GIGAIPC QBiX-JMB-CFLA310HG-B1 Installation and operation manual

1
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
QBiX-JMB-CFLA310HG-B1
Industrial System with Intel® H310 Chipset, Support for Intel®
9th/8th Gen. Core™ i Processor and Discrete GFX card support
Startup Manual
Packing List
Before you begin installing your card, please make
sure that the following items have been shipped:
For Main system : 9BQJH310AMR-SI
1. Terminal Blocks Male Plug x 1 (P/
N: 25IO0-2ESDV0-D2R)
2. Screw M3x4L x 12 (P/N : 25984G-1C014-S00)
For Expansion slot kit : 6BQJH310BPR-SI
1. Power Cable #18 350mm x 2 (P/N: 25CRI-
35030I-S9R)
2. Screw #6-32x4L x16 (P/N: 25KS2-13004F-S0R)
Dimension
Specifications
Dimension System Size : 224W x 368D x 166.3H(mm) -
Discrete GFX max 250W support.(optional)
CPU Support for 9th/8th Generation Intel®
Core™ i7/i5/i3, Pentium® and Celeron®
processors in the LGA1151 package,
TDP under 65W
Chipset Intel® H310 Express Chipset
Memory 2 x DDR4 SO-DIMM sockets, Max. Capacity
32 GB, Dual channel DDR4 2666/2400 MHz
Ethernet 1 x GbE LAN Ports (Intel® I219V)
3 x GbE LAN Ports (Intel® I211AT)
Graphic
Support
Integrated Graphics Processor - Intel® HD
Graphics support:
1 x DVI-D port, supporting a maximum
resolution of 1920x1080 @60Hz
1 x D-Sub port, supporting a maximum
resolution of 1920x1200 @60Hz
1 x DP port, supporting a maximum
resolution of 4096x2160 @30Hz
2 independent displays output
Audio Realtek® Audio Codec
Storage 3 x 2.5" HDD/SSD (SATA 6Gb/s)
Expansion
Slots
1 x 2280 M.2 M-Key (SATA 6Gb/s)
1 x 2230 M.2 E-Key (WiFi/BT)
1 x Full-size Mini PCIe with SIM slot (PCIe
x1 + USB2.0) -- support 3G/4G module
1 x PCIe slot -- Discrete riser card support
Caution: DANGER OF EXPLOSION IF
BATTERY IS INCORRECTLY REPLACED.
REPLACE ONLY WITH THE SAME OR EQUIVALENT
TYPE RECOMMENDED BY THE MANUFACTURER,
DISCARD USED BATTERIES ACCORDING TO
THE MANUFACTURER’S INSTRUCTIONS.

2www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Front I/O 1 x Power Switch/Power/HDD LED
3 x Audio Jacks (Line in, Line out, Mic in)
1 x Display port
1 x DVI-D
1 x VGA
2 x COM Ports (RS-232/422/485 &
RI/5V/12V)
2 x COM Ports (RS-232)
4 x RJ45 LAN Ports
4 x USB 3.2 Gen 1
4 x USB 2.0
1 x 4-pin Terminal Block
2 x External Antenna Holes (Optional)
Riser Card
(Optional)
PCIe x4 (Gen3 x1)
PCIe x16 (Gen3 x16) -- Discrete GFX card:
max. 250W, max length 293mm
Rear I/O —
Power DC in +24V~48V (full Range)
-- Support discrete GFX card
Operation
Temperature
For Main system :
Operating temperature: -20°C to 50°C (CPU
TDP 65W)
Operating temperature: -20°C to 60°C (CPU
TDP 35W)
For Full system :
Depends on the Graphic cards installed in
the system
Operating humidity: 0-90% (non-
condensing)
Non-operating temperature: -40°C to 85°C
Non-operating humidity: 0%-95% (non-
condensing)
Use wide temperature range memory and
storage
Vibration
During
Operation
Operation: IEC 60068-2-64, 1 Grms,
random, 5 ~ 500 Hz, 1 hr / Per Axis, With
SSD/M.2 2280 & Without Graphics Cards
Non-operation: IEC 60068-2-6, 2 G, Sine, 10
~ 500 Hz, 1 Oct/min, 1 hr / Per Axis
Shock During
Operation
Operation: IEC 60068-2-27, 50 G, half sine,
11 ms duration, with SSD
Packaging
Content
For Main system : 9BQJH310AMR-SI
Carton size: 351 x 300 x 166 (mm)
Packing Capacity: 1pc
Including:
Terminal Blocks Male Plug x 1 (P/N: 25IO0-
2ESDV0-D2R)
Screw M3x4L x 12 (P/N :
25984G-1C014-S00)
For Expansion slot kit : 6BQJH310BPR-SI
Carton size: 460 x 315 x 279 (mm)
Packing Capacity: 1pc
Including:
Power Cable #18 350mm x 2 (P/N: 25CRI-
35030I-S9R)
Screw #6-32x4L x16 (P/N: 25KS2-13004F-
S0R)
System I/O Interface
LAN 1
LAN BLAN A
COM 4
DVI-D
COM 3
External Antenna (optional) External Antenna (optional)
4 x I/O Bracket
VGA
Power/ HDD LED
Power/ HDD LED
COM 1/2
Digital Display
USB2 (USB2.0)
USB1 (USB3.2 Gen 1)
USBC1 (USB2.0)
Audio Jacks
LAN 2
DC IN (4-pin terminal block 12V~48V)
Oeder
Information
System : 9BQJH310AMR-SI &
6BQJH310BPR-SI
(Built in Components: Please contact
with your sales representative for more
information or e-mailed to : sales@gigaipc.
com)

