GVM GVM-680RS User manual

GVM-680RS / GVM-880RS

DAFTAR ISI
Product introduction Page 1-------------------------------------------
Disclaimers Page 2--------------------------------------------------------
Precautions Page 2-------------------------------------------------------
Product Detail Page 3~4-------------------------------------------------
Product structure analysis Page 5------------------------------------
Installation method Page 6~8----------------------------------------
Accessories installation method Page 9----------------------------
Description of product control keys Page 10-----------------------
Function introduction and instruction for use ----------------------
------------------------------------------------------------------- Page 11~14
APP control and multiple units control Page 15------------------
Use and preservation Page 16-----------------------------------------
Simple faults and troubleshooting Page 16,17--------------------
Packing list Page 18------------------------------------------------ -------

1
Welcome to use "GVM-680RS / GVM-880RS". This product is specially designed
for senior photographers. The product usage scenarios are suitable for live
broadcast/outdoor/studio photography, etc., and can also be used for YouTube
video shooting. The main features of the product are:
PENGENALAN PRODUK
①
②
Infinitely adjustable RGB color and dual color temperature characteristics,
brightness/color temperature RGB hue/color purity can be controlled at will,
color temperature range 3200K~5600K. The use of high CRI LED lamp beads
helps restore and enrich the color of the object, providing you with natural
and vivid shooting effects.
The APP intelligent control system can be controlled by your smart mobile
device.
③With LCD screen display and stable system, it supports 360° rotation, which
can effectively control light. You can also install folding and soft light boards
to avoid excess light, make the light softer, and customize the control fill
light, allowing you to shoot the desired results easily and easily.
We firmly believe that the correct use of this product will definitely be of great
help to your shooting work. It is strongly recommended that you read the
following user guide carefully before using the product.
④8 kinds of scene lights can be simulated: lightning, police car, candlelight,
TV, broken light bulb, party, disco, paparazzi.

2
1.
CATATAN KESELAMATAN
①Please use the matching power adapter or lithium battery with the same
specification to power the product. Do not use power adapter with different
output voltage parameters.
The product is not waterproof, please use it in rainproof environment.
②
The product is not anti-corrosion, therefore do not let the product touch
any corrosive liquid.
③
When using the product, make sure the product is put firmly and prevent
from falling and damage.
④
If the product will not be used for a long time, please switch off the power
to reduce energy loss.
⑤
CATATAN PENTING
Before using this product, please read the instructions carefully and make sure
use the product correctly. If you don’t obey the instructions and warnings, you
maybe cause harm to yourself and the people around, or even damage the
product and other things around.
2. Once you use this product, you are deemed to have read the disclaimer and warning
carefully, understand and acknowledge all the terms and contents of this statement,
and promise to take full responsibility for the use of this product and possible
consequences.

3
GVM-680RS
SPESIFIKASI PRODUK
Product model : GVM-680RS
Brand : GVM
Product Name : Photography lights
Product Type : Photography Fill Light
Product material : Aluminum alloy
Lamp beads quantity : 560
Color rendering index : ≥97
Color temperature : 3200K~5600K
Hue : RGB 0~360°
SAT : 0%~100%
Brightness : 8500lux/0.5m ; 3000lux/1m
Light adjustment method : Step-less adjustment
Features / Features : RGB, SAT, APP, Joint control, Special light,
High color rendering index light beads, Upgrade LED screen
Power : 50W
Voltage : AC:100-240V
Power supply mode : DC input&Battery
Power supply : DC15V/4A
Battery Capacity : 7.4V-4400mAh*2 ( to be purchased separately)
Product Weight : 1.2 KG
Product Size ( mm ) : 270*318*40
Cooling : Natural heat dissipation
Commodity origin : China. Huizhou

4
GVM-880RS
SPESIFIKASI PRODUK
Product model : GVM-880RS
Brand : GVM
Product Name : Photography lights
Product Type : Photography Fill Light
Product material : Aluminum alloy
Lamp beads quantity : 752
Color rendering index : ≥97
Color temperature : 3200K~5600K
Hue : RGB 0~360°
SAT : 0%~100%
Brightness : 11200lux/0.5m ; 3600lux/1m
Light adjustment method : Step-less adjustment
Features / Features : RGB, SAT, APP, Joint control, Special light,
High color rendering index light beads, Upgrade LED screen
Power : 60W
Voltage : AC:100-240V
Power supply mode : DC input&Battery
Power supply : DC15V/4A
Battery Capacity : 7.4V-4400mAh*2 ( to be purchased separately)
Product Weight : 1.2 KG
Product Size ( mm ) : 270*318*40
Cooling : Natural heat dissipation
Commodity origin : China. Huizhou

5
Cooling hole
Mode button
Compound
knob buttons
Adapter
interface
Battery tank
Brightness
control
Button
Power switch
LED display
screen
Soft light spot
locking mouth
LED lamp beads
Lamp rack interface
Lamp rack interface
Angle fixing knob
Lamp holder fixing knob
U-frame
MO DE
BRR
Battery AdapterOFF
CCT/ HUE / SAT / SCE
BAGIAN PRODUK

