Gigaset Maxwell Basic User manual

Maxwell #asic
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / Cover_front_maxwell-basic.fm / 6/9/16
Template Go, Version 1, 01.07.2014

2
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / Cover_front_maxwell-basic.fm / 6/9/16

1
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / LUGIVZ.fm / 6/9/16
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Contents
Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Illustration in the user guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Using the telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Getting to know your telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Call lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Message Centre . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Voice mails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Directories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Basic settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Configuring other settings with the Web configurator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Status of the telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Service (Customer Care) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Manufacturer's advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Menu tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Display icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
If the telephone is connected to a telephone system, the telephone system can have a
bearing on the telephone functions or block or add to them.
Further information: User guide for the telephone system
This guide is aimed at telephone users.
Information for administrators: wiki.gigasetpro.com

2
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Keys
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / overview_maxwell_basic.fm / 6/9/16
Overview
Keys
1Display keys Activate the display key functions p. 7
2Volume keys Depending on the operating mode: Adjust the volume
of the speaker, receiver, headset or ringtone
p. 15
3Star key Display special characters when inputting text p. 10
Activate/deactivate the ringtone p. 14
4Hash key Switch text mode (upper/lower case letters, digits) p. 10
Lock/unlock the keypad p. 10
10
13
1 2 3 4
9
12
11
6
7
14
8
5
15

3
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / overview_maxwell_basic.fm / 6/9/16
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Keys
5Status LED Status display for incoming calls
Flashes: Incoming call
Lights up: Call in progress
6Control key Scroll through lists and entries. In idle status: p. 8
Open the call list p. 19
Open the menu p. 9
Open the directory p. 23
7Do Not Disturb key Activate/deactivate Do Not Disturb (DND) p. 14
Lights up: "Do Not Disturb" function is activated
8Message Centre Open call and message lists p. 19
Flashes: New message in the Message Centre
9Consultation call key Initiate/end consultation call; put participant on hold p. 17
10 End/back key Cancel function; p. 9
go back one menu level (press briefly);
return to idle status (press and hold)
p. 9
11 Conference call key Initiate conference call p. 17
12 Handsfree key Activate/deactivate speakers p. 15
Start dialling p. 11
Lights up: Call is being made via the speaker
(handsfree mode)
13 Headset key Make call via headset p. 13
Start dialling p. 11
Lights up: Call is being made via the headset
14 Mute key Activate/deactivate microphone (mute) p. 15
Lights up: The microphone is muted
15 Microphone Microphone of the handsfree unit

4
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Connections
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / overview_maxwell_basic.fm / 6/9/16
Connections
1 Expansion module with function keys
2 LAN (PoE)
3PC; a PC can also be connected to the telephone instead of to the local network,
the telephone establishes the network connection
4 Receiver
5 Headset with RJ11 plug
6 Power adapter
1 2 3 4 5 6

5
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / user_guide_operating_steps.fm / 6/9/16
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Illustration in the user guide
Illustration in the user guide
Icons
Keys
Procedures
Example: Setting the display language
¤. . . use to select Settings OK Language OK . . . use to select
the language Select ( = selected)
Important information regarding function and appropriate handling or functions
that could generate costs.
Prerequisite for carrying out the following action.
Additional helpful information.
Handsfree key Do not disturb key
Headset key Message key
End/Back key / Volume keys
Conference call key Hash key
Consultation call key Star key
Mute key – Digit/letter keys
/ Control key rim / centre
OK,Back, Select, Save, . . . Display keys
Step Follow this procedure
¤Press the centre of the Control key in idle status.
The main menu opens.
¤
¤OK
Navigate to the icon using the Control key .
Press OK to confirm. The submenu Settings opens.
¤Language
¤OK
Select the Language entry using the Control key .
Press OK to confirm. The submenu Language opens.
¤Press the Control key to select the language required.
¤Select Press the Display key Select to highlight the entry.
The selected option is indicated with .

6
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Safety precautions
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / security.fm / 6/9/16
Safety precautions
Read the safety precautions and the user guide before use.
Comprehensive user guides for all telephones and telephone systems as well as
for accessories can be found online at www.gigasetpro.com in the Support cat-
egory. We thereby help to save paper while providing fast access to the com-
plete up-to-date documentation at any time.
Use only the power adapter indicated on the device.
Use only the cable supplied for LAN connection and connect it to the intended ports
only.
Using your telephone may affect nearby medical equipment. Be aware of the technical
conditions in your particular environment, e.g., doctor's surgery.
If you use a medical device (e.g., a pacemaker), please contact the device manufac-
turer. They will be able to advise you regarding the susceptibility of the device to exter-
nal sources of high frequency energy (for the specifications of your Gigaset product
see "Specifications").
The devices are not splashproof. For this reason do not install them in a damp environ-
ment such as bathrooms or shower rooms.
Do not use the devices in environments with a potential explosion hazard
(e.g., paint shops).
Remove faulty devices from use or have them repaired by our Service team, as these
could interfere with other wireless services. Disconnect the telephone network con-
nector (TNV circuit connector).
The device cannot be used in the event of a power failure. It is also not possible to
transmit emergency calls
To connect the phone to the local network and PC only use shielded cables.

