GYROZEN 2236R User manual

Large Capacity, High Speed Centrifuge
2236R
User’s Manual
Large Capacity, High Speed Centrifuge 2236R
UM-2236R(E)(Rev.4) 2021.01.21
Manufacturer: GYROZEN Co., Ltd.
1F & 5F, 16 Arayuk-ro, Gimpo-si, Gyeonggi-do, KOREA
Tel) [phone], FAX) [phone]
[email protected]
http://www.gyrozen.com

Refrigerated,High Speed Centrifuges, 2236R
CONTENTS
1. Safetywarningsandcautions ------------------------------------------------------------------------------------------------------------------------------ 3
1.1 Safety label ------------------------------------------------------------------------------------------------------ 3
1.2 Safety Precautions 4
2. Product compositionandinformation 5
2.1 Productcomposition 5
2 . 2. Accessories 5
2.3TechnicalSpecification 6
3. Product assemblyandinstallation 8
3.1 Product Installation 8
3.2 Power connection -------------------------------------------------------------------------------------------- 9
3.3 LidOpen----------------------------------------------------------------------------------------------------- 10
3.4 Rotormountingandremoval 10
3.5Mounting thesampletube 12
4. Method ofuseandprecautions 13
4.1Control panel 13
4.2Speedsetting 17
4.3TimeSetting 18
4.4TemperatureSettingandfastcooloperation 19
4.5Acceleration / Deceleration(ACC/DEC)Setting 20
4.6Save, recall anddeleteprograms 21
4.7History 23
4.8Start/ Stop 24
4.9MultiSteps 25
4.10 In case of emergency, manuallid opening 25
4.11 Drainholeopen 26
5. Maintenance 27
6. Troubleshooting 27
6.1Checklist before reporting afailure 27
6.2 Errormessageinformation 28
7. Rotorandaccessoryinformation 30
8. DeclarationofConformity 40
2
Large Capacity, High Speed Centrifuge 2236R

Operating Manual
Thisinstruction manualcontainsdetailedinstructionstooperatetheCentrifuge2236R.
Forproperuseandmaintenance,besuretoreadtheinstructionsanduseit properly.
1. SafetyWarningsandCautions
1-1. SafetyLabel
Labelsattachedtothemainbodyprovideusageandsafetyinformation
Labtel Instruction
Cautionsignindicatingforwarning
CautionsignforElectricShockhazard
Rotor/ tubeinsertionandLidclosingcautionsigns
3
Large Capacity, High Speed Centrifuge 2236R

Refrigerated,High Speed Centrifuges, 2236R
1.2 Safetyprecautions
Beforeusingthisproduct,besuretoreadtheuser'smanualtoprevent
malfunctionsthatmayoccurduringuse.
1.Alwaysmakesurethatthedeviceis fixedon alevelsurfacethatcanwithstandshakingandtheweightofthedevice d
uringoperationandplacedon a safetable.
2.Donotmovetheproductduringoperation,andleaveasafespacewithin 30cmaroundthecentrifugeforuser s
afety.
-Atalltimes,the locationof the deviceshouldhaveenoughspacearoundthe deviceforproperaircirculation.
3. Alwaysinstallthe equipmentin aplacewheretemperatureandhumiditycanbecontrolled.
-Permissible ambient temperature: +5℃~+35℃/+41℉~+95℉, relative humidity:≤85%
4. Beforeconnectingthe power,theratedvoltageshouldbe checked.
5. Donot useunauthorizedrotorsoraccessories.
6. Beforeusingthe device,makesurethatthe rotorandrotorlid aresecurelylocked.
-Therotormustbeproperlyinstalledandmustbeusedwiththemotorshaftsecurelylocked.
7. Checkthat the rotoris properlypositionedonthe motorshaftby turningit manually.
8. Donot stopthe rotorby handwhilethe machineis in use.
9. Emergencydooropeningis onlyusedwhenmotioniscompletelystopped.
10. Permissiblespeedsandspecialspecificgravityshouldnot beused.
If the densityofthe wholesampleis greaterthan1.2g/ml,themaximumrotationalspeedshouldbereducedto avoid
rotorfailure.
11.Whenholdingthe sample,do not exceed80%ofthetotalvolumeofthe tube.Otherwise,the tube maybreakorthe s
amplesolutionmayflow.
12.In ordertoavoidunbalancedrotors,tubesshouldalwaysbesymmetricallyfilledwithwell-balancedsamples. If
necessary,theycanbepairedusingwatertoachievebalance.
13.Theoperatingspeedshouldnot behigherthanthe respectiveguaranteedg valuesofthe centrifuge,rotor,bucket o
radapterandsampletube. In particular,theguaranteedgvalueofthe sampletubeshouldnot be neglected.
14. Therotorshouldbe cleanedanddriedaftereveryuseforlonglife andsafety.
15. Alwaysdisconnectthe powersupplyduringregularinspectionandserviceto avoidelectricshock.
16. Alwayscentrifugebiologicalmaterialandusea validateddisinfectionprocedure.
17. Donot centrifugeflammable,toxic,radioactive,explosive,orcorrosivesubstances.
18. If itis necessaryto usetoxicorradioactivesubstancesorpathogenicmicroorganismsbelongingto WHORisk
GroupII, the nationalregulationsof“Laboratory Bio-safetyManual” must beobserved.
4
Large Capacity, High Speed Centrifuge 2236R

