Gigaset N510 IP PRO Instruction sheet

Configuration Manual
(for VOIspeed 6)
1
DECT Gigaset
N510 IP PRO
SUMMARY
Summary...................................................................................................................................................... 1
1. System Features of the DECT Gigaset N510 IP Pro........................................................................ 2
Base Station Gigaset N510 IP Pro............................................................................................................... 2
Environmental Requirements.................................................................................................................... 3
The base should be placed in closed, dry rooms with a temperature range of +5 ° C and +45 ° C.
Protect from moisture, dust, corrosive liquids and vapours................................................................. 3
Structural Requirements............................................................................................................................ 3
Acronyms..................................................................................................................................................... 4
2. Installing the Gigaset N510 IP Pro....................................................................................................... 5
3. Configuration of the Gigaset N510 IP Pro........................................................................................... 8
How to Access the WEB administrator page.......................................................................................... 9
Assign a Static IP to the Base ................................................................................................................ 10
User Configuration.................................................................................................................................... 12
Codec Settings.......................................................................................................................................... 15
Assigning Lines for the User................................................................................................................... 16
VoIP Configuration.................................................................................................................................... 18
4. System Management ........................................................................................................................... 19
Configure System Timings...................................................................................................................... 19
Select Country........................................................................................................................................... 20
Start Registration for DECT Telephones............................................................................................... 21
Restart & Reset......................................................................................................................................... 22
Save and Reset......................................................................................................................................... 23
Updating Firmware................................................................................................................................... 24
5. Synchronisation of the Dect Gigaset................................................................................................ 25

Configuration Manual
(for VOIspeed 6)
2
6. Create a User on the VOIspeed PBX................................................................................................ 26
1.SYSTEM FEATURES OF THE DECT GIGASET N510 IP PRO
Maximum number of base stations that you can install
1
Maximum number of simultaneous conversations
4
Maximum number of user registrations
6
Maximum cover range of the Base Station
Approx.300m
Cover range for the Base Station for typical installations/ offices
Approx 50m
BASE STATION GIGASET N510 IP PRO
The Base Station is positioned in the area where calls are made, and via its internal radio antenna
manages up to 4 voice channels (simultaneous calls).
The Base Statition can be powered via PoE (802.3af) and therefore via a PoE switch (maximum
power of 4.0W). The base station coverage varies between 50m (in a closed space) and 300
meters in an open space. The coverage decreases according to the obstacles encountered by the
radio waves (eg. Cement walls, scaffolding etc). The range is reduced by about 50% when the
Eco Mode is active. Never place close to other electrical devices to avoid mutual interference.

Configuration Manual
(for VOIspeed 6)
3
ENVIRONMENTAL REQUIREMENTS
The base should be placed in closed, dry rooms with a temperature range of +5 ° C and +45 ° C.
Protect from moisture, dust, corrosive liquids and vapours.
STRUCTURAL REQUIREMENTS
The following are tips on how to position the radio unit (ie. the base station):
•For larger rooms, you should install the radio unit horizontally, towards the centre of the
room by placing it under the ceiling.
•To cover the corridors we suggest that you place the unit vertically pointing the LED of the
radio unit to the hallway, or vertically at the intersection of several corridors so that the
signal follows the line of the corridor. You should place it at half-height between floor and
ceiling. If there is a large object in the way, try to place the unit on top of it yet some way
away from the ceiling.
•Mounting the unit vertically on a wall, the radio coverage front (side the LED is positioned)
will be double compared to the rear. The attenuation is greater with an exterior wall.
•Please don’t install the station close to large metal objects.
•If the building has reinforced concrete walls, the attenuation will be very high.

