GVM GVM-PRO-YU600C User manual

GVM-PRO-YU600C
V0

CONTENTS
Important Safety Instructions ---------------------------------------------- Page 1~2
Product introduction ---------------------------------------------------------- Page 3
Warning ------------------------------------------------------------------------ Page 3
Disclaimers -------------------------------------------------------------------- Page 4
Product parameter ------------------------------------------------------------ Page 4
Product structure analysis ---------------------------------------------------- Page 5
Installation method -------------------------------------------------------- Page 6~8
Description of product control keys ------------------------------------------ Page 9
Function introduction & instructions for use --------------------------- Page 10~12
APP control -------------------------------------------------------------- Page 12~13
Quick troubleshooting ------------------------------------------------------- Page 14
Precautions ------------------------------------------------------------------- Page 14
Use and preservation -------------------------------------------------------- Page 15
Packing list ------------------------------------------------------------------- Page 15
Product Warranty -------------------------------------------------------- Page 16~17

1
IMPORTANT SAFETY INSTRUCTIONS
First and foremost: this product lighting and staging equipment and is professional
should be used by a professional lighting technician or under the guidance of a
professional. When using this product, you must always follow the cautions below:
1．Read the product manual carefully before use.
2．This product is only suitable to use in a temperature range of -20℃ to 45℃.
3．Do not place the equipment near flammable and volatile solvents such as alcohol
and gasoline.
4．Before storing the device, make sure it has cooled down completely. When being
stored, unplug the power cord from the device. The equipment should be stored in
its carrying case or a well-ventilated and dry place.
5．This lighting fixture is not for general illumination and should not be used as such.
Individuals with eye injuries or sensitivity should avoid using this lighting fixture.
6．This is a professional light and children are prohibited from using it. Parents or
guardians must closely supervise children when they are near the equipment to
prevent personal injury caused by colliding with or misusing the equipment.
7．Before using the equipment, please remove the protective cover.
8．When the lighting fixture is on, it is forbidden to stare directly at the light source
under any circumstances. High-intensity lighting should only be used under the
guidance of a professional lighting technician. Avoid staying in a high-intensity light
environment for a long time. If feeling any discomfort, please immediately turn off
the lighting fixture, and seek medical attention.
9．When the lighting fixture is on, use it carefully and avoid contacting high-
temperature components such as LED light sources to prevent being burnt.
10.Do not use damaged equipment or accessories. Wait for a professional repairman to
inspect and repair it before it is confirmed that the equipment can function normally.
11.If the light source is damaged or deformed due to heat, please stop using it and
contact the manufacturer, service agents, or qualified repairman promptly to replace
the light source to avoid accidents.
12.If the product is cracked due to falling, squeezing, or strong impact during use,
please stop use it to avoid being electrically shocked by touching internal electronic
components.
13.Do not disassemble the product by yourself. If the product malfunctions, it must be
checked and repaired by the manufacturer or authorized repair personnel.
14.Before cleaning and maintenance, be sure to unplug the power To unplug supply.
never pull on the cable but always pull the plug itself. This device shall only operate
with earthed power outlets or emergency power generators.

2
15.When cleaning the device, do not wipe it with a wet cloth. Use a dry and soft cloth to
wipe off the dirt.
16.If an extension cord is required, it needs to have the necessary capacity to power the
respective unit. Using an extension cord with a lower current capacity than the
devices need may cause overheating.
17.For some products with long power cords, please place the power cords properly
and avoid contact with overheated surfaces that may damage or trip personnel.
Please use the original power cords of our manufactory. The damage caused by
using non-original power cords is not covered by our repair service.
18.Do not use product accessories that are not recommended by our brand to avoid
fire, electric shock, or personal injury.
19.Some products use batteries for power supply. Do not use any batteries, power
sources, or accessories that are not specified in the user manual. Please keep
batteries and other accessories out of reach of children and infants. If a child or
infant swallows a battery or accessory, seek medical attention immediately. If the
battery leaks, changes color, deforms, smokes, or emits an odor, remove it
immediately. Be careful not to get burned during the removal. Continued use of
such batteries may cause a fire, electric shock, or skin burns. Do not use any
deformed or modified batteries. Do not disassemble or modify this product or the
battery. Do not heat the battery or solder it. Do not let the battery come into contact
with fire or water, or subject it to strong external force. Do not insert the battery's
positive and negative ends incorrectly, or mix and use old and new batteries or
different types of batteries.
20.For some products with built-in lithium batteries, please use a dedicated charger for
charging, and following the correct operating instructions within the prescribed
voltage and temperature range.
21.The warranty last for one year. Consumables like batteries, adapters, power cords,
and other accessories are not covered by the warranty.
22.The one-year warranty will be invalidated if the equipment is found to have been
repaired privately. The related repair costs will be charged.
23.Equipment malfunctions caused by non-standard operations are not covered by the
warranty.
24.The safety instructions are based on our factory's strict testing. If there are any
changes in the equipment's design and specifications, we reserve the right not to
notify you. Customers can visit our official website to check the latest digital version
of the instructions and learn about the newest product information.
Keep these instructions!

