GYROZEN MicroCentrifuge mini User manual

1
MicroCentrifuge, mini
Personal Micro Centrifuge
mini
User’s Manual
Manufacturer: GYROZEN Co., Ltd.
[email protected]
http://www.gyrozen.com
UM-mini(E)(Rev. )
1F & 5F, 16 Arayuk-ro, Gimpo-si, Gyeonggi-do, KOREA
Tel) [phone], FAX) [phone]
2

2
MicroCentrifuge, mini
Content
1. Meanings of Symbols & Safety Precautions....................................................................................................3
1.1 Safety Labels on Instrument........................................................................................................................3
1.2 Safety Precautions .............................................................................................................................................3
2. Product Description & Technical Specifications ............................................................................................5
2.1 Product Description..........................................................................................................................................5
2.2 Technical Specifications ..................................................................................................................................5
3. Installation...........................................................................................................................................................................6
3.1 Power On/Off and Door Release...............................................................................................................6
3.1.1 Power On/Off .........................................................................................................................................6
3.1.2 Door Release ...........................................................................................................................................7
3.2 Rotor Coupling and Disassembling .........................................................................................................8
3.2.1 Fixed Angle Rotor ................................................................................................................................8
3.3 Positioning of Sample Tubes .......................................................................................................................9
4. Operation .......................................................................................................................................................................... 10
4.1 Key Functions of Control Panel............................................................................................................... 10
4.2 Setting Speed .................................................................................................................................................... 10
4.2.1 Setting the RPM Value ................................................................................................................... 11
4.2.2 Setting the RCF Value ..................................................................................................................... 12
4.3 Setting the Time Value................................................................................................................................. 13
4.4 Start/Stop ............................................................................................................................................................ 14
4.5 Pulse ....................................................................................................................................................................... 14
4.6 Emergency Door Open................................................................................................................................. 15
5. Maintenance .................................................................................................................................................................... 16
5.1 Outer part of Instrument............................................................................................................................ 16
5.2 Chamber ............................................................................................................................................................... 16
5.3 Shaft ....................................................................................................................................................................... 16
5.4 Rotor....................................................................................................................................................................... 16
5.5 Transportation of Instrument................................................................................................................... 16
6. Trouble Shooting .......................................................................................................................................................... 17
6.1 Check List............................................................................................................................................................. 17
6.2 Error code ............................................................................................................................................................ 18
7. Ordering Information for Rotors & Accessories ........................................................................................ 20
8. CE........................................................................................................................................................................................... 21

3
MicroCentrifuge, mini
This manual is for the users who operate the device for the first time.
This manual provides information on the detailed instructions, precaution, troubleshooting
and maintenance care.
1. Meanings of Symbols & Safety Precautions
1.1 Safety Labels on Instrument
The labels on the instrument represent safety instructions and directions.
Symbol
Meaning
Symbol
Meaning
Indicate a hole for
manual door opening
in case of emergency
Attention and warning for
electric shock
Symbol
Meaning
Attention and warning for correct way of
sample balancing in the rotor.
Attention and warning for rotor coupling.
Attention and warning for door opening and
closing.
1.2 Safety Precautions
Before using the instrument, please read this operation manual to ensure correct usage.
Incorrect handling of the instrument could possibly result in personal injury or physical
damage on the instrument or its accessories.
1. ALWAYS locate the instrument on a flat, rigid and stable table capable of withstanding
the weight of the instrument and its spinning operation.
2. ALWAYS make a safety zone of 30 cm around the centrifuge to indicate that neither
hazardous materials nor persons should be permitted within the area during operation.
ALWAYS position the instrument with enough space on each side of instrument to
ensure proper air circulation.
3. ALWAYS install the instrument within a temperature and humidity controlled environment.
(Permissible ambient temperature: +5°C ~ +35 °C, Relative humidity: ≤ 85%)
4. Before connecting the power, check the rated voltage.
5. Should not use unapproved rotors and associated accessories.
Only use rotors from Gyrozen Co., Ltd. with appropriate centrifugal tubes and

