Gigaset Gigaset C675 IP User manual

1
Gigaset IP Phones / GBR / A31008-xxxx-xxxx-x-xxxx / C47x_S675_S685_IP_UpdateFileIVZ.fm / 4/2/09
Version 4, 29.10.2007
Gigaset S675 IP, S685 IP, C475 IP:
New and updated functions
This document is a supplement to the user guide for the following Gigaset VoIP phones:
Gigaset C475 IP, Gigaset S675 IP and Gigaset S685 IP
In the time since the user guides were completed, the functionality of these devices has
been increased (firmware version 02.140 or higher). These changes are described in this
document.
Important information for the Gigaset S685 IP:
This document is a supplement to the user guide for Gigaset S685 IP devices manufactured
before May 2009. The label in the handset's battery compartment will bear the inscription
"Gigaset S68H" (no "S2").
The label is located on the bottom of the battery compartment.
The user guide can be found on the CD supplied with the device.

2
Gigaset IP Phones / GBR / A31008-xxxx-xxxx-x-xxxx / C47x_S675_S685_IP_UpdateFileIVZ.fm / 4/2/09
Version 4, 29.10.2007
Contents
Overview of the new and updated functions . . . . . . . . . . . . . . . . . . . . . . . . 3
Description of new and updated functions . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Changes to phone setup process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Starting the Gigaset.net assistant when first opening the Gigaset.net-directory . . . . . . . 7
Info Center – with the handset always online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Sending and receiving SMS (text messages) via VoIP . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Reading e-mail messages on the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Deactivating your handset's microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Network services during an external call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Operating the base on on the PABX –
Setting access codes (external line prefixes) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Entering an HTTP proxy server (only when connected to an
internal company network) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Activating/deactivating the STUN server of the Gigaset.net connection . . . . . . . . . . . . 19
Activating the fixed line network connection as an alternative connection . . . . . . . . . . 20
R key function for VoIP – Hook flash/call diversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Defining local communication ports for VoIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Amendment to "Call signalling and number assignment" . . . . . . . . . . . . . . . . . . . . . . . . 25
Amendment to "Changing the display language" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Amendment to "Defining dialling plans" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Correction to "Checking the base MAC address" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Checking extended service information for the base . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Information on operating Gigaset VoIP telephones with
Network Address Translation (NAT) routers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Edited/extended table of VoIP status codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Deleted function: "Send line selection for outgoing calls with */#" . . . . . . . . . . . . . . . . 33
Handset menu overviews . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Gigaset S67H to Gigaset S675 IP, Gigaset S68H to Gigaset S685 IP . . . . . . . . . . . . . . . . 34
Gigaset C47H to Gigaset C475 IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

3
Overview of the new and updated functions
Gigaset IP Phones / GBR / A31008-xxxx-xxxx-x-xxxx / description.fm / 4/2/09
Version 4, 29.10.2007
Overview of the new and updated functions
New functions
uInfo Center: You can use your Gigaset S67H/S68H/C47H handset to retrieve online con-
tent that is provided specifically for the handset from the Internet.
£Page 8
uYou can now also send and receive SMS messages via your VoIP connection. To send
SMS messages via VoIP, you merely have to specify one of your VoIP connections as a
send line for the send service centre.
£Page 12
uYou can display the text of e-mail messages on the handset.
£Page 14
uYou can deactivate your handset's microphone during an external call via the left display
key. In this case, the other party cannot hear you, but you can still hear him/her. Network
functions (e.g. external consultation calls, initiate/end conference call) that can no
longer be accessed via the left display key due to this new function are now provided in
the pop-up menu.
£Page 16
uIf you connect the telephone to a PABX, you can save the PABX access code on your
phone.
£Page 18
uIf you connect your phone to an internal company or organisation network (Intranet),
you can (if necessary) store the address of the internet HTTP proxy server on the base.
Each time the telephone accesses the Internet, this HTTP proxy server is addressed.
£Page 18
uYou can now activate your fixed line connection as an alternative connection. If the tel-
ephone cannot establish a VoIP connection, it automatically attempts to establish a con-
nection via the fixed line network.
£Page 20
uAs before, you can assign a VoIP provider feature to the Skey. Alternatively, you can
use the Skey for transferring calls (call transfer via VoIP).
£Page 21
uDepending on your router's NAT, you can activate/deactivate the STUN server for your
Gigaset.net connection.
£Page 19