6
1The lamp can be installed and fixed on the bracket by rotating the knob
clockwise, and unloaded by rotating in the counterclockwise direction.
CARA PEMASANGAN

7
2Insert the diffuser from the side of the light panel.
Loosen the adjustment knobs on both sides of the U-bracket, adjust
the angle of the panel you need, and then tighten the adjustment
knobs on both sides of the U-bracket.
3

8
Battery
Installation Slot
Adapter Interface
（Battery sold separately）
There are two power supply modes to choose.
① Connect the power cord and adapter for power supply.
②Purchase two other suitable lithium batteries and use them for power
supply.( both battery cells must be plugged in to power )
4

9
CARA PEMASANGAN AKSESORIS
Only some packages include the following accessories, subject to the actual purchase of the package
Light control folding can control the Angle of light.
Align the front mounting holes with the screw holes of the hinges and lock the
latches with screws.
Light control folding :

10
MODE
BRG
CCT / HUE / SAT / SCE
Battery AdapterOFF
1
2
3
56
SC: CH:
Rotate
Slave
Master
APP
O%
K
ms
CCT : HUE :
TIM : SAT :
74
CARA PENGGUNAAN TOMBOL
PADA PRODUK
1
2
3
5
6
4
7
DC15V power input interface
Power switch
Mode control button: Change mode control
Change channel button: When is in master/slave mode, press this button
to select the channel.
Multifunctional button: Press once to switch light mode. Press for 3
seconds to enter/exit the scene mode; Spin the knob to adjust the
parameters of the current light mode.
LED screen: The screen display the current brightness, control mode,
light mode, light parameters, scene number, channel numerical, and
battery power of the light.
Brightness adjustment button: Adjust the brightness

11
The screen display the current brightness, control mode, light mode, light
parameters, scene number, channel numerical, and battery power of the light.
① LED screen：
Press the mode button to change the control mode, such as:
Rotate, slave, master, APP
② Mode types and functions：
SC: CH:
Rotate
Slave
Master
APP
O%
K
ms
CCT : HUE :
TIM : SAT :
Battery power
Scene number
Brightness
Channel value
Control mode
Correlated Color
Temperature/
HUE/Saturation/
Time parameter
(Only display the current
control mode)
(Only the currently adjustable
light mode is displayed)
The light mode
of the current
adjustable
parameters
(Only the currently
adjustable light
mode is displayed)
(lights only when the
light mode is a scene)
CARA PENGGUNAAN MENU
Rotate mode: Adjust the parameters of the light through the controller
behind the light.
Slave mode: The channel can only be adjusted through the ▲ and ▼
buttons of the controller behind the light. When the channels of the slave
and the master are the same, they can be synchronously controlled by
the master.
Slave mode:
Rotate mode:

12
③ Adjust brightness (BRG): range 0%~100%
⑤ Adjust HUE: range 0°~ 360°
④ Adjust color temperature (CCT): range 3200K~5600K
In Master mode / Rotate mode, short press the composite knob to switch
the light mode to HUE, and then turn the composite knob button to adjust
the hue.
In Master mode / Rotate mode, short press the composite knob to switch
the light mode to CCT, and then turn the composite knob button to adjust
the color temperature.
In APP mode, connect to APP and adjust color temperature through APP.
In Master mode / Rotate mode, turn the brightness adjustment knob to
adjust the brightness.
In APP mode, connect to APP and adjust brightness through APP.
Master mode: Adjust the light and channel of the light through the controller
behind the light, and the slaves of the same channel will also be adjusted
synchronously.
APP mode: Adjust the light parameters through APP.APP mode:
Short press the compound knob to switch the light mode, which are: CCT,
HUE, SAT; Long press the compound knob for 3 seconds to enter/exit the
scene mode.
Master mode:
CCT: Adjustable color temperature, range 3200K~5600K
HUE: Adjustable light color, range 0~360°
SAT: Adjustable light color saturation, range 0%~100%
SC: The product can simulate 8 kinds of scene lights: ①Lightning, ②Police
car, ③Candlelight, ④TV, ⑤Bad light bulb, ⑥Party, ⑦Disco, ⑧Paparazzi.
CCT:
HUE:
SAT:
SC:

13
⑥ Adjust SAT: range 0%~100%
⑦ Adjustment scene (SC): range 1~8
⑨ APP control:
Switch the photography light to the APP mode, connect the Bluetooth of the
camera light through the mobile phone, and then use the APP to control the
brightness, color temperature, hue, sat, scene, channel, and on/off of the
camera light. If there is a slave, you can also go through the APP Perform
online control.
In Master mode / Rotate mode, short press the composite knob to switch
the light mode to SAT, and then turn the composite knob button to adjust
the color purity.
In APP mode, connect to APP and adjust SAT through APP.
In APP mode, connect to APP and adjust hue through APP.
In Master mode/Rotate mode, long press for 3 seconds and press the
composite knob to enter/exit scene light (SC) mode. At this time, short
press the composite knob to select scenes, all scenes can be adjusted
by rotating the brightness adjustment knob; the current scene When it is
scene No. ⑤, turn the compound knob to adjust the color temperature;
when the current scene is scene No. ⑥or ⑦, turn the compound knob to
adjust the time. (Other scenes can only adjust the brightness).
⑧ Adjust CH: range 1~12
In Master mode/Slave mode, tap the plus/minus key to set the channel value.
In APP mode, connect to APP and set the channel value through APP.
In the APP mode, connect to the APP and adjust the scene through the APP.

