GYROZEN 1096R User manual

Multi-purpose/ Large Capacity, High Speed Centrifuge
1736R/1096R
User’s Manual
Manufacturer: GYROZEN Co., Ltd.
[email protected]m http://www.gyrozen.com
UM-1736R/1096R(E)(Rev.1)
1F & 5F, 16 Arayuk-ro, Gimpo-si, Gyeonggi-do, KOREA
Tel) [phone], FAX) [phone]

2
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R

3
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R

4
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
CONTENTS
Page #
1. Meanings of Symbols & Safety Precautions.............................................................................6
1-1. Meanings of Symbols ............................................................................................................6
1-2. Safety Precautions .................................................................................................................6
2. Product Description & Technical Specifications...................................................................8
2-1. Product Description ...............................................................................................................8
2-2. Technical Specifications.......................................................................................................8
3. Preinstallation Requirements....................................................................................................9
3-1. Environmental Requirement.................................................................................................9
3-2. Electricity Requirement.......................................................................................................10
3-3. Unpacking..............................................................................................................................10
4. Installation..................................................................................................................................10
4-1. Balance Adjustment.............................................................................................................10
4-2. Power On/Off and Lid Release...........................................................................................11
4-3. Rotor Coupling and Disassembling..................................................................................11
4-4. Balance Adjustment –Final................................................................................................13
4-5. Positioning of Sample Tubes ............................................................................................. 13
5. Operation.....................................................................................................................................14
5-1. Key Functions of Control Panel.........................................................................................14
5-2. Setting the RPM/RCF Value................................................................................................ 14
5-3. Setting the Time Value.........................................................................................................15
5-4. Setting Temperature and Fast Cool ..................................................................................16
5-5. Acceleration / Deceleration.................................................................................................17
5-6. Program Saving & Recalling............................................................................................... 17
5-7. Start/Stop ...............................................................................................................................18
5-8. Setting the Key Lock Mode................................................................................................. 19
5-9. Repeat Account and Sound Pitch of End Alarm............................................................. 19
5-10. Pulse .....................................................................................................................................20
5-11. Emergency Lid Open .........................................................................................................20
6. Maintenance..................................................................................................................................20
6-1. Outer part of Instrument......................................................................................................20
6-2. Chamber................................................................................................................................. 21
6-3. Shaft........................................................................................................................................21

5
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
6-4. Rotor........................................................................................................................................21
6-5. Transportation of Instrument .............................................................................................21
7. Trouble Shooting.......................................................................................................................... 21
7-1. Check List ..............................................................................................................................21
7-2. Error Code..............................................................................................................................22
8. CE Declaration..............................................................................................................................24

6
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
1. Meanings of Symbols & Safety Precautions
1-1. Meanings of Symbols
1-1-1. Symbols on the instrument
Symbol
Meaning
Symbol
Meaning
Attention and warning.
Attention and warning for
electric shock
Attention and warning for correct way of sample
balancing in the rotor.
Attention and warning for rotor coupling.
Attention and warning for lid opening and closing
1-1-2. Symbols in this document
1-2. Safety Precautions
Before using the instrument, please read this operation manual to ensure correct usage. Incorrect handling of the
instrument could possibly result in personal injury or physical damage on the instrument or its accessories.
1. ALWAYS locate the instrument on a flat, rigid and stable floor capable of withstanding the weight of the
instrument and its spinning operation.
2. ALWAYS make a safety zone of 30 cm around the centrifuge to indicate that neither hazardous
materials nor persons should be permitted within the area during operation.
ALWAYS position the instrument with enough space on each side of instrument to ensure
proper air circulation.
3. ALWAYS install the instrument within a temperature and humidity controlled environment. (Permissible
ambient temperature: +5°C ~ +35 °C, Relative humidity: ≤ 85%)
4. Before connecting the power, check the rated voltage.
Symbol
Meaning
Symbol
Meaning
This symbol refers to safety
relevant warnings and indicates
possible dangerous outcomes.
☞
Note.
This symbol refers to the important
reminder.