3
PRODUCT INTRODUCTION
Welcome to use " GVM-PRO-YU600C”, this product is specially designed for senior
photography enthusiasts. The product is suitable for live streaming / outdoor /
studio photography, and also for YouTube video shooting.
The main features of the product are:
1．APP control, which can be controlled by your iOS and Android smart mobile
devices; At the same time, it supports Bluetooth Mesh networking, and can be
controlled in groups with GVM brand devices that support Mesh networking.
2．With standard DMX interface, low precision 8bit and high precision 16bit DMX
control and mode can be realized.
3．Has 6 lighting modes : CCT, HSI, RGB, GEL color paper, light source matching, and
field light effect.
We believe that once using our product correctly, you can make huge progress
when shooting. Before using the product, you are strongly recommended to read
the instructions below carefully.
WARNING:
High-power LED lights are strictly prohibited from being directly viewed or shining
into other people's eyes.
Do not unplug the power cord or connecting wires while the light is on to avoid
personal injury.
Do not cover the heat dissipation port when the lamp is in operation.
Keep children away from touching or using this light.
As professional lighting equipment, please make sure to operate it correctly
according to the user manual.

4
DISCLAIMERS
1. Before using this product, please read the text carefully to ensure that the correct
operation of the product carried out. to follow and not following the is Failure
instructions and warnings in this document may cause damage to the product or
other surrounding items, or even harm you and others around you.
2. By using this product, you are deemed to have carefully read the disclaimer and
warning, understand and agree all the terms and contents of this statement, to
and promise to take full responsibility for the use of this product and the possible
consequences.
3. Design and specifications are subject to change without notice.
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
PRODUCT PARAMETER
Brand: GVM
Product odel: GVM-PRO-YU600CM
Product Name: Photography light
Product ype: Photography fill lightT
Features: Multi-scene mode / High-display finger light beads
Control Method: Panel Control / APP(Bluetooth connection) / Bluetooth MESH
networking / Wireless remote control / DMX
Light Adjustment Method: Stepless adjustment
Color Rendering index : ≥97
Color Temperature: 2000K~10000K
Illuminance: [email protected]，16000lux@1m
Power: 600W
Product Weightt: 15KG
Product Size (mm): 820×523×165
Lamp Beads Quantity: 3120 lamp beads
Power upply ode: AC input & Electric box power supplyS M
Voltage: 100V~240V
Cooling: Radiator and an coolingf
Product aterial: Aluminum alloy / ngineering plasticM E
Commodity rigin: ChinaO , Huizhou

5
ON/OFF
COOL
BACKMODE
MENU
INT/SELECTOR/R CCT/HUE/G SAT/GM/B
ON
OFF DMX-IN DMX-OUT
PUSH
1+ 2-
Display
MODE
MENU
Multifunctional coding
knob①: INT/SELECTOR/R
Multifunctional coding
knob②: CCT/HUE/G
Multifunctional coding
knob③: SAT/GM/B
AC input
DC input
DMX input interface
DMX output interface
ON/OFF
ON/OFF/COOL Key
BACK
Accessory lock
Locking screw handle
Harness storage rope
U Shaped bracket
Light stand fixing
knob
PRODUCT STRUCTURE DIAGRAM

6
1
INSTALLATION METHOD
Loosen the light stand fixing knob, install the light to the light stand as shown
below, and then tighten the light stand fixing knob.
2Loosen the locking screw handle, adjust the angle of the light, and then turn the
locking screw handle tightly.

