Goodwe A-BP Series User manual

Quick Installation Guide
A-BP Series
GW5000A-BP | GW6000A-BP | GW7000A-BP | GW7600A-BP | GW8600A-BP | GW9600A-BP
AC-Coupled Inverter
V1.1-2022-12-30

01
Safety Disclaimer
• The information in this quick installation guide is subject to change due to product updates
or other reasons. This guide cannot replace the product labels or the safety precautions in
the user manual unless otherwise specied. All descriptions here are for guidance only.
• Before installations, read through the quick installation guide. For additional information,
please see the user manual.
• All operations should be performed by trained and knowledgeable technicians who are
familiar with local standards and safety regulations.
• Check the deliverables for correct model, complete contents, and intact appearance. Contact
the manufacturer if any damage is found or any component is missing.
• Use insulating tools and wear personal protective equipment when operating the equipment
to ensure personal safety. Wear anti-static gloves, clothes, and wrist strip when touching
electronic components to protect the inverter from damage. The manufacturer shall not be
liable for any damage caused by static electricity.
• Strictly follow the installation, operation, and conguration instructions in this guide and user
manual. The manufacturer shall not be liable for equipment damage or personal injury if you
do not follow the instructions. For more warranty details, please visit https://en.goodwe.com/
warranty.
DC Side:
1. Ensure the component frames and the bracket system are securely grounded.
2. Connect the DC cables using the delivered PV connectors. The manufacturer shall not be
liable for equipment damage if other connectors are used.
3. Ensure the DC cables are connected tightly, securely, and correctly. Inappropriate wiring
may cause poor contacts or high impedances, and damage the inverter.
4. Measure the DC cable using the multimeter to avoid reverse polarity connection. Also, the
voltage should be under the max DC input voltage. The manufacturer shall not be liable for
the damage caused by reverse connection and extremely high voltage.
5. To avoid shock hazards, ensure the minimum impedance of the PV string to the ground
exceeds R, R=Max. Input Voltage (V)/30mA.
6. Keep the battery o, and the inverter disconnects with PV panels and other AC power
before connecting the battery and the inverter. The rated voltage of the battery should
meet specications of the inverter.
7. The PV modules used with the inverter must have an IEC61730 class A rating.
AC Side:
1. The voltage and frequency at the connecting point should meet the on-grid requirements.
2. Additional protective devices like circuit breakers or fuses are recommended on the AC
side. Specication of the protective device should be at least 1.25 times the max AC output
current.
3. PE cable of the inverter must be connected rmly.
4. You are recommended to use copper cables as AC output cables. If you prefer aluminum
cables, remember to use copper to aluminum adapter terminals.
01 Safety Precautions
General Disclaimer
WARNING

02
Product:
1. Do not apply mechanical load to the terminals, otherwise the terminals can be damaged.
2. All labels and warning marks should be visible after the installation. Do not scrawl, damage,
or cover any label on the device.
3. Do not touch the running equipment to avoid being hurt as its temperature may exceed
60℃. Do not install the equipment at a place within children's reach.
4. Unauthorized dismantling or modication may damage the equipment, the damage is not
covered under the warranty.
5. Do not start the BACK-UP function if the inverter is not connected to the battery.
6. If there is any radio or wireless communication equipment below 30MHz near the inverter,
you have to:
• Install the inverter at least 30m far away from the wireless equipment.
• Add a low pass EMI lter or a multi winding ferrite core to the DC input cable or AC output
cable of the inverter.
7. Warning labels on the inverter are as follows.
Check Items Before Switching Power ON
No. Check Item
1The product is rmly installed at a clean place that is well-ventilated and easy-to-
operate.
2The PE, DC input, AC output, and communication cables are connected correctly
and securely.
3 Cable ties are intact, routed properly and evenly.
4 Unused ports and terminals are sealed.
5The voltage and frequency at the connection point meet the inverter grid
connection requirements.
HIGH VOLTAGE HAZARD.
Disconnect all incoming power
and turn o the product before
working on it.
Delayed discharge. Wait 5 minutes
after power o until the components
are completely discharged.
Read through the guide before
working on this device.
Potential risks exist. Wear proper
PPE before any operations.
High-temperature hazard. Do
not touch the product under
operation to avoid being burnt.
Grounding point. Indicates the
position for connecting the PE cable.
CE marking Do not dispose of the inverter
as household waste.Discard the
product in compliance with local
laws and regulations, or send it back
to the manufacturer.
5min

