GEZE Slimdrive EMD Invers Operating instructions

1
Slimdrive EMD
Invers
GB Mounting and service instructions

Slimdrive EMD Invers
2
Contents
1 Symbols and means of representation ............................................................................................................3
2 Product liability ........................................................................................................................................................3
3 Safety ...........................................................................................................................................................................3
3.1 Proper use ...........................................................................................................................................................................................................3
3.2 Standards .............................................................................................................................................................................................................4
3.3 Additional applicable documents ..............................................................................................................................................................4
3.4 Safety instructions ...........................................................................................................................................................................................4
3.5 Safety-conscious working .............................................................................................................................................................................4
3.6 Inspection of the mounted system............................................................................................................................................................4
3.7 Environmentally-conscious working ........................................................................................................................................................4
4 Transportation and storage .................................................................................................................................5
5 Tools .............................................................................................................................................................................5
6 Product description ................................................................................................................................................5
6.1 System description and technical data ....................................................................................................................................................5
6.2 Basic structure and extension ......................................................................................................................................................................6
6.3 Types of mounting, stops ..............................................................................................................................................................................7
7 Mounting ....................................................................................................................................................................8
7.1 General information for mounting ............................................................................................................................................................8
7.2 Fitting template for drive, roller guide rail and link arm (Invers version) ....................................................................................9
7.3 Mounting dimensions for the mounting types .................................................................................................................................. 10
7.4 Mounting the drive ........................................................................................................................................................................................18
7.5 Door stop limiting ..........................................................................................................................................................................................18
7.6 Mounting the roller guide rail ....................................................................................................................................................................18
7.7 Mounting the lever (for mounting with roller guide rail) ...............................................................................................................18
7.8 Mounting the link arm (alternatively to lever with roller guide rail) .......................................................................................... 20
7.9 Mounting the gear shaft cover ................................................................................................................................................................. 20
7.10 Mounting the actuation sensors ............................................................................................................................................................. 20
8 Electrical connection ........................................................................................................................................... 21
8.1 Mains connection .......................................................................................................................................................................................... 21
8.2 Terminal assignment and cables ............................................................................................................................................................. 21
9 Settings .................................................................................................................................................................... 22
9.1 Setting the opening force .......................................................................................................................................................................... 22
9.2 Opening speed in deenergized state ....................................................................................................................................................23
9.3 Latching action function ............................................................................................................................................................................23
10 Service and maintenance .................................................................................................................................. 23
10.1 Dangers during mechanical service ....................................................................................................................................................... 23
10.2 Maintenance work ......................................................................................................................................................................................... 24
10.3 Electrical servicing ........................................................................................................................................................................................ 24
10.4 Electrical faults................................................................................................................................................................................................ 24

Slimdrive EMD Invers
3
Symbols and means of representation
Symbols and means of representation1
Warnings
In these instructions, warnings are used to warn against material damage and injuries.
Always read and observe these warnings.
X
Observe all the measures that are marked with the warning symbol and warning word.
X
Warning
symbol
Warning word Meaning
WARNING Danger for persons.
Non-compliance can result in death or serious injuries.
Further symbols and means of representation
Important information and technical notes are emphasised in order to illustrate the correct operation.
Symbol Meaning
means "important note"
means "additional information"
XSymbol for an action: Here you have to do something.
Observe the sequence if there are several action steps.
X
Product liability2
In accordance with the liability of manufacturers for their products as dened in the German "Produkthaftungs-
gesetz" (Product Liability Act), the information contained in this brochure (product information and proper use,
misuse, product performance, product maintenance, obligations to provide information and instructions) is to be
observed. Non-compliance releases the manufacturer from its statutory liability.
Safety3
Proper use3.1
The Slimdrive EMD Invers door drive is designed for the automatic opening and closing of swing-door single ac-
tion doors. The door opens mechanically in case of a power failure or an alarm.
The Slimdrive EMD Invers is suitable:
solely for use in dry roomsà
in entrances and interior areas of pedestrian trac in commercial plants and public areasà
in private areas.à
The Slimdrive EMD Invers
is designed for use at RWA incoming air doorsà
is designed for use at escape and rescue routesà
may not be used at re or smoke proof doorsà
may not be used for hazardous areas.à
Any other use than the proper use, such as permanent manual operation, as well as all changes to the product
are impermissible.
Observe the "GEZE Product information for door closers".

