GYROZEN 406 User manual

Low-Speed Centrifuge
406
User’s Manual
Manufacturer: GYROZEN Co., Ltd.
[email protected]
http://www.gyrozen.com
UM-406(E)(Rev.2), 20210121
1F & 5F, 16 Arayuk-ro, Gimpo-si, Gyeonggi-do, KOREA
Tel) [phone], FAX) [phone]

2
Low-Speed Centrifuge 406
CONTENTS
Page #
1. Meanings of Symbols & Safety Precautions ..................................................................................................3
1-1. Meanings of Symbols ................................................................................................................................3
1-2. Safety Precautions ....................................................................................................................................3
2. Product Description & Technical Specifications ...........................................................................................5
2-1. Product Description ...................................................................................................................................5
2-2. Technical Specifications ............................................................................................................................5
3. Installation ......................................................................................................................................................6
3-1. Power ON /OFF and Door Release ...........................................................................................................6
3-2. Rotor Coupling and Disassembling.............................................................................................................7
3-3. Positioning of Sample Tubes ......................................................................................................................7
4. Operation .......................................................................................................................................................8
4-1. Key Functions of Control Panel .................................................................................................................8
4-2. Setting the RPM/RCF Value ......................................................................................................................8
4-3. Setting the Time Value ..............................................................................................................................9
4-4. START / STOP ........................................................................................................................................10
4-5. Program Save / Recall..............................................................................................................................10
4-6. Emergency Door-Lock Release ................................................................................................................10
4-7. Replacement of Fuse................................................................................................................................11
5. Maintenance ................................................................................................................................................11
5-1. Outer part of instrument ..........................................................................................................................11
5-2. Chamber .................................................................................................................................................11
5-3. Shaft ........................................................................................................................................................11
5-4. Rotor .......................................................................................................................................................11
5-5. Transportation of the Instrument...............................................................................................................12
6. Trouble Shooting ........................................................................................................................................12
6-1. Check List ...............................................................................................................................................12
6-2. Error Code ................................................................................................................................................12
7. Rotors and Accessories ...............................................................................................................................14
8. Product Range .............................................................................................................................................15
9. CE ................................................................................................................................................................16

3
Low-Speed Centrifuge 406
1. Meanings of Symbols & Safety Precautions
1-1. Meanings of Symbols
1-1-1. Symbols on the device
Symbol
Meaning
Symbol
Meaning
Attention and warning.
Attention and warning for
electric shock
Attention and warning for
rotor coupling.
Attention and warning for
door opening and closing
Attention and warning for
correct way of sample
balancing in the rotor.
Indicate a hole for manual
door opening in case of
emergency
1-1-2. Symbols in this document
Symbol
Meaning
Symbol
Meaning
This symbol refers to safety
relevant warnings and indicates
possible dangerous outcomes.
☞
Note.
This symbol refers to the important
reminder.
1-2. Safety Precautions
Before using the instrument, please read this operation manual to ensure correct usage. Incorrect handling of the
instrument could possibly result in personal injury or physical damage on the instrument or its accessories.
1. ALWAYS locate the instrument on a flat, rigid and stable table capable of withstanding the weight of the
instrument and its spinning operation.
2. ALWAYS make a safety zone of 30 cm around the centrifuge to indicate that neither hazardous
materials nor persons should be permitted within the area during operation.
ALWAYS position the instrument with enough space on each side of instrument to ensure
proper air circulation.
3. ALWAYS install the instrument within a temperature and humidity controlled environment. (Permissible
ambient temperature: +5°C ~ +35 °C, Relative humidity: ≤ 85%)
4. Before connecting the power, check the rated voltage.
5. Should not use unapproved rotors and accessories.