4
MicroCentrifuge, mini
suitable adaptors to embrace sample containers tightly enough inside rotors.
6. Before operating the instrument, check if the rotor and the rotor lid are securely fastened.
Should operate the instrument with a rotor properly installed and secured to the
motor shaft.
7. Mount the rotor on the motor shaft properly, check it with spinning manually.
8. Do not stop the rotor by touching with hand during the instrument is running.
9. Emergency door open should be performed only when spinning is completely stopped.
10. Should not exceed the rated speed or specific gravity. Samples whose density is greater
than 1.2g/ml must have reduced maximum rotational speed to avoid rotor failure.
11. The sample content should not exceed 80% of total capacity of a tube. Otherwise, it
would cause spillage of sample fluid and even the tube breakage.
12. ALWAYS load the tubes symmetrically with evenly weighted samples to avoid rotor
imbalance. If necessary, use the water blank to counterbalance the unpaired sample.
13. The operation speed should not exceed the highest value of the individual guaranteed g-
forces of each centrifuge, rotor, bucket or adaptors and sample container, especially the
guaranteed g-force of sample container should not be neglected.
14. The rotors should be cleaned and kept dry after every use for longer life and safety.
15. ALWAYS disconnect the power supply prior to maintenance care and service to avoid
electrical shock.
16. ALWAYS use proven disinfection procedures after centrifuging biohazardous materials.
17. Should not centrifuge flammable, toxic, radioactive, explosive, or corrosive materials.
18. When it is necessary to use toxic or radioactive materials or pathogenic micro-organisms
which belong to the Risk Group II of WHO: “Laboratory Bio- safety Manual,” should
follow national regulations.
Do not place dangerous materials within 30 cm distance around the instrument, and that is also
recommended by IEC 61010-2-020.
Use the emergency door open function only when the door button on the control panel is dumb
under the condition of complete stop of rotor running.
Never try to open or move the instrument if it is not completely stopped.
If the power input is more than +/- 10% of the recommended voltage or fluctuates frequently, it may
cause malfunction of the instrument and often result serious damage.
Install the instrument at the place without any kinds of corrosive gases.

5
MicroCentrifuge, mini
2. Product Description & Technical Specifications
2.1 Product Description
2.2 Technical Specifications
Max. RPM/RCF
13,500 rpm/ 12,300 xg
(GRF-m2.0-12)
6,000 rpm/ 1,850 xg
(GRA-s0.2-32)
Max. capacity
12 x 2.0 ml tubes
4 x 8-tube PCR strips
Time control
Pulse or timed ≤30 min
RCF/RPM conversion
Yes
Noise level (dependent on rotor)
≤56 dB
Acc. time to max. speed
≤12 sec
Dec. time from max. speed
≤16 sec
Parameters on display window
RPM(RCF), Oper Status, Door Open/Close, Min(sec)

6
MicroCentrifuge, mini
Display
Blue LCD
Safety lid lock
Yes
Automatic door release at completion
Yes
Power supply (V/Hz)
220V/50~60Hz (110V optional)
Power Requirement (VA)
110VA
Dimension (W x D x H)
208 x 245 x 145 mm
Weight without rotor
4.4 kg
CE MARK
Yes
Cat. No.
GZ-1312
Cat No. GZ-1312, Microcentrifuge includes Fixed Angle rotor GRF-m2.0-12 and 12 of
0.2ml adaptors.
The 0.5ml adaptors and PCR tube rotor is optional.
3. Installation
3.1 Power On/Off and Door Release
3.1.1 Power On/Off
Action
1
Connect the AC power cord to the
power socket on the back of the
instrument and put the plug into the
outlet.
▶Check the proper power.