Slimdrive EMD Invers
4
Safety
3.2 Standards
The following are to be taken into consideration during the development and operation of the drive:
àThe guidelines for power-operated windows, doors and gates BGR 232 (issued by the German Federation of
trade associations)
àEU Machinery Directive 2006/42/EC (risk analysis)
àFire-prevention regulations, accident-prevention regulations
àStandards, e.g. VDE 0100
àCountry-specic regulations
àDIN 18650, DIN EN 60335-2-103
3.3 Additional applicable documents
Type Material number/Drawing number
EMD wiring diagram 138949
EMD cable plan 70106-9-0971
3.4 Safety instructions
àThe prescribed mounting, maintenance and repair work must be performed by properly trained personnel
authorised by GEZE.
àThe country-specic laws and regulations are to be observed during safety-related tests.
àGEZE shall not be liable for injuries or damage resulting from unauthorized modication of the system.
àGEZE shall not be liable if products from other manufacturers are used with GEZE equipment. Only original
GEZE parts may be used for repair and maintenance work as well.
àThe connection to the power supply must be made by a professional electrician.
Perform the power connection and safety earth conductor test in accordance with DIN VDE 0100-610.
àUse a customer-accessible 10-A automatic circuit-breaker as the line-side disconnecting device.
àProtect the display programme switch against unauthorised access.
àIn accordance with Machinery Directive 2006/42/EC, a risk analysis must be performed and the door system
identied in accordance with CE Identication Directive 93/68/EEC before commissioning the door system.
àObserve the latest versions of guidelines, standards and country-specic regulations, in particular:
àBGR 232 "Guidelines for power-operated windows, doors, gates"
àDIN 18650 "Building hardware - Powered pedestrian doors"
àVDE 0100; Part 610 "Erection of low-voltage installations"
àAccident-prevention regulations, especially BGV A1 "General regulations" and BGV A2 "Electrical systems
and equipment"
3.5 Safety-conscious working
àProtect the workplace against unauthorised entry.
àUse only cables prescribed in the cable plan. Secure loose cables with cable ties.
àBefore working on the electrical system disconnect the drive from the power supply and check the isolation
from supply. Note that the system will still be supplied with power, despite the fact that the power supply is
disconnected, if an uninterruptible power supply (UPS) is used.
àAlways use insulated wire-end ferrules for wire cores (see wiring diagram Mat. No. 138949).
àAttach safety labels to glass leaf doors (Mat. No. 081476). Risk of injury through breakage of glass.
àRisk of injury by sharp edges and moving parts at the drive.
3.6 Inspection of the mounted system
SafetyXanalysisX(dangerXanalysis)
In accordance with Machinery Directive 2006/42/EC and DIN 18650, a risk analysis must be performed and the
door system identied in accordance with CE Identication Directive 98/68/EEC before commissioning the door
system.
This includes:
àChecking measures for security and prevention of crushing, impact, shearing or drawing-in spots.
àChecking the function of the safety and actuation sensors.
àChecking the protective conductor connection to all metal parts which can be touched.
3.7 Environmentally-conscious working
XXWhen disposing of the door system, separate the dierent materials and have them recycled.

Slimdrive EMD Invers
5
Transportation and storage
4 Transportation and storage
àThe Slimdrive EMD Invers door drive is not built for hard knocks or for falling from a height.
àDo not throw, do not drop!
àStorage temperatures under -30 °C and above +60 °C can result in damage to the device.
àOnly for dry areas!
àProtect against humidity.
5 Tools
Tool Size
Tape measure
Marking pen
Drill bits Dia. 4.2
Threading tap M 5
Allen key 4 mm
Screw driver Blade width 3 and 5 mm crosstip
Hook wrench Mat. No. 111247 Ø 20 - 22
Centre punch
Hammer
Self-adhesive tape for fastening the drill-
ing template
Wire stripper
Crimping pliers for cables
Torque spanner
6 Product description
6.1 System description and technical data
The Slimdrive EMD Invers is a swing door drive operating fully automatically that is actuated by sensors or
switches.
The Slimdrive EMD Invers operates with a motor during opening and closing. In the case of a power failure or
triggered alarm it opens mechanically.
The use of a 2-leaf system with two Slimdrive EMD Invers drives is possible under the following conditions:
àIt must be ensured that the two door leaves do not jam and block each other during opening, since the drives
do not have a mechanical opening sequence control.
àIf necessary, corresponding information is to be obtained beforehand from the door manufacturer.
EMDXInversXmax.XeldXofXapplication,Xsingle-leaf
Link arm
Roller guide rail
Door width (mm)
Door mass (kg)