4
Low-Speed Centrifuge 406
Only use rotors from Gyrozen Co., Ltd. with appropriate centrifugal tubes and suitable
adaptors to embrace sample containers tightly enough inside rotors.
6. Before operating the instrument, check if the rotor and the rotor lid are securely fastened.
Should operate the instrument with a rotor properly installed and secured to the motor shaft.
7. Mount the rotor on the motor shaft properly, check it with spinning manually.
8. Do not stop the rotor by touching with hand during the instrument is running.
9. Emergency Door-Lock Release should be performed only when spinning is completely stopped.
10. Should not exceed the rated speed or specific gravity. Samples whose density is greater than 1.2g/ml
must have reduced maximum rotational speed to avoid rotor failure.
11. The sample content should not exceed 80% of total capacity of a tube. Otherwise, it would cause
spillage of sample fluid and even the tube breakage.
12. ALWAYS load the tubes symmetrically with evenly weighted samples to avoid rotor imbalance. If
necessary, use the water blank to counterbalance the unpaired sample.
13. The operation speed should not exceed the highest value of the individual guaranteed g-forces of each
centrifuge, rotor, bucket or adaptors and sample container, especially the guaranteed g-force of sample
container should not be neglected.
14. The rotors should be cleaned and kept dry after every use for longer life and safety.
15. ALWAYS disconnect the power supply prior to maintenance care and service to avoid electrical shock.
16. ALWAYS use proven disinfection procedures after centrifuging biohazardous materials.
17. Should not centrifuge flammable, toxic, radioactive, explosive, or corrosive materials.
18. When it is necessary to use toxic or radioactive materials or pathogenic micro-organisms which belong
to the Risk Group II of WHO: “Laboratory Bio-safety Manual,” should follow national regulations.
Do not place dangerous materials within 30 cm distance around the instrument, and that is
also recommended by IEC 61010-2-020.
Use the Emergency Door-Lock Release function only when the door button on the control
panel is dumb under the condition of complete stop of rotor running.
Never try to open or move the instrument if it is not completely stopped.
If the power input is more than +/- 10% of the recommended voltage or fluctuates
frequently, it may cause malfunction of the instrument and often result serious damage.
Install the instrument at the place without any kinds of corrosive gases.

5
Low-Speed Centrifuge 406
2. Product Description & Technical Specifications
2-1. Product Description
Cat no. GZ-0406 includes GRA-15-6A.
2-2. Technical Specifications
Max. RPM/RCF
4,000 rpm/ 2,075 xg
Max. capacity
6 x 15 ml
Time control
Timed, < 100 min or continuous
RPM/RCF conversion
Yes

6
Low-Speed Centrifuge 406
Noise level
≤52 dB
Acc/Dec(sec)
≤20 sec / ≤20 sec
Program memory
10
Imbalance cutout
Yes
Safety door lock
Yes
Door drop protection
Yes
Automatic door release at completion
Yes
Power supply(V/Hz)
220/50~60 (110V optional)
Power requirement(VA)
140
Dimension(W x D x H, mm)
296 x 412 x 206
Weight without rotor (Kg)
17.5
CE mark
Yes
Cat. No.
GZ-0406
3. Installation
3-1. Power ON /OFF and Door Release
3-1-1. Power ON /OFF
Action
1. Connect the AC Power cord at the power socket on the right back
of the instrument.
2. Turn on the instrument by pressing a switch on the right side
of the instrument.
3. Press the ‘Door’ button to open the door.

