. Each indicator
circle represents approximately 25% of
battery capacity. Four lit circles represent a
fully charged battery
For an accurate reading of
battery levels, it is best to
turn off light unit before using
battery level indicator feature
instruCtiOns
Note
BATTERY
COMPATIBILITY
CHART

LED-5700T - USER MANUAL
10 LED-5700T - USER MANUAL 11
ADJUSTING
FEATURES
· To adjust the 3200K-5400K variable color
temperature range, simply rotate color
variation wheel until desired effect is
achieved
· To adjust the flicker-free dimmable
features, simply rotate the dimming wheel
until desired effect is achieved
· To install the diffusion or magenta filters,
align filter with clasps found on edge of
LED light. Ensure that filter tab is facing
upward and slide filter along clasps; gently
snap filter in place
CUSTOMER SUPPORT
For more information about this product or to
contact the Genaray Customer Support Center
with any questions, please send your email
correspondence to: [e-mail]
instruCtiOns
PRODUCT
SPECIFICATIONS
Bulb Type: 120 Daylight and 120 Tungsten LEDs
Brightness: 1100 lux @ 3'
Color Temperature: 3200K-5400K
voltage: DC 7.2-8.4V
Weight: 9.1oz
Dimension: 6.25"x3.5"x2"

ONE-YEAR LIMITED WARRANTY
Genaray provides a limited warranty that this product is free from defects in
materials and workmanship to the original purchaser under normal use for a period
of one (1) year from the original purchase date or thirty (30) days after replacement,
whichever occurs later (the “Warranty Period”). Our responsibility with respect
to this limited warranty shall be limited solely to repair or replacement, at its
option, of any product which fails during normal consumer use. To obtain warranty
coverage during the Warranty Period, contact your place of purchase (“Seller”) to
obtain a return merchandise authorization (“RMA”) number, and return to Seller the
defective product along with proof of purchase and the RMA number. This warranty
does not extend to damage or failure which results from misuse, neglect, accident,
alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED
HEREIN, GENARAY MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY
IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty
provides you with specific legal rights, and you may also have additional rights which
vary from state to state. © Copyright 2013 Genaray