Slimdrive EMD Invers
6
Product description
6.2 Basic structure and extension
Drive
1 Motor-gearing unit
2 Transformer
3 Side elements
4 Base plate
5 EMD Invers control
6 Drive axle, continuous
7 Power storage
8 Hood anodised or coloured
(for 2-leaf version available also continuous or
with intermediate hood)
        
RollerXguideXrailXwithXlever
Mounting depends on the type of stop selected.
1 Lever
2 Roller
3 Rail
4 End piece




EMDXInversXlinkXarm
For sot depth SD:
0–100 mm
100–200 mm
200–300 mm
MountingXplateXforXdrivesX(optional)
Depending on the installation situation a mount-
ing plate is required.
A mounting plate is generally recommended to
facilitate mounting.
(For 2-leaf version available also continuous or
with intermediate mounting plate)
ActuationXelementsX(accessories)
In accordance with the specications in the wiring diagram, Mat. No. 138949.

Slimdrive EMD Invers
7
Product description
6.3 Types of mounting, stops
The 2-leaf version corresponds to that of the 1-leaf mounting type.
The opening angle of the door has to be limited by a door stop.
The Slimdrive EMD Invers allows the following types of stop, each for doors DIN left and doors DIN right:
HingeXside
Transom mounting hinge side
Slimdrive EMD Invers
with roller guide rail (710 mm)
EMD Invers: max. sot depth SD: 0 mm
EMD Invers max. door overlap O: 30 mm
OppositeXhingeXside
Transom mounting opposite hinge side
Slimdrive EMD Invers
with link arm for
sot depths SD: 0–100 mm
100–200 mm
200–300 mm
Door panel mounting hinge side
Slimdrive EMD Invers
with roller guide rail (760 mm)
EMD Invers max. sot depth SD: 0 mm
Max. door overlap O: 30 mm
Transom mounting opposite hinge side
Slimdrive EMD Invers
with roller guide rail (710 mm)
Max. sot depth SD: –30 to +50 mm
for internal door hinges
EMD Invers SD: 0 mm
Max. door overlap O: 0 mm

O = Door overlap SD = Sot depth

Slimdrive EMD Invers
8
Mounting
7 Mounting
7.1 General information for mounting
ImportantXinstructionsXforXsafeXmounting
àObserve all the instructions. Incorrect mounting can result in serious injuries.
àThe specied ambient temperature range at the installation location of the drive must be observed.
àAfter completing mounting the settings and functionality of the drive have to be checked!
7.1.1 Scope of delivery and completeness
XXOpen all the packaging units.
XXCheck whether the scope of delivery is complete.
XXFamiliarise yourself with the parts.
The Slimdrive EMD Invers door drive with roller guide rail or link arm consists of:
àDrive unit
à1 drive
à1 set of fastening screws
àDrilling templates
àCover
à1 hood
Further parts, depending on order:
àRoller guide rail
à1 rail
à1 lever
à1 set of fastening screws
or:
àEMD Invers link arm
à1 link arm (size depending on sot depth)
àAccessories (optional)
àActuation elements: in accordance with the specications in the wiring diagram, Mat. No. 138949.
àDoor stop buer/integrated opening restrictor (only for roller guide rail).
àDisplay programme switch
àMounting plate(s) with a set of fastening screws
àSmoke switch control unit
àInterrupter button
7.1.2 Preparations to be made by the customer
CheckingXofXtheXlocationXconditionsXandXtheXrequiredXphysicalXconditions
àThe substructure has to ensure safe fastening of the drive.
àSuitable means of fastening such as anchors, rivet nuts, etc., have to be used.
XXBefore mounting the drive check whether the door leaf is in a good mechanical state and can be opened and
closed easily.
àThe bottom edge of the element mounted at the lowest point (guide rail or link arm) has to be mounted at
least 2 m above the oor.
àCables have to be laid in accordance with the cable plan.
XXCheck the planned type of stop on the leaf or frame prole (see Section 6.3).

