GLP Impression E350 User manual

DMX Channel Index
Software
v.
28
-
40
-
31
-
27

GLP® impression® E350 DMX Channel Index Revision A
This user manual covers fixture software version v. 28-40-21-27
© 2018 German Light Products GmbH. All rights reserved.
The marks ‘GLP’, ‘German Light Products’ and ‘impression’ are trademarks registered as the
property of German Light Products GmbH in Germany, in the United States of America and in other
countries.
The information contained in this document is subject to change without notice. German Light
Products GmbH and all affiliated companies disclaim liability for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss occasioned by the use of, inability to
use or reliance on the information contained in this document.
Head office:
German Light Products GmbH (GLP), Industriestrasse 2, 76307 Karlsbad, Germany
Tel (Germany): [phone] - 0
Service & Support EMEA:
GLP, Industriestrasse 2, 76307 Karlsbad, Germany
Tel. (Germany): [phone]
Email: [e-mail]
www.glp.de
Service & Support USA:
GLP USA, 1145 Arroyo St., Ste. A, 91340 San Fernando, California
Tel (USA): [phone]
Support (US): [email protected]
www.germanlightproducts.com

GLP®
impression® E350 DMX Channel Index Rev. A 3
impression E350 DMX channel index
Normal mode (27 DMX channels)
Channel Function Description DMX
range
Default
DMX % Range Fade
1 Pan coarse Left – right in 1.2°
increments (16 bit) 0 – 65535 32767 0 – 100% Fade
2 Pan fine
3 Tilt coarse Up – down in 1.2° increments
(16 bit) 0 – 65535 32767 0 – 100% Fade
4 Tilt fine
5 Color wheel Open – White 7500 K
Color 01 – Congo blue (UV)
Color 02 – Green
Color 03 – Orange
Color 04 – Magenta
Color 05 – Blue
Color 06 – CTC 1
Color 07 – CTC 2
Color 08 – CTC 3
Color 09 – Minus green
Color 10 – Red
Color wheel indexing 0 – 360°
(continuous color changing)
Color wheel rotation CW
fast – slow
Color wheel rotation stop
Color wheel rotation CCW
slow – fast
0 – 3
4 – 7
8 – 11
12 – 15
16 – 19
20 – 23
24 – 27
28 – 31
32 – 35
36 – 39
40 – 43
44 – 167
168 – 211
212
213 – 255
0 0 – 1.2%
1.6 – 2.7%
3.1 – 4.3%
4.7 – 5.9%
6.3 – 7.5%
7.8 – 9.0%
9.4 – 10.6%
11.0 – 12.2%
12.5 – 13.7%
14.1 – 15.3%
15.7 – 16.9%
17.3 – 65.5%
65.9 – 82.7%
83.1%
83.5 – 100%
Snap
Snap
Snap
Snap
Snap
Snap
Snap
Snap
Snap
Snap
Snap
Fade
Fade
Snap
Fade
6 Cyan Cyan 0 – 100% 0 – 255 0 0 – 100% Fade
7 Magenta Magenta 0 – 100% 0 – 255 0 0 – 100% Fade
8 Yellow Yellow 0 – 100% 0 – 255 0 0 – 100% Fade
9 CTC Off (default: 7500 K)
8000 K
7900 K
7800 K
7700 K
7600 K
7500 K
7400 K
7300 K
7200 K
7100 K
7000 K
6900 K
6800 K
6700 K
6600 K
6500 K
6400 K
6300 K
6200 K
6100 K
6000 K
5900 K
0 – 31
32 – 35
36 – 39
40 – 43
44 – 47
48 – 51
52 – 55
56 – 59
60 – 63
64 – 67
68 – 71
72 – 75
76 – 79
80 – 83
84 – 87
88 – 91
92 – 95
96 – 99
100 – 103
104 – 107
108 – 111
112 – 115
116 – 119
0 0 – 12.2%
12.5 – 13.7%
14.1 – 15.3%
15.7 – 16.9%
17.3 – 18.4%
18.8 – 20.0%
20.4 – 21.6%
22.0 – 23.1%
23.5 – 24.7%
25.1 – 26.3%
26.7 – 27.8%
28.2 – 29.4%
29.8 – 31.0%
31.4 – 32.5%
32.9 – 34.1%
34.5 – 35.7%
36.1 – 37.3%
37.6 – 38.8%
39.2 – 40.4%
40.8 – 42.0%
42.4 – 43.5%
43.9 – 45.1%
45.5 – 46.7%
Snap
Fade

