GREAT PLAINS Turbo Max 1800TM User manual

Manufacturing, Inc.
www.greatplainsmfg.com
© Copyright 2021 Printed 2021-03-24 586-536Q-ENG
EN
Table of Contents Index
Table of Contents Index
ORIGINAL INSTRUCTIONS
Assembly Manual
1800TM, 2400TM & 3000TM
Turbo Max
Read the operator’s manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit.
43132

Table of Contents Index
Table of Contents Index

1800-3000TM Cover Index Table of Contents
Great Plains | 586-536Q-ENG | 03/24/2021 Cover Index iii
© Copyright 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021 All rights Reserved
Great Plains Manufacturing, Inc. provides this publication “as is” without warranty of any kind, either expressed or implied. While every precaution has been
taken in the preparation of this manual, Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed
for damages resulting from the use of the information contained herein. Great Plains Manufacturing, Inc. reserves the right to revise and improve its products
as it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, Max-Chisel, Row-Pro,
Singulator Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press.
Registered Trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land Pride, MeterCone,
Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-Till, Ultra-Till, Whirlfilter, and Yield-Pro.
Brand and Product Names that appear and are owned by others are trademarks of their respective owners.
Printed in the United States of America
Table of Contents
Important Safety Information.................................................1
Introduction.............................................................................4
Description of Unit .............................................................4
Models Covered ................................................................4
Document Family...............................................................4
Tools Required ..................................................................4
Pre-assembly Checklist .....................................................4
Using This Manual.............................................................5
Definitions...................................................................5
Shipping Inventory.............................................................5
Unloading ..........................................................................7
Unpacking Components .............................................7
Unload Smaller Items First .........................................7
Unpacking Boxes .......................................................7
Further Assistance .....................................................7
Assembly.................................................................................8
Center Frame & Lift Assembly ...................................8
Center Transport 1800 ...............................................9
Center Transport 2400-3000 ......................................9
Level Bar & Fold Brackets ...............................................10
Valve Brackets & Valves .................................................11
Valve Brackets & Hoses ..................................................11
Hitch ................................................................................12
Wing & Lift Assembly ...............................................14
Wing Transport.........................................................16
Depth Stop & Angle Gauge......................................17
Attach Hose Clamps and Hose Wraps.....................18
Hydraulic Hose Hookup............................................18
Hose Handles...........................................................18
Purging Hydraulic System ........................................19
Center Gang Bar 1800 .............................................20
Center Gang Bar 2400-3000 ....................................22
Wing Gang Bar 1800-2400.......................................24
Wing Gang Bar 3000................................................26
Front Light Assembly................................................28
Rear Lights and SMV Assembly...............................28
Splitter Switch...........................................................30
3000 Wing Fold Assist..............................................31
Proximity Sensor Adjustment ...................................31
Gang Cylinder Purging .............................................32
Hose Routing Hitch ..................................................33
Gauge Wheel (optional) ...........................................33
Rolling Harrow (optional)..........................................34
Reel Following Rolling Harrow (optional) .................35
Hydraulic Reel Down Pressure Kit ..................................36
Hydraulic Reel Attachment.......................................37
Install Rear Hitch (optional) .............................................38
Extended Rear Hitch ................................................38
A-Frame Hitch ..........................................................38
Rear Stand ...............................................................39
Weight Package Assembly (Optional)......................39
Appendix - Reference Information......................................41
Torque Values Chart .......................................................41
Tire Inflation Chart...........................................................42
Hydraulic Connectors and Torque...................................43
Hydraulic Lift Layout (S/N GP-C6545H+)........................44
Hydraulic Lift Layout (S/N GP-C6544H-).........................45
1800-2400TM Hydraulic Fold Layout (S/N GP-C6545H+) ..
46
1800-2400TM Hydraulic Fold Layout (S/N GP-C6544-)..47
3000TM Hydraulic Fold Layout (S/N GP-C6545+)..........48
3000TM Hydraulic Fold Layout (S/N GP-C6544H-) ........49
1800-2400TM Hydraulic Gang Angle Layout (S/N GP-
C6545H+)........................................................................50
1800-2400TM Hydraulic Gang Angle Layout (S/N GP-
C6544H-).........................................................................51
3000TM Hydraulic Gang Angle Layout (S/N GP-C6545H+)
53
3000TM Hydraulic Gang Angle Layout (S/N GP-C6545H+)
54
3000TM Hydraulic Gang Angle Layout (S/N GP-C6544H-)
55
1800TM Machine Layout.................................................56
2400TM Machine Layout.................................................57
3000TM Machine Layout.................................................58
1800TM Rolling Harrow Layout.......................................59
1800TM Heavy Reel Following Rolling Harrow Layout ...60
1800TM Hydraulic Reel Layout .......................................61
2400TM Rolling Harrow Layout.......................................62
2400TM Heavy Reel Following Rolling Harrow Layout ...63
2400TM Hydraulic Reel Layout .......................................64
2400TM Hydraulic Reel Layout .......................................65
3000TM Rolling Harrow Layout.......................................66
3000TM Heavy Reel Following Rolling Harrow Layout ...67
3000TM Hydraulic Reel Layout .......................................68
3000TM Hydraulic Reel Layout .......................................69

Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index iv
1800-3000TM Table of Contents Index

1800-3000TM Table of Contents Index Important Safety Information
Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 1
Important Safety Information
Look for Safety Symbol
The SAFETY ALERT SYMBOL indicates there is a potential
hazard to personal safety involved and extra safety precaution
must be taken. When you see this symbol, be alert and
carefully read the message that follows it. In addition to design
and configuration of equipment, hazard control and accident
prevention are dependent upon the awareness, concern,
prudence and proper training of personnel involved in the
operation, transport, maintenance and storage of equipment.
Be Aware of Signal Words
Signal words designate a degree or level of hazard seriousness.
DANGER indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury. This signal
word is limited to the most extreme situations, typically for
machine components that, for functional purposes, cannot be
guarded.
WARNING indicates a potentially hazardous situation which,
if not avoided, could result in death or serious injury, and
includes hazards that are exposed when guards are removed. It
may also be used to alert against unsafe practices.
CAUTION indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury. It may
also be used to alert against unsafe practices.
Use Adequate Lifting Means
The frame sections and gangs of this machine are
extremely heavy. If using multiple lifters, make sure each
is rated for at least its share of the load.
Prepare for Emergencies
Be prepared if a fire starts
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctor, ambulance, hospital
and fire department near phone.
Be Familiar with Safety Decals
Read and understand the “Safety Decals” section of the
Operators Manual.
Read all instructions noted on the decals.
Keep decals clean. Replace damaged, faded and illegible
decals.
> 14,000
POUNDS

Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 2
1800-3000TM Table of Contents Index Important Safety Information
Wear Protective Equipment
Wear protective clothing and equipment.
Wear clothing and equipment appropriate for the job.
Avoid loose-fitting clothing.
Because prolonged exposure to loud noise can cause
hearing impairment or hearing loss, wear suitable
hearing protection such as earmuffs or earplugs.
Because operating equipment safely requires your full
attention, avoid wearing entertainment headphones while
operating machinery.
Avoid High Pressure Fluids
Escaping fluid under pressure can penetrate the skin, causing
serious injury.
Avoid the hazard by relieving pressure before
disconnecting hydraulic lines.
Use a piece of paper or cardboard, NOT BODY PARTS, to
check for suspected leaks.
Wear protective gloves and safety glasses or goggles when
working with hydraulic systems.
If an accident occurs, seek immediate medical assistance
from a physician familiar with this type of injury.
Use Safety Lights and Devices
Slow-moving tractors and towed implements can create a
hazard when driven on public roads. They are difficult to see,
especially at night.
Use flashing warning lights and turn signals whenever
driving on public roads.
Use lights and devices provided with implement.
Keep Riders Off Machinery
Riders obstruct the operator’s view. Riders could be struck by
foreign objects or thrown from the machine.
Never allow children to operate equipment.
Keep all bystanders away from machine during operation.
Shutdown and Storage
Lower implement, put tractor in park, turn off engine, and
remove the key.
Secure Turbo Max using blocks and supports provided.
Detach and store Turbo Max in an area where children
normally do not play.