Slimdrive EMD Invers
9
Mounting
7.2 Fitting template for drive, roller guide rail and link arm (Invers version)
The top of the door must be aligned exactly horizontally, both in the closed and in the open position.
XXPick up the correct tting template in accordance with the mounting type (Section 7.3).
XXTake the type of fastening into account (direct fastening or with mounting plate, see Section 7.3).
XXAlign the tting template parallel to the top of the door.
XXAx the template with adhesive tape in accordance with the specied mounting type.
The door and type of stop sketches on the template are helpful.
TransomXmountingXhingeXside
TransomXmountingXoppositeXhingeXside
DoorXpanelXmountingXhingeXside
XXIn the case of doors not closing smoothly separate or fold the template along the perforation.
XXPredrill doors of wood with Ø 2.5 mm.

Slimdrive EMD Invers
10
Mounting
7.3 Mounting dimensions for the mounting types
7.3.1 Transom mounting hinge side with roller guide rail (single-leaf)
The drilling images DIN left and DIN right are mirrored.
XXUse suitable tting templates (see Section 7.2).





 











 









Fixing with mounting plate Direct xing
1 Low-voltage connection for sensors, door opener, programme switch and bolt switch contact
(line-feed Ø 15–20 mm)
2 Dimensional reference hinge middle
3 Covered power supply 230 V / 50 Hz for power supply cable (line-feed Ø 15–20 mm)
4 Use 8 screws
5 Use at least 2 screws for each drilling row
FasteningXmeans
àMounting plate = M5
àBase plate = M5 or chip board screws
àRoller guide rail = M5 or chip board screws
DriveXorientation
XXMount the drive so that the transformer points to
the hinge.
RequiredXspace
6 Required space for Slimdrive EMD Invers
7 Dimensional reference top edge door prole
(= top edge of roller guide rail)
8 Required space for roller guide rail




Slimdrive EMD Invers
11
Mounting
7.3.2 Transom mounting opposite hinge side with roller guide rail (single-leaf)
The drilling images DIN left and DIN right are mirrored.
XXUse suitable tting templates (see Section 7.2).






   




















Fixing with mounting plate Direct xing
1 Low-voltage connection for sensors, door opener, programme switch and bolt switch contact
(line-feed Ø 15–20 mm)
2 Dimensional reference hinge middle
3 Covered power supply 230 V / 50 Hz for power supply cable (line-feed Ø 15–20 mm)
4 Use 8 screws
5 Use at least 2 screws for each drilling row
FasteningXmeans
àMounting plate = M5
àBase plate = M5 or chip board screws
àRoller guide rail = M5 or chip board screws
DriveXorientation
XXMount the drive so that the control unit points to
the hinge.


RequiredXspace
6 Required space for Slimdrive EMD Invers
7 Dimensional reference bottom edge frame
(lintel)
8 Required space for roller guide rail






Slimdrive EMD Invers
12
Mounting
7.3.3 Transom mounting opposite hinge side with link arm (single-leaf)
The drilling images DIN left and DIN right are mirrored.
XXUse suitable tting templates (see Section 7.2).









 
















Fixing with mounting plate Direct xing
1 Low-voltage connection for sensors, door opener, programme switch and bolt switch contact
(line-feed Ø 15–20 mm)
2 Dimensional reference hinge middle
3 Covered power supply 230 V / 50 Hz for power supply cable (line-feed Ø 15–20 mm)
4 For mounting dimensions of the link arm refer to the instructions "Mounting instructions for link arm EMD
Invers", Drwg. 70106-9-9551 Mat. No. 118268
5 Use 8 screws
6 Use at least 2 screws for each drilling row
FasteningXmeans
àMounting plate = M5
àBase plate = M5 or chip board screws
DriveXorientation
XXMount the drive so that the control unit points to
the hinge.


