Hantek DPO7000 Series Installation and operation manual

DPO7000 series
Digital oscilloscope
Performance Verification Guide
202304

Warranties and Declarations
Copyright
The copyright of this document belongs to Qingdao Hantek Electronics Co., LTD.
Statement
Qingdao Hantek Electronics Co., Ltd. reserves the right to amend this document without prior notice.
Qingdao Hantek Electronics Co., Ltd. promises that the information provided is correct and reliable but
does not guarantee that this document is free from errors. Before using this product, please make sure
that the specifications of relevant technical documents are the latest effective version. If you use
documents or products of Qingdao Hantek Electronics Co., LTD and need products, patents or works
of third parties to cooperate with them, you shall be responsible for obtaining the consent and
authorization of the third parties. The above consent and authorization shall not be the liability of
Hantek.
Product certification
Hantek certified DPO series oscilloscope to meet China's national industry standards and has passed
the CE certification.
Contact us
If you have any questions when using the products of Qingdao Hantek Electronics Co., LTD., you can
obtain service and support through the following ways:
Email: [e-mail], s[email protected]
Website: http://www.hantek.com

Safety requirement
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Performance Verification Guide
1
1 Safety requirement
1.1 Summary of general security issues
Read the following safety precautions carefully to avoid injury and to prevent damage to
this product or any product connected. To avoid possible dangers, please use this
product in accordance with the regulations.
⚫Only professionally authorized personnel can perform repairs.
⚫Use the right power cable.
Use the power cable approved by the country in which the product is used only.
⚫Connect and disconnect correctly.
Before connecting the probe to the circuit being measured, please connect the
probe to the oscilloscope first. Before disconnecting the probe from the oscilloscope,
please disconnect the probe and the circuit under test first.
⚫Ground the product.
To avoid electric shocks, the product is grounded through a grounding conductor of
the power cable. The grounding conductor must be connected to the ground before
connecting the input or output terminals of the product. Ensure that the product is
properly grounded.
⚫Connect the probe properly.
The ground wire of the probe is the same as the ground potential. Do not connect
the ground wire to high voltage.
⚫View all terminal rating values.
To avoid fire or excessive current, please check all rating values and signs on the
product. Please consult the product manual for details of the rating values before
connecting the product.
⚫Do not operate with the cover open.
Do not run the product with the cover or panel open.
⚫Avoid circuit exposure.
Do not touch exposed connectors and components after power is switched on.
⚫Do not operate if the product is suspected to be faulty.
If you suspect that the product has been damaged, please ask qualified
maintenance personnel to check it.

Safety requirement
EN
DPO7000 Performance Verification Guide Copyright © Qingdao Hantek Electronics Co., LTD
2
⚫Maintain proper ventilation.
⚫Do not operate in a humid environment.
⚫Do not operate in inflammable or explosive environment.
⚫Please keep the product surface clean and dry.
Warning:
Equipment that meets Class A requirements may not provide adequate protection
for broadcast services in residential environments.
1.2 Security terms and signs
Security terms in this manual:
Warning:
Indicates that the operation may not cause immediate damage to you.
Note:
Indicates that the operation may cause damage to the product or other property.
Safety terms on products:
Warning:
Indicates a potential hazard may be caused to you if you do not perform this
operation.
Safety signs on the product:
Hazardous
Voltage
Safety
Warning

Document overview
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Performance Verification Guide
3
2 Document overview
This document describes how to quickly understand the front and back panels, user
interfaces, and basic operation methods of the DPO7000 series digital oscilloscopes.
Tip:
The latest version of this manual can be downloaded at (http://www.hantek.com).
Document number:
202304
Software version:
Software upgrade may change or increase product functionalities, please pay attention
to Hantek website for the latest version.
Document format conventions:
1 Virtual keys and main interface icons
Use [name] to represent virtual keys and main interface icons. For example, [Utility] is
for .
2 Menu
Use "menu text (bold) + color" to represent a label or a menu option. For example, I/O
means to click the "I/O" option on the current operation interface to enter the function
configuration menu of "I/O".
3 Operation steps
Use "->" to represent the next step. For example, [Utility] ->Language means click
Utility label before clicking Language menu.
Document content conventions:
DPO7000 series tablet oscilloscope consists of the following models. Unless otherwise
specified, this manual uses DPO7504E as an example to describe the DPO7000 series
and basic operations.
Model
Bandwidth
Channel
Signal source
Digital Channels
DPO7104E
100MHz
4
1
16
DPO7102E
100 MHz
2
1
16
DPO7104C
100 MHz
4
-
-