7
MicroCentrifuge, mini
Note!
The door is not opened while the instrument is running.
If the door is opened, the instrument could not be operated even with pressing the ‘Start’
button.
Power Failure: If there is any power failure during the operation, door is not opened with
‘Door’ button. Door can be opened only when the operation is completely stopped and
the power is on again. If you want to open the door at the power failure, please refer to
‘4.6 Emergency Door Open’.
2
Turn on the instrument by pressing the
power switch on the back of the
instrument. Turn on the switch [ I ].
3.1.2 Door Release
For door opening, [DOOR] button is used.
Display shows the status of door (open , closed ).
Action
1
Press the [DOOR] button to open the
closed centrifuge door ( ).
▶When the door is open, the display
status changes from to .
▶The door is automatically opened
with end alarm when the operation is
completed.

8
MicroCentrifuge, mini
Note!
When the PCR rotor is coupled, please do not speed over 6,000 rpm/2,400 rcf.
3.2 Rotor Coupling and Disassembling
3.2.1 Fixed Angle Rotor
Action
1
Before coupling a rotor, clean the
motor shaft, rotor, and chamber with
soft dry towel.
▶If you find any foreign substances,
they must be removed from the motor
shaft, rotor and chamber.
2
Mount a proper rotor into the motor
shaft and fix it using Rotor Locking Nut.
▶To assemble the rotor, rotate the
Rotor Locking Nut clockwise until
tightly assembled.
▶To disassemble the rotor, rotate the
Rotor Locking Nut counterclockwise.
▶Grasp the rotor with one hand and
assemble or disassemble the rotor
using the Rotor Locking Nut.
3
After placing the sample tubes into the
holes of the rotor, close the rotor lid
until hearing clank shut.
▶When you open the lid, lift the
snap-fit knob.

9
MicroCentrifuge, mini
3.3 Positioning of Sample Tubes
Action
1
2
Before loading sample tubes, check the water
drop or dirt in the rotor hole or inner adaptor.
▶If you find any water drops or dirt in the
rotor hole or adaptor, remove them with soft
and dry cloth.
The sample tubes should be placed in the rotor
holes in a balanced way.
▶The sample tubes should be loaded
symmetrically with the density and the weight
considered to avoid imbalance.
▶In case the number of samples cannot make
balance in weight, please use control tubes.
Otherwise, it can cause noise or vibration, which
may damage the instrument.
▶Only use appropriate centrifugal tubes and
do not exceed the speed beyond the tube’s max
g-strength.
▶If the sample contents exceed 80% of total
capacity of the tube, it may cause spillage of the
sample and the tube breakage. For safety, fill
the 70~80% of the tube volume at the
maximum.

10
MicroCentrifuge, mini
4. Operation
4.1 Key Functions of Control Panel
Display Window
Shows speed, time, status of running and the status of door opening or closing.
RPM/RCF Modes are displayed as rpm and rcf.
While running, is flickering.
appears when the Door is opened and appears when the Door is closed.
Time is displayed as ‘min’
Setting Buttons
When setting up the RPM/RCF and Time, you can put the set value with up (▲) and
down (▼) button.
Function Buttons
Door For opening instrument door
Pulse For quick spin down
Start/Stop Commend start and stop operation
4.2 Setting Speed
The rotation speed is indicated as RPM (Rotation Per Minute) / RCF (Relative Centrifugal
Force).
The speed range of mini is 1,200~13,500 rpm and 100~12,300 x g.
Display value: multiply 1,000 to check real value. (Example: RPM display value 13.5
indicates RPM 13,500.)

11
MicroCentrifuge, mini
4.2.1 Setting the RPM Value
Action
1
Press the [RPM/RCF] once.
▶The RPM mode is activated by
pressing [RPM/RCF].
▶If the RCF mode is selected, press
[RPM/RCF] once more.
▶The input RPM value flickers on the
display window and can be set here.
2
Press the [▲▼] buttons to change
input value.
▶RPM setting unit: 0.1 unit
(0.1=100rpm)
▶ After 5 seconds from pressing the
input value, the setting value is saved.
▶ If you want to check the input value,
press [RPM/RCF] button.
▶ If you do not press the [▲▼]
button for 5 seconds, the setting mode
is cleared.