7
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / operating.fm / 6/9/16
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting to know your telephone
Using the telephone
Getting to know your telephone
Display
Display in idle status (example):
Display keys
The display keys perform a range of functions depending on the operating situation.
1 Name of the standard connection, possibly abbreviated (is allocated by the
administrator e. g. extension and/or name of the telephone user)
p. 11
2 Message display: New messages on the answer machine p. 22
Missed calls p. 19
3Displaykeyfunctions p.7
4 Status icons p. 45
5 Date and time p. 27
Setting/modifying display colours: p. 30
Setting date and time: p. 27
Activating/deactivating screensaver: p. 37
4
5
2
3
01/04/2016
12:15
415
Redial Select Line
10 Ben
1
Back OK Current display key
functions
Display keys

8
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting to know your telephone
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / operating.fm / 6/9/16
Control key
In the description below, the side of the Control key (up, down, right, left) that you have to press
in the different operating situations is marked in black, e. g. for "press right on the Control
key" or for "press the centre of the Control key".
In idle status
In submenus and lists and selection fields
In input fields
During a conversation
The Control key enables you to navigate the menus and input fields, and also
to call up certain functions depending on the situation.
Open the main menu
Open the call lists
Open the directory assigned to the key Briefly press
Open the list of available directories Press and hold
Select/confirm function
Scroll one line upwards/downwards Briefly press
Scroll the list upwards/downwards Press and hold
Moves the cursor up/down line by line Briefly press
Moves the cursor to the left/right one character at a time Briefly press
Moves the cursor rapidly to the left/right Press and hold
Open the directory Briefly press
Open the list of available online directories Press and hold

9
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / operating.fm / 6/9/16
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting to know your telephone
Menu navigation
The functions of the telephone are displayed in a menu that consists of several levels.
Menu overview p. 44
Main menu
In idle status: Press the centre of the Control key .
Submenus
If not all the functions can be displayed, arrows are shown below.
Displaying more list entries: . . . scroll in the direction of the arrow with the Control key
Returning to the previous menu level
¤Press the Display key Back
or
¤press the End key briefly
Returning to idle status
¤Press and hold the End key
The function selected from the display menu is
displayed with an icon.
Arrows indicate whether there are more menu entries:
above, below, above and below
¤. . . Use the Control key to select a submenu
¤Press the Display key OK
or
¤Press the Control key
The functions in the submenus are displayed as lists. The
selected function is highlighted.
¤. . . Use the Control key to select a function
¤Press the Display key OK
or
¤Press the Control key
If a key is not pressed, after 3 minutes the display will automatically change to idle
status.
Settings which have not been saved or confirmed are rejected.
Menu
Settings
OKBack
Settings
Date + Time
Audio Settings
OKBack

10
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting to know your telephone
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / operating.fm / 6/9/16
Entering text
Input position
¤Use to select an entry field. A field is activated when the cursor is blinking inside it.
¤Use to move the position of the cursor.
Correcting incorrect entries
Delete characters to the left of the cursor:
Entering letters/characters
Switch between lower case, upper case and digit entry mode:
¤Press the Hash key . . . the mode set is displayed at the bottom on the right
When editing a directory entry, the first letter and each letter following a space is
automatically in upper case.
Entering special characters:
¤Press the Star key . . . the available special characters are displayed . . . use to
navigate to the character you want OK
Locking/unlocking the keypad
The keypad lock prevents any accidental use of the telephone.
Multiple letters and digits are assigned to each key
between and and the key. As soon
as a key is pressed, the possible characters are displayed
at the bottom of the display.
The selected character is highlighted.
Select letters/digits:
¤Press the key briefly several times in succession
Locking the keypad: ¤Press and hold . . . the following icon appears on the
display
Unlocking the keypad: ¤Press and hold . . . use to enter the keypad lock PIN
(default setting: 1234) OK
Changing the keypad lock PIN with the Web configurator: p. 32
If a call is indicated on the handset, the keypad automatically unlocks and you can
accept the call. It then locks again when the call is finished.
It is not possible to call emergency numbers either when keypad lock is activated.
Edit Entry
Surname:
abc
Pa|
...........................................................
abc2äáàâãç