RequiredXspace
7 Required space for Slimdrive EMD Invers
8 Dimensional reference bottom edge frame
(lintel)
9 Space required link arm





Slimdrive EMD Invers
13
Mounting
7.3.4 Door panel mounting hinge side (single-leaf)
àThe drilling images DIN left and DIN right are mirrored.
XXCheck whether there is enough space to open the door suciently.
XXConnect all the cables with door transmission to the junction boxes (concealed/surface mounting).
XXUse suitable tting templates (see Section 7.2).









 













 


Fixing with mounting plate Direct xing
1 Dimensional reference hinge middle
2 Use 8 screws
3 Use at least 2 screws for each drilling row
FasteningXmeans
àMounting plate = M5
àBase plate = M5 or chip board screws
àRoller guide rail = M5 or chip board screws
DriveXorientation
XXMount the drive so that the control unit points to
the hinge.

RequiredXspace
4 Required space for roller guide rail
5 Dimensional reference top edge door prole
6 Required space for Slimdrive EMD Invers






Slimdrive EMD Invers
14
Mounting
7.3.5 Transom mounting hinge side with roller guide rail (double-leaf)
XXUse suitable tting templates as for the single-leaf version (see Section 7.2).
FasteningX2xXEMDXInversXwithXintermediateXmountingXplate

 












 
 

   



FasteningX2xXEMDXInversXwithXcontinuousXmountingXplateX
 

 
 
 
DirectXfasteningX2xXEMDXInvers








 


1 Covered power supply 230 V / 50 Hz for
power supply cable (line-feed Ø 15–20 mm)
2 Low-voltage connection for sensors, door
opener, programme switch and bolt switch
contact (line-feed Ø 15–20 mm)
3 Moving leaf
4 Fixed leaf
5 Dimensional reference hinge middle
6 Door leaf width
7 Hinge distance B3

Slimdrive EMD Invers
15
Mounting
7.3.6 Transom mounting opposite hinge side with roller guide rail (double-leaf)
XXUse suitable tting templates as for the single-leaf version (see Section 7.2).
FasteningX2xXEMDXInversXwithXintermediateXmountingXplate





















 



   
FasteningX2xXEMDXInversXwithXcontinuousXmountingXplateX



   
DirectXfasteningX2xXEMDXInvers















 






   
1 Covered power supply 230 V / 50 Hz for
power supply cable (line-feed Ø 15–20 mm)
2 Low-voltage connection for sensors, door
opener, programme switch and bolt switch
contact (line-feed Ø 15–20 mm)
3 Dimensional reference hinge middle
4 Moving leaf
5 Fixed leaf
6 Door leaf width
7 Hinge distance B3

Slimdrive EMD Invers
16
Mounting
7.3.7 Transom mounting opposite hinge side with link arm (double-leaf)
XXUse suitable tting templates as for the single-leaf version (see Section 7.2).
FasteningX2xXEMDXInversXwithXintermediateXmountingXplate
 














   
 




 

FasteningX2xXEMDXInversXwithXcontinuousXmountingXplateX
   
 


DirectXfasteningX2xXEMDXInvers
 

 

 
 




   
 



 
1 Low-voltage connection for sensors, door
opener, programme switch and bolt switch
contact (line-feed Ø 15–20 mm)
2 Covered power supply 230 V / 50 Hz for
power supply cable (line-feed Ø 15–20 mm)
3 Dimensional reference hinge middle
4 Moving leaf
5 Fixed leaf
6 Door leaf width
7 Hinge distance B3

Slimdrive EMD Invers
17
Mounting
7.3.8 Door panel mounting hinge side with guide rail (double-leaf)
XXUse suitable tting templates as for the single-leaf version (see Section 7.2).
FasteningX2xXEMDXInversXwithXcontinuousXmountingXplateX
 






















DirectXfasteningX2xXEMDXInvers











 



 





1 Covered power supply 230 V / 50 Hz for
power supply cable (line-feed Ø 15–20 mm)
2 Low-voltage connection for sensors, door
opener, programme switch and bolt switch
contact (line-feed Ø 15–20 mm)
3 Dimensional reference hinge middle
4 Moving leaf
5 Fixed leaf
7 Door leaf width
8 Hinge distance B3