7
DC/Battery powered
interface (①+/②-)
AC power cord connector
3Connect the AC power cord for the power supply.
4The DC battery cable is connected to the power supply.

8
5
6
7
The installation steps of the
barn door are shown on the
right.
The installation steps of the
Honeycomb Grid are shown
on the right.
The installation steps of the
softbox are shown on the
right.

9
4
5
6
8
1
7
2
Display: Displays current settings, modes, and parameters.
MODE: Lighting mode switch button.
MENU: Press this key to enter the settings menu.
BACK: Press this key to return to the previous menu.
ON/OFF/COOL KEY: When the light is off, long press to turn on the light; when
the light is on, long press to turn off the light, and activate the large air volume
to dissipate heat until the temperature is lowered to a touchable temperature.
Knob ①: INT/SELECTOR/R, multi-functional code knob, by pressing or rotating
can be "selected" or "brightness/red" adjustment.
knob ②: CCT/HUE/G，Multifunctional coding knob, can be adjusted by rotating
“color temperature/hue/green".
3knob ③: SAT/GM/B, Multifunctional coding knob, can be adjusted by turning
“Saturation/Green Shift/Blue".
DESCRIPTION OF PRODUCT
CONTROL KEYS
4
5
6
2
8
1
7
3

10
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
FUNCTION INTRODUCTION &
INSTRUCTIONS FOR USE
① MENU ：
Press the MENU button to enter the menu settings page. Menu interface contains
DMX settings, dimming curve, wireless settings, studio mode settings, frequency
settings, fan settings, language, and system settings.The menu interface contains
DMX settings, dimming curve, wireless settings, studio mode settings, frequency
settings, fan settings, language, and system settings.
Press the MENU button to enter the menu setting page → Rotate [Knob①] select
project → Press [Knob①] Enter the project settings interface → Press or rotate
[Knob①] set the parameters of the project → Press [BACK] Return to the previous
menu.
DMX SETTINGS (Figure1): SETTINGS DMX
parameter, [ADDRESS (001-512)] and
[PROFILES MODE (8bit/16bit)], and 14
built-in DMX models: 1.CCT&RGB, 2.CCT
&HSI, 3.CCT, 4.RGB, 5.HSI, 6.SOURCE,
7.GEL, 8.FX, 9.ZONE CCT&RGB, 10.ZONE
CCR&HSI, 11.ZONE CCT, 12.ZONE RGB,
13.ZONE HSI, 14.Ultimate.
DIM CURVE (Figure2): Set DIM CURVE, [Linear,
Log, Exponential, S curve].
BT SETTINGS (Figure3): RF Channel Settings,
bluetooth switch, BT Reset.
STUDIO Mode (Figure4): Setting up studio
mode and non-studio mode.
Studio mode: turn on the light again after
power failure, and the light will be turned
on directly;
Non-studio mode: To restart the light after
power failure, you need to press the
ON/OFF button to turn it on.
FREQUENCY SETTINGS (Figure5): SETTINGS
Dimming Frequency, Frequency range:
18KHz-22KHz.

FAN SETTINGS (Figure6): Set the cooling
fan mode.
LANGUAGE (Figure7) : Set system language.
SYSTEM SETTINGS (Figure8) : View system
information and restore factory settings.
11
Figure 6
Figure 8
Figure 7
② MODE ：
6 lighting modes : CCT, HSI, RGB, GEL color paper, light source
matching, and field light effect.
Press the [MODE] button to enter the mode selection main page
→ rotate [Knob 1] to select the mode → press [Knob 1] to enter
the corresponding mode interface → Set the parameter of the
project by pressing or rotating [Knob 1] → press [BACK] Back to
previous.
CCT MODE : White light mode with adjustable light intensity and
color temperature.
[Knob1] Adjust INT, [Knob2] Adjust CCT, [Knob3] Adjust G/M.
HSI MODE : Color light mode, adjustable hue, saturation, light
intensity(HSI=hue, saturation, light intensity), 36 million adjustable
colors.
[Knob 1] Adjust INT, [Knob 2] Adjust HUE, [Knob 3] Adjust SAT.
RGB MODE : Color light mode, adjustable red light, green light,
10
blue light, to achieve 1.6X10 adjustable colors.
[Knob 1] Adjust overall INT, Press [Knob 1] Button, Switch to RGB
adjustment, [Knob 1] Adjust the brightness of the red light,
[Knob2] Adjust the brightness of the green light, [Knob 2] Adjust
the brightness of blue light.