11
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / telephony.fm / 6/9/16
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Making calls
Making calls
Making a call
¤. . . use to enter a number lift the handset
or
¤lift the handset . . . use to enter a number Dial
Calls are initiated via the standard send connection if you do not select another option. To use
another VoIP connection:
¤Select Line . . . use to select required connection Dial . . . use to enter the
number Dial
When entering the call number:
Incoming call during number entry:
The phone is connected to the LAN.
At least one VoIP connection has been set up and assigned to the telephone.
VoIP connections are set up by the administrator with the Web configurator or
assigned using a PABX.
Up to four VoIP connections (call numbers) can beassigned to the telephone. The first
connection to be set up is the standard send connection. The name of the standard
send connection is displayed in idle status at the top left of the display header
( p.7).
No connection available: the following icon is shown in the display
Information about the telephone connections and the standard send connection:
Web configurator p. 40
Using the speaker to make calls: ¤Press the Handsfree key
Using the headset to make calls: ¤Press the Headset key
You can switch over at any time during the conversation.
In the following instructions, the icon also always stands for or .
Deleting incorrectly entered numbers to the left of the cursor: ¤
Transferring a number to the local directory: ¤( p.23)
Cancel dialling: ¤End
Accept the call: ¤Accept
Reject the call: ¤Reject

12
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Making calls
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / telephony.fm / 6/9/16
Dialling from the directory
¤. . . use to open the directory select entry lift the handset
or
¤. . . use to select Contacts OK select entry lift the handset
More than one number in the directory entry: . . . use to select a number OK
Dialling from the redial list
The redial list contains the most recently dialled numbers.
¤In idle status press Redial select entry lift the handset
or
¤. . . use to open the call lists Outgoing select entry lift the handset
Dialling from a call list
The call lists contain the most recent accepted, outgoing and missed calls ( p. 19). If the
number is saved in the directory, the name is displayed.
¤. . . use to open the call lists select a list (All, Accepted, Missed, Outgoing)
select entry lift the handset
or
¤. . . use to select Call Lists select a list OK select an entry
lift the handset
Ringback
Asking for a ring back when the line of a participant you have called is busy.
Initiating ringback
¤Ringback . . . the ringback request is registered
When the other participant's line is free, the ringback is initiated. The telephone rings,
Ringback is displayed in the header.
There can be an active ringback on each line.
Cancelling ringback
¤. . . use to select Select Services OK Cancel Ringback OK
The list of new missed calls can also be opened by pressing the Message key .
The PABX or the provider supports this function.

13
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / telephony.fm / 6/9/16
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Making calls
Anonymous calling
Withhold Calling Line Identification. The number is not shown to the person receiving the call.
¤. . . use to select Select Services OK Withhold Number OK
if necessary, use to select a line Change ( = calls are anonymous)
Incoming calls
An incoming call is indicated by ringing, by a display on the screen and by the flashing Status
LED.
The display shows
The PABX or the provider supports this function.
•the line on which the call is coming in on
•the caller's name if it has been stored in the
directory
•the caller's number if it has been transmitted
( p.13)
Accepting the call: ¤lift the handset
Switching the ringtone off:
¤Silence
Rejecting the call: ¤Reject
When a call comes in, the system looks for a matching entry in the local directory. If
the number is not found there, other directories are searched, if any have been
configured.
1 IP1
Peter Smith
004989123456789
Reject Silence
)
(
)
(

14
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Making calls
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / telephony.fm / 6/9/16
Protection from incoming calls
Activating/deactivating the ringtone
An incoming call is not signalled by ringing, but is displayed on the screen.
Switching the ringtone on/off: Press and hold the Star key
Ringtone is switched off: the following icon appears on the display
Switching the alert tone (beep) on/off
Switch on an alert tone (beep) instead of the ringtone:
¤Press and hold the Star key press Beep within 3 seconds . . . the following icon
appears in the status line
Switching off the alert tone: Press and hold the Star key
Switching the "Do not disturb" function on and off
Incoming calls are not signalled.
Switching "Do not disturb" on or off: Press the Do not disturn key
"Do not disturb" is switched on: the Do not disturb key is illuminated, the display shows
"Do not disturb" active
Ringtone silencing for anonymous calls: p. 28.
Set up call forwarding: p. 18
The administrator can create alist of numbers which should never be signalled bythe
telephone in the Web configurator.