14
⑩ On-line control (Joint control between lamps):
Prepare two or more photography lights, set one to Master mode, and the
others to Slave mode, and set the channel (CH) of the master and slave.
When the master and slave channels are the same, the slave of the same
channel can be synchronously controlled through the controller behind
the master.
Prepare two or more photography lights, set one to APP mode, and connect
the mobile phone APP to set the channel; set the rest to Slave mode, and
set the same channel. When the APP mode machine connected with the
mobile phone APP and the slave machine channel are the same, at this
time, the connected APP mode machine can be controlled through the
mobile phone APP, and the slave machine of the same channel as the APP
mode machine can be synchronously controlled.

15
Scan the QR code on the back of the manual to download the APP
PENGENALAN PRODUK
If there is a slave, the APP will synchronously control the slave of the same
channel as the connected APP mode machine.
Turn on the video light and set the mode to APP mode. Open the “GVM LED”
application software on the phone ( The phone needs to turn on bluetooth and
GPS), then enter the bluetooth's search interface →Find the bluetooth
named “BT_LED” and connect →Wait for connection →After connect
success, it will automatically enter the app's control interface. At this time, the
video light have been connected and you can controll the APP.
You can save 6 custom light effects in “My Scenes”. After setting the light
effect parameters →click the “ ” icon in the right corner →pop up the
“Save Current Scenes” →click “OK”. This light effect can be found in “My
Scenes” at this time.
Color temperature
control interface
RGB control
interface
Scene light
control interface
Save light
effect interface

16
PERAWATAN
Do not put the product in a highly humid, strong electromagnetic field,
direct sunlight, high-temperature environment. If not use the product for a
long time, disconnect the power and take out the battery.
Clean：Before clean, disconnect the power plug. And use wet cloth rather than any
detergent or soluble liquid, avoiding damaging the surface layer.
Repairing：If there is fault or performance degradation, do not unpack the shell by
yourself, avoiding damage the machine and lose the right of maintenance. When there
is a fault, do not hesitate to contact us, and we will do our best to deal with the problem.
Accessories：Please use the accessories provided by manufacturer and approved
ones, in order to maximize the performance.
Guarantee：Do does not modify the product, or you will lose the right of maintenance.
Clean：
Repairing：
Accessories：
Guarantee：
Power：Make sure the power is in the demanded range, not too high or too low. Correctly
load the battery, in order not the damage to machine.
Power：
SIMPIE FAULTS
AND TROUBLESHOOTING
Phenomenon
①
②
Make sure the adapter is well
contacted with the power plug.
Charge the battery before using
it.
Check the product Solution
The switch
indicator
does not light up
Check the matching power
adapter indicator light up
or not.
When using lithium battery,
make sure there's no "low
power" protection.

17
Check if the mode were set as
slave mode, lightness and color
temperature of the products
cannot be controlled in slave
mode.
Pressthe“MODE”button for once,
switch the mode from slave mode
to master mode.
The brightness/
color temperature
knob is out of
control
APP can't
connect
Check if the product is “OFF”
because of the APP of the
mobile phone.
Press the “ON/OFF” button once
again.
The product is in
the "ON" state,
the display and
lights are not on
Check whether the device is
in APP mode and whether
"BT_LED" is displayed on the
APP
Normal steps:
①Switch to APP mode after
turn on;
②Turn on bluetooth and GPS on
the phone
③Open the APP, search and
connect to Bluetooth BT_LED
Check whether the color purity
SAT value is too low or 0; the
color purity value is 100, the
color difference is most obvious.
In RGB mode,
the lamp beads
have no RGB
color.
①
②
In the Master mode / Rotate
mo d e , ligh t l y pres s t h e
compound knob button to
switch to SAT, then turn the
compound knob button to
increase the color purity;
In WIFI mode, connect APP,
adjust color pure SAT
through APP.
Phenomenon Check the product Solution

Photography
lights
GVM-
680RS
1
Power cord
Adapter
Diffuser
Folding
N a m e
Q u a n t i t y
GVM-
680RS
-2L
GVM-
680RS
-3L
N o t e s
Light stand
Carrying Case
2
1 2
1 2
1 2
2 3
Instructions 111
1
111
2 3
3
3
3
3
ISI DALAM PAKET
GVM-
880RS
1
GVM-
880RS
-2L
GVM-
880RS
-3L
2
1 2
1 2
1 2
2 3
111
1
111
2 3
3
3
3
3
18