3
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Jumpers and Connectors
The board has a number of jumpers that allow you to configure your system to suit your
application. The table below lists the function of each of the jumpers and connectors.
Front I/O Connectors
No. Code Scription
1VGA VGA Connector
2DVI-D DVI-D Connector
3DP Digital Display Port
4COM 1/2 RS-232/422/485
5COM 3/4 RS-232
6USB 1 4 x USB 3.2 Gen 1
7USB 2 2 x USB 2.0
8USB C1 2 x USB 2.0
Internal I/O Connectors
COM3
2 x DDR4 SO-DIMM sockets SATA Power Connector 3 x SATA 6 Gb/s Connector
TPM Connector
M2E Slot
M2M Slot
MINI-PCIe Slot with SIM slot
SIM Card Slot
PCIE X8 SlotPCIE X16 Slot
COM4
Front I/O Connectors
9 LAN 1 Intel® I219V
10 LAN 2 Intel® I211AT
11 LAN A Intel® I211AT
12 LAN B Intel® I211AT
13 LED Power and Storage Device Status LED
14 DC-12-48V Power connector
When installed Graphic card, power
would support from +24V ~ 48V
15 Audio Audio Jacks (Line in, Line out & Mic in)

4www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Expansion I/O Connectors
No. Code Scription
1DC_OUT GPU Power Supply Connector DC Output
2SYS_FAN1 Fan1 Power Connector
3SYS_FAN2 Fan2 Power Connector
4PCIEX4 PCIE x4 Slot
5PCIEX8 PCIE x8 Slot
6PCIEX16 PCIE x16 Slot
DC_OUT SYS_Fan 1 PCIE x4 Slot
PCIE x8 Slot
PCIE x16 Slot
SYS_Fan 2
Expansion Front View Expansion Rear View
4 x I/O Bracket System FAN2
System FAN1

5
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
System Dimensions

6www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Simple Installation Process
Memory Installation
QBiX-JMB-CFLA310H-A1 supports DDR4 SO-DIMM type memory module.
1. Loosen 4 screws and remove the bottom cover.
2. Loosen 4 screws to remove memory thermal cover.
3. Affix thermal pad on memory and assemble memory.
Note : Thermal pad and memory thermal cover must be fully mated and compacted.
4. Install 4 screws and memory thermal cover.
5. Replace the bottom cover and secure with screws.

7
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
M2E (Support NGFF-2230 Wifi/BT) Installation
1. Loosen 4 screws and remove the bottom cover.
2. Loosen 4 screws to remove M2E thermal cover.
3. Install the module in the M2E (Support NGFF-2230 Wifi/BT) slot and secure with screws.
4. Affix thermal pad on M2E card and assemble.
5. Install 4 screws and M2E thermal cover.
6. Replace the bottom cover and secure with screws.

8www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Storage Installation 1 (2.5” HDD/SSD)
1. Loosen 4 screws and remove the bottom cover.
2. Loosen 4 screws to remove storage tray.
3. Secure storage with 4 x screws.
4. Assemble SATA cable/power cable and replace storage tray securely with 4 x screws.
5. Replace the bottom cover and secure with screws.