03
LED Explanation
Indicator Status Explanation
SYSTEM
ON = The system is ready.
BLINK = The system is starting.
OFF =The system is not working.
BACK-UP
ON = Back-up is ready / power available.
OFF = Back-up is o / power not available.
BATTERY
ON = The battery is charging.
BLINK 1 = The battery is discharging.
BLINK 2 = The battery is low / soc is low.
OFF = The battery is disconnected / not active.
GRID
ON = The grid is active and connected.
BLINK = The grid is active but not connected.
OFF = The grid is not active.
ENERGY
ON = Consuming energy from grid / buying.
BLINK 1 = Supplying energy to grid / zeroing.
BLINK 2 = Supplying energy to grid / selling.
OFF = The grid is not connected or the system is not working.
COM
ON = Both BMS communication and meter communication are
ok.
BLINK 1 = BMS communication fails; meter communication is ok.
BLINK 2 = BMS communication is ok; meter communication fails.
OFF = BMS communicationand meter communication fail.
WiFi
ON = WiFi connected / active.
BLINK 1 = WiFi is resetting.
BLINK 2 = WiFi is not connected to the router.
BLINK 4 = WiFi server problem.
OFF = WiFi is not active.
FAULT
ON = A fault has occured.
BLINK 1 = Back-up output overload / reduce load.
BLINK 4 = CT wiring fault.
OFF = No fault.

04
Parts
02 Product Introduction
1
2
3
4
5
6
7
8
9
10
11
12
1. WiFi Reset Reload 2. LED Indicators 3. Battery Terminal
4. Auto-transformer Terminal 5. Back-up Terminal 6. On-Grid Terminal
7. Grounding (PE) Busbar 8. Energy Meter CT Terminal 9. BMS
10. EMS 11. Grounding (PE) Busbar 12. WiFi Module

05
Dimensions
Auto Transformer
A-BP Inverter
345mm
13.6in
174mm
6.9in
110mm
4.3in
120mm
4.7in
120mm
4.7in
110mm
4.3in
277mm
10.9in
415mm
16.3in
175mm
6.9in
110mm
4.3in
110mm
4.3in
140mm
5.5in
120mm
4.7in
120mm
4.7in
150mm
5.9in
791mm
31.1in
1. WiFi Reset Reload 2. LED Indicators 3. Battery Terminal
4. Auto-transformer Terminal 5. Back-up Terminal 6. On-Grid Terminal
7. Grounding (PE) Busbar 8. Energy Meter CT Terminal 9. BMS
10. EMS 11. Grounding (PE) Busbar 12. WiFi Module

06
x 1 x 1 x 7 x 1 x 1 x 1
x 1
x 1
x 1
x 3 x 2 x 2
x 1 x 1
x N
Auto Transformer
A-BP Inverter
x 1 x 1 x 4 x 1 x 4 x 8
03 Inverter Installation
N = Quantity depends on the inverter model.

07
Angle Requirements
Space Requirements
300mm
11.81in
200mm
7.87in 300mm
11.81in
100mm
3.94in
100mm
3.94in
0%~95%RH
-31°F~140°F
(-35°C~60°C)
500mm
19.69in
300mm
11.81in 300mm
11.81in
200mm
7.87in
200mm
7.87in
NEMA
TYPE 4X

08
Inverter Installation
Auto Transformer
A-BP Inverter
1 2 3
4
5
1 2 3
4
5

09
Preparations Before Electrical Connection
04 Electrical Connection
456
1
2
12
3
2
1
2
1
1
1
2

10
Battery Cable
1
2
3
2.5~3 N·m
1
1
2
Φ: max 7.4mm
(0.29in)
Φ: max 7.4mm
(0.29in)
Φ: max 7.4mm
(0.29in)
90℃ Copper, 6AWG
18mm
(0.71in)
18mm
(0.71in)
18mm
(0.71in)

11
On-Grid Cable
L2L1
N
1
2
3
L2
L2
L1
N
N
L1
L2
N
L1
Φ: max 7.4mm
(0.29in)
Φ: max 7.4mm
(0.29in)
Φ: max 7.4mm
(0.29in)
90℃ Copper, 8-10AWG
18mm
(0.71in)
18mm
(0.71in)
18mm
(0.71in)

12
L2
NL1
BACKUP Cable
Φ: max 7.4mm
(0.29in)
Φ: max 7.4mm
(0.29in)
Φ: max 7.4mm
(0.29in)
90℃ Copper, 8-10AWG
18mm
(0.71in)
18mm
(0.71in)
18mm
(0.71in)
3
1
2
L2
N
L1
L2
N
L1
N
L1
L2