Operating Manual
2. Product composition andinformation
2.1Productcomposition
UserManual Rotor LockingTool
Leveler
Lubricant(grease)
Touchpen
Power Cord &Plug
Spanner
1.Lid
2. Powersocket
3. Chamber
4. EmergencyManualLidOpenHole
5. Drain Knob
6. ControlPanel
7. Powerswitch
8. Heightadjustablefixedwheels
2.2 Accessories
※Rotorsoldseparately(referto7.Rotorandaccessoryinformation)
5
Large Capacity, High Speed Centrifuge 2236R

10
Large Capacity, High Speed Centrifuge 2236R
2.3 Technical Specifications
☞This instrument has following functions for safety.
1. Automatic rotor identification function.
2. Automatic detection and alarms for imbalance, excess speed and heating.
3. User ID and protocol management with historical tracking
4. Holding or changing of time and temperature possible while running
Max.RPM/RCF
Fixed angle 22,000 rpm / 54,111 xg
Swing out 4,000 rpm / 3,134 xg
Max. capacity
Fixed angle 6 x 1,000 ml
Swing out 4 x 250 ml
Temp. range(℃) -20 ~ +40
FAST COOL button Yes
OS / Control Display Windows CE / 7' Touch Screen
Time control Pulse, timed < 100 hr.
or continuous
RPM/RCF conversion Yes
Noise level (dB) ≤56
Acc/Dec 9/10 steps
Program memory 100
Rotor Identification Automation
Imbalance cutout Yes
Safety lid lock Yes
Lid drop protection Yes
Power supply(V/Hz) 230V~ , 50/60 (110V optional)
Power requirement(KVA) 4.0
Dimension(W x D x H, mm) 824 x 634 x 1,049
Weight without rotor (Kg) 240
CE mark Yes
Cat. No. GZ-2236R

Refrigerated,High Speed Centrifuges, 2236R
3. Product assembly andinstallation
3.1 ProductInstallation
1. Afterpurchasingthecentrifuge,removethepackagingbox and protective filmand checkthecomponents.
▶Accessories:Centrifuge/ UserManual / PowerCord&Plug/ Rotor LockingTool/ Lubricant
(grease)leveler /Spanner/Touchpen/WallOutletSocket
2.Placethedeviceon aflatand hardplace,placealeveler on thetopof
thedevice,and keepthewaterdropletsinsidethedevicelevel.
▶Adjust the level of the machinebyturning the redgear ofthe wheel
accordingto themethodbelowsothatallwaterdropletsinsidetheleveler
are within the black linesonbothsides.
3. Turntheheight-adjustingredgearsof thefourmovablewheelsat the bottom of the machineto increasethe height.
Adjusttodothe1stequilibrium work.
(Referto 3.5RotorMountingand Dismounting,and afterinstalling therotor,
completethefinalequilibrationwork)
▶The height adjustment red gear is interlocked with the rubber feet to
fix the device on the floor of the installation site.
▶Youcaneasilyoperatetheredgear by usingtheprovidedspanner.
▶Highandlow rubberfeetfixed:counterclockwise
▶Liftrubber feet:clockwise
8
Large Capacity, High Speed Centrifuge 2236R