12
MicroCentrifuge, mini
4.2.2 Setting the RCF Value
Action
1
Press [RPM/RCF] twice.
▶The RCF mode is activated by
pressing [RPM/RCF] twice.
▶If the RPM mode is selected, press
[RPM/RCF] once more.
▶The input RCF value flickers on the
display window and can be set here.
2
Press the [▲▼] buttons to change input
value.
▶RCF setting unit: 0.1 unit
(0.1=100rcf).
▶After 5 seconds from pressing the
input value, the setting value is saved.
▶If you want to check the input value,
press [RPM/RCF] button.
▶If you do not press the [▲▼] button
for 5 seconds, the setting mode is
cleared.
Note!
When the PCR rotor is coupled, please keep in mind that do not over speed at the max.
6,000 rpm/2,400 rcf.

13
MicroCentrifuge, mini
4.3 Setting the Time Value
Time control: 1 min. ~30 min.
Time setting unit: 1min.
Action
1
Press the [TIME] button once.
▶‘min’ on LED is flickering.
2
Press the [▲▼] buttons to change
input value.
▶After 5 seconds from pressing the
input value, the setting value is saved.
▶If you do not press the [▲▼]
button for 5 seconds, the setting mode
is cleared.

14
MicroCentrifuge, mini
4.4 Start/Stop
Action
1
After setting RPM/RCF and Time, press
[Start/STOP] button.
▶The running starts only when the
door is closed.
▶In case of pressing the [Start /Stop]
button while running, the running is
stopped
4.5 Pulse
It is for quick spin down.
Action
1
Touch the [Pulse] button.
▶If you press ‘Pulse’ button and
release at the point you want to stop,
the centrifuge decelerates immediately.
▶When the running is stopped, the
door is opened automatically with
beeping sound.

15
MicroCentrifuge, mini
4.6 Emergency Door Open
When the door of the instrument is not opened automatically or by pressing the [Door]
button due to an accidental power shut-off or any unexpected causes, users can
manually open the door by following the instruction.
Action
1
Check if the rotor in the centrifuge is
completely stopped.
2
After pulling the instrument forward
about 10cm, find the “Emergency Door
Open Hole” at the bottom of the
instrument
3
Insert spikes (a car key, scissors and etc.)
2~3 cm into the “Emergency Door Open”
hole and pull the spikes at the opposite
direction of the arrow.
▶After the door is opened, it is
recommended to wait until electricity
gets back to normal.
Caution!
The manual door release should be performed only when spinning is completely stopped.
If not, it could bring about harmful damage to the operators or the samples.

16
MicroCentrifuge, mini
5. Maintenance
5.1 Outer part of Instrument
1. Clean the outside of the instrument with dry soft cloth. If necessary, dip the cloth in
neutral detergent and clean any contaminated area. Keep completely dry after cleaning.
2. Do not use any volatile chemicals such as alcohol, benzene, benzole, and thinner, etc.
3. Be careful not to make scratches on the surface of the instrument.
Scratches may cause corrosion on the surface of the instrument.
Any parts with rust should be cleaned with neutral detergents and kept dry.
5.2 Chamber
1. Keep dry inside the chamber after every use.
2. If the chamber is contaminated, clean contaminated area with the cloth dipped in
neutral detergent.
5.3 Shaft
1. Always keep the motor shaft clean to avoid any imbalance problem caused by the
contaminants.
2. After using the instrument, take out the rotor from the shaft and clean the shaft with
dry soft cloth to keep dry.
3. If the rotor cannot be easily removed from the shaft, do not pull the rotor by force and
call a service engineer authorized by GYROZEN Co., Ltd.
5.4 Rotor
1. If any parts become contaminated, clean them with soft wet cloth and keep the rotor
dry.
2. Be careful not to make scratches inside or on the surface of rotors. Any small scratches
can cause corrosion of the rotor and big damage to the instrument.
3. While the instrument is not used, remove the rotor from the motor shaft and stand it
upside down.
5.5 Transportation of Instrument
1. If you need to move or ship the instrument, be cautious to protect the motor shaft
from any physical impact or turbulence.
2. Do not mount a rotor in any cases of movement. Fill inside the chamber with proper
materials to keep the motor shaft on place and not to be influenced by physical
pressure.

