GVS S Series User manual

Indoor Monitor
S Series Digital System Indoor Monitor
User Manual_V1.0
Model No.: SI701
User Manual

Contents
Chapter 1 Function Review ..........................................................................................1
Chapter 2 Product Introduction ...................................................................................2
2.2 Product Dimension ............................................................................................ 3
2.3 Interface Introduction ......................................................................................... 3
2.4 Parameter .......................................................................................................... 4
2.5 Installation height ...............................................................................................5
Chapter 3 Basic Function .............................................................................................7
3.1 Standby Interface ...............................................................................................7
3.2 Call ...................................................................................................................10
3.3 Video Surveillance ........................................................................................... 16
3.4 Voice Message ................................................................................................ 18
3.5 Smart Home .....................................................................................................19
Chapter 4 System Setting .......................................................................................... 26
4.1 Display Setting .................................................................................................26
4.2 Volume Setting .................................................................................................27
4.3 Time Setting .....................................................................................................27
4.4 Language Setting .............................................................................................28
4.5 Do Not Disturb ................................................................................................. 29
4.6 Wi-Fi Setting .................................................................................................... 30
4.7 Cloud Intercom Setting .................................................................................... 30
4.8 Password Setting .............................................................................................31
4.9 About ................................................................................................................32
4.10 Configuration ................................................................................................. 33

1
Chapter 1 Function Review
This product based on SIP protocol, is the main device for the S series video door
phone system, it supports video phone, unlocking, monitoring. Details of the device are
as follows:
7” capacitive touch screen
Support custom wallpaper and screensaver
Support real time surveillance to outdoor/villa station, IP camera
Support multi - indoor monitor in one apartment
Support the blacklist and whitelist function to intercept unfamiliar call
New missed call assistant function,support automatically answer calls from
visitors, play local recording, and record voice messages from visitors
Support RS485 smart home
Support video chat between residents and visitors/guard unit
Support voice intercom between residents in the same community and other
indoor monitors in the same flat

2
Chapter 2 Product Introduction
2.1 Product Appearance
MIC
Touch Screen
Speaker

3
2.2 Product Dimension
2.3 Interface Introduction
Number①
+12V、GND: defense area detector power terminal (current≤200mA);
DB、DA: RS485 interface;
Alarm: alarm output interface(reserved);
Z8: doorbell function as default;
Z7 to Z1: standard defense area interface, support normal open/close security module.
①②③

4
Number②
External power input: DC 24 V.
Number③
Network Port (support standard 48V PoE Switch, power with1、2/3、6).
2.4 Parameter
Working Voltage: DC 24V
Device Quiescent Current: ≤ 80 mA
Device Working Current: ≤ 200 mA
Screen Size: 7 inch
Resolution: 1024 × 600
Appearance Dimension (L × W × D): 182 × 119 × 15mm
Environment Temp.: -10℃~ +45℃
NOTE: The installation bracket of indoor monitor is not align to the middle
of the device rear interface.

5
2.5 Installation height
Suggestion Installation Height: 1.5m
Ground

6
2.6 Installation Instruction
Wall
BOX
86x86mm
Screw
Bracket
Step 1: Aim the bracket screws to the
holes on the 86*86 installation box
and fasten the bracket.
Step 2: Wire the indoor station, then
aim the bracket at the bracket holes
on the back of the indoor station (as
of ②), when all four holes are aimed,
lightly push down the monitor
vertically (as of ③), thereupon you
will hear a slight crack sound, the
device is then properly installed (as of
④).
②
③
④
①

7
Chapter 3 Basic Function
3.1 Standby Interface
Standby Interface
Top Contacts
Press to check and call the top contracts that have been added.
Resident List
Press to call all contacts in the resident list and check the details of each
contact.
Dialing Keypad
Press to dial on the keypad, call Indoor Monitor, Outdoor Station and Guard
Unit.
Call Record
Press to check, read, delete call history among Indoor Monitor, Outdoor
Station and Guard Unit.
Monitor
Press to monitor Outdoor/Villa Station, Gate Station, IP camera.