Operating Manual
3.2Powerconnection
1. Afterconnectingthepoweroutletprovidedby themanufacturer,connecttheAC powercordto the powersocketlocatedon the
rightrearside ofthe mainbody.
▶Pleasechecktheratedvoltage(230V~,50/60Hz)to be used.
2.Pushthepowerswitchbutton on therightsideof themainbody upwardin theON direction.
▶Thedisplay screenappearsas NowLoading..>>Loadingimages..SDCard Found.
3.Click OK on the pop-upwindowthatappearson thedisplaywindow.
▶Press OK → Move to UNLOCKscreen
4. PressUNLOCKon the displaywindow.
▶Press UNLOCK→ move to mainscreen
[PowerOutlet][Power connection]
9
Large Capacity, High Speed Centrifuge 2236R

Refrigerated,High Speed Centrifuges, 2236R
3.3Lidopen
Canbe usedto open lids.Lidopeningcanbe confirmedthroughthe DOORiconon the mainscreen.
1. Withthelid closed, pressOPENDOOR.
▶WhenLidis open, theLidiconwillappearonthemainscreen.
[Whenthe lid isclosed] [Whenthe lid isopen]
Attention! MotorizedLidClosureSystem
Thelid locksystemof thisproductis lockedwithonlyalighttouch,so do not applyexcessive
force.
3.4 Rotor mountingandremoval
1. Beforeassemblingthe rotor,removeforeign matterormoisture
fromthe motorshaftand rotorwithadrycloth.
Attention!Electricalrequirements
220Vpowerisused,andif thevoltagechangesbymorethan±10%fromthestandardvoltage,precisereliability ca
nnotbe obtained during operation. In addition,it isnecessaryto ensurethatconstantpowerissuppliedto avoid an
y damagetovariouspartsinthecentrifuge.Thisdeviceisintendedtobe usedat220Vvoltageatthetimeof shipm
ent.
10
Large Capacity, High Speed Centrifuge 2236R

Operating Manual
Swing-OutRotor
2.Aligntherotorto thecentralaxisofthechamberand rotateitbyusingthe
providedRotorLockingTool.
▶Rotor mounting:clockwise
▶Rotorseparation:counterclockwise
▶Holdtherotorwingwithonehandandusethetoolwiththeotherhandtoinstallor r
emove.
3. Attachabucketsuitable forthe sampletube to therotorlatch.
▶When using, the rotor must be equipped withthesame bucket.
▶Be carefulnot to haveany dustorforeignsubstancesin thejointarea
betweenthe rotor andbucket.
▶Manuallyrotatethe rotorto checkthatall installed bucketsaresmoothly spr
eadout,and if thespreadingis not smoothor the spreadingangleis not the sa
me,applyLubricant(grease)to thejointoftherotorandbucket(rotor clasp).
Fixed AngleRotor
2.Aligntherotortothecentralaxisof thechamberandrotateit usingthe
providedRotor LockingTool.
▶Rotor mounting: clockwise
▶Rotorseparation:counterclockwise
▶Holdthe rotorwith one hand and installor removeit with theother hand
byusing atool.
3.Putthesampletubesuitable fortherotor,closetherotorlid,and thenturn t
he lid nut clockwisetofixit.
▶Rotor Lid Installation: Clockwise
Rotor LidSeparation:Counterclockwise
▶Holdthe rotorwith one hand and rotatethelid nutwiththe other handto
combineor separatethelid.
Attention! Checkrotor connectionbeforedriving
Beforeuse, makesure thattherotor is securelyfastenedtothe
motorshaft.
Rotor Lidinstallation
checkIfit is afixedanglerotor,makesurethattherotorlid is well
locked.
11
Large Capacity, High Speed Centrifuge 2236R