Document overview
EN
DPO7000 Performance Verification Guide Copyright © Qingdao Hantek Electronics Co., LTD
4
Model
Bandwidth
Channel
Signal source
Digital Channels
DPO7102C
100 MHz
2
-
-
DPO7204E
200 MHz
4
1
16
DPO7202E
200 MHz
2
1
16
DPO7204C
200 MHz
4
-
-
DPO7202C
200 MHz
2
-
-
DPO7354E
350 MHz
4
1
16
DPO7352E
350 MHz
2
1
16
DPO7354C
350 MHz
4
-
-
DPO7352C
350 MHz
2
-
-
DPO7504E
500 MHz
4
1
16
DPO7502E
500 MHz
2
1
16
DPO7504C
500 MHz
4
-
-
DPO7502C
500 MHz
2
-
-

Overview
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Performance Verification Guide
5
3 Overview
3.1 Preparation before testing
Before conducting testing, users need to first prepare as follows:
1. Power on
2. Warm up (run the oscilloscope for at least 30 minutes)
3. Self correction
Power on
When the oscilloscope is powered on, press the power button in the lower left corner of
the front panel to start the oscilloscope. During the startup process, the oscilloscope
performs a series of self checks, and the startup screen appears after the self check is
completed.
If the oscilloscope cannot start normally, please refer to the "Troubleshooting" section in
the “DPO7000 User Manual”to identify and resolve the cause, and then perform self
calibration and performance testing.
Preheat
Turn on or run the oscilloscope for at least 30 minutes.
Self correction
Before calibration, please ensure that the oscilloscope has been preheated or operated
for more than 30 minutes.
1. Firstly, confirm to disconnect all input channels.
2. Enter the oscilloscope function, click on [Utility] -> More -> System -> SelfCal
menu and follow the instructions on the display screen to perform calibration.
Calibration takes approximately 2-3 minutes.
3. Under the oscilloscope function, click on the [Acquire] ->Acquisition method
menu, set the acquisition mode to average, and set the average number of times to
16.
4. Set the vertical gear of each channel to 2 mV/div and check the offset degree of
each channel waveform. If the deviation is greater than 0.5 div, recheck the
surrounding area for interference signals, etc., and perform calibration again after
checking for errors.

Overview
EN
DPO7000 Performance Verification Guide Copyright © Qingdao Hantek Electronics Co., LTD
6
3.2 Record of test results
When executing each test, the test results can be recorded and retained in the test
record table after each test item. In addition, the appendix section of this manual also
provides additional test result record forms. This table lists various tests and their
corresponding performance indicator limits, and provides spaces for users to record test
results.
Hantek suggests that you prepare a separate test record form before each test. This
ensures that the tables in this document can be reused.
3.3 Technical Parameter
In Chapter 4 of this manual, corresponding indicators are provided for each test. If you
need other technical parameters, please refer to the "DPO7000 Data Manual" (available
for download from the Hantek website at www.hantek.com).
Tips:
All indicators are valid when the oscilloscope is preheated for more than 30 minutes.

Performance verification Test
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Performance Verification Guide
7
4 Performance verification Test
This chapter takes the DPO7504E machine as an example to introduce the
performance verification and testing methods and processes of the DPO7000 series
digital oscilloscope. The testing equipment used in this manual is FLUKE5000.
Note:
1. Before performing performance verification tests, please ensure that the
oscilloscope passes self check and self calibration.
2. Before performing each performance verification test below, please ensure that the
oscilloscope has been preheated for at least 30 minutes.
3. Before or at the end of each performance verification test below, please set the
oscilloscope to the default settings.
4.1 Impedance Test
4.1.1 Index
Input impedance
Analog channel
1MΩ：0.99MΩ至 1.01MΩ
4.1.2 Test Connection Diagram
4.1.3 Test Procedure
1. Connect the active signal probe of Fluke5000 to the CH1 channel of the
oscilloscope, as shown in the above figure.
2. Configure oscilloscope:
⚫Click on [CH1] in the button area to open the CH1 channel.
⚫Set the vertical gear of CH1 to 100 mV/div.
3. Open Fluke5000, set its impedance to 1 M Ω, select the resistance measurement
function, read and record the measured resistance value.

