GlammFire Crea7ion EvoPlus Thales User manual

INSTRUCTIONS MANUAL
THALES

GlammFire. PAG./2
Thank you for purchasing a GlammFire product.
In order to activate your 2-year GlammFire warranty, please register your GlammFire product at
www.GlammFire.com/pt/sobre/garantia or complete your warranty card and send it to us along with a
purchase copy, to our address, within 30 days after the purchase.
For more information please check the Warranty chapter.

GlammFire. PAG./3
INDEX
1—Material Supplied 4
2—Components 4
3—Safety Instructions 5
3.1—Ventilation 5
3.2—Cautions 5
4—Fuel 7
4.1—Bioethanol –The adequate fuel 7
5—Installation 8
5.1—Flammable material 8
5.2—Materials: stone/metal/ceramics 8
6—Installation Procedures 9
7—Extension of tube (option) 16
8—Maintenance 17
9—Overall Dimensions 17
10—After-Sales Service 18
11—Warranty 18

2—Componentes
1. Fixing to the ceiling;
2. Finishing mirrors;
3. Fitting tube;
4. Campanula;
5. Bottom of the fireplace;
6. Crea7ion EvoPlus Fire Round;
7.Decorative plates.
Please read this Instructions Manual carefully before using your decorative fireplace. It contains important operating
and maintenance instructions, that should be followed correctly in order to ensure a durable use of your decorative
fireplace.
All presented cautions and warnings must be respected.
Keep this manual for future reference.
This Instructions Manual is subject to change without notice.
1—Material Fornecido
1.
5
1.
6.
2.
3.
4.
1. 1x Burner EvoPlus Fire Round
2. 1x Ceiling fixing tube;
3. 2x Finishing mirrors;;
4. 1x Square fitting tube;
5. 1x Bottom of the fireplace;
6. 1x Campanula
7. 2x Nut;
8. 2x Stainless steel washer;
9. 3xSpacers;
10. 1x Tightening wrench;
11. Bolts;
12. Screws+bushings;
13. 1X Bearing;
14. 1X Rubber base;
15. Extension of tube (option).
2.
3.
4.
5.
6.
7.
10.
15.
GlammFire. PAG./4
13.
7.
8.
9.
14.

GlammFire. PAG./5
3—Safety Instructions
3.1—Ventilation
It is recommended that you keep a good ventilation of the area, in order to ensure a healthy level of oxygen.
Biothanol combustion releases carbon dioxide (CO2) and water (H2O). The combustion requires oxygen, therefore the
area where the fireplace is should have adequate ventilation with ventilation grids or other means, to allow air quality
and circulation.
3.2—Cautions
GlammFire is concerned about your safety, therefore we have taken all necessary consideration for conception, fabri-
cation, assembly and transport, to ensure perfect functioning.
We therefore ask you to thoroughly follow our instructions for assembly, use and maintenance.
 Do not cover your decorative fireplace;
 Keep it away from flames, ignition sources and flammable materials;
 Do not place the fireplace near windows or doors that can create drafts. These drafts may cause irregular function-
ing;
 Do not blow to the combustion fire line when igniting or during normal functioning of the fireplace;
 Keep a regular watch, during use of the fireplace;
 Keep children and animals away from the fireplace. Children do not recognize danger. Therefore make sure children
are kept at a safe distance;
 Keep children watched when fireplace is working;
 The fireplace should not be exposed to direct sunlight or any heat source, as it may damage its materials;
 If you spill bioethanol onto the floor, you must absorb it with a cloth, and then clean with a wet cloth, to avoid igni-
tion outsider the combustion fire line and stains on the floor;
 In case you spill bioethanol in the fireplace clean it immediately with a wet cloth, to avoid ignition outside the com-
bustion fire line and damages to the finishing of the fireplace (paint, lacquers, leathers, amongst others);
 Attention: While working the fireplace may achieve very high temperatures. Therefore avoid touching it. Areas of
potential contact with skin may cause burns;
 Do not fill the combustion fire line while hot, wait for it to cool down;
 Never pour bioethanol over the flame;
 After extinction of the flame wait approximately 15 minutes before handling the fireplace;
 In case of fire use a fire blanket or a fire extinguisher;