7
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
5. Should not use unapproved rotors and accessories.
Only use rotors from GYROZEN Co., Ltd. with appropriate centrifugal tubes and suitable
adaptors to embrace sample containers tightly enough inside rotors.
6. Before operating the instrument, check if the rotor and the rotor lid are securely fastened.
Should operate the instrument with a rotor properly installed and secured to the motor shaft.
7. Mount the rotor on the motor shaft properly, check it with spinning manually.
8. Do not stop the rotor by touching with hand during the instrument is running.
9. Emergency lid open should be performed only when spinning is completely stopped.
10. Should not exceed the rated speed or specific gravity. Samples whose density is greater than 1.2g/ml
must have reduced maximum rotational speed to avoid rotor failure.
11. The sample content should not exceed 80% of total capacity of a tube. Otherwise, it would cause
spillage of sample fluid and even the tube breakage.
12. ALWAYS load the tubes symmetrically with evenly weighted samples to avoid rotor imbalance. If
necessary, use the water blank to counterbalance the unpaired sample.
13. The operation speed should not exceed the highest value of the individual guaranteed g-forces of each
centrifuge, rotor, bucket or adaptors and sample container, especially the guaranteed g-force of sample
container should not be neglected.
14. The rotors should be cleaned and kept dry after every use for longer life and safety.
15. ALWAYS disconnect the power supply prior to maintenance care and service to avoid electrical shock.
16. ALWAYS use proven disinfection procedures after centrifuging biohazardous materials.
17. Should not centrifuge flammable, toxic, radioactive, explosive, or corrosive materials.
18. When it is necessary to use toxic or radioactive materials or pathogenic micro-organisms which belong
to the Risk Group II of WHO: “Laboratory Bio- safety Manual,” should follow national regulations.
Do not place dangerous materials within 30 cm distance around the instrument, and that is also
recommended by IEC 61010-2-020.
Use the emergency lid open function only when the lid button on the control panel is dumb
under the condition of complete stop of rotor running.
Never try to open or move the instrument if it is not completely stopped.

8
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
2. Product Description & Technical Specifications
2-1. Product Description
1
Lid
2
Power Socket
3
Display & Control Panel
4
Power Switch
5
Manual Lid Opening Hole
6
Caster
2-2. Technical Specifications
Max. RPM/RCF
Fixed angle
17,000 rpm / 32,310 xg
10,000 rpm / 14,981 xg
Swing out
4,000 rpm / 3,134 xg
5,000 rpm / 5,324 xg
Max. capacity
Fixed angle
6 x 500 ml
Swing out
4 x 250 ml
4 x 1,400 ml
Temp. range (℃)
-20 ~ +40
-10 ~ +40

9
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
FAST cool button
Yes
Time control
Pulse, timed < 10 hr
or continuous
Time counting modes
Selectable, at set speed or from starting
RPM/RCF conversion
Yes
Noise level (dB)
≤56
ACC/DEC
9/10 steps
Program memory
100
Parameters on display window
RPM (RCF), Oper Status
Lid Open/Close, Hr : Min, Temp, ACC, DEC
Display
Blue LCD
Automatic rotor Identification
Yes
Imbalance cut-off
Yes
Safety lid lock
Yes
Lid drop protection
Yes
Motorized lid open & close
Yes
Power supply(V/Hz)
220/50~60 (110V optional)
Power requirement
2,500VA
3KVA
Dimension(W x D x H, mm)
473 x 600 x 840
643 x 762 x 850
Weight without rotor (kg)
110
180
CE mark
Yes
Yes
Cat. No.
GZ-1736R
GZ-1096R
☞This instrument has following functions for safety.
1. Automatic rotor identification function.
2. Automatic detection and alarms for imbalance, excess speed and heating.
3. Automatic lid lock function.
3. Preinstallation Requirements.
3-1. Environmental Requirement
1. Install the instrument on the flat and rigid floor. If you place the centrifuge on the slopping area, the
motor shaft might be distorted by the rotor weight and centrifugal force.

10
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
2. Install the instrument about 30cm away from the wall for the air circulation. It is also recommended to
install the instrument at the dustless place as much as possible.
3. Install the instrument at the place with appropriate temperature and humidity. It has to be maintained at
the proper temperature & humidity. (Permissible ambient temperature: +5°C –+35 °C, Relative
humidity: 30% ~ 85%)
4. Install the instrument at the place without any kinds of corrosive gases.
3-2. Electricity Requirement
1. Check the proper voltage of your instrument and connect to adequate power outlet.
2. If the power input is more than +/- 10% of the recommended voltage or fluctuates frequently, it may
cause malfunction of the instrument and often result serious damage.
3-3. Unpacking
1. Untie the plastic banding over the paper box and get rid of box from the instrument main body.
2. Unwrap the vinyl coat surrounding the main body.
3. Place the instrument on a proper place by moving instrument‟s wheel.
4. Removal of Safety Padding
4. Installation
4-1. Balance Adjustment
Imbalancing of the instrument itself causes vibration, noise and error during operation. Check the level of the floor
surface with a Bubble Leveler before installation.
Action
After locating the instrument on the solid and flat floor, check the horizontality
with a Bubble Leveler.
1. Place the Bubble Leveler on top of the instrument.
Try to locate all bubbles in the center of the Bubble Leveler with rotating the red gear which is in
caster of the instrument.
2. Adjust the height of four–wheel, which is at the bottom of the instrument, with rotating the red gear
(which is in caster of the instrument) for the first balance adjustment. (For the final
balance adjustment, please refer to 4-4. BalanceAdjustment-Final )
For fixing a wheel: rotate the red gear counterclockwise with a spanner
For loosing a wheel: rotate the red gear clockwise with a spanner