7
Low-Speed Centrifuge 406
3-1-2. Door Release
Action
1. For opening the door, press the [DOOR] button.
The door is automatically opened after
completion spinning with beeping sound.
Close the door until hearing clank shut.
When the door is opened, the door LED
turns on.
☞
The door is not opened while the instrument is running.
If the door is opened, the instrument could not be operated even with pressing the ‘Start’
button.
Power Failure: If there is any power failure during operation, door is not opened with ‘Door’
button. Door can be opened only when the operation is completely stopped and the power is on again.
If you want to open the door at the power failure, please refer to ‘4-6. Emergency Door-Lock Release’.
3-2. Rotor Coupling and Disassembling
Action
1. Before coupling a rotor, clean the motor shaft and chamber with
soft dry towel.
2. Mount a proper rotor into the motor shaft. Put the Washer ( ) at the
center hole of the rotor and assemble it with Rotor Locking Nut ( ).
To assemble the rotor: Rotate the Rotor Locking Nut clockwise until
tightly assembled.
To disassemble the rotor: Rotate the Rotor Locking Nut
counterclockwise.
3. Load the 15ml sleeves at every hole.
3-3. Positioning of Sample Tubes
1. Before loading sample tubes, check the water drop or dirt in the rotor hole or inner adaptor.
If there is a water drop or dirt in the rotor hole or inner adaptor, remove it with soft dry cloth.
2. Tubes should be placed in the rotor with same amount of samples at symmetrical positions.
Only use appropriate centrifugal tubes and do not exceed the speed beyond the tube’s max.
g-force.
For safety, fill the sample for 70~80% in the tubes.

8
Low-Speed Centrifuge 406
Correct Way of Sample Balancing & Tube Usage
If the number of samples is not in pair, please load the control tubes at each symmetrical position. Otherwise,
it results noise and vibration, which eventually damage the instrument.
☞
For safety, the ‘Imbalance Cut Off’ function will be occurred, if there is imbalance of loading tubes (Error
8, Imbalance error). Please refer to 6. Trouble Shooting.
4. Operation
4-1. Key Functions of Control Panel
□ START/STOP
Use to start or stop operation
□ PROG
Use to save a set of setting values or recall the saved program number
□ Door
Use to open the instrument door
□ RPM/RCF
For automatic conversion of RPM/RCF and to set the speed
□ TIME
Use to set time, available range up to 99 min 59 sec (00: continuous)
4-2. Setting the RPM/RCF Value
▶Maximum RPM/RCF: 4,000 RPM/ 2,700 x g
Action
4-2-1. Setting the RPM Value
▶Speed setting unit: 10rpm or 100rpm
1. Press the [RPM/RCF] button once.

9
Low-Speed Centrifuge 406
RPM MODE is generated by pressing a [RPM/RCF] button once.
2. Press the [▲▼] buttons to change input value.
After keeping holding finger on the [▲▼] buttons for
5 seconds, the unit of setting value is changed to 100
rpm from 10rpm.
3. Press the [RPM/RCF] button again for saving.
4-2-2. Setting the RCF Value
▶Speed setting unit: 1 rcf or 10 rcf
1. Press the [RPM/RCF] button twice.
RCF MODE is generated by pressing a [RPM/RCF]
button twice.
2. Press the [▲▼] buttons to change input value.
After keeping holding finger on the [▲▼] buttons for 5
seconds, the unit of setting value is changed to 10 rcf
from 1 rcf.
3. Press the [RPM/RCF] button again for saving.
4-3. Setting the Time Value
▶Speed setting unit: 1min. or 10min./ 1 sec. or 10 sec
Action
4-3-1. Setting the MIN. Value
1. Press the [TIME] button once.
Minutes MODE is generated with pressing a [TIME]
button once.
2. Press the [▲▼] buttons to change input value.
After keeping holding finger on the [▲▼] buttons for 5
seconds, the unit of setting value is changed to 10min
from 1 min.
3. Press the [TIME] button again for saving.
4-3-2. Setting the SEC. Value
1. Press the [TIME] button twice.
Seconds MODE is generated with pressing a [TIME]
button twice.
2. Press the [▲▼] buttons to change input value.
After keeping holding finger on the [▲▼] buttons for 5
seconds, the unit of setting value is changed to 10 sec. from 1 sec.
3. Press the [TIME] button again for saving.