Performance verification Test
EN
DPO7000 Performance Verification Guide Copyright © Qingdao Hantek Electronics Co., LTD
8
4. Adjust the vertical gear of oscilloscope CH1 to 500 mV/div, read and record the
resistance measurement again.
5. Close CH1. Measure the impedance of CH2, CH3, and CH4 in sequence using the
above method and record the measurement results.
4.1.4 Test Record Form
Channel
Vertical gear
Test Result
Test Scope
Passed
or not
CH1
100mv/div
0.99 MΩ to 1.01 MΩ
500mv/div
CH2
100mv/div
500mv/div
CH3
100mv/div
500mv/div
CH4
100mv/div
500mv/div
4.2 DC Gain Accuracy Test
4.2.1 Index
DC Gain Accuracy
Index
±3% ×Fullscale
Full scale=8 * Current vertical gear
4.2.2 Test Connection Diagram

Performance verification Test
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Performance Verification Guide
9
4.2.3 Test Procedure
1. Connect the active signal probe of Fluke5000 to the CH1 channel of the
oscilloscope, as shown in the above figure.
2. Set the impedance of Fluke5000 to 1 M Ω.
3. Output a DC signal with a voltage V1 of+3mVDC through Fluke5000.
4. Configure oscilloscope:
⚫Open the CH1 channel on the oscilloscope interface.
⚫Click on the Attenuation menu and set the probe attenuation ratio to 1X, with
a default value of 1X.
⚫Set the vertical gear to 1mV/div.
⚫Set the horizontal time base to 1 μs/div。
⚫Set the vertical offset to 0.
5. Click on [Acquire] -> Acquisition -> Average, and then click on the Averages
menu button to set the average frequency to 32.
6. Adjust the trigger level to prevent the signal from being mistakenly triggered.
7. Click on [Meas], select the data source as CH1, select the measurement item as
the average value, and set the read average value to Vavg1.
8. Adjust Fluke5000 to output a DC signal with a voltage V2 of -3mVDC.
9. Turn on the average measurement function, read and record Vavg2.
10. Calculate the relative error of the vertical gear: | (Vavg1- Vavg2) - (V1- V2) |/full
scale × 100%。
11. Keep the other settings of the oscilloscope unchanged:
12. Set the vertical gears to 500uV/div, 2 mV/div, 5 mV/div, 10 mV/div, 20 mV/div, 50
mV/div, 100 mV/div, 200 mV/div, 500 mV/div, 1 V/div, 2 V/div, 5 V/div, and 10 V/div.
13. Adjust the output voltage of Fluke5000 to 3 times and -3 times the current vertical
gear in sequence.
14. Repeat steps 3 to 7 above and record the test results.
15. Calculate the relative error of each vertical gear: | (Vavg1- Vavg2) - (V1- V2) |/full
scale ×100%。
16. Close CH1. Test the relative errors of CH2, CH3, and CH4 gears in sequence
using the above method and record the test results.

Performance verification Test
EN
DPO7000 Performance Verification Guide Copyright © Qingdao Hantek Electronics Co., LTD
10
4.2.4 Test Record Form
Channel
Vertical
gear
Test Result
Test Scope
Passed
or not
Vavg1
Vavg2
Calculated
value
CH1
500 uV/div
±3% ×
Fullscale
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1V/div
2V/div
5V/div
10V/div
CH2
500 uV/div
±3%
×Fullscale
1 mV/div
2 mV/div

Performance verification Test
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Performance Verification Guide
11
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1V/div
2V/div
5V/div
10V/div
CH3
500 uV/div
±3%
×Fullscale
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div

Performance verification Test
EN
DPO7000 Performance Verification Guide Copyright © Qingdao Hantek Electronics Co., LTD
12
1V/div
2V/div
5V/div
10V/div
CH4
500 uV/div
±3%
×Fullscale
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1V/div
2V/div
5V/div
10V/div
4.3 Bandwidth Test
The bandwidth test verifies the bandwidth performance of the oscilloscope by testing its
amplitude loss at full bandwidth.