1800-3000TM Table of Contents Index Important Safety Information
Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 3
Tire Safety
Tire changing can be dangerous and should be performed by
trained personnel using correct tools and equipment.
When inflating tires, use a clip-on chuck and extension
hose long enough for you to stand to one side–not in front
of or over tire assembly. Use a safety cage if available.
When removing and installing wheels, use wheel-handling
equipment adequate for weight involved.
Safety At All Times
Thoroughly read and understand the instructions in this
manual before operation. Read all instructions noted on the
safety decals.
Be familiar with all machine functions.
Operate machinery from the driver’s seat only.
Do not leave machine unattended with tractor engine
running.
Do not stand between the tractor and machine during
hitching.
Keep hands, feet and clothing away from power-driven
parts.
Wear snug-fitting clothing to avoid entanglement with
moving parts.
Watch out for wires, trees, etc., when folding and raising
machine. Make sure all persons are clear of working area.

Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 4
1800-3000TM Table of Contents Index Introduction
Introduction
The Turbo Max has been designed with care and built by
skilled workers using quality materials. Proper setup,
maintenance, and safe operating practices will help the
customer get years of satisfactory use from the machine.
Description of Unit
The 1800-3000TM Turbo Max is a three section “vertical”
tillage tool. Working width ranges from 18 to 30 feet. The
implement is designed to cut and size residue, till soil for faster
seedbed warming, break up soil crust on hard dried fields
while eliminating compaction layers. The front and rear gangs
may be adjusted from 0-6 degree angle, depending on the
aggressiveness desired. Various finishing attachments are also
available to further smooth, redistribute residue, kill weeds,
and break clods.
Models Covered
Document Family
Tools Required
•Basic Hand Tools
•Torque Wrench
•Fork Truck, Overhead Hoist or Loader
Pre-assembly Checklist
Before assembling, read and understand “Important
Safety Information” in front part of this manual.
Have at least two people on hand while assembling.
Make sure area is level and free of obstructions
(preferably an open concrete area).
Have all major components
Have all fasteners and pins shipped with machine.
1800TM 18’ (7.5in) spacing
2400TM 24’ (7.5in) spacing
3000TM 30’ (7.5in) spacing
586-536Q Pre-Delivery Manual
586-536M Operator Manual
586-536P Parts Manual
586-536Q-ENG Assembly Manual (this document)
Figure 1
2400 Turbo Max
43133

1800-3000TM Table of Contents Index Introduction
Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 5
Using This Manual
This manual was written to help you assemble and pre-
pare the new machine for the customer. The manual
includes instructions for assembly and setup. Read this
manual and follow the recommendations for safe, effi-
cient and proper assembly and setup.
An operator’s and parts manual is also provided with the
new machine. Read and understand “Important Safety
Information” and “Operating Instructions” in the oper-
ator’s manual before assembling the machine. Refer to
the parts manual for proper part’s identification. As a ref-
erence, keep the operator’s and part’s manual on hand
while assembling.
The information in this manual is current at printing.
Some parts may change to assure top performance.
Definitions
The following terms are used throughout this manual.
A crucial point of information related to the preceding topic.
Read and follow the directions to remain safe, avoid serious
damage to equipment and ensure desired field results.
Useful information related to the preceding topic.
Right-hand and left-hand as used in this
manual are determined by facing the
direction the machine will travel while in
use unless otherwise stated. An orientation
rose in some line art illustrations shows the
directions of: Up, Back, Left, Down, Front,
Right.
Shipping Inventory
The machine will be shipped unassembled as shown in a big
shipping rack and shipping boxes on pallets. The only parts
that will be assembled are the gang assemblies, reel and
rolling harrow attachment assemblies.
Refer to Figure 3
•All frame sections, hitch and torque tubes will be
shipped in shipping container rack.
•Small parts and bolts will be shipped in boxes.
L
R
Figure 2
Right / Left
43133
U
D
F
B
L
R
Figure 3
Shipping Rack & Box
42967

Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 6
1800-3000TM Table of Contents Index Introduction
Refer to Figure 4
•Rear attachments and gang assemblies will be shipped in
shipping container rack.
•Shipping containers or racks do not need to be returned
to Great Plains.
Figure 4
Shipping Gangs & Attachments
42968