9
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Storage Installation 2 (M2M Storeage)
1. Loosen 4 screws, and then remove the bottom cover.
2. Loosen 4 screws to remove the hard disk storage aluminum sheet.
3. Loosen the 2 screws to remove the aluminum heat sink and thermal pad.
4. Assemble the M2M (NGFF-2280 SATA) storage hard drive.
5. Install the 2 screws to securely replace the aluminum heat sink and heat sink paste.
6. Install 4 screws to firmly install the hard disk storage aluminum sheet.
7. Replace the bottom cover and secure with screws.

10 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Mini-PCIe Slot (PCIeX1 + USB2.0) and SIM Card Slot Installation
QBiX-JMB-CFLA310H-A1 supports one full size Mini-PCIe.
1. Loosen 4 screws, and then remove the bottom cover
2. Loosen 4 screws to remove the hard disk storage aluminum sheet
3. Assemble the Mini-PCIe expansion Card (Mini-PCIeX1 + USB2.0) or 3G/4G SIM Card in SIM Slot.
4. Install 4 screws to firmly install the hard disk storage aluminum sheet
5. Replace the bottom cover and secure with screws.

11
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
How to combine the QBiX-JMB-CFLA310H-A1 system & PCI-E extension chassis
QBiX-JMB-CFLA310HG-B1 is combined with QBiX-JMB-CFLA310H-A1 and Expansion PCIE Slot Chassis.
1. Loosen 4 screws and remove the bottom cover of QBiX-JMB-CFLA310H-A1. (refer Figure 1 and 2)
2. Loosen 8 screws and remove the cover of Expansion PCIE Slot Chassis. (refer Figure 3 and 4)
3. Loosen 4 screws on the system fan side of Expansion PCIE Slot Chassis to seperate into 2 parts
as below A & B parts. (refer Figure 5 and 6)
1
2
4
3
5
6
A
B

12 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
How to combine the QBiX-JMB-CFLA310H-A1 system & PCI-E extension chassis (Cont.)
9
10
11
7
8
A
4. Assemble 4 screws (Torsion : 4 - 5 kgf.cm) to fix A parts on the QBiX-JMB-CFLA310H-A1 system
(refer Figure 7)
※Recommend to use at least 15cm length screwdriver.
5. Insert the PCIe riser card into PCI-E slot of QBiX-JMB-CFLA310H-A1 system from Top to Bottom.
(refer Figure 8)
6. Assemble 5 screws (Torsion : 4 - 5 kgf.cm) to fix B parts on the QBiX-JMB-CFLA310H-A1 system.
(refer Figure 9)
7. Remove the screws on the IO Bracket, and then insert the graphic card into the PCI-E slot
of PCI-E extension chassis from top to bottom. Connect the power cord in the extension card to
the power connector of the graphics card (refer Figure 10 and 11)
B
NOTE 1 : To connect 1 or 2 power cables on the graphic
cards is depends on different graphic card spec.
NOTE 2 : If only 1 power connector on the graphic card, you
can choose any one of two power cables for
connection.
NOTE 3 : The graphic card model uses on above picture
(refer Figure 11) is for reference only.

13
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
12
13
How to combine the QBiX-JMB-CFLA310H-A1 system & PCI-E extension chassis (Cont.)
8. Reinstall the cover back, and please be careful for the cables that may be harmed by the cover.
(refer Figure 12)
9. Assemble 10 screws (Torsion : 4 - 5 kgf.cm). (refer Figure 13)

14 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
1
How to disassemble the graphic card
1. Remove 10 screws to open the bottom cover. (refer Figure 1)
2. Remove 9 screws to seperate the QBiX-JMB-CFLA310H-A1 system and PCI-E extension chassis.
(refer Figure 2, or please refer to page 11/Figure 5 and page 12/Figure 9)
3. Push the lock on the PCIe slot down to easily disassemble the graphic card. (refer Figure 3)
4. Disassemble the graphic card from the PCIe slot. (refer Figure 4)
2
3
4
NOTE 1 : The graphic card model in this page is for
reference only.

