Gira Powernet Single Switching Actuator User manual

GIRA
Info Powernet Single Switching Actuator
Installation Instructions
Powernet Single Switching Actuator 03/99 Page: 1 of 3
Powernet Single Switching Actuator Order No.: 0864 00
System Information
This device is a product of the GIRA- Powernet ®EIB system and complies with EIBA directives.
Detailed technical knowledge obtained in instabus or GIRA-Powernet ®EIB training courses is a
prerequisite to proper understanding.
The functionality of this device depends upon the software. Detailed information on loadable software
and attainable functionality may be taken from the manufacturer’s ETS2 product database as well as
from the GIRA-Powernet ® EIB controller database.
Planning, installation and commissioning of the unit is done by means of the ETS2 software, Ver. 1.1
or later, as well as by the GIRA-Powernet ® EIB controller.
Function
dfe
g
c
With the aid of the GIRA-Powernet ® EIB
switching actuator, a group of consumers can be
triggered.
If touch sensors are plugged on, local operation
will be possible (for single touch sensor, even
without previous project planning). Further keys
can be used for controlling other GIRA-Powernet
® EIB devices.
Installation
Switch off the mains voltage before
establishing the electrical connection.
This device is provided for installation in standard
60 mm flush-mounted boxes. Switching actuator
cshould be solely fixed by the supporting ring in
connection with the screws provided on the flush-
mounted box. User interface (AST) dis at the
bottom.
Connect to the mains via screw terminals e.
Refer to the connection diagram.
This device may only be used with approved
covers or touch sensors. The contacting of the
touch sensor is made by AST d.
Assigning the Physical Address
Press programming key fon the device. Red
LED glights up. It will go out upon the takeover
of the physical address.
Warning
Caution! The installation and assembly of
electrical equipment may only be performed
by a skilled electrician.
Subject to technical modifications.

GIRA
Info Powernet Single Switching Actuator
Installation Instructions
Powernet Single Switching Actuator 03/99 Page: 2 of 3
NL
N
L
230 V AC ~
50 Hz
Specifications
Power Supply
Mains voltage: AC 230 V ∼
Mains frequency: 50 Hz
Rated current: 6 A (resistive load)
3 A cos ϕ≥0.5 (inductive load)
Minimum current: 10 mA
Connection: screw terminals, 2.5 mm2max.
Switching capacity
230 V incand. lamps: 1000 W
Halogen HV lamps: 500 W
Halogen LV lamps
Normal transformer: 500 VA max., cos ϕ≥0.5
Tronic transformer: 500 VA max., cos ϕ≥0.8
Fluorescent lamps
uncompensated: 500 VA max., cos ϕ≥0.5
shunt-compensated: cos ϕ= 1; Ctot ≤14 μF = 2 x 58 or 3 x 36 or 6 x 18 W
Twin-lamp circuit: 1000 W max.; cos ϕ= 1
Electronic ballast: 13 x 18 W or 10 x 36 W or 6 x 58 W
Switching frequency: 1 x per second max.
Ambient temperature: -5 °C to +45 °C
Protective system: IP 20

GIRA
Info Powernet Single Switching Actuator
Installation Instructions
Powernet Single Switching Actuator 03/99 Page: 3 of 3
Acceptance of guarantee
We accept the guarantee in accordance with the corresponding legal provisions.
Please return the unit postage paid to our central service department giving a brief description
of the fault:
Gira
Giersiepen GmbH & Co. KG
Service Center
Dahlienstrasse 12
D-42477 Radevormwald
The CE sign is a free trade sign addressed exclusively to the authorities and does not include
any warranty of any properties.
Gira
Giersiepen GmbH & Co. KG
Postfach 1220
D-42461 Radevormwald
Telefon: +49 / 21 95 / 602 - 0
Telefax: +49 / 21 95 / 602 - 339
Internet: www.gira.de