Refrigerated,High Speed Centrifuges, 2236R
Attention!Sampleweight asymmetry detection
For the safety of not only the devicebutalsothe user,there is a function that detects asymmet
ry and forcibly stops the operationwhen the sample weight is differentthan a certain amount.
3.5 Mountingthe sampletube
1.Beforeinsertingthesampletube, checkthatthereis no foreignmatteror moistureinside therotorholeor
bucket.
▶If thereis any foreignmatteror moisture,be sureto removeit with adrycloth.
2. Thesampletube mustbe placedand mountedsymmetrically.
▶There should be no difference in weight ofthe tube filled withthesample, and the densityshould be
s
▶Be sureto useatube dedicatedto acentrifuge.CheckMax.RCF valueforeachtube, do notusemore
than the allowedstandard.
1,000xg
Check the centrifugal f
orce strength of the sa
mple container itself
? ? ?
9,000 xg8,000xg10,000xg
12
Large Capacity, High Speed Centrifuge 2236R

Operating Manual
□SPEED
Therotationspeedis expressedin RPM/RCF, and the maximumRPMis 22,000 and themaximumRCFcanbe
setup to 54,111 xg.Also,the maximumRPM/RCF value accordingto the rotor isautomaticallycalculated and di
splayedasa setvalue (setspeed).
□TIME
Thetimecan besetin hours, minutesand seconds,up to 99hours59minutes59 secondsorcontinuously
(display window:0:00:00).Also,afterstartingtheoperation,thetimechangeappearsas ALL(timeincreaseswith
start)and Atthe setSpeed(timeincreasesafterreachingthesetspeed).
□TEMP
temperature canbe set from-20℃ to 40℃. It also supports a fast cool functionthat canreach a set
□ACC/DEC
In the caseof startand stop,accelerationspeedcanbe setin 9stepsand decelerationspeedin 10 steps(natural
deceleration:0).
□Start/Stop
Forstartandstopmotion.
4. Methodof usageand precautions
4.1ControlPanel
13
Large Capacity, High Speed Centrifuge 2236R

Refrigerated,High Speed Centrifuges, 2236R
□OPEN DOOR
Ifthelid is closed,youcanopen thelid.
□MENU
Youcansave/load/deleteprograms,operationlog information,andMULTISTEP.
□INFORMATION
Youcancheckproductinformation.
1. PressonINFORMATION icon( )
□Rotor List
Therotornumberinstalledin thechamberis displayed.
1. Pressthe Rotor No.(ex.GRF-L-50-6).
▶Rotor No.Press→movetoRotorListscreen
[2236RInformationScreen]
[Rotor ListScreen
14
Large Capacity, High Speed Centrifuge 2236R

Operating Manual
□Setting
Volume.YoucansetTouchCalibration, Clock,and PW.
1. Presson theSetting ( )
▶Click theSettingiconto displaytheoptionscreen.
2. Pressthe desiredsettingmode.
▶Whenyouclickthe settingmode,anew window
appears.
□Volume
Youcansetthevolumeand soundlevel.
□Touch Calibration
Youcanadjust the touchscreensensitivity.
15
Large Capacity, High Speed Centrifuge 2236R

Refrigerated,High Speed Centrifuges, 2236R
□CLOCK
Youcansetthecurrenttime.
□SET PW
Youcansetapasswordforthestartupscreen.
▶WhenSET PW is set,theloginscreenappearswith poweron.
16
Large Capacity, High Speed Centrifuge 2236R

Operating Manual
4.2 Speedsetting
Rotationspeedis displayedin RPM/RCF, RPM canbe setup to 22,000 and RCF canbe setup to
54,111xg.TheRCF valuesforRPMareinterlockedand automaticallycalculated.
1. PressSPEED
▶The SPEEDsettingscreenappears.
2. Afterpressingthe RPMor RCFdisplay, enter the
setting valueusingthenumerickeypadandselectOK.
▶IfyouclickOK, the speedsetting valueisfinallysaved.
▶Ifyouenter thesettingvalue incorrectly, pressthe
[CLEAR]button. RPM displayis changedto0.
17
Large Capacity, High Speed Centrifuge 2236R