Slimdrive EMD Invers
18
Mounting
7.4 Mounting the drive
Ensure that the connection cables are not pinched.
XXPull the hood o.
If provided:
XXScrew on the mounting plate.
XXScrew on the drive.
For positioning refer to the top view in the drawings in Section 6.3.
XXUse the supplied M5 screws or enclosed chip board screws.
7.5 Door stop limiting
XXCheck the physical conditions.
XXOpen and close the door manually.
XXWhen mounting the door panel take care of the pinch
and shearing points of the door edges when laying the
cables.
XXMount the oor stop buer or the integrated opening
restrictor Mat. No. 123232, see Section 8.6. 
7.6 Mounting the roller guide rail
XXSlide the lling pieces (2) into the rail (1) and screw on
together at the marked location.
XXEnsure that the seating and alignment are correct.
Optional:
XXInstall the integrated opening restrictor Mat. No.
123232.

7.7 Mounting the lever (for mounting with roller guide rail)
WARNING!
Danger of injury, danger of damage to the Slimdrive EMD Invers!
The mounted and possibly tension lever is braked electrically. Disconnecting a motor cable releases the stored
energy of a tensioned lever in unbraked form and accelerates the lever back to the initial position.
XXDo not disconnect any of the motor cables (1).
In order to mount the lever use only the supplied hexagon socket-head screw with coating in the lower thread
section.
XXCheck the proper connection (see gure below).

Slimdrive EMD Invers
19
Mounting
7.7.1 Use of the roller lever types depending on the mounting type
Mounting type Mounting side Roller lever
Transom mounting hinge side DIN left Standard
DIN right Standard
Transom mounting opposite hinge
side
DIN left Door leaf DIN left
DIN right Door leaf DIN right
Door leaf mounting hinge side DIN left Door leaf DIN left
DIN right Door leaf DIN right
7.7.2 Transom mounting hinge side with roller guide rail
Ensure that the correct lever DIN right or DIN left conforming to the order is installed.
See stamp on the roller lever.
XXOpen the door (4).
XXPut on the lever (1) as shown with the dashed
line.
XXScrew in the hexagon socket-head screw (2),
tightening torque 12…15 Nm.
XXPretension the lever (1) and insert it into the
roller guide rail (5), while closing the door.
XXMounting the stop buer (6).
XXIf necessary, vary the spring pretension at the
hole nut (3).






7.7.3 Transom mounting opposite hinge side with roller guide rail
XXOpen the door (4).
XXPut on the lever (1) as shown with the dashed
line.
XXScrew in the hexagon socket-head screw (2),
tightening torque 12…15 Nm.
XXPretension the lever (1) and insert it into the
roller guide rail (5), while closing the door.
XXMounting the stop buer (6).
XXIf necessary, vary the spring pretension at the
hole nut (3).







Slimdrive EMD Invers
20
Mounting
7.7.4 Door panel mounting hinge side with roller guide rail
Ensure that the correct lever DIN right or DIN left conforming to the order is installed.
See stamp on the roller lever.
XXOpen the door (6) to the maximum opening
width, x it there.
XXPut on the lever (2) as shown with the dashed
line.
XXScrew in the hexagon socket-head screw (3),
tightening torque 12…15 Nm.
XXPretension the lever (2) and insert it into the
roller guide rail (1).
XXMounting the stop buer (5).
XXIf necessary, vary the spring pretension at the
hole nut (4).






7.7.5 DIsmantling the lever
Dismantling the lever is carried out in the reverse order of mounting for all mounting types.
XXPut the door in the open position.
XXTake the lever out of the roller guide rail (pretension is released).
XXRemove the screw and take o the lever.
7.8 Mounting the link arm (alternatively to lever with roller guide rail)
XXObserve the instructions enclosed in the link arm packaging.
XXIt is imperative that you observe the maximum level pretension specied in it.
7.9 Mounting the gear shaft cover
XXObserve the instructions enclosed with the covers.
7.10 Mounting the actuation sensors
XXSensors mounted on the wall or ceiling have to be positioned so that the door does not move through the
eld of detection of the sensor during opening and closing since self-actuation is otherwise possible.
XXFor electrical connections, see the wiring diagram Mat. No. 138949.