11
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
4-2. Power On/Off and Lid Release
Action
4-2-1. Power On/Off
1. After connecting the AC Power cord at the power socket
on the right back of the instrument, turn on the Earth
leakage Breaker Switch.
Check the proper power.
2. Turn on a power switch on the right side of the instrument.
With beeping sound, right before setting value is displayed.
The default values are Max. rpm, 10 min, ACC 7, DEC 7 and 25°C.
4-2-2. Lid Release
1. For opening the lid, touch the [LID] button.
Should touch the [LID] button when the lid is
closed (Lid LED shows off)
Close the lid until hearing clank shut.
When the lid is opened, the lid LED turns on.
☞
The lid is not opened while the instrument is running.
If the lid is opened, the instrument could not be operated even with pressing the „Start‟ button.
For operational safety, this instrument has the automatic rotor recognition function.
When you supply the power, "Rotor Scan…” will be appeared. If the rotor is absent, the “Error 9” will
be appeared. This message will be cleared after rotor coupling and running.
The lid is not automatically opened after finishing operation to keep the sample at proper
temperature.
Power Failure: If there is any power failure during operation, lid is not opened with [LID] button. Lid
can be opened only when the operation is completely stopped and the power is on again. If you want
to open the lid at the power failure, please refer to „5-11. Emergency Lid Open‟.
4-3. Rotor Coupling and Disassembling
Action
1. Before coupling a rotor, clean the motor shaft and rotor with soft dry towel.

12
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
4-3-1. Swing-Out Rotor
2. Mount a proper rotor into the motor shaft.
3. Grasp the rotor with one hand, and place Rotor Locking Tool at the center
hole of the rotor.
To assemble the rotor: Rotate the Rotor Locking Tool clockwise
until tightly assembled.
To disassemble the rotor: Rotate the Rotor Locking Tool
counterclockwise.
4. Hang the appropriate buckets into the rotor.
Load the identical bucket at each wing for safety. (Do not leave a
vacant wing without bucket. All wings should hold identical
bucket. )
Remove dirt and water drop around hooks of rotor and hanging
part of bucket.
5. Spin the rotor manually to check if bucket swinging is free enough and ever. If they do not swing freely,
apply the Lubricant (grease) to the linking area.
4-3-2. Fixed Angle Rotor
2. Mount a proper rotor into the motor shaft.
Grasp the rotor with one hand, and place Rotor Locking Tool at the center
hole of the rotor.
To assemble the rotor: Rotate the Rotor Locking Tool clockwise until
tightly assembled.
To disassemble the rotor: Rotate the Rotor Locking Tool
counterclockwise
3. To close of the rotor lid, rotate the rotor lid nut clockwise.
For opening lid: rotate the rotor lid nut counterclockwise.

When you run a fixed angle rotor, make sure that the rotor lid is tightly closed. If you don‟t close the
rotor lid completely, it will be crushed.
☞For operational safety, this instrument has the automatic rotor recognition function.

13
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
4-4. Balance Adjustment –Final
1. Mount the rotor and place the Bubble Leveler on the middle of the
top of a rotor.
Confirm that air bubbles of all three windows of the
Bubble Leveler are within the black lines.
2. To adjust the balance status, rotate the red colored ring at
the wheel caster clockwise or counterclockwise until the device
is well balanced.
4-5. Positioning of Sample Tubes
1. Before loading sample tubes, check the water drop or dirt in the rotor hole or inner adaptor.
If there is a water drop or dirt in the rotor hole or inner adaptor, remove it with soft dry cloth.
2. Tubes should be placed in the rotor with same amount of samples at symmetrical positions.
Only use appropriate centrifugal tubes and do not exceed the speed beyond the tube‟s max.
g-force.
For safety, fill the sample for 70~80% in the tubes.
Correct Way of Sample Balancing and Tube Usage
If the number of samples is not in pair, please load the control tubes at each symmetrical
position. Otherwise, it results noise and vibration, which eventually damage the instrument
☞For safety, the „Imbalance Cut Off‟ function will be occurred, if there is imbalance of loading tubes (Error 8,
Imbalance error). Please refer to 7. Trouble Shooting.