8
Monitoring Record
Press to check, read, delete video surveillance history among Indoor Monitor,
Outdoor Station and Guard Unit.
Do Not Disturb
Press to turn on the DND function and mute the ringing tone.
Setting
Press to enter Setting page.
Sidebar
Standby Interface
Press to enter standby interface, select the corresponding icon to go to the
function page.
Call
Press to enter call page, set top contacts, resident list, call record, black/white
list, and contacts.
Monitor
Press to monitor outdoor/villa station, Gate Station, IP camera.
Message
Press to enter message setting, view and delete visitors and local messages,
and enable the missed call assistant function.
Setting
Press to enter Setting page.

9
Device Configuration
Community
1. Power on to select a language and configure the network (disable auto
configuration).
2. Create a smart cloud intercom APP account, bind to the created community, scan the
cloud intercom binding QR code on the device, and bind the device to the community.
Villa
1. Power on to select a language and configure the network (enable auto
configuration).
2. Create smart cloud intercom APP account, click "Add" in the upper left corner of the
APP standby interface, select create house, build your own house.
3. Scan the cloud intercom binding QR code on the device and bind the device to the
created house.

10
3.2 Call
3.2.1 Top Contacts
Top Contacts Interface
In the resident list, press to enter the details page of a contact, and press to add
the contact to top contacts for short calling.
3.2.2 Resident List
The resident list displays the networked devices discovered after automatic
configuration is enabled, the devices imported from the resident list, and the devices
manually added.
Resident List Interface

11
Indicates the online devices on the same network segment discovered by the
device；
Indicates that the devices on the same network segment discovered by the
device are currently offline；
Indicates the device delivered from the resident list and the device manually
added by the user, that is, the local device；
Press to enter the contact details interface, which displays information about the
current contact, such as the device name, IP address, local SIP account, SIP account 1,
and SIP account 2.
Contact Details Interface
Press to add the current contact to top contacts.
Press to add the current contact to black list.
Press to add the current contact to white list.

12
3.2.3 Dialing Keypad
Dialing Keypad Interface
Enter the user name of the SIP account corresponding to the device to dial to the device.
For example, if you enter 000100011 for the SIP account sip:
000100011@192.168.150.100:8060, the dial is connected.
3.2.4 Call Record
Call Record Interface
The call records between other devices and the local device are displayed. Unread call
records are displayed with a red dot. Call record for which a photo has been taken have
a photo icon.

13
3.2.5 Contact Setting
Support editing, adding, and deleting contacts or groups in the resident list.
Contact Setting Interface
Support editing remark, ringtone, and DTMF password for automatically discovering
and delivering contacts from the resident list.
Edit Contact Interface
To add a contact, need to enter contact remark, SIP account, select a affiliated group,
and select ringtone. (If the device has the access control function, you also need to
enter the DTMF unlocking password corresponding to the device).

14
Add Contact Interface
To add a group, need to enter the group name and select the affiliated group (if do not
select a group, need to create a group).
Add Group Interface
Support deleting manually added devices and groups, as well as devices discovered in
auto configuration mode (offline).
3.2.6 Black/White List
Select Not turned on, Enable Blacklist, and Enable Whitelist.

15
Black/White List Interface
After the blacklist is enabled, support adding contacts from the call record or resident list.
The blacklisted contact cannot make calls to the local device.
Black List Interface
After the whitelist is enabled, support adding contacts from the resident list. Only
whitelisted contacts can make calls to the device.

16
White List Interface
3.3 Video Surveillance
3.3.1 Video Surveillance interface
enter the video surveillance interface, select the device that you want to monitor in the
device list on the right. Press start monitoring, press on the upper right corner
to get full interface monitoring.
Video Surveillance Interface

17
3.3.2 Monitoring Record
A snapshot taken during monitoring generates a monitoring record.
Monitoring Record Interface
3.3.3 Monitoring Setting
Monitoring Settings support checking all monitored URL address.
Add new device：enter the device name and URL.
Add New Device Interface