15
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / telephony.fm / 6/9/16
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Making calls
During a conversation
Changing the volume
Changing the volume of the handset, the handsfree function or the headset during a call.
If there is no input for two seconds, the most recent value is stored automatically.
Muting
Switching off the microphone in the handset, the handsfree facility and the headset. The other
party to the call no longer hears what is being said.
Activating/deactivating the microphone: Press the Mute key
Microphone is switched off: the Mute key is illuminated
Switching the handsfree function on/off
Making calls via the speaker and the microphone of the handsfree function.
Switching on the handsfree function during a call:
¤Press the Handsfree key Replace handset
Handsfree function is switched on: the key is illuminated
Switching off the handsfree function during a call:
¤Lift the handset continue the call through the handset
Displaying information
¤Info . . . Information about the device is displayed ( p. 31)
Ending a call
¤Replace the handset
Louder: Save The volume can be set at 10 levels.
The current setting is displayed.
Quieter: Save
Permanent volume settings: p. 28.

16
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Making calls
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / telephony.fm / 6/9/16
Talking with several participants on the telephone
Accepting/rejecting Call Waiting
Another call comes in during a conversation. The call is signalled in the display and by the Call
Waiting tone. Call Waiting is displayed in the header.
Accepting the call:
¤Accept . . . the connection to the waiting participant is made. The first participant is put on
hold and hears some on-hold music.
Rejecting the call:
¤Reject
Permit/prevent Call Waiting
Permit or prevent Call Waiting during a call for all or for certain lines.
¤. . . use to select Select Services OK Call Waiting OK if
necessary, press to select line Change ( = Call Waiting is permitted)
Consultation calls
Consulting a second participant during a conversation.
¤Initiate a consultation call via the keypad or from the directory
. . . when the participant picks up, conduct consultation call
The display shows:
On hold: <Number> or <name in the directory>
Ending a consultation call:
¤End . . . the connection to the participant on hold is reactivated
or
¤Replace the handset . . . both calls are ended
The call on hold is transferred to the consultation participant.
If the consultation participant does not accept the call: a recall is initiated by the participant
on hold (your telephone rings). If you accept the call, you will be reconnected to the
participant previously on hold.
The PABX or the provider supports this function and the function is activated on the
telephone ( p. 34).
Define settings for Call Waiting with the Web configurator p. 34
¤Press the Consultation call key
or
¤Consult
. . . the first conversation is put on hold
On hold: Peter Smith
004989123456789
End Swap
Call Swap

17
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / telephony.fm / 6/9/16
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Making calls
Initiating consultation call from the directory
During the conversation:
¤Press the Control key select entry Options Dial OK . . . if necessary,
select the number with OK . . . the first conversation is put on hold, the number is
dialled
or
¤Consult . . . the first conversation is put on hold Directory select entry Dial . . .
if necessary, use to select the number OK . . . the number is selected
Call swapping
Switch back and forth between two participants. The other call is placed on hold.
¤Call a second participant during an external conversation (consultation call) or accept a
waiting call . . . use Swap to switch between the participants
Ending the connection to the active participant:
¤End . . . the connection to the participant on hold is reactivated
Conference call
Speaking to two participants at the same time.
Initiating a conference from call swapping:
¤Press the Conference call key . . . the active participant and the participant on hold
will be switched into the conference
Ending a conference call:
¤End or replace the handset . . . the conference ends for all the participants
Transferring a call
Connecting both external participants to one another during call swapping or in an external
consultation call:
¤Replace the handset . . . the call on hold will be transferred to the active participant.
If the active participant does not accept the call, a recall will be initiated by the participant on
hold.
Other ways of ending the call-swapping session:
•Replace the handset : The other two participants will be connected to one
another.
•The active participant ends the conversation: The connection to the participant
on hold is reactivated
•The participant on hold ends the conversation: The connection to the active
participant remains active.
Initiating a conference call during a conversation:
¤Press the Conference callkey call second
participant . . . the conference is established as
soon as the call is accepted
Peter Smith
004989123456789
End
Conference

18
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Making calls
Gigaset Maxwell basic / LUG IE-UK en / A31088-N4002-R101-3-7619 / telephony.fm / 6/9/16
Call divert
All incoming calls are diverted to another line or a network mailbox. A call divert function can be
configured for every line on the telephone.
Activating call divert:
¤. . . use to select Select Services OK Call Divert OK . . .
if necessary, use to select a connection Change
¤. . . use to select Phone Number enter number Save
or
¤. . . use to select Voice Mail Save . . . calls are forwarded to the answer machine
assigned to the connection.
In idle status, the active call divert and the destination for the diverted call are shown on the
display.
Deactivating call divert:
¤. . . use to select Select Services OK Call Divert OK . . .
connections with active call divert are marked with . . . use to select a
connection Change
The PABX or the provider supports this function.
If calls are diverted to an answer machine, it must be set up by the administrator with
the Web configurator.
Specifying different call diverts for engaged numbers or calls which are not picked up
with the Web configurator p. 35