4
Overview of the new and updated functions
Gigaset IP Phones / GBR / A31008-xxxx-xxxx-x-xxxx / description.fm / 4/2/09
Version 4, 29.10.2007
Updated/extended functions
uChanges to getting the phone started.
For example, Gigaset.net assistant is only started when you first open the Gigaset.net
directory.
£Page 5
uSince several consecutive RTP ports are required for each VoIP connection, you can now
specify a port number range for the RTP ports when configuring the telephone.
£Page 23
uThe signalling of calls made to a number that is not assigned to a handset as a receive
number has changed.
£Page 25
uWhen defining dialling rules, you can use the new option Use Area Codes to specify
whether or not the "automatic area code" is also to be dialled.
£Page 26
uThe key combination for checking the MAC address of the base has changed
£Page 26
New information on troubleshooting/problem analysis
uNew functions (e.g. immediate download of a provider profile) have been added to the
service information that you can use during an external call (e.g. with the Gigaset serv-
ice).
£Page 27
uIf your phone is connected to a NAT router, the NAT can cause problems during VoIP
telephony (especially if you connect multiple VoIP telephones to your router). Notes on
resolving these problems can be found in these amendments.
£Page 28
uThe table of VoIP status codes that you can display on the screen has been extended.
The extended table can be found in these amendments.
£Page 30
Function no longer in use
uWhen dialling, you can no longer select the line type by adding #or *.
(Only for devices manufactured after May 2009)
£Page 33

5
Description of new and updated functions
Changes to phone setup process
Gigaset IP Phones / GBR / A31008-xxxx-xxxx-x-xxxx / description.fm / 4/2/09
Version 4, 29.10.2007
Description of new and updated functions
Changes to phone setup process
This section amends the section "First steps – Making settings for VoIP telephony" in the user guide for
your Gigaset VoIP phone.
The procedures for "Making settings for VoIP telephony" have changed as follows.
1. Auto-configuration:
After you have started the installation assistant and entered the system PIN, the follow-
ing is displayed:
If you have received an auto-configuration code (Activation Code) from your VoIP pro-
vider:
¤Press the key below §Yes§ on the display screen.
You are prompted to enter the code.
¤Use the keypad to enter the auto-configuration code (max. 32 characters) and press
§OK§.
All data necessary for VoIP telephony is loaded directly from the Internet to your phone.
The handset returns to idle status. The configuration is complete.
If your VoIP provider has supplied you with an authentication name/password and,
where applicable, a user name:
¤Press the key below §No§ on the display screen.
The VoIP configuration is then performed as described in the user guide for your tele-
phone.
Do you have a
code for auto
configuration?
No Yes

6
Description of new and updated functions
Changes to phone setup process
Gigaset IP Phones / GBR / A31008-xxxx-xxxx-x-xxxx / description.fm / 4/2/09
Version 4, 29.10.2007
2. Gigaset.net assistant:
After you have completed the VoIP configuration, i.e. after entering your user data or
the auto-configuration code for your VoIP account, the Gigaset.net assistant is no long-
er started (the step "Entering your name in the Gigaset.net directory" in the telephone
user guide can be skipped). After you have entered your user data or the auto-configu-
ration code, the handset reverts to idle status.
The Gigaset.net assistant is started when you open the Gigaset.net directory for the first
time (£Page 7). You can then enter your name in the Gigaset.net directory.
3. If a firmware update for your telephone is available in the Internet:
In this case, the message New firmware available is displayed if you press the flashing mes-
sage key after starting your handset and connecting the base.
Perform the firmware update (press the right display key §Yes§). Once the update has
been completed (after approx. 3 minutes) the handset's idle display appears again and
the message key fflashes. If you press f, the following is displayed: Start wizard for
entry of VoIP connection data?. You can then start the connection assistant as described in
the user guide.

7
Description of new and updated functions
Starting the Gigaset.net assistant when first opening the Gigaset.net-directory
Gigaset IP Phones / GBR / A31008-xxxx-xxxx-x-xxxx / description.fm / 4/2/09
Version 4, 29.10.2007
Starting the Gigaset.net assistant when first opening the Gigaset.net-
directory
After setup, you can use the Gigaset.net assistant to enter your name in the Gigaset.net
directory, i.e. create a Gigaset.net directory entry for your telephone. To do so, open the
Gigaset.net directory.
Precondition: Your handset is in idle status.
sPress and hold.
qIf necessary, select Gigaset.net from the list of available online directories and
press §OK§.
The following appears in the handset's display:
¤Press the display key §Yes§ to start the assistant.
¤Using the keypad, enter the name that you would like to be listed under in the
Gigaset.net directory. The name may contain a maximum of 25 characters.
¤Press the right-hand display key §OK§.
If there is already an entry with this name, you are requested to enter a different name.
If an entry was created successfully in the Gigaset.net directory, the message "Your user
name has been added to Gigaset.net!" is displayed.
The handset returns to idle status.
Pleasenote
The Gigaset.net assistant is only opened the first time you open the Gigaset.net directory.
If you press §No§, the assistant will be cancelled and not restarted. You can then enter your
name using the Gigaset.net directory menu (§Options§ ¢Own details).
Gigaset.net
Start assistant
for Gigaset.net?
No Yes
Gigaset.net
Your Gigaset.net
nickname:
ÝOK

