Welcome to "GVM-Y30D160 / GVM-Y60D256". This product is specially
designed for senior photography enthusiasts. The product is suitable for
live / outdoor / studio photography, and also for YouTube video shooting.
The main features of the product are:
PENGENALAN PRODUK
①
③
Step-less adjustable dual color temperature feature, color range 3200K ~
5600k, Using LED bulbs, which is helpful to restore and enrich the color of
objects and provide you with natural and vivid shooting effect.
With digital screen display and stable system, which can support 360 °
rotation and effectively control the light Line. You can customize the control
of fill light, so that you can easily shoot the desired results.
We firmly believe that the correct use of this product will definitely help your
shooting work. Before using the product, we strongly recommend that you
carefully read the following user guide.
1.
CATATAN PENTING
Before using this product, please read the instructions carefully and make sure
use the product correctly. If you don’t obey the instructions and warnings, you
maybe cause harm to yourself and the people around, or even damage the
product and other things around.
2. Once you use this product, you are deemed to have read the disclaimer and warning
carefully, understand and acknowledge all the terms and contents of this statement,
and promise to take full responsibility for the use of this product and possible
consequences.
②APP intelligent control system, which can be controlled by your smart mobile
devices.

2
GVM-Y30D160
SPESIFIKASI PRODUK
Brand : GVM
Product Model : GVM-Y30D160
Product Type : Photography Fill Light
Product Name : Photography lights
Function / Feature: APP, Joint control, LED digital display
High color rendering index light beads
Color Rendering Index : ≥97
Color Temperature : 3200K-5600K
Brightness: 2300lux/0.5m ; 800lux/1m
Light Adjustment Method : Stepless adjustment
Lamp Beads Quantity : 160
Product Weight : 2KG
Power : 30W
Product Size(mm) : 328*328*40
Cooling : Natural heat dissipation
Product Material : Aluminum alloy
Voltage : DC15V
Power Supply : DC15V/3A
Power Supply Mode : DC input & Battery
Battery Capacity : NF series battery * 2 (sold separately)
Commodity Origin : Huizhou.China

3
SPESIFIKASI PRODUK
GVM-Y60D256
Brand : GVM
Product Model : GVM-Y60D256
Product Type : Photography Fill Light
Product Name : Photography lights
Function / Feature: APP, Joint control, LED digital display
High color rendering index light beads
Color Rendering Index : ≥97
Color Temperature : 3200K-5600K
Brightness: 5100lux/0.5m ; 1750lux/1m
Light Adjustment Method : Stepless adjustment
Lamp Beads Quantity : 256
Product Weight : 2.7KG
Power : 60W
Product Size(mm) : 430*418*40
Cooling : Natural heat dissipation
Product Material : Aluminum alloy
Voltage : DC15V
Power Supply : DC15V/4A
Power Supply Mode : DC input & Battery
Battery Capacity : NF series battery * 2 (sold separately)
Commodity Origin : Huizhou. China

00K
SLAVE
%P
MODE/RESET
CCT
MIN MAX
BRT
MIN MAX
Battery AdapterOFF
1
C
D
5
V
4
U-frame
Lamp rack interface
Angle fixing knob
Lamp holder fixing knob
Lamp rack interface
BAGIAN PRODUK
WIFI reset /
Mode button
Brightness
adjustment knob
Adapter interface
Battery tank
Color temperature
adjustment knob
Indicator light
Power interface
Electronic display
Integrated
control channel
Select button

5
1The lamp can be installed and fixed on the bracket by rotating the knob
clockwise, and unloaded by rotating in the counterclockwise direction.
CARA PEMASANGAN
Loosen the adjustment knobs on both sides of the U-bracket, adjust
the angle of the panel you need, and then tighten the adjustment
knobs on both sides of the U-bracket.
3

3
6
Battery
installation slot
Adapter interface
（battery lead）
There are two power supply modes to choose.
① connect the power cord and adapter for power supply.
②purchase two other suitable lithium batteries and use them for power
supply.
00K
SLAVE
%P
MODE/RESET
CCT
MIN MAX
BRT
MIN MAX
Battery AdapterOFF
1
C
D
5
V
( both battery cells must be plugged in to power )

1
2
3
5
6
4
7
8 9
7
1
2
3
5
6
4
7
8
9
DC15V power input interface
Power switch
Mode button/WIFI reset button: Modes include master mode and slave
mode; WIFI username and password reset button
Channel addition and subtraction key: adjust channel（ 0~11 ）
Brightness indicator: when adjust the brightness knob, the indicator
is on
Color temperature indicator: when adjust the color temperature knob,
the indicator is on
Nixie tube: show value including lightness, color temperature and
channel
Color temperature adjustment button: adjust the color ( 3200K~5600K )
Brightness adjustment button: adjust the brightness（ 10%~99% ）
Note: indicator ⑤ and indicator ⑥ will be on simultaneously when in slave mode
CARA PENGGUNAAN TOMBOL
PADA PRODUK
00K
SLAVE
%P
MODE/RESET
CCT
MIN MAX
BRT
MIN MAX
Battery AdapterOFF
1
C
D
5
V