Performance verification Test
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Performance Verification Guide
13
4.3.1 Index
Index
Bandwidth
100MHz
±3dB
200MHz
±3dB
350MHz
±3dB
500MHz
±3dB
4.3.2 Test Connection Diagram
4.3.3 Test Procedure
1. Connect the active signal probe of Fluke5000 to the CH1 channel of the
oscilloscope and follow the test connection diagram.
2. Open Fluke5000 and set its impedance to 1 M Ω.
3. Configure oscilloscope:
⚫Click [CH1] in the button area to open the CH1 menu.
⚫Click on the Attenuation menu and set the probe attenuation ratio to 1X, with
a default value of 1X.
⚫Add a 50 ohm adapter at the CH1 channel connection.
⚫Set the horizontal time base to 500 ns/div.
⚫Set the vertical gear to 100 mV/div.
⚫Set both horizontal and vertical offsets to 0.
⚫Set the trigger level to 0 V.
4. Output a sine signal with a frequency of 1 MHz and an amplitude of 600 mVpp (V)
through Fluke5000.
5. Click on the [Meas] menu, select the data source as CH1, select the measurement
item as amplitude, read and record V1.

Performance verification Test
EN
DPO7000 Performance Verification Guide Copyright © Qingdao Hantek Electronics Co., LTD
14
6. Once again, output a sinusoidal signal with an amplitude of 600 mVpp at other
frequencies (not greater than 250MHz. The maximum frequency setting here
varies depending on the model of the oscilloscope being tested) through
Fluke5000.
7. Set the corresponding horizontal time base according to different frequencies.
8. Turn on the effective value measurement function, read and record the value (V1).
9. Calculate amplitude loss: Amplitude loss (dB)=20 ×lg (V1/V).
10. Keep the other settings of the oscilloscope in step 3 unchanged and set the vertical
gear to 200 mV/div.
11. Output a sine signal with a frequency of 1 MHz and an amplitude of 1.2 Vpp
through Fluke5000.
12. Repeat steps 5-9.
13. Keep the other settings of the oscilloscope in step 3 unchanged and set the vertical
gear to 2V/div.
14. Output a sine signal with a frequency of 1 MHz and an amplitude of 5.5 Vpp
through Fluke5000.
15. Repeat steps 5-9.
16. Close CH1. Test CH2, CH3, and CH4 in sequence according to the above testing
method and record the test results.
4.3.4 Test Record Form
Voltage
Range
Fluke Amp
Fluke Freq
Meas
Result
Range
Passed
or not
100mV/div
600mV
1MHz
-3dB to 3dB
10MHz
20MHz
50MHz
100MHz
200MHz
250MHz

Performance verification Test
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Performance Verification Guide
15
200mV/div
1.2V
1MHz
-3dB to 3dB
10MHz
20MHz
50MHz
100MHz
200MHz
250MHz
2V/div
5.5V
1MHz
-3dB to 3dB
10MHz
20MHz
50MHz
100MHz
200MHz
250MHz
10MHz
20MHz
50MHz
110MHz

Test Record Form
EN
DPO7000 Performance Verification Guide Copyright © Qingdao Hantek Electronics Co., LTD
16
5 Test Record Form
Impedance Test
Channel
Vertical gear
Test Result
Test Scope
Passed
or not
CH1
100mv/div
0.99 MΩ to 1.01 MΩ
500mv/div
CH2
100mv/div
500mv/div
CH3
100mv/div
500mv/div
CH4
100mv/div
500mv/div
DC Gain Accuracy Test
Channel
Vertical
gear
Test Result
Test Scope
Passed
or not
Vavg1
Vavg2
Calculated
value
CH1
500 uV/div
±3% ×
Fullscale
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div

Test Record Form
EN
Copyright © Qingdao Hantek Electronics Co., LTD DPO7000 Performance Verification Guide
17
500 mV/div
1V/div
2V/div
5V/div
10V/div
CH2
500 uV/div
±3%
×Fullscale
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1V/div
2V/div
5V/div
10V/div
CH3
500 uV/div
±3%
×Fullscale
1 mV/div

Test Record Form
EN
DPO7000 Performance Verification Guide Copyright © Qingdao Hantek Electronics Co., LTD
18
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
1V/div
2V/div
5V/div
10V/div
CH4
500 uV/div
±3%
×Fullscale
1 mV/div
2 mV/div
5 mV/div
10 mV/div
20 mV/div
50 mV/div
100 mV/div
200 mV/div
500 mV/div