1800-3000TM Table of Contents Index Introduction
Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 7
Unloading
Once everything is unloaded from “storage pod” you may
proceed with taking parts out of shipping containers.
Carefully move everything to level site and prepare to un
pack items.
Unpacking Components
Be sure you have read and understood the Important Safety
Information, starting on page 1 of this manual, before you
start unpacking components.
Centering components:
Be sure and center fork truck or chains (overhead hoist) on
components so they won’t slide and cause injury.
Carefully un-band components.
Now unload individual components one at a time using a
fork truck or overhead hoist.
Move each component out of the way so you have plenty of
room to remove the next one.
Unload Smaller Items First
Unloading the frames is a potentially dangerous operation.
Reduce risk and complication by first unloading
1. the tire wheel assemblies,
2. the smaller items
Place these components well out of the maneuvering area
needed for unloading the gang assemblies and frames.
3. Carefully unload the frames and hitch out of shipping
rack
Unpacking Boxes
Position boxes in area that you can maneuver
components up to machine to assembly.
4. Carefully remove banding from boxes.
5. Carefully remove banding from brace bars and finishing
reels.
6. Locate and identify all components before assembling.
Further Assistance
Great Plains Manufacturing, Inc. wants you to be satisfied
with your new Turbo Max. If for any reason you do not
understand any part of this manual or are otherwise dissatisfies
with the product please contact:
Great Plains Service Department
1525 E. North St.
PO Box 5060
Salina, KS 67402-5060
Or go to www.greatplainsag.com and follow the contact
information at the bottom of your screen for our service
department.

Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 8
1800-3000TM Table of Contents Index Assembly
Assembly
Center Frame & Lift Assembly
Refer to Figure 5
Note:Once the center frame has been uncrated and put on
stands, the brace bar may be installed. See “Parts Man-
ual” for part numbers and description of parts.
7. Align holes in plates of the center brace bar with holes
on front of center frame , secure with 34 x 2 hex bolts
, 34 lock washers and nuts.
8. Carefully lower the torque tube (models 2400 or 3000)
or torque tube (model 1800) with an overhead hoist
until holes are aligned with the holes on top of center
frame and secure with 1.25 x 7.75 pins , and
1.25 x 6.75 pin , 38 x 214 Gr. 8, and special thread bolts
and 38 top lock nuts.
9. Align hole in lift strap and cylinder mount plate in
proper orientation shown in drawing. Secure lift strap
with 1 x 312 hex bolts and 1 lock nuts, rear of cylinder
mount plate to plates of torque tube or with 1 x 4
hex bolt and 1 lock nut.
10. Install the cylinders using 1 x 318 pins , 1.5 x 1.0
x.075 machine washers and 316 x 2 cotter pin.
11. Install cylinder transport locks to cylinders using
38 x 3 pins and clip pins
12. Tighten all bolts with lock nuts snug, but do not torque.
The rest of the bolts may be tightened to specs, See
“Torque Values Chart” on page 41.
1
2
3
4
5
26
17
7
8 9
8
10
9 4 5
11
12 13
14 12
15
5
7
6
17
11
9
10
14
15
4
13
13
12
3
Figure 5
Center Frame & Lift Assembly TP-69125
U
D
F
B
L
R
2
1
8
10

1800-3000TM Table of Contents Index Assembly
Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 9
Center Transport 1800
Refer to Figure 6
13. Slide hub/spindle assembly into torque tube and
align holes. Secure with 12 x 412 hex bolts and 12 top
lock nut.
14. Attach tire/wheel assembly with 58 lug nuts .
15. Tighten all bolts with lock nuts snug, but do not torque.
The rest of the bolts may be tightened to specs, See
“Torque Values Chart” on page 41.
Center Transport 2400-3000
Refer to Figure 7
16. Slide walking beam assembly into torque tube and
align holes. Secure with 12 x 6, Gr. 8 hex bolts and 1/2
top lock nut.
17. Slide hub/spindle assemblies into walking beam
assembly and align holes. Secure with 12 x 5 hex bolts
and 12 top lock nut.
18. Attach tire/wheel assemblies with 58 lug nuts .
19. Tighten all bolts with lock nuts snug, but do not torque.
The rest of the bolts may be tightened to specs, See
“Torque Values Chart” on page 41.
5
4
3
2
1
U
D
F
B
L
R
Figure 6
Center Transport 1800
42952
12
3
4 5
7
U
D
F
B
L
R
6
4
1
5
4
3
2
Figure 7
Center Transport 2400-3000
42953
12
3
4
1
5
6 7

Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 10
1800-3000TM Table of Contents Index Assembly
Level Bar & Fold Brackets
Refer to Figure 8
20. Install front and rear (model 3000 only) fold brackets
with 34 x 2 hex bolt (rear plate), 34 lock washers and
nuts.
21. Attach outside plates of wing stops with 58x 112 hex
bolts , 58 lock washers and nuts. Secure inside plate to
rear truss bars with 58x 4132 x 512 u-bolts , 58 lock
washers and nuts.
22. Attach 34 x 3 hitch pin to tube wing stops .
23. Install rear level bar to torque tube with 1 x 912 pins
, 38 x 214, Gr. 8 hex bolts and 38 nylon lock nut.
24. Install h-bracket assembly to front of rear level bar
with 34 x 2, Gr. 8 hex bolts , 34 lock washers and nuts.
25. Install bottom of h-bracket assembly to center brace
bar with 1 x 314 clevis pin , 1.5 x 1.00 x.075 machine
washer and 316 x 2 cotter pin.
26. Bolts may be tightened to specs, See “Torque Values
Chart” on page 41 and all cotter pins may be bent.
1
2
3
4
3 5
13 3
6
7 8
912
5
9
10
11
8
1
2
1
12
3
3
4
5
11
10
6
7
9
13
U
D
F
B
L
R
Figure 8
Level Bar & Fold Brackets TP-69126

1800-3000TM Table of Contents Index Assembly
Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 11
Valve Brackets & Valves
Refer to Figure 11
The valves and brackets should be installed in the
correct locations on your machine. If for some reason
they are not follow the steps below to install.
27. Use 516 x 412 Gr. 5 hex bolt , 516 lock nuts and washers
to secure the bypass valve to the by pass valve
bracket .
28. The bypass valve bracket is attached to the center
frame using 38x 114 hex bolts , 38 lock washers and
hex nuts.
29. The lock valve is attached to a mounting plate that is
welded to the frame. Use 14x 134 Gr. 5 hex bolts to
secure to the frame.
30. Depth control valve is secured to the frame using
516 x 2 hex bolts and 516 lock washers.
31. Be sure hoses are routed as shown in, See “Valve
Brackets & Hoses” on page 11.
32. Bolts may be tightened to specs, Bolts may be tightened to
specs, See “Torque Values Chart” on page 41.
Valve Brackets & Hoses
Refer to Figure 12
The hoses will be shipped hooked up to valves,
cylinders, bulkhead fittings, and will be routed on the
machine in the proper places. The hoses from the
hitch will need to be connected to the bulkhead fittings
on the center brace bar. The bypass , lock valve ,
and depth control valve hoses will be routed
underneath or around the weight kits so that they
may be installed or removed without taking hoses or
valves lose. The hoses will be secured to the frames
using hose holders and P-clips. If any of the hoses are
not already secured to the frame route the hoses
along the path with the hose holders to the bulkhead
brackets and fittings. See “Appendix - Reference
Information” on page 41 for proper mounting
instructions.
1
5
3
6
2
4
U
D
F
B
L
R
Figure 9
Valve Brackets & Valves
TP-69107
3
1
2
2
4
5
6
7
8
4
2
1
3
Figure 10
Valve Brackets & Hoses
TP-69120
1 2
3
4

Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 12
1800-3000TM Table of Contents Index Assembly
Hitch
Refer to Figure 11
33. Bolt the hitch frame to front trusses with the 114 x 8 Gr. 8 bolts , 114 flat washer (one side of uniball to take up space)
and 114 top lock nuts. Tighten bolts snug, do not torque, as the hitch must pivot freely.
34. Install jack on front outside of hitch to support the front of hitch for the rest of assembly.
35. Attach h-bracket in orientation shown below with 1 x 229 64 clevis pins , 1.5 x 1.00 x 0.075 machine washers and 316 x 2
cotter pins.
36. Attach level bar tube with 114 x 812 Gr. 8 special thread bolts , rear bolt from left side, front bolt from right side and
secure with 114 top lock nuts.
37. Attach rear of level turnbuckle with 1 x 8 Gr. 8 special thread bolt , front with 1 x 6, Gr. 8 special thread bolt and 1
top lock nuts.
38. Attach two, 134 gang wrenches and one, 2516-115 16 turnbuckle wrench over pegs on back of hitch, secure with 316 w/
cotter/chain .
39. Install the spring hose holder to welded nut on front of hitch with 12 x 1 Gr. 5 bolt , 12 lock washer and flat washer.
40. Align holes in hitch base with holes on front of hitch frame . Align holes of safety chain support in orientation
shown, secure with two, 1 x 8 Gr. 8 special thread bolts , six, 1 flat washers (4 right side, 2 left side), 1 lock washers and
1 nuts.
41. Attach safety chain to bottom side of hitch frame , secure with 78 x 3 hex bolt , 78 flat washer, 78lock washer and 78
nut.
42. Mount manual pack with 14 x 1 hex bolts , mini end wheel press wheels , 14 lock washers and nuts. Tighten all bolts
with lock nuts snug, but do not torque. The rest of the bolts may be tightened to specs, See “Torque Values Chart” on
page 41.
1 2 3
4 1
6
7 8
10 911
12 13
14
15 16
17 118
919
20 121
22 23 24

1800-3000TM Table of Contents Index Assembly
Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 13
U
D
F
B
L
R
4
11
1
7
14
10
22
6
16
21
15
9
19
20
18
17
9
85
Figure 11
Hitch 42958
23
12
3
2
13
8
24

Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 14
1800-3000TM Table of Contents Index Assembly
Wing & Lift Assembly
Refer to Figure 12
43. Attach wing brace to wing frame with 34 x 2 hex
bolts , 34 lock washers and nuts.
44. Attach wing brace and wing frame to center frame
with wing hinge pins , 114 flat washers (rear side of
wing hinge tubes only, do not use washer on wing brace
bar) and 1 lock nuts.
45. Install lh and rh wing wheel arms with 1 x 7 pins , 38
x 214, Gr. 8, special thread hex bolts and 38nylon lock
nut.
Be sure turnbuckle assembly is preset at 45 34” before
installing as shown below. See gang angle adjustment in
“Operator Manual” before going to field.
46. Install wing wheel turnbuckles to front, top hole, of
cylinder mount plate with 1 x 4 hex bolts and 1 lock
nuts.
47. Install rear hole of cylinder mount plate to inside of
plates of wing wheel arms with 1 x 4 hex bolts and
1 lock nuts.
48. Secure front of wing wheel turnbuckles to plate on
wing frame with 1 x 4 hex bolts and 1 lock nuts.
49. Install wing lift cylinders (base end to cylinder mount
plate ) with 1 x 318 pins , 1.5 x 1.0 x.075 machine
washers and 316 x 2 cotter pin.
50. Attach wing stop brackets to plate of wing frame
with 58 x 112 hex bolts , 58 lock washers and nuts.
51. Now the base end of fold cylinders may be hooked up
with the 1 x 318 clevis pin , 1.5 x 1.00 x 0.075 machine
washer and 316 x 2 cotter pin.
52. Do not hook up rod end of fold cylinder until system is
purged of air. See “Purging Hydraulic System” on
page 19.
53. Tighten all bolts with lock nuts snug, but do not torque.
The rest of the bolts may be tightened to specs, See
“Torque Values Chart” on page 41.
1 2
3
1 2
4 5
6 7
8
9
9
10 11
10
611
9
2 11
12
10 13
14 2
15
16
13
16

1800-3000TM Table of Contents Index Assembly
Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 15
U
D
F
B
L
R
11
10
6
11
13
8
7
2
3
14
15
1
4
5
16
13
16
12
11
9
Figure 12
Wing & Lift Assembly 42959
5

Great Plains | 586-536Q-ENG | 03/24/2021 Table of Contents Index 16
1800-3000TM Table of Contents Index Assembly
Wing Transport
 Model 1800 does not use tire/wheel on inside of
wheel arm.
Refer to Figure 13
54. Slide hub/spindle assembly into torque tube and
align holes. Secure with 516 x 312 hex bolts and
516 top lock nut.
55. Attach tire/wheel assembly with 58 lug nuts .
56. Tighten all bolts with lock nuts snug, but do not torque.
The rest of the bolts may be tightened to specs, See
“Torque Values Chart” on page 41.
1
U
D
F
B
L
R
3
4
5
2
Figure 13
Wing Transport
42960
12
3
4 5