8
Description of new and updated functions
Info Center – with the handset always online
Gigaset IP Phones / GBR / A31008-xxxx-xxxx-x-xxxx / description.fm / 4/2/09
Version 4, 29.10.2007
Info Center – with the handset always online
You can use your Gigaset S67H, S68H or C47H handset to access online content on the
Internet, i.e. request info services specific to your handset's display. The info services avail-
able are constantly updated. A preselection has already been made for your handset, but
you can change these settings and add new services. Visit the Gigaset.net page
www.gigaset.net on the Internet and compile your personal info services.
Customising info services
¤On the PC, open the page Settings ¢Services of the Web configurator for your handset.
¤Click the link gigaset.net/myaccount.
Or:
¤Enter the following address in the address field of your PC's web browser:
www.gigaset.net
¤Enter your Gigaset.net user ID and password on the Gigaset.net page. You will find your
user ID and password on the Web configurator page "Settings ¢Services").
In both cases, a Web page is opened on which you can compile your info services.
Starting Info Center, selecting info services
v¢êSel. Services ¢Info Center
The menu of your Info Center, i.e. a list of user-specified info services (see above) is dis-
played. You can navigate between the info services.
Example:
sSelect the info service and press §OK§.
To access certain info services (personalised services), it is necessary to register with a
user name and password. In this case, enter your access data as described in the section
"Registration for personalised info services" on Page 9.
Info Center
Weather
News
Info service 3
Info service 4
Info service 5
Info service 6
ÝOK

9
Description of new and updated functions
Info Center – with the handset always online
Gigaset IP Phones / GBR / A31008-xxxx-xxxx-x-xxxx / description.fm / 4/2/09
Version 4, 29.10.2007
Messages when loading requested information
The information is loaded from the Internet. Wait a few seconds until the information is dis-
played. The display shows Please wait.
If the information for an info service cannot be displayed, one of the following messages
appears:
Requested page can’t be reached.
Possible causes of this are:
uTime limit exceeded (timeout) when loading the information, or
uthe Internet server for the info service cannot be accessed.
¤Check your Internet connection and repeat the request at a later time.
Coding error on requested page
The content of the requested info service is coded in a format which the handset cannot
display.
Can’t display requested page
General error when loading the info service.
Login failed.
Registration has failed. Possible causes of this are:
uYou have not entered your registration data correctly.
¤Reselect the info service and repeat the registration process. Please remember that
data is case sensitive.
uYou are not entitled to access this info service.
Registration for personalised info services
If a special registration with user name and password is required to access an info service,
the following is displayed after the service has been called up (example):
Username Enter the user name that you have agreed with the info service provider.
Password Enter the password associated with this user name.
§Save§ Press the display key to send the registration data.
If registration was successful, the requested info service is displayed.
Login
Username:
Password:
ÝSave

10
Description of new and updated functions
Info Center – with the handset always online
Gigaset IP Phones / GBR / A31008-xxxx-xxxx-x-xxxx / description.fm / 4/2/09
Version 4, 29.10.2007
If registration failed, a message to this effect appears on the display £Messages when
loading requested information, Page 9.
Operating the Info Center
Depending on the type of info service requested, you can carry out the following actions:
Scrolling within an info service
¤You can use sto scroll downwards within an info service, and tto scroll up (back).
Skipping back to the previous page
¤Press the left display key ”.
Skipping back to the Info Center menu
¤Briefly press the end call key a.
You want to go offline:
Press and hold the end call key a, the handset returns to idle status.
Selecting a hyperlink
uHyperlink to further information:
If the page contains a hyperlink to further information, this is indicated by the gicon.
If a page is opened using hyperlinks, the first hyperlink is highlighted.
¤Using the control keys (sand/or t) as required, you can navigate to the hyperlink
that you would like to select. The hyperlink is then highlighted by bars.
¤Press the right display key §Link§, to open the relevant page.
uHyperlink to a phone number:
If a hyperlink contains a phone number, you can copy the number to the local directory
or call the number directly (Click-2-Call functionality).
¤Select the hyperlink using the sand/or tkeys, as required.
¤You can identify a hyperlink of this type by the fact that §Call§ is shown above the right
display key.
¤Press §CopyToDir§ if you want to copy the phone number to your handset's local direc-
tory.
Or:
¤Press §Call§ to call the stored number.
Pleasenote
Please remember that registration data is case sensitive.