10
Low-Speed Centrifuge 406
4-4. START / STOP
Action
1. After setting RPM/RCF and Time, press [START/STOP] button.
During running, a ‘Start LED’ is turned on.
In case of pressing the [START/STOP] button during
running, the running is stopped.
4-5. Program Save / Recall
Action
4-5-1. Program Save
1. Set parameters. (Refer to 4-2 ~ 4-3)
2. Press the [PROG] button longer than 3 seconds to save your
preferred set values.
The LED of [PROG] button and SEC/Save is turned on.
3. Input the program number by using [▲▼] button.
Save up to 10 programs
4. Press the [PROG] button again to complete the saving.
The setting value is saved
If you do not press the [PROG] buttons for 5 second, the setting mode is cleared.
4-5-2. Program Recall
1. To recall the saved program, just press the [PROG] button
shortly.
The LED of [PROG] and MIN/Call is turned on.
2. Check the program number to call and enter the program
number you want to recall by pressing [▲▼] button.
3. Press [PROG] button once again.
The setting values are displayed according to your saved
number.
If you do not press the [PROG] buttons for 5 second, the setting mode is cleared.
4-6. Emergency Door-Lock Release
For Emergency Door-Lock Releasing, you can use the Emergency Door-
Lock Release Tool as long as the instrument is completely stopped.
The door can be unlocked manually with Emergency Door-Lock Release
Tool through the emergency opening hole.
1. Find the emergency hole at the left side of the instrument
2. Insert the Emergency Door-Lock Release Tool into the hole
and push it until the door is released.

11
Low-Speed Centrifuge 406
4-7. Replacement of Fuse
When the power is not turned on, please check the Power Switch, the connection of Power Outlet and Power
Socket. If the power is still not turned on, replace the fuse as following instruction.
Action
1. Separate the AC Power Cord at the back of the instrument and push Fuse Case by the flat-head
screwdriver for bringing out the Fuse Case.
2. Replace the damaged fuse with new one from the fuse case and then connect in the power.
5. Maintenance
5-1. Outer part of Instrument
1. Clean the outside of the instrument with dry soft cloth. If necessary, dip the cloth in neutral detergent
and clean contaminated area. Keep completely dry after cleaning.
2. Do not use any volatile chemicals such as alcohol and benzene, etc.
3. Be careful not to make scratches on the surface of the instrument. The scratches can cause corrosion
on the surface of the instrument.
If any rust appears, clean it with neutral detergents and keep dry.
5-2. Chamber
1. Keep dry inside the chamber after every use.
2. If the chamber is contaminated, dip the cloth in neutral detergent and clean contaminated area.
5-3. Shaft
1. Always make special attention to clean the motor shaft to avoid any imbalance problem due to the
contaminants.
2. After using the instrument, take out the rotor from the shaft, and clean the shaft with dry soft cloth to
keep dry.
5-4. Rotor
1. If any parts are contaminated with samples, clean the rotor with soft wet cloth and keep the rotor dry.
2. Be careful not to make scratches inside or on the surface of rotors. Any small scratches can cause
Manual opening should be performed only when spinning is completely stopped. Otherwise, harmful
damage will be accompanied to not only operators but samples.
After opening the door manually, it is recommended to wait until normal electricity comes back.