Refrigerated,High Speed Centrifuges, 2236R
4.3 Timesetting
Thetimecanbe set in "hours", "minutes"and "seconds",and canbe setup to 99:59:59 secondsor continuously (d
isplay window 0: 00:00).Also,after starting the operation, the timechangeappears as Normal(timeincreases wit
hstart)andat setSPEED (timeincreasesafterreachingsetspeed).
1. PressonTIME
▶The TIMEsetting screenappears.
2. PressHH:MM:SSindividually onthe time
display, enter the setting value using thenumeric
keypadandpressOK.
▶If you clickOK, the time setting value is finally
set
▶Ifyouenter thesetting value incorrectly, press
the [CLEAR]button. RPM display ischangedto 0
Attention! Timemodedefinition(ALLmode/atsetSPEED mode)
For accurate timemanagement,the timemode can be set to ALLmode
(time increases with start) and at set SPEED mode (time increases after
reachingthe setspeed).
▶ALL mode: From t0 to t2
▶at set SPEED mode::From t1 to t2
18
Large Capacity, High Speed Centrifuge 2236R

Operating Manual
3. Fast cooloperation
1. After entering the settemperatureaccording to
the generaltemperaturesettingmethod,press
Fast Cool whenquick coolingisrequired.
▶It reachesthesettemperaturewhile rotating at 1,000
rpm.(Slow rotation acceleratesair circulation in the
chamberto speedcooling)
2.Selectthedesiredtemperaturebymovingthe
temperaturescalebar left/right, thenpressOK.
▶Whenyou press OK,thetemperature
setting value is finallysaved.
Attention! Fast Cooloperation
Thefastcoolfunctionworkswiththerotormounted.Do notusethefastcoolfunctionwhentherotoris not
fullysecuredorthe sampletube isinsertedasymmetrically.
19
Large Capacity, High Speed Centrifuge 2236R
Temperature4.4setting and fast cooloperation
1. Temperaturesetting
Thetemperaturesettingrangecanbesetfrom-20℃to 40℃.In addition,fortemperature-sensitivesamples,
Thisbuttonsupportsthe FastCoolfunctionto reachtemperaturesbelowroomtemperatureinashort
1. PressonTEMP
▶TheTemperaturesetting screenappears

Refrigerated,High Speed Centrifuges, 2236R
4.5 Acceleration/deceleration(ACC/DEC)setting
Accelerationspeedcanbe setup to 9stepsand decelerationspeedup to 10 steps(naturaldeceleration:0) to protectsensitive
samplesandcleanlayerseparation.
1. Presson ACC/DEC
▶TheACC/DEC setting screenappears.
2.SelectACCor DECvalueto setand pressOK.
▶If youclickOK, the ACC/DECsettingvalueisfinally
saved.
▶ACC(DEC) canbe setfrom1(0)to 9levels.
(ACC 9: Fastestaccelerationsection, DEC0,
naturaldeceleration)
20
Large Capacity, High Speed Centrifuge 2236R

Operating Manual
4.6Save,recallanddeleteprograms
1. If you wantto savethe program,enter the settingvalues
(speed,time,temperature,acceleration/deceleration,etc.),
press MENU, and selectSAVEPROG.
2.Enterthename/user/ passwordand clickOK.
▶A“Saving Program:Are you sure?” messagewindow
appears.
3.ClickOKif youwantto save.
▶ClickOKto savethe program.
▶Ifyouwanttocancelthesavedvalue,press
CANCEL.
Savetheprogram
Whenoperatingthe deviceundervarious conditions, settingvaluessuchas speedand timecan
be savedin advanceand thenrecalledand usedimmediatelyasneeded.
21
Large Capacity, High Speed Centrifuge 2236R