 Do not use water to extinguish the fire;
 Do not use chemical products to clean the fireplace, as they may damage the materials. When in doubt contact an
authorized dealer;
 After flame cutting may remain small residual flames at the point of fuel inlet for approximately 2 to 10 minutes. At
the end of this time the flame will extinguish naturally;
 If bioethanol pours out during the process of filling up the tank, clean the tank and surrounding area, before using
again;
 Decorative stones, wood or other accessories should not be placed directly on top of the burning area. Should you
use decorative accessories make sure:
 The accessories do not interfere with the flame;
 Are only for decorating the fireplaces and combustion fires;
 There is no risk of falling inside the combustion fire.
GlammFire. PAG./6

GlammFire. PAG./7
4—Fuel
4.1—Bioethanol –The adequate fuel
 GlammFire fireplaces are designed to work with quality bioethanol, fully tested. Only this fuel ensures clean and
efficient combustion. Fuel with less or inappropriate quality may lead to:
 Higher probability of malfunction;
 Reduction in durability of the system;
 Incomplete and inefficient combustion;
 Smoke and odours;
 Residues inside the combustion fire line.
 Bioethanol is internationally recognized as being the major source of renewable energy, 100% ecological and envi-
ronmentally friendly. It is made from fermentation and distillation of sugars from plants, such as sugar cane, potato,
beetroot and cereals;
 The use of bioethanol guarantees a reduction of 85% in CO2 emissions, therefore contributing for the reduction of
global warming;
 Use only liquid bioethanol as fuel. Only bioethanol will make a clean and perfect combustion;
 Keep bioethanol away from children and animals, as well as from a working fireplace;
 Avoid contact with eyes and skin;
 Do not drink bioethanol. In case you do go to the nearest hospital;
 Bioethanol should be kept at a minimum distance of 1 m from the fireplace;
 Do not place bioethanol in front of the fireplace;
 For security reasons bioethanol should be stored at a room temperature of approximately 20 ºC.
 Use only liquid bioethanol, recommended by GlammFire.

5—Installation
5.1—Flammable material
 Do not place flammable materials near the fireplace, within 1m;
 Racks or shelves should be distant 1m from the combustion fire line;
5.2—Materials: stone/metal/ceramics
 A - 150 mm;
 B - 150 mm;
A
B
C
C (distance from the bottom part to the campanula) must be 100mm.
GlammFire. PAG./8

GlammFire. PAG./9
6—Instalação
At least two people are required for this procedure.
Thales is a fireplace designed to be installed in places with a ceiling height between 2500 and 2700mm having an
available regulation of 200mm. It should be at
and it should be at a distance from the floor to the bottom of the fireplace of 300mm having an available regulation of
200mm. There should be a distance of 100mm between the bottom of the fireplace and the campanula.
Note: If the ceiling height of the installation place is larger than 2700mm there is a 500mm available extension of tube
Screw the fireplace to the ceiling at the desired location, using the most appropriate screws to the surface to install.
Warning: The ceiling where the fireplace will be installed shall comprise a
strong framework structure in order to support the weight of the model. It
is not allowed to place extra weight at the fireplace body.
Figure 1 –Top part to screw to the ceiling

GlammFire. PAG./10
Assemble the body by placing the tube (D) so that it engages the top of the structure (E). It is important to follow the
order of the components: washer (H), 3 x spacers (I) inside the bearing (J), washer (H), nut (G) and locknut (G). The
nuts are tightened with the supplied wrench (F), make sure that the first nut is tightened allowing the assembly to
rotate.
Note: If the assembly does not rotate, slightly relieve pressure on the nuts.
Figure 4—Assembly representation
D
E
G
H
I
J
H
Figure 2—Assembly representation
Figura 3—Assembly order

K
L
After the part (K) is fixed to the ceiling and the set (L) is completely assembled, place the set (L) on the part (K), tighten
with the supplied bolts, as shown in figure 6. Check that the assembly is well placed and tight.
Figure 5—Identification of assembly sets
Figure 6—Tube tightening with bolts
GlammFire. PAG./11

GlammFire. PAG./12
Figure 8—Complete installation of the fireplace to the ceiling
Figure 7—Ceiling finishing mirrors
After complete fixing and the ceiling finishings com-
pleted, install the final finishing mirrors.

Place the lower part of the chimney aligned with the campanula and turn both so that it is similar to figure 10.
Figure 9- Bottom of the fireplace
GlammFire. PAG./13
Figure 10- Positioning the fireplace
Place the rubber base on the bottom of the
fireplace to avoid damage to the floor surface.