13
To CT
CT Cable
BMS
Type One: CAN1 Battery (CAN1 Communication)
To Grid CT
1
2
1
1
2
3
CAN1

14
Type Two: LG Battery (485 Communication)
A-BP LG Battery
NC CAN_H
LG_EN+ EN GND
LG_EN- ENABLE_H
485-1A RS485_H
485-1B RS485_L
NC CAN_L
1
2
1
1
2
3
1
2
3
1
2
1
LG_EN+
LG_EN-
LG_EN+
LG_EN-
485

15
Communication Module
Auto-transformer (Optional)
L1 N L2 PE
NTC
2
L1/L2
N
PE
NTC
1
Φ: max 7.4mm
(0.29in)
18mm
(0.71in)
18mm
(0.71in)
18mm
(0.71in)
7mm(0.28in)
90℃ Copper, 8-10 AWG
22-24 AWG, 600V insulated
Φ: max 7.4mm
(0.29in)
Φ: max 7.4mm
(0.29in)

16
Turn on
Turn o
124
3
12
4
3
A-BP Series (Full Backup)
Power ON
Power OFF
1
3
2
4
Auto-transformer
Automatic
transfer Switch
Loads
Power Meter
On-grid Output Breaker
Back-up Output Breaker
Main
Breaker
DC Breaker
Battery
BMS NTC
CT1
CT2
Meter CT Communication
Grid
05 Wiring System

17
Note 1: The backup Output L1 or L2 Max continuous current carrying capacity≤40A. Note 2: The actual 50A circuit breaker is installed in this box or other boxes.
Wiring Box Of A-BP Series AC Coupled Inverter (Full Load)
From Utility Meter
To Main Panel
Auto-transformer Temp. sense [T1,T2]
22AWG(20~24AWG),600V insulated
Auto-transformer
AC[L1,N,L2],8AWG(8~12AWG)
BMS Cable
22AWG(20~24AWG),600V insulated
BAT+,BAT-,6AWG(6~12AWG)
Two Meter CTs
1" Conduit
*Note 1
*Note 2 *Note 2
ATS BOX
1" Conduit
1" Conduit
1" Conduit
AC BACKUP
[L1,N,L2],8AWG(8~12AWG)
AC Grid
[L1,N,L2],8AWG(8~12AWG)
Ground Bus-bar
Neutral Bus-bar
50A
CB
50A
CB
50A
CB
50A
CB
200A CB
PE -+
Controller
CT1
CT2
Auto-transformer
Battery L2 N L1 PE T1T2
L2 N L1 PE T1T2
L2 CT2 CT1 L1 N
L2 CT2 CT1 L1 N
PE L2 L1N
PE L2 L1N

18
Turn on
Turn o 124
3
5
12
43
5
Power ON
Power OFF
1
3
2
4
5
Meter CT Communication
Power Meter
Main Breaker
AC Breaker
AC Breaker
DC Breaker
Back-up Breaker
Auto-transformer
Battery
BMS
120V
Loads
Loads
240V
Loads
PE
N
L2
L1
PE
N
L2
L1
NTC
CT1
CT2
Grid
A-BP Series (Partial Backup)

19
Wiring Box Of A-BP Series AC Coupled Inverter (Partial Load)
Note 1: The rated current of the circuit breaker depends on the load power. Note 2: The Max continuous output current Per Phase @ 120 V is 40A. Note 3: The back-up Output L1 or L2 Max continuous current carrying capacity≤40A.
120V
BACKUP
Loads
Auto-transformer
Battery
To BACKUP Loads
240V
BACKUP
Loads
To Utility Meter
Two Meter CTs
Ground Bus-bar
Ground Bus-bar
Neutral Bus-bar
Neutral Bus-bar
BACKUP Loads
Distribution Panel
Main Distribution
Panel
BACKUP Panel Main Breaker
BACKUP Panel Loads Breakers
*Note 3
*Note 2
*Note 1
1" Conduit 1" Conduit1" Conduit1" Conduit
PE
L1
L2
NMain Breaker
PE +- PE +-
CB CB CB CB CB CB CB
50A CB
CB CB CB CB CB
50A CB
50A
CB
20A
CB
20A
CB
20A
CB
20A
CB
50A
CB
Auto-transformer Temp. sense [T1,T2]
22AWG(20~22AWG), 600V insulated
AC BACKUP
[L1,N,L2], 90℃, 8-10AWG
AC Grid
[L1,N,L2], 90℃, 8-10AWG
Auto-transformer
AC[L1,N,L2], 90℃, 8-10AWG
BMS Cable
22AWG(20~24AWG),600V insulated
BAT+, BAT-, 90℃, 6AWG
L2 N L1 PE L2 N L1 PE
PE L2 N L1
PE L2 N L1
L2 N L1 PE
L2 N L1 PE
T1T2
T1T2
CT1
CT2