15
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this Startup Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or
spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily
accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may cause
damage.
7. The openings on the enclosure are for air convection. Protect the equipment from overheating. DO
NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to the power
outlet.
9. Position the power cord so that people cannot step on it. Do not place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by
transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified
service personnel.
14. If one of the following situations arises, get the equipment checked by service personnel:
• The power cord or plug is damaged.
• Liquid has penetrated into the equipment.
• The equipment has been exposed to moisture.
• The equipment does not work well, or you cannot get it to work according to the user’s manual.
• The equipment has been dropped and damaged.
• The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE TEMPERATURE
MAY GO BELOW -40°C (-40°F) OR ABOVE 85°C (185°F). THIS COULD DAMAGE THE EQUIPMENT. THE
EQUIPMENT SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED
BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.
17. RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted Access Area.
18. DISCLAIMER: This set of instructions is given according to IEC 704-1. GIGAIPC disclaims all
responsibility for the accuracy of any statements contained here in.

16 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
QBiX-JMB-CFLA310HG-B1
Industrial Fanless System with Intel® H310 Chipset,
Support for Intel® 9th/8th Gen. Core™ i Processor and Discrete GFX card
BIOS Manual
Introduction
How to Entering into BIOS menu
Function Keys to setup in BIOS Setup program
BIOS (Basic input/output system) provides hardware detailed information and boot-
up options, which include firmware to control, set-up and test all hardware settings.
Therefore, BIOS is the communication bridge between OS/application software and
hardware.
Once the system is power on, press the <DEL> key as soon as possible to access into BIOS
Setup program.
Function keys Description
→← Select Screen
↑↓ Select Item
Enter Execute command or enter the submenu
＋Increase the numeric value or make changes
–Decrease the numeric value or make changes
F1 General Help
F2 Previous Values
F3 Load Optimized Defaults Settings
F4 Save changes & Exit the BIOS Setup program
ESC Exit the BIOS Setup program

17
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Function keys Description
→← Select Screen
↑↓ Select Item
Enter Execute command or enter the submenu
＋Increase the numeric value or make changes
–Decrease the numeric value or make changes
F1 General Help
F2 Previous Values
F3 Load Optimized Defaults Settings
F4 Save changes & Exit the BIOS Setup program
ESC Exit the BIOS Setup program
1. The Main Menu
The main menu shows the basic system information.
Use arrow keys to move among the items.
Items Description
Project Name Shows Project name information
BIOS Version Shows the BIOS version of the system
Build Date and Time Shows the Build Date and Time when the BIOS was created.
LAN1 MAC Address Shows LAN1 MAC Address information
LAN2 MAC Address Shows LAN2 MAC Address information
Total Memory Shows the total memory size of the installed memory
ME FW version Shows ME firmware version
System Date Set the Date for the system
(Format : Week - Month - Day - Year)
System Time Set the time for the system
(Format : Hour - Minute - Second)

18 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
2. Advanced
The Advanced menu is to configure the functions of hardware settings through submenu.
Use arrow keys to move among the items, and press <Enter> to access into the related
submenu.

19
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
2.1 Trusted Computing
Use Trusted computing submenu to choose TPM interface.
Item Description
TPM Device Selection PTT : Internal TPM (Default setting)
dTPM : External TPM (When using External TPM module or having TPM chip on MB)
Security Device
Support
Enabled : Enables TPM feature (Default setting)
Disabled : Disables TPM feature
Pending operation None : No execution will be conducted (Default setting)
TPM clear : Set to clear data on TPM
Physical Presence Spec
Version
Choose PPI spec version
Option items : 1.2 or 1.3 (Default setting)
PH Randomization Enabled : Enables Platform Hiearchy (PH) Randomization. (Default setting)
Disabled : Disables Platform Hiearchy (PH) Randomization.

20 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
2.2 IT8786 Super IO Configuration
Item Description
Super IO Chip Shows Super I/O chip model
Serial Port 1 Configuration
Serial Port 2 Configuration
Press [Enter] to configure advanced items :
Serial Port :
Enabled : Enables allows you to configure the serial port settings (Default setting)
Disabled : if Disabled, displays no configuration for the serial port
Device settings :
Display the specified Serial Port base I/O address and IRQ
COM Port Mode :
Choose RS-232, RS-422, or RS-485 feature
Serial Port 3 Configuration
Serial Port 4 Configuration
Press [Enter] to configure advanced items :
Serial Port :
Enabled : Enables allows you to configure the serial port settings (Default setting)
Disabled : if Disabled, displays no configuration for the serial port
Device settings :
Display the specified Serial Port base I/O address and IRQ