www.glp.de
4 impression® S350 DMX Channel Index Rev. A
9
continued
5800 K
5700 K
5600 K
5500 K
5400 K
5300 K
5200 K
5100 K
5000 K
4900 K
4800 K
4700 K
4600 K
4500 K
4400 K
4300 K
4200 K
4100 K
4000 K
3900 K
3800 K
3700 K
3600 K
3500 K
3400 K
3300 K
3200 K
3100 K
3000 K
2900 K
2800 K
2700 K
2600 K
2500 K
120 – 123
124 – 127
128 – 131
132 – 135
136 – 139
140 – 143
144 – 147
148 – 151
152 – 155
156 – 159
160 – 163
164 – 167
168 – 171
172 – 175
176 – 179
180 – 183
184 – 187
188 – 191
192 – 195
196 – 199
200 – 203
204 – 207
208 – 211
212 – 215
216 – 219
220 – 223
224 – 227
228 – 231
232 – 235
236 – 239
240 – 243
244 – 247
248 – 251
252 – 255
47.1 – 48.2%
48.6 – 49.8%
50.2 – 51.4%
51.8 – 52.9%
53.3 – 54.5%
54.9 – 56.1%
56.5 – 57.6%
58.0 – 59.2%
59.6 – 60.8%
61.2 – 62.4%
62.7 – 63.9%
64.3 – 65.5%
65.9 – 67.1%
67.5 – 68.6%
69,0 – 70.2%
70.6 – 71.8%
72.2 – 73.3%
73.7 – 74.9%
75.3 – 76.5%
76.9 – 78.0%
78.4 – 79.6%
80.0 – 81.2%
81.6 – 82.7%
83.1 – 84.3%
84.7 – 85.9%
86.3 – 87.5%
87.8 – 89.0%
89.4 – 90.6%
91.0 – 92.2%
92.5 – 93.7%
94.1 – 95.3%
95.7 – 96.9%
97.3 – 98.4%
98.8 – 100%
Fade
10 Gobo wheel 1
gobo selection
Open 0 – 15 0 0 – 5.9% Snap
Gobo 01 16 – 31 6.3 – 12.2%
Gobo 02 32 – 47 12.5 – 18.4%
Gobo 03
48 – 63 18.8 – 24.7%

GLP®
impression® E350 DMX Channel Index Rev. A 5
10
continued
Gobo 04 64 – 79 25.1 – 31% Snap
Gobo 05
80 – 95 31.4 – 37.3%
Gobo 06 96 – 111 37.6 – 43.5%
Gobo 07 112 – 127 43.9 – 49.8%
Gobo wheel rotation stop 128 50.2%
Gobo wheel rotation CW
fast – slow 129 – 191 50.6 – 74.9% Fade
Gobo wheel rotation stop 192 75.3% Snap
Gobo wheel rotation CCW
slow – fast 193 – 255 75.7 – 100% Fade
11 Gobo wheel 1
index & rotation
Gobo index 0 – 360° 0 – 32767 0 0 – 50.0% Fade
Gobo rotation CW
fast – slow 32768 – 49151 50.0 – 74.9% Fade
12 Gobo rotation stop 49152 75% Snap
Gobo rotation CCW
slow – fast 49153 – 65535 75.1 – 100% Fade
13 Gobo wheel 2
(fixed gobos)
gobo selection
Open 0 – 7 0 0 – 2.7% Snap
Gobo 01
8 –15 3.1 – 5.9%
Gobo 02 16 – 23 6.3 – 9.0%
Gobo 03 24 – 31 9.4 – 12.2%
Gobo 04 32 – 39 12.5 – 15.3%