12
Low-Speed Centrifuge 406
corrosion of the rotor and big damage to the instrument.
3. If you do not use the instrument, keep the rotor separately from the motor shaft and stand it upside
down.
5-5. Transportation of the Instrument
1. If you need to move or ship the instrument, be cautious to protect the motor shaft from any physical
impact or turbulence.
2. Do not mount a rotor in any cases of movement. Fill inside the chamber with proper materials to keep
the motor shaft on place and not to be influenced by physical pressure.
6. Trouble Shooting
6-1. Check List
Symptom
Check List
Power failure
Connect the AC Power cord and make sure that the line is completely
connected between the instrument and power outlet. Check the power
switch is turned on. (Please refer to 3-1. Power on/off and Door Release)
Can’t be started
If the door is not closed completely, the instrument can’t run.
Check the Door LED on the display window and close the door
completely.
Can’t open the door
If the power is out, check the main fuse for the laboratory to supply the
power. If it is not solved in shortly, open the door with the Emergency
Door-Lock Release Tool manually for safety of sample. (Please refer to 4-
6. Emergency Door-Lock Release)
Can’t close the door
Remove the dirt at the door latch and then close the door completely
again. If the door seems not being closed by mechanical reason, please
contact our service team.
Noise and vibration during running
Please check the balanced status of both the table and the instrument.
Please re-check the coupling status of the following three matches to
minimize the noise
1. the balanced way of coupling of the rotor into the motor shaft
2. the completeness of fixing of the Rotor Locking Nut on the
rotor
3. the matching status of rotor lid with the rotor
(Please refer to 3-2. Rotor Coupling and Disassembling)
Check balances of samples in the rotor. (Please refer to 3-3. Positioning
of Sample Tubes) and load the same weight of samples symmetrically.
6-2. Error Code
If any of the following error messages comes up with beeping sound, press ‘PROG’ button to clear the error
status and make the instrument restore its default setting. If the error message does not disappear, check into the
current status by referring to the following information.
Error
Possible Causes
Actions
Error 1
RPM
- If the speed does not reach 200 rpm within 2 seconds after motor starts
to operate, this message may appear.
- Check whether the motor is normally working or not.
- If the error message does not disappear, please contact a Service
Engineer of your local GYROZEN’s partner.

13
Low-Speed Centrifuge 406
Error 2
Door Open
- If the door opens while spinning or has any trouble in the door sensor,
this message may come up.
- Remove the dirt at the door latch and close the door completely. Check
the door closing status on the display window.
- If the error message does not disappear, please contact a Service
Engineer of your local GYROZEN’s partner.
Error 3
Motor
Overheating
- If the motor is overheated, this message may come up.
- Keep off the power supply for an hour, and turn on the power to check
up the instrument.
- If the error message does not disappear, please contact a Service
Engineer of your local GYROZEN’s partner.
Error 4
Low Voltage
- If the power input (V/Hz) is at least 10% lower than the recommended
power, this message may come up.
- Turn off the power supply and check the voltage of the Power supply
(V/Hz).
- Use AVR to provide proper power.
Error5
High Voltage
- If the power input (V/Hz) is at least 10% higher than the recommended,
this message may come up.
- Turn off the power supply and check the voltage of the Power supply
(V/Hz).
- Use AVR to provide proper power.
Error 6
Overspeed
- If the instrument spins faster than allowed (1,000 rpm higher than the
set speed), it may cause overload to motor capacity or any trouble in
the output of motor.
- Turn off and on the power supply to check up the instrument.
- If the error message does not disappear, please contact a Service
Engineer of your local GYROZEN’s partner.
Error 7
Software
- If the installed software has any bugs, this message may come up.
- Contact a Service Engineer of your local GYROZEN’s partner and get
the firmware upgrade. Wire disconnection or tuning of the instrument
must be performed only by a Service Engineer authorized by
GYROZEN Co., Ltd.
Error 8
Imbalance
- Check the balance status of the samples in the rotor (Please refer to 3-
3. Positioning of Sample Tubes) and turn off and on the instrument to
check the status.
- If the error message does not disappear, please contact a Service
Engineer of your local GYROZEN’s partner.
Error 9
RPM Sensor
- If the rpm sensor recognition fails, this message comes up.
- The message will be cleared by coupling an appropriate rotor (Please
refer to 3-2. Rotor Coupling and Disassembling.).
- Disassemble and couple a compatible rotor and turn off and on the
instrument to check out the status.
- If the error message does not disappear, please contact a Service
Engineer of your local GYROZEN’s partner.
* Any wire disconnection or tuning of the instrument must be performed only by a service engineer who is
authorized by GYROZEN Co., Ltd.

14
Low-Speed Centrifuge 406
7. Rotors and Accessories

15
Low-Speed Centrifuge 406
8. Product Range

16
Low-Speed Centrifuge 406
9. CE
