GVS T Series User manual

OUTDOOR STATION
T-Series 2-Wire Wall Mounted Outdoor Station
User Manual_V1.0
T-OS18
User Manual

1
CONTENTS
Chapter 1 Function Overview ..............................................................................2
1.1 Functional features ........................................................................................ 2
1.2 Specifications ................................................................................................. 2
Chapter 2 Product Introduction .......................................................................... 3
2.1 Appearance ..................................................................................................... 3
2.2 Dimension .........................................................................................................4
2.3 Interface Introduction ..................................................................................... 5
Chapter 3 Installation ............................................................................................6
3.1 Installation Height .......................................................................................... 6
3.2 Installation Steps .............................................................................................7
3.3 Unlocking Wiring ............................................................................................ 7
Chapter 4 Operation Instructions .......................................................................9
4.1 Calling Resident ..............................................................................................9
4.2 Unlock .............................................................................................................. 9
1) Unlock by Indoor Monitor ................................................................................9
2) Unlock by IC Card ............................................................................................9
3) Unlock by external push button ..................................................................... 9
4) Unlock by APP ................................................................................................. 9
4.3 Two Door Locks ..............................................................................................10

2
Chapter 1 Function Overview
This product is an Outdoor Station in 2-wire analog video door phone system. Two core
wire is adopted to connect into the system, which enable visual intercom with the Indoor
Monitor. It supports IC card control.
1.1 Features
Support video intercom with HD, unlocking, remote call to Tuya APP, real-time
video intercom and unlocking
Support for opening two locks
Support IC card
Support real-time monitoring, human detection recording and alarm to Tuya APP,
easy to view in real time at any time on the APP
Low light for color display at night
1.2 Specifications
Working parameters
Working Voltage: DC 15~24V
Static Current: ≤ 160mA (DC 30V)
Working Temperature: -25℃~55℃
Working Current: ≤ 220mA (DC 24V)
Storage Temperature: -40℃~70℃
Dimension(H/W/D):: 168 x 86 x 33.5mm
Camera
Type: CMOS
Pixels: 2.0 MP
View Angle: 110°
Fill-in Light Type: white light

3
Chapter 2 Product Introduction
2.1 Appearance
Speaker

4
2.2 Dimension
Unit: mm

5
2.3 Interface Introduction
Interface Introduction:
BUS-A, BUS-B: Bus interface; (no polarity)
NO, COM, NC: normally open, common interface, normally closed; (dry contact)
LOCK+ : Electronically controlled lock unlocking; (DC12V)
GND: Ground wire
SW1: Unlock at inside door by electric locking.
BUS-A BUS-B NC COM NO LOCK+ GND SW1

6
Chapter 3 Installation
3.1 Installation Height
Suggested Installation Height: camera is 1.6m above the ground

7
3.2 Installation Steps
Step 1: Drill holes in the wall to fix the expansion nails to the wall, refer to the size of the
holes in the picture below (149.5 x 64.5), wire the device and fix it to the wall with 4
self-tapping screws.
Step 2: Fix the card paper with content
to the card window. Make the wire
connections according to the wiring
diagram.
Step 3: Assemble the aluminums panel
on Outdoor Station, using plum screws
to secure it in the position shown.

8
3.3 Unlocking Wiring
Signal unlock wiring
12V electric lock wiring (12V electric lock)
Normally open lock wiring(relay lock)
Exit button unlock wiring
Note] Power cannot be supplied from Outdoor Station.
[Note] This wiring has no polarity.
[Note] This wiring has no polarity.
Power

9
Chapter 4 Operation Instructions
4.1 Calling Resident
By short pressing Call button on the device, visitor starts calling Indoor Monitor. If there
is no answer within 30 seconds, the call will be ended. At the same time, you can call
the mobile phone app and connect to the Indoor Monitor to make a video call. After
receiving unlock signal from Indoor Monitor, the door lock will be opened. When mobile
phone APP answers, the mobile phone can make a real-time video call and unlock the
door, at which point the Indoor Monitor stops ringing and turns off the display.
4.2 Unlock
1) Unlock by Indoor Monitor
Door can be unlocked from Indoor Monitor when it’s communicating with Outdoor
Station or under surveillance mode. Indoor Monitor can choose to unlock door 1 or 2.
2) Unlock by IC Card
The resident can unlock the door by holding the registered access card close to the card
swiping area on the device, by default the door lock 1 will be unlocked.
3) Unlock by external push button
As there is an interface for integration of external push buttons, when this is connected,
a normal push button can be used to unlock the door. Exit button unlocks door lock 1 by
default.
4) Unlock by APP
Unlocked by the Tuya APP on your mobile phone.

10
4.3 Two Door Locks
Outdoor Station supports two door locks, i.e a 12V electric lock and a relay signal lock.