Configuration Manual
(for VOIspeed 6)
4
ACRONYMS
AC
Authorisation Code
Nr. ARI
Access Rights Identity –Serial number of the KWS6000 –found under
the base or printed on the base box.
Db
Decibel
DECT
Digital Enhanced Cordless Telecommunications
DHCP
Dynamic Host Configuration Protocol
DNS
Domain Name System
e.i.r.p.
Equivalent Isotropic Radiated Power
GAP
Generic Access Profile
IP
Internet Protocol
IPEI
International Portable Equipment Identity –Telephone serial number
LAN
Local area Network
LED
Light Emitting Diode
MAC
Media Access Control –Hardware address of the device connected to
the network
MTU
Maximum Transmission Unit
MWI
Message Waiting Indication
NIC
Network Interface Card
NTP
Network Time Protocol
PBX
Private Branch eXchange
PoE
Power over Ethernet
PP
Portable Parts –Portable telephones
RSSI
Received Signal Strength Indicator
RTP
Real-time Transport Protocol
SIP
Session Initiated Protocol
TFTP
Trivial File Transfer Protocol
UDP
User Datagram Protocol
VoIP
Voice Over IP
WLAN
Wireless Local Area Network
WRFP
Wireless Radio Fixed Part –Repeater Wireless

Configuration Manual
(for VOIspeed 6)
5
2.INSTALLING THE GIGASET N510 IP PRO
Functions of the button on the base
- the led indicates the operating status of the unit
Gigaset N510 IP Pro –from the front –Registration/ paging button
The back view:
Gigaset N510 IP Pro –from the back
Functions of the registration/ paging button on the base:
Lights up
LAN connection active (phone is
connected to router)

Configuration Manual
(for VOIspeed 6)
6
Flashes
Data transfer to LAN connection
Press briefly
Launch paging (hanset search)
Press and hold
Set base to registration mode
Checking the package contents
1. One base, Gigaset N510 IP Pro
2. One power adapter for connecting the base to the mains power supply
3. One Ethernet (LAN) cable ( Cat 5 with 2 RJ45 modular jacks) for connecting the base
to a router/ switch (LAN/ Internet)
4. One CD
Note: the device colour may differ from the one shown here.

Configuration Manual
(for VOIspeed 6)
7
Setting up the base
The following diagram is an overview of tall the connections for your base. The individual
connections are described in detail below. In order to make calls over VoIP you must connect the
base to the Internet and register at least one handset to the base.
Follow the steps in the order given below:
Follow the steps in the order given below:
1. Connect the power cable to the base.
2. Connect the base to the mains power supply.
3. Connect the base to the router/ switch to access the Internet and configure the base via the
Web configurator (Internet connection via router and moden or via router with integrated
modem).
4. Connect the PC to the router.
NB. The Gigaset N510 IP PRO is supplied with sufficeint power via PoE (Power over Ethernet) if
the device is connected to an Ethernet switch with PoE functionality (PoE class IEEE802.3af). In
this case it is not necessary to tconneccdt the device to the mains power supply and steps 1 and 2
should be omitted.

Configuration Manual
(for VOIspeed 6)
8
3.CONFIGURATION OF THE GIGASET N510 IP PRO
This section provides information on how to configure the base via the Web Adminsitrator page.
NB. The base is preconfigured with dynamic IP (DHCP)

Configuration Manual
(for VOIspeed 6)
9
HOW TO ACCESS THE WEB ADMINISTRATOR PAGE
The web interface page can be accessed using any standard browser on your PC that uses the
same base network.
1. Open the web browser
2. In the address space write: http://baseIPaddress and press return.
Note: You can find your base IP address on the DHCP server (if it is there) or using a software
which scans the network which starting from the MAC address substitutes it with the base IP
address (for example, NetScan).
1. You can select your language for the web interface
2. In the PIN field insert the system PIN (default 0000)
3. Click on OK

Configuration Manual
(for VOIspeed 6)
10
ASSIGN A STATIC IP TO THE BASE
The base can be used with either a dynamic IP address (where you have a DHCP server) or with a
static IP address. To use it with a dynamic IP address you only need to select ‘Automatic’ from the
drop down menu ‘IP Address’, after this it will be described as a static IP setting.
.

Configuration Manual
(for VOIspeed 6)
11
Network configuration
On the page Configuration Network IP Configuration you can define your IP address, subnet,
gateway and DNS.
1. Click on Configuration then on Network and finally on IP Configuration
2. Chose Static from the drop down menu matching the first IP Address
3. In the field IP address insert the IP that will be assigned to the base
4. Fill in the remaining fields with information of the network that will be used for the base
5. Click on OK to save the configuration.