14
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
5. Operation
5-1. Key Functions of Control Panel
□ RPM/RCF
For automatic conversion of RPM/RCF and to set the speed
□ TIME
Use to set time, available range up to 9 hour 59 min (00:00: continuous)
□ Temp
Use to set temperature (-20°C ~ 40°C for 1736R/ -10°C ~ 40°C for 1096R)
Use to reach rapid refrigeration up to the setting temperature. (touch for more than 2
seconds for „Fast Cool‟.)
□ ACC/DEC
Use to set the acceleration & deceleration level from 1 to 9 steps. „0‟ in deceleration step
means natural deceleration. Larger number means faster acceleration or deceleration.
□ PROG
Use to save a set of setting values or recall the saved program number
□ KEY LOCK
Use for key lock mode
□ AT SET SPEED
Use to count the run time once the actual run speed reaches to the set speed value
□ Pulse
Use for quick runs
□ Enter
Use for completion of data setting
□ Start/Stop
Use to start and stop operation
□ Lid
Use to open instrument lid
□ Sound
Use to set the number of sound and volume
5-2. Setting the RPM/RCF Value
Action
5-2-1. Setting the RPM/RCF Value
1. Touch the [RPM/ RCF] button once.
RPM MODE is generated with touching a [RPM/
RCF] button once.
RCF MODE is generated with touching the [RPM/

15
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
AT SET SPEED Mode
For exact time control, this instrument can be set with AT SET SPEED mode which counts supports
the run time once the actual run speed reaches to the set speed value and stops when the deceleration
begins.
*[AT SET SPEED] lamp turns on: From t1 to t2
*[AT SET SPEED] lamp turns off: From t0 to t2
RCF] button twice.
RPM/ RCF LED is flickering at the display window.
2. Touch the number buttons to change input value.
If you do not touch the number button for 15
seconds, the setting mode is cleared.
3. Touch the [Enter] button to complete the setting.
Touch [Enter] to save the setting value.
If wrong number is entered, touch [] button and change the value again
5-3. Setting the Time Value
Action
5-3-1. Setting the AT SET SPEED mode
1. Touch the [AT SET SPEED] button once.
5-3-2. Setting the ‘MIN/ HOUR’ Value
Action
Time is down-counted after starting centrifugation.
1. Touch the [TIME] button once.
„MIN‟ value on LED is flickering.
2. Touch the number buttons to change the minute value.
If you do not touch the number button for 15

16
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
seconds, the setting mode is cleared.
If wrong number is entered, touch [] button and change the value again.
3. Touch the [Enter] button to pass the „HOUR‟ value setting.
4. Touch the number buttons to change the hour value.
If you do not touch the number button for 15
seconds, the setting mode is cleared.
If wrong number is entered, touch [] button
and change the value again.
5. Touch the [Enter] button to complete the setting.
5-4. Setting Temperature and Fast Cool
Action
5-4-1. Setting Temperature
▶1736R: Temperature can be set from -20℃to
40℃
▶1096R: Temperature can be set from -10℃to
40℃
1. Touch the [TEMP] button. Default or latest temperature value blinks on the display window.
2. Touch the number buttons to change temperature.
If you touch [+/-] button, you can set -(minus)
degree values.
If you touch [+/-] button twice, -(minus) degree is
cleared.
If you do not touch the number button for 15
seconds, the setting mode is cleared.
If wrong number is entered, touch [] button and change the value again.
3. Touch the [Enter] button to complete setting.
.
5-4-2. Fast Cool
1. Setting the temperature. (Please refer to 5-4-1.
Setting Temperature)
2. After installation of the rotor and closing the lid of
instrument, touch the [TEMP] button for more than 2
seconds.
For fast cooling, the instrument is refrigerated down to the set temperature in a short time or