www.glp.de
6 impression® S350 DMX Channel Index Rev. A
13
continued
Gobo 05 40 – 47 15.7 – 18.4% Snap
Gobo 06
48 – 55 18.8 – 21.6%
Gobo 07 56 – 63 22.0 – 24.7%
Gobo 08 64 – 71 25.1 – 27.8%
Gobo 09 72 – 79 28.2 – 31%
Gobo 10 80 – 87 31.4 – 34.1%
No function 88 – 127 34.5 – 49.8%
Gobo wheel rotation stop 128 50.2% Snap
Gobo wheel rotation CW fast
– slow 129 – 191 50.6 – 74.9% Fade
Gobo wheel rotation stop 192 75.3% Snap
Gobo wheel rotation CCW
slow – fast 193 – 255 75.7 – 100% Fade
14 Shutter Closed 0 – 15 255 0 – 5.9% Snap
Pulse, random, slow – fast 16 – 47 6.3 – 18.4% Fade
Ramp-up, random, slow –
fast 48 – 79 18.8 – 31%
Ramp-down, random, slow –
fast 80 – 111 31.4 – 43.5%
Ramp-up-down, random,
slow – fast 112 – 143 43.9 – 56.1%
Strobe with b/o pause 5 – 0.1
sec. 144 – 199 56.5 – 78.0%
Strobe 1 – 10 Hz 200 – 239 78.4 – 93.7%
Open 240 – 255 94.1 – 100% Snap

GLP®
impression® E350 DMX Channel Index Rev. A 7
15 Dimmer coarse
Intensity 0 – 100% 0 – 65535 32768 0 – 100% Fade
16 Dimmer fine
17 Focus coarse
Near – far 0 – 65535 32768 0 – 100% Fade
18 Focus fine
19 Zoom Wide – narrow 0 – 255 128 0 – 100% Fade
20 Frost No frost 0 – 3 0 0 – 1.2% Snap
Frost light 0 – 100% 4 – 127 1.6 – 49.8% Fade
Frost heavy 0 – 100% 128 – 255 50.2 – 100%
21 Prism No prism 0 – 7 0 0 – 2.7% Snap
Prism rotation CW fast - slow 8 – 130 3.1 – 51% Fade
Prism rotation stop 131 51.4% Snap
Prism rotation CCW
slow – fast 132 – 255 51.8 – 100% Fade
22 Effect wheel
position
Effect wheel out – in –
tilt 0 - 90° 0 – 255 0 0 – 100% Fade
23 Effect wheel
index/rotation
Effect wheel rotation stop 0 0 0% Snap
Effect wheel rotation CW
fast – slow 1 – 127 0.4 – 49.8% Fade
Effect wheel rotation stop 128 50.2% Snap
Effect wheel rotation CCW
slow – fast 129 – 255 50.6 – 100% Fade
24 Iris Open – closed 0 – 255 0 0 – 100% Fade