12
APP download method
Register Account
Figure 1
APP CONTROL
(Scan the QR code on the back of the manual to download the APP)
Android version : Official website QR code, Google Play,
Huawei Store, etc.
iOS version : App Store
Register and sign in with your email address. (Figure 1)
There may be a delay in sending the verification code, and
the delivery speed depends on the email server you are
using.
Some email servers may recognize our verification emails as
advertising Please check your blocked email inbox.
GEL color paper mode : There are two color paper types, ROSCO and LEE, and each
of the two color papers has 30 color swatches.
Rotate and short press [Select ] key to select GEL mode, select
3200K or 5600K color temperature (CCT), and select the
corresponding color paper of Rosco or LEE brand to output the
desired light.
Source MODE (Source): There are 12 different types of light
sources to choose from, which can save a lot of adjustment
time when you need a specific light source.
Rotate and short press [Select] key to select Source mode,
choose the desired light source effect.
Light Effect Mode : This mode provides 20 light effects:
lightning, color temperature cycle, wax candle, bad bulb, TV,
paparazzi, explosion, breathing light, disco, police car light,
party party, hue cycle, fireworks, fire truck, ambulance, distress
signal, color switch, color color replacement, color shift, color
gradient.
Rotate and short press [Select] key to select FX mode.

13
Equipment management
① After successfully adding your
lighting device, your device will be
displayed in the "My Devices" list;
(Figure 3)
② Click the device bar to enter the
device control. (Figure 4)
Figure 3
Figure 4
Adding Devices Figure 2
① Before adding devices, please make sure you have turned
on the Bluetooth and network data function of your
phone, and reset the Bluetooth of your lighting device.
② Click the "Add Device" button on the "My Devices" page to
find the nearby Bluetooth lighting devices that have been
opened, and select the device to be connected to the
network. (Figure 2)
* Android devices need to open the location permission to
connect the device with Mesh technology, we will not
collect any of your location information in this process.

14
Phenomenon Check the product Solution
The light is not on
after turning on
After the APP enters
to add a device, the
Bluetooth of the
device cannot be
searched.
The APP fails to
connect the device
to the network
confifiguration of
the device.
The device cannot
be searched after
being removed
from the APP.
The device in the
APP cannot be
clicked to enter the
control
1．When the AC power supply is used,
check whether the AC port is properly
connected to the power supply.
2．Check whether the DC port is properly
connected to the power supply box
when the power box supplies power.
Check whether the device is turned on
normally and whether it has been
bound by others.
Check whether the device is turned on
normally and whether it has been
connected and bound by others; check
the Bluetooth of the mobile phone and
whether the network is in good
condition.
Whether to remove the device when the
device is offline or in poor network
conditions.
Check if the device is online (a small
green dot is displayed); if it is offline,
follow the steps of the network
connection failure step to check.
Ensure that the AC power cable
connector is in good contact.
Make sure the DC cable plugs are in
good contact.
Normal steps:
1．Turn on the Bluetooth and
network data functions of the
mobile phone, the Android
system needs to Enable location
permissions;
2．Reset device Bluetooth.
Retry the connection after resetting
the device Bluetooth and restarting
the APP.
After resetting the device's Bluetooth,
search again to add the device.
Restart the device, wait for 5
seconds, it can be controlled when it
is displayed as online; reset the
device's Bluetooth, and add the
device to the device list again.
QUICK TROUBLESHOOTING
PRECAUTIONS
1．The product is not waterproof, it needs to be protected against wet conditions
condensation, dripping and splashing water, air humidity;
2．The product is not anti-corrosion, do not let the product get into contact with any
corrosive liquid;
3．When the product is in use, ensure that the product is placed firmly to prevent it
from falling and being damaged;
4．When the product is not used for a long time, please turn off the power of the
product to save energy consumption;