17
MicroCentrifuge, mini
6. Trouble Shooting
6.1 Check List
If any problems occur in the centrifuge, please check the following list before contact
your local GYROZEN partner.
Symptom
Checklist
Power failure
Make sure the AC Power cord completely connects the instrument
to the power outlet. Check the power switch is on. Please refer to
[3.1.1 Power On / Off].
Can’t be started.
If the door is not closed completely, the instrument does not run.
Check the door status on the display window and close the door
completely if not. Please refer to [3.1.2 Door Release].
Can’t open the door.
If the power is out, check the main fuse for the laboratory to supply
the power. If it is not solved shortly, open the door with the manual
door release tool. Please refer to [4-6. Emergency Door Open].
Can’t close the door.
Remove the dirt at the door latch and keep the door completely
closed.
If the door is not closed by any reasons, please contact GYROZEN
service team.
Noise and vibration
during running
Please check if the table and the instrument keep level.
Please recheck the three coupling status on the following.
1. Balanced coupling of the rotor to the motor shaft
2. Complete fixing of the rotor by the Rotor Locking Nut
3. Fastening of the Rotor Lid and the rotor. Please refer to [3.2
Rotor Coupling and Disassembling].
Check the balanced positioning of the samples in the rotor. Please
refer to [3.3 Positioning of Sample Tubes].

18
MicroCentrifuge, mini
6.2 Error code
The following error messages comes up with 5 times beeping sound. Check into the
current status by referring to the following information.
Possible Causes
Actions
Error 1
Motor
If the speed does not reach 200 rpm within 2 seconds
after motor starts to operate, this message may appear.
Check whether the motor is normally working or not.
If the error message does not disappear, please contact
a Service Engineer of your local GYROZEN’s partner.
Error 2
Door Open
If the door opens while spinning or has any trouble in
the door sensor, this message may come up.
Remove the dirt at the door latch and close the door
completely. Check the door closing status on the display
window.
If the error message does not disappear, please contact
a Service Engineer of your local GYROZEN’s partner.
Error 3
Motor
Overheating
If the motor is overheated, this message may come up.
Keep off the power supply for an hour, and turn on the
power to check up the instrument.
If the error message does not disappear, please contact
a Service Engineer of your local GYROZEN’s partner.
Error 4
Low Voltage
If the power input (V/Hz) is at least 10% lower than the
recommended power, this message may come up.
Turn off the power supply and check the voltage of the
Power supply (V/Hz).
Use AVR to provide proper power.
Error 5
High Voltage
If the power input (V/Hz) is at least 10% higher than the
recommended, this message may come up.
Turn off the power supply and check the voltage of the
Power supply (V/Hz).
Use AVR to provide proper power.
Error 6
Overspeed
If the instrument spins faster than allowed (1,000 rpm
higher than the set speed), it may cause overload to
motor capacity or any trouble in the output of motor.
Turn off and on the power supply to check up the

19
MicroCentrifuge, mini
instrument.
If the error message does not disappear, please contact
a Service Engineer of your local GYROZEN’s partner.
Error 7
System
If the installed software has any bugs, this message may
come up.
Contact a Service Engineer of your local GYROZEN’s
partner and get the firmware upgrade.
Wire disconnection or tuning of the instrument must be
performed only by a Service Engineer authorized by
GYROZEN Co., Ltd.

20
MicroCentrifuge, mini
7. Ordering Information for Rotors & Accessories