Configuration Manual
(for VOIspeed 6)
12
USER CONFIGURATION
In the section Configuration Telephone Connections you can insert up to 6 DECT users. To
add a user you only need to click on ‘Modify’ for the connection that you intend to create and then
click on ‘Show advanced settings’ and complete all the fields as shown in the figures and then
table below:

Configuration Manual
(for VOIspeed 6)
13

Configuration Manual
(for VOIspeed 6)
14
Connection name or number
Insert an identifying name for the user that you are creating
Name authentication
User name for the user (identical to that on VOIspeed)
Password authentication
Password for the user (identical to that on VOIspeed)
Username
Username (identical to that on VOIspeed)
Name shown
Insert an identifying name for the user that you are creating
Domain
Company domain (configured in the section Company PBX)
Server Registration
IP server of the VOIspeed PBX
Refresh time
60 seconds
Outbound server address
IP address of the VOIspeed PBX
Leave blank any additional fields that have not been listed in this table

Configuration Manual
(for VOIspeed 6)
15
CODEC SETTINGS
For each user listed in the DECT Base Station you can chose the codec that will be used and its
priority. To do this you need to access the section Configuration Telephone Audio and click
on ‘Show advanced settings’.
For this to work correctly on the DECT system with VOIspeed 6 you need to leave between the
‘Codecs selected’ only the G711 and the G729 (optional) putting the G711 codec in first position as
shown in the figure below:
For this to work correctly on the DECT system with VOIspeed 6 you need to leave between the
‘Codecs selected’ only the G711 and the G729 (optional) putting the G711 codec in first position as
shown in the figure below:

Configuration Manual
(for VOIspeed 6)
16
ASSIGNING LINES FOR THE USER
The configuration of this section is very important, as if not correctly configured could prevent the
receiving and sending of calls between the DECT users. Each telephone (identified on the
extension line) should have selected its corresponding user (shown in the connection column) for
both incoming and outgoing calls. The correct configuration is shown in the table below:

Configuration Manual
(for VOIspeed 6)
17

Configuration Manual
(for VOIspeed 6)
18
VOIP CONFIGURATION
In the section Configuration Telephone Advanced VoIP settings you can configure how to
manage the transfer of calls, music on hold and the RTP ports via which the audio packets will be
sent.
For the correct configuration with VOIspeed 6, please follow the settings highlighted in the image
below:
Press the R key to transfer the call
Select ‘No’
Forward the call by hanging up
Select ‘Yes’
RTP port
Insert 5004-5058
Music on hold
Select ‘No’

Configuration Manual
(for VOIspeed 6)
19
4.SYSTEM MANAGEMENT
Under the section Configuration Management it is possible to manage the system and:
-Configure the system timetable
-Select the country in which you find yourself (useful for the Country Code and ring tone),
-Start the registration of DECT telephones on the DECT base station.
-Restart the base or reset factory settings
-Make a backup of the settings or restore
-Update the Firmware (via the Gigaset server)
CONFIGURE SYSTEM TIMINGS
Enter in the section Configuration Management Date and Hour to configure the time adding a
STNP server or, in the event in which the base does not have internet access, specify manually the
date and time. It is also possible to enable the automatic updating of daylight saving time.
The configurations shown below are useful for the automatic update of the date and time and
daylight saving time via the SNTP server (NB. the Base station must have internet access)
If there is no internet access, you only need to select ‘No’ in the section ‘Automatic update of the
system time’ and insert the date and time manually.

Configuration Manual
(for VOIspeed 6)
20
SELECT COUNTRY
Enter in the section Configuration Management Local settings to configure the Country in
which the Base Station is working to work out automatically the international prefix to associate the
International calls, and the corresponding ring tone. As shown in the example below, if the base is
in the UK, select UK from the drop down menu of ‘Country’ options and ‘Ringtone map’.