15
Photography Lights 1
AC POWER CABLE
Barn Door
Name Quantity Notes
Honeycomb Grid
1
Carrying Case 1
Softbox
DMX CABLE
Manual 1
1
Need to be purchased separately
Need to be purchased separately
Need to be purchased separately
PACKING LIST
USE AND PRESERVATION
Do not place the product in a high humidity, strong electromagnetic direct field,
sunlight, or high-temperature environment. If the product will not be used for a long
time, please disconnect power and remove the battery. its
Clean: Before cleaning, disconnect the power plug. And use a damp cloth instead of
any detergent or soluble liquids to avoid damaging the surface layer.
Power: Make sure the power is within the demanded range, not too high or too low.
Correctly load the battery, in order not damage to the machine.
Repairing: If there is a fault or performance degradation, do not unpack the shell by
yourself, avoiding damage to the machine and losing the right of maintenance. When
there is a fault, do not hesitate to contact us, and we will do our best to deal with the
problem.
Accessories: Please use the accessories provided by the manufacturer and approved
ones, to maximize the performance.
Warranty: Do not modify the product, or you will lose the right to maintenance.

16
Dear user, this warranty card is an important proof for applying for warranty service. Please
cooperate with the salesperson to fill it out and keep it properly. Thank you!
Product
Information
User
Information
Note: this form should be confirmed by the salesperson's stamp.
Applicable Products
This document applies to the products listed in the relevant "Product Warranty Information" (see
instructions below). Other products or components that do not fall within this scope (such as
promotional products, gift items, and other components added after the factory) are not covered
by this warranty promise.
Warranty Period
The corresponding warranty period for products and components shall be executed according to
the relevant "Product Warranty Information". The warranty period starts from the first day of
purchase of the product, and the date of registration on the warranty card at the time of purchase
shall prevail.
Seller
Information
Remarks
Model Number Product Barcode
Name Contact Number
Mailing Address
Name
Contact Number
Mailing Address
Sales Date
PRODUCT WARRANTY

17
How to Obtain Warranty Service
You can directly contact the product salesperson or authorized service agency, or call GVM's after-
sales service hotline to contact us and have our service personnel arrange service for you. When
applying for warranty service, you should provide a valid warranty card as a warranty certificate to
be eligible for warranty service. If you cannot provide a valid warranty card, we may also provide
you with warranty service under the circumstance that our products or components are confirmed
to be within the warranty scope, but this is not our obligation.
Cases where warranty does not apply:
If the product meets the following conditions, the warranty and service under this document will not
apply:
1．The product or parts have exceeded the corresponding warranty period.
2．Malfunctions or damages caused by incorrect or improper use, maintenance, or storage, such as
improper handling, use for purposes other than the reasonable expectations of the product,
incorrect insertion or removal of external devices, falling or crushing due to external force, or
exposure to inappropriate temperature, solvents, acids, alkalis, water immersion, or damp
environments.
3．Malfunctions or damages caused by unauthorized installation, repair, modification, addition, or
disassembly by institutions or personnel not authorized by GVM.
4．Modifications, changes, or removals of the original identification information of the product or its
parts.
5．Lack of valid warranty card.
6．Malfunctions or damages caused by the use of unauthorized, non-standard or non-publicly
released software.
7．Malfunctions or damages caused by force majeure or accidents;
8．Other malfunctions or damages not caused by quality issues of the product itself. In such cases,
you should seek solutions from the relevant responsible parties, and GVM will not be held liable.
Malfunctions or damages caused by components, accessories, or software not covered by the
warranty or beyond the warranty scope that render the product unable to function properly are
not covered by the warranty. Fading, wear, and consumption that is normal during the product
usage process are not covered by the warranty.
Product Warranty and Service Support Information
Product
Category
Component
Other
Optional Maintenance
Period(Month) Warranty Service Type
Circuit Board 12 Month Customer service repair
Imaging lens, softbox, adapter, power
cord, battery Handle, light stand, battery
holder, battery, Fresnel lens, grid, belt,
etc. Consumable or electrically sensitive
parts are not covered by the warranty.
None No Warranty
The product warranty period and service types are implemented according to the following "Product
Warranty Information" for each product category, component, and optional equipment:

20
Facebook
GVM Official website Download APP
Web: www.gvmled.com
B&H Email: [email protected]
GVM Email: [email protected]
Amazon Email: [email protected]
Warehouse Address: 12285 MCNULTY RD, STE 105 PHILADELPHIA, Pennsylvania 19154, USA
Huizhou City Latu Photographic Equipment Co., Ltd.