17
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
setting time. During the fast cooling, the rotor runs at low speed (1,000 rpm).
The passed time is showed on the display window.
☞
If you‟d like to load your sample tubes before pressing the [Fast Cool] button, please check if the
sample is safe during spinning at 1,000 rpm.
Before starting Fast Cooling, please check the rotor coupling and symmetry of sample tubes.
5-5. Acceleration / Deceleration
Use the adjustment function of acceleration (level: 1~9) & deceleration levels (level: 0~9) to protect sensitive
samples.
Action
1. Touch [ACC/DEC] button.
2. Touch the number buttons to change input ACC
value.
Input the desired level of ACC from 1 to 9.
(Level 9: The fastest acceleration)
If you do not touch the number button for
15 seconds, the setting mode is cleared.
If wrong number is entered, touch []
button and change the value again.
3. Fix theACC level by touching [Enter] button.
4. Touch the number buttons to change input DEC value.
Input the desired level of DEC from 0 to 9.
(Level 0: Natural deceleration / Level 9: The
fastest deceleration)
If you do not touch the number button for 15 seconds, the setting mode is cleared.
If wrong number is entered, touch [] button and change the value again.
5. Fix the DEC level by touching [Enter] button.
5-6. Program Saving & Recalling
Action
5-6-1. Program Saving

18
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
1. Set parameters. (Refer to 5-2 ~ 5-5)
2. Touch the [PROG] button twice.
„SAVE‟ is turned on the display window.
3. Touch the number buttons to change input Program number.
If you do not touch the number button for 15
seconds, the setting mode is cleared.
Save up to 100 programs. (Program
numbers from 00 to 99).
If wrong number is entered, touch []
button and change the value again.
4. Touch the [Enter] button to complete the saving.
5-6-2. Program Recalling
1. To recall the saved program, touch the [PROG] button
once.
„CALL‟ is turned on the display window.
2. Touch the number buttons to select program number
you want to recall and then touch the [Enter] button.
If you do not touch the number button for 15
seconds, the setting mode is cleared.
If wrong number is entered, touch []
button and changethe value again.
5-7. Start/Stop
Action
5-7-1. Start
1. After setting RPM/RCF and Time, touch [Start/Stop]
button.
During running, a „Start LED‟ is turned on.
The instrument is running only when the lid is closed.
When you touch the [Enter] button during operation, display window shows the saved setting
parameters
5-7-2. Stop

19
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
1. In case of touching the [Start/Stop] button, the operation is stopped.
When you touch the [Start/Stop] button twice, the operation is stopped with DEC 9.
5-8. Setting the Key Lock Mode
Action
1. Touch [KEY LOCK] button.
All input buttons except for [KEY LOCK]
button can be locked for protocol security
(lock: LED on/ unlock: LED off)
If you touch the [KEY LOCK] button again in the key lock mode, the key lock mode is
cleared.
5-9. Repeat Account and Sound Pitch of End Alarm
Repeat account and sound pitch of the end alarm can be selected.
Action
5-9-1. Setting the Sound Pitch of End Alarm
1. Touch [SOUND] button.
„Sound LEVEL_03‟ appears on the display
window.
2. Touch the number buttons to change the value for the pitch of sound.
3. Fix the value by touching [ENTER] button.
Sound LEVEL: 0~10 (0: silent)
5-8-2. Setting the Repeat Count of End Alarm
1. Touch [AT SET SPEED] button for more than 2
seconds.
„Sound rPt‟ appears on the display window.
2. Touch the number buttons to change the value
for the repeat count.
3. Fix the value by touching [ENTER] button.
The number of finishing sound: 0~99 (0: silent, 99: 99 times)

20
Multi-purpose/ Large Capacity, High Speed Centrifuge 1736R/ 1096R
5-10. Pulse
It is for quick and short spin down.
Action
1. If you touch [PULSE] button and release at the
point you want to stop, the centrifuge decelerates immediately.
When the operation is completely stopped, lid is automatically opened.
5-11. Emergency Lid Open
For emergency lid opening, you can use the Emergency Lid-Lock Release Tool when the instrument is
completely stopped.
The lid can be unlocked manually with the Emergency Lid-Lock Release Tool through the emergency lid-lock
release hole.
Action
1. Find the emergency lid-lock release hole
in the front body of the instrument and
take out the white rubber closure.
2. Insert the Emergency Lid-Lock Release
Tool into the hole and revolve it counter
clockwise until the lid is released.
6. Maintenance
6-1. Outer part of Instrument
1. Clean the outside of the instrument with dry soft cloth. If necessary, dip the cloth in neutral detergent
and clean contaminated area. Keep completely dry after cleaning.
2. Do not use any volatile chemicals such as alcohol and benzene, etc.
3. Be careful not to make scratches on the surface of the instrument. The scratches can cause corrosion
on the surface of the instrument.
If any rust appears, clean it with neutral detergents and keep dry.
Manual opening should be performed only when spinning is completely stopped. Otherwise, harmful
damage will be accompanied to not only operators but samples.
After opening the lid manually, it is recommended to wait until normal electricity comes back.
