Getac V200 User manual

Rugged Mobile Computing Solutions
V200
USER’S MANUAL

June 2011
TRADEMARKS
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc.
All brand and product names are trademarks or registered trademarks of
their respective companies.
NOTE
The information in this manual is subject to change without notice.
Most screens and operating instructions in this manual are based on
Windows 7. If you’re using a different version of Windows, the screens and
related operations may not be the same.
For the latest version of the manual, please visit the Getac website
at www.getac.com.

ENERGY STAR®is a government program that offers businesses and
consumers energy-efficient solutions, making it easy to save money while
protecting the environment for future generations.
Please reference ENERGY STAR®related information
from www.energystar.gov.
As an ENERGY STAR®Partner, Getac Technology Corporation has
determined that this product meets the ENERGY STAR®guidelines for
energy efficiency.
An ENERGY STAR®qualified computer uses 70 % less electricity than
computers without enabled power management features.
Earning the ENERGY STAR®
zWhen every home office is powered by equipment that has earned the
ENERGY STAR®, the change will keep over 289 billion pounds of
greenhouse gases out of the air.
zIf left inactive, ENERGY STAR®qualified computers enter a low-power
mode and may use 15 watts or less. New chip technologies make power
management features more reliable, dependable, and user-friendly than
even just a few years ago.
zSpending a large portion of time in low-power mode not only saves
energy, but helps equipment run cooler and last longer.
zBusinesses that use ENERGY STAR®enabled office equipment may
realize additional savings on air conditioning and maintenance.

zOver its lifetime, ENERGY STAR®qualified equipment in a single home
office (e.g., computer, monitor, printer, and fax) can save enough
electricity to light an entire home for more than 4 years.
zPower management (“sleep settings”) on computers and monitors can
result in much savings annually.
Remember, saving energy prevents pollution
Because most computer equipment is left on 24 hours a day, power
management features are important for saving energy and are an easy way
to reduce air pollution. By using less energy, these products help lower
consumers’ utility bills, and prevent greenhouse gas emissions.