GlammFire. PAG./14
Figure 12—Placing the burner in the fireplace without glass
Figure 11—Metal handle properly seated
Then place the EvoPlus Fire Round burner using the handle supplied to assist in its handling (see burner's instructions
manual, chapter: Installation Procedures).

GlammFire. PAG./15
Figure 13—Burner placed in the fireplace without glass
Figure 14—Burner placed in the fireplace

GlammFire. PAG./16
7—Extension of tube (option)
If the ceiling height of the fireplace installation is larger than 2700mm, GlammFire provides the option of a 500mm
extension in order to fit to the desired dimension.
This extension has the same diameter of the insert piece with a standard height dimension of 540mm, thus adding
500mm to the piece so that the total length is 1040mm.
Figura 15—Extension of tube (option)

8—Maintenance
 The combustion fire line should be cleaned regularly using a damp cloth with bioethanol;
 The more persistent marks can be removed using a soft cloth moistened in bioethanol;
 Never use chemicals not suitable for cleaning stainless steel;
 Do not use steel-wool or abrasive sponges. The surface can be scratched by them;
 The manufacturer is not liable for any damage arising from misuse and/or fraudulent of the product. The manufac-
turer also can not be blamed for the failure to observe the cleaning or application instructions and/ or use of any
other cleaning techniques;
 Note: Failure to follow the above rules eliminates any factory warranty on all models or fireplaces, losing the cus-
tomer the right to require repair under warranty.
9—Overall Dimensions
GlammFire. PAG./17

10—After-Sales Service
In case of doubt or any anomaly, do not use the fireplace and please contact a specialized technician.
11–Warranty
In order to activate your GlammFire 2 year warranty, please register your new GlammFire product at
www.GlammFire.com/en/about/warranty or complete your warranty card and return it to us, along with a copy of the
proof of purchase, at our address within 30 days of purchase.
All our Bioethanol Fireplaces and Burners, Electric Fireplaces, Fire Pits & Barbecues carry a warranty against defects of
manufacture and faulty workmanship for a period of 2 years from the date of purchase.
This warranty does not cover glass replacement, batteries, damage caused by accident or misuse of the appliance, or
the assembly/disassembly not indicated in the instruction manuals. If the product fails (not considering the above
mentioned events) within the warranty period, defective pieces will be replaced free of charge if it is proved any de-
fect of manufacture.
Regarding defective pieces, they will be sent free of charge and their switch is responsibility of the retailer responsible
for the purchase of the appliance.
Our warranty is offered as an addition to your statutory rights. It is applicable to the original purchaser only, non-
transferable. All repairs must only be fitted by an authorised service technician. Use of spare parts other than those
supplied by the manufacturer will invalidate the appliance warranty and must only be fitted by an authorised service
technician.
IMPORTANT: Registering your product does not require proof of purchase, if it will be made on our website, and
must be based on the date of purchase. It will be assumed that registration information accurately reflects the infor-
mation on the proof of purchase which will be required upon servicing of any/all products under warranty.
If the information conflicts, information stated on the proof of purchase will be deemed accurate and true and war-
ranty will be assessed accordingly.
GlammFire. PAG./18

GlammFire. PAG./19
GlammFire fireplaces are manufactured under the strict Standard of the world recognized ISO 9001:2008 (TUV)
Quality Assurance Certificate.
GlammFire products are designed with superior components and materials, assembled by trained craftsmen who take
great pride in their work.
Once assembled the complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure
that you, the customer, receive the quality product that you expect from GlammFire.
GlammFire is always concerned with the environment. This is reflected by the projection of their products and their
packaging. Focusing on the reduction of energy consumption, raw materials, natural resources and quantity of waste
generated, GlammFire follows the policy of the 4R's (Reduce, Reuse, Recycle and Recover). Thus GlammFire has in
mind the use of long lasting products as well as reusable and recyclable products.
GlammFire recommends reusing the GlammFire’s packaging separately and deposit plastic, paper, cardboard and
glass in the appropriate collection point.
"In nature nothing is created, nothing is lost, everything is transformed."
Antoine Laurent de Lavoisier
Series and Guarantee numbers
Distributor code
Name and Address of the Distributor
Equipment Guarantee beneficiary
Version Address
Controller Tel.
Availability date
Local…………………………………………..Date……………………..
Signature

PT12251-A
Recuperadores Pachinha Lda.
Zona Industrial da Lagoa, Lote G1
4950-850 CORTES - MONÇÃO PORTUGAL
Tel[phone]
Fax[phone]
[email protected]om
www.glammfire.com
