LED Video Light
Thank you for purchasing this Godox Product!
LED36 video light is excellent for macrophotography, product shooting, and
video recording, etc. This lightweight and portable light provides high
brightness and accurate color temperature. You can flexibly control the light
brightness by using the dimmer and by interlocking multiple lights.
Foreword:
01. 36 LED Beads
02. Power Switch
03. Brightness Controller
04. Battery Compartment
05. Light Hotshoe Connection
06. Locking Ring A
07. Locking Ring B
08. Camera Hotshoe Connection
09. 1/4″ Bracket Mounting Hole
Parts:
Installation and Operation
1.Installing the Video Light
Screw the Locking Ring A (06) and B (07) to the
highest point so that the light is fixed and insert the
Camera Hotshoe Connection horizontally into the
hotshoe of a camera or a camcorder.
Tighten the Locking Ring B (07).
Open the Battery
Compartment (04).
2.Using the Video Light
Install batteries (2*AA)
according to indications
in the compartment and
then close it.
Switch the power on,
the video light giving
out light.
Turn the Brightness Controller (03) to adjust the
brightness.
Turn the power off if it will not be used.
3.Interlocking Multiple Video Lights
Through the Light Hotshoe Connection
(05) and Camera Hotshoe Connection
(08), multiple video lights can be
interlocked together to strengthen the
lighting brightness and get a better
control of the lighting effects.
Battery
Power
Duration
Color Temperature
Brightness
Brightness Control
LED Beads Quantity
Operation Temperature
Dimension
Net weight
Technical Data:
* Product design and specifications are subject to change without notice.
Note: If your camcorder has no hotshoe connection, you are advised to purchase a
connecting bracket for camcorder. The video light has a 1/4″ Bracket Mounting Hole as
your camcorder does. Therefore, you can easily connect both the light and the
camcorder to the bracket.
Model: LED 36
Instruction manual | 说明手册
Chinese English Bilingual | 中英文双语
Two AA batteries
<1.3W
Approx. 1.5 hours with alkaline batteries
5500~6500K
>260Lux (0.5m)
Stepless
36
-10~40℃
70*89*38mm
80g
01 03
02
05
06 07
08
09
04
Always keep this product dry. Do not use in rain or in damp conditions.
Do not disassemble. Should repairs become necessary, this product must
be sent to an authorized maintenance center.
Keep out of reach of children.
As this product do not have waterproof function, please take measures of
waterproof in rainy or damp environment.
Do not use or store the product if the ambient temperature reads over 50°C.
Do not use the flash unit in the presence of flammable gases, chemicals and
other similar materials. In certain circumstance, these materials may be
sensitive to the strong light emitting from this flash unit and fire or
electromagnetic interference may result.
Observe precautions when handling batteries
● Do not put batteries into a fire or apply direct heat to them.
● Batteries are prone to leakage when fully discharged. To avoid
damage to the product, be sure to remove batteries when the
product is not used for a long time or when batteries run out of
charge.
● Should liquid from the batteries come into contact with skin or
clothing, rinse immediately with fresh water.
Warning:
