Gyrocopters Whiz User manual
Whiz
N.W
AlF
5-GH
Riding preparation
Read this instruction carefully to know the product performance and requests.
1.Check the tire pressure: Whether the pressure is sufficient. In case of insufficient tire pressure, the tire requires
to be inflated to the normal state; Whether the tire lace is overly worn, or the tire surface is overly damaged or
cracked, the new tire should be replaced immediately to the relevant maintenance place to prevent the vehicle
from skidding on the wet or smooth road.
2.Check the circuit system: Battery power should be always sufficient to support the completion of your required
mileage. Charge it first if the battery is not enough. Check if the dashboard (non standard configuration,) of the
digital tube and battery indicator light work normal, if there is a fault, eliminate it first for maintenance.
3.Check the brake system: Check whether the power function of the brake is normal or not If the brake power
failure function is invalid, please do not use it. Please send it to the relevant maintenance place in time for
maintenance.
4.Check other items: Make sure that the entire vehicle's (mainly front and back wheel) screws are tight; the
handlebar is adjusted well; the wheel lock has been opened; the foot has been put in place; the quick
dismantling folding device is fine , and the safety buckle is in place.
Warning
1)During driving on an uphill surface, adverse wind and bad road conditions, manpower should be used to assist
power riding to reduce the battery load.
2)If there is any kind of abnormal condition during the riding, emergency brake should be made on both front
and rear brake, and the power switch should be turned off immediately. Continue ridding only after ensuring that
the vehicle is in normal condition.
3)Gyrocopters Whiz Ebike is comfortable water and snow but it should not be miss leaded to be completely
soaked in water. The wading depth should not exceed the lower edge of the motor hub or it would cause internal
leakage of the motor hub.
4)For your safety and others, please ride on the non motorized lane, and do not carry people while obeying the
traffic rules.
5)Before driving your Gyrocopters Whiz Ebike as a newbie, you should thoroughly understand the performance
of the electric vehicle.
6)Do not drive with motor vehicles or drive too close to automobiles. Avoid driving into the blind spot area of
motor vehicle drivers.
Note: Turn off the power while parked to save electricity
3. Brake
1)When you have to use the brake while driving, stop pedaling first and then use the brakes. .
2)Brake rear wheel first, then brake front wheel.
3)When the emergency brake is needed, the front and rear brake should be used at the same time because the
braking effect will be reduced if using alone.
Note:
1)While braking, speeding or turning, you must be very careful. Try not to increase the manpower at this time.
2)Drive at a slower speed and leave a enough distance for others.
3)Pay more attention to slippery and smooth road, and keep enough brake distance.
Maintenance
4.Folding ( Follow the folding method)
5.Parking
1)When you get off the Gyrocopters Whiz Ebike, you should turn off the power switch to ensure the service life of
batteries, motors and electrical switches as well as to prevent accidents.
2)When open the kickstand, it' s recommended to park the vehicle in a spacious place. When temporarily
parking is made , please use the safety lock to lock the vehicle (the safety lock is not provided as the
accessories).
3)Do not park your Ebike in the building hall, evacuation staircase, safety exit and follow the safety code of a
park correctly.
1.About the charger
1)When charging, please use factory designated special charger it should not be charged in the residential
buildings, and place it where the children can not touch safe.
2)Pay attention to the charger plug when the charger is used, so as to avoid damaging the plug and causing poor
input or output. At the same time, pay attention to assure it is moistureproof and waterproof.
3)The charger is not allowed to be used in unstable, excessive oil fumes and dust, humid, direct sunlight
environment do not connect electrical appliances while their is lightning and maintain good ventilation conditions.
4)While using and storage of the charger, pay attention to avoid external objects entering, strictly prohibit any
liquid or metal and other objects into the charger, so as to avoid the internal short circuit of the charger Beware of
an impact or a violent shock.
5)There is a high voltage inside the charger Please do not open it without professionals. Please do not change
the plug and wire of the charger by yourself
6)The charger should not be carried in the car when possible. If it is necessary to carry it, it should be placed in
the toolbox aher the shock absorption is done well, and the device in the charger should not be dismantled or
replaced by yourself.
Charging process
1)While charging, put the charger in the ventilation place first, then plug the charger outlet into the charging
hole, then plug the charger into the electricity .
2)When lndicator changes from red to green, it indicates that battery charge is full. It should be recharged for for
1-2 hours to ensure that the battery is fully charged. The longest time should not exceed 6 hours.
3)After charging, the input plug of the charger should be unplugged and then the output plug should be
connected to the Gyrocopters Whiz Ebike.lt is forbidden to connect the charger to the electric power outlet for a
long time without charging. If you smell the odor in the charging process or find the charger temperature is too
high, please stop charging immediately and send it back to the maintenance department to repair it.
Notice
Declaration of responsibility
2.About the battery(Non professionals shouldn' t dismantle it)
1)Between the limit of O degree ~ 45 degree, the battery is charged; Between -20 degree ~ 60 degree discharge,
keeping the battery dry and strictly forbidden to put the battery in the acid and alkaline liquid, avoiding the rain,
away from the fire source, the heat source and the high temperature environment. It is strictly forbidden to
reverse the positive and negative electrodes of the battery. It is strictly prohibited to destroy, disassemble the
battery or make the battery short circuited. When charging, please use the original special charger.charging
should not be more than 6 hours, the charging current is not more than 2A. In the long run, please keep the
battery in the cool and dry place, and charge the battery for five hours a month. When charging, the battery must
be handled according to the instructions. Otherwise, the user will be responsible for the result.
2)The newly purchased Gyrocopters Whiz Ebike may not be ready to ride so please charge then ride the bike.
3)Users must charge according to the requirements of the instructions when charging, otherwise the
consequences will be conceited. Pay attention to the battery type and applicable voltage charged by the charger,
and strictly prohibit mixing. When charging, it should be placed in a ventilated environment. It is strictly prohibited
to recharge in residential buildings, confined space or hot weather.
4)When the vehicle is folded, the two metal contacts on the battery box end can not touch at the same time,
which will result an accident caused by the short circuit of the battery.
5)Batteries should not be stored or used under high temperature for more than 60C in the sun. If you don't need it
for a long time, please charge the battery once a month and charge it to half full at a time.
6)Strictly prohibit the battery to get soaked in water.
3. About the motor
Attention should be paid for protecting motor outlet to avoid short circuit of motor line wear and burning motor. At
the same time, attention should be paid to avoid motor immersion in water for long time.
4. About the controller
Attention should be paid to the protection of the exposed wires of the vehicle, so as to avoid causing the shortcircuit
burn out of the controller, and strictly prohibit the flushing of the controller with water.
You must wear helmets, gloves, kneecap and elbow protectors before riding.
It is best to ride at medium speed. Do not continue pedaling when slowing down.
It is not allowed to ride on motorways, pedestrians and steep slopes. (climbing gradient should be less than 20
degrees)
It is not allowed to ride over the maximum weight of the body as mentioned. (maximum load 120KG)
It is not allowed to use in extremely hot and cold environment It is not suitable to ride on a bumpy wet road.
Strictly prohibit to be used by children under 16 years of age. Illegal use may encounter many unexpected
dangers. The company does not undertake any liability of damage to life or personal injury and property
damage when not following this manual.
The company has the right to amend the product type, specification or related information mentioned in the manual
and reserve the final interpretation right.
The specific type of functions mentioned in this manual is applicable to this particular type only.
Any changes or changes in the product type, the specification or related information mentioned in this manual
will not notice the user.
Without the written permission of the company, no copy, modification, retransmission, dissemination or release
of the version manual shall be made in any form.
Please read the handbook carefully before using the product and operate it in accordance with the manual.
Otherwise, the company is not responsible for the damage of the products caused by improper use or error or the
loss of personal and property.
For product related information, please inquire on Gyrocopters.ca
OPERATING RANGE