www.glp.de
8 impression® S350 DMX Channel Index Rev. A
25 Special / Control No function
Dimmer curve extra soft*
Dimmer curve linear*
No function
Display off*
Display auto-off*
Display on*
Display orientation normal*
Display orientation invert*
No function
No DMX = blackout*
No DMX = hold*
No DMX = stand-alone*
No DMX = DMX shot*
No function
Fan regulated*
Fan high*
Fan medium*
Fan low*
No function
Position feedback off*
Position feedback on*
Effect shortcuts off*
Effect shortcuts on*
Tilt invert off*
Tilt invert on*
Pan invert off*
Pan invert on*
Zoom invert off*
Zoom invert on*
Focus tracking off*
Focus tracking near*
Focus tracking medium*
Focus tracking far*
No function
PWM 2200 Hz **
PWM 3000 Hz **
PWM 4800 Hz **
PWM 9600 Hz **
No function
PWM 25 kHz **
No function
Set fixture to factory defaults**
No function
Reset pan/tilt *
Reset head*
Reset all*
0 – 38
39 – 41
42 – 44
45 – 53
54 – 56
57 – 59
60 – 62
63 – 65
66 – 68
69 – 71
72 – 74
75 – 77
78 – 80
81 – 83
84 – 86
87 – 89
90 – 92
93 – 95
96 – 98
99 – 104
105 – 107
108 – 110
111 – 113
114 – 116
117 – 119
120 – 122
123 – 125
126 – 128
129 – 131
132 – 134
141 – 143
144 – 146
147 – 149
150 – 152
153 – 191
192 – 194
195 – 197
198 – 200
201 – 203
204 – 206
207 – 209
210 - 239
240 – 242
243 – 245
246 – 248
249 – 251
252 – 255
0 0 – 14.9%
15.3 – 16.1%
16.5 – 17.3%
17.6 – 20.8%
21.2 – 22%
22.4 – 23.1%
23.5 – 24.3%
24.7 – 25.5%
25.9 – 26.7%
27.1 – 27.8%
28.2 – 29.0%
29.4 – 30.2%
30.6 – 31.4%
31.8 – 32.5%
32.9 – 33.7%
34.1 – 34.9%
35.3 – 36.1%
36.5 – 37.3%
37.6 – 38.4%
38.8 – 40.8%
41.2 – 42.0%
42.4 – 43.1%
43.5 – 44.3%
44.7 – 45.5%
45.9 – 46.7%
47.1 – 47.8%
48.2 – 49.0%
49.4 – 50.2%
50.6 – 51.4%
51.8 – 52.5%
55.3 – 56.1%
56.5 – 57.3%
57.6 – 58.4%
58.8 – 59.6%
60.0 – 74.9%
75.3 – 76.1%
76.5 – 77.3%
77.6 – 78.4%
78.8 – 79.6%
80.0 – 80.8%
81.2 – 82.0%
82.4 – 93.7%
94.1 – 94.9%
95.3 – 96.1%
96.5 – 97.3%
97.6 – 98.4%
98.8 – 100%
Snap

GLP®
impression® E350 DMX Channel Index Rev. A 9
26 FX1 selection No FX
Chaser 1-2-3-4-3-2-1
Crossfade 1-2-3-4-3-2-1
Chaser 1+2 – 3+4
Crossfade 1+2 – 3+4
Chaser 1+4 – 2+3
Crossfade 1+4 – 2+3
Chaser random
Crossfade random
No function
0 – 10
11 – 14
15 – 18
19 – 22
23 – 26
27 – 30
31 – 34
35 – 38
39 – 42
43 – 255
0 0 – 3.9%
4.3 – 5.5%
5.9 – 7.1%
7.5 – 8.6%
9 – 10.2%
10.6 – 11.8%
12.2 – 13.3%
13.7 – 14.9%
15.3 – 16.5%
16.9 – 100%
Snap
27 FX1 adjustment FX1 speed slow – fast 0 – 255 0 0 – 100% Fade
* Move from zero and hold value for 3 seconds to apply
** Move from zero and hold value for 5 seconds to apply
Notes:
Percentage values are calculated by dividing DMX values by 2.56 and rounding to the
nearest 0.1%.
To apply a command on Channel 25 (Special / Control), start at a value of zero, then
move to the required value and hold it for the required time (e.g. 3 seconds). If you move
to the required value from any other value than zero, the command will not be applied.
To adjust the PWM frequency using the Special / Control channel, start at a value of zero,
move to the required value and hold it for at least 5 seconds.
Default settings are written in bold type.
