Hantek HT360 Series User manual

HT360 Series
Leeb Hardness Tester
User Manual
2022.12

Warranties and Representations
Copyright
The copyright of this document belongs to Qingdao Hantek Electronics Co., Ltd.
Statement
Qingdao Hantek Electronics Co., Ltd. reserves the right to modify this document without notice.
Qingdao Hantek Electronics Co., Ltd. promises that the information provided is correct and reliable
but does not guarantee that this document is error-free. Before using this product, please make sure
that the relevant technical document is the latest and valid version. If your company uses the
documents or products of Qingdao Hantek Electronics Co., Ltd. and requires the cooperation of a
third party's products, patents or works, your company shall be responsible for obtaining the consent
and authorization of the third party. The above consent and authorization are not the responsibility of
the Hantek.
Product certification
Hantek certifies HT360 series leeb hardness tester to meet China national industry standards, has
passed the CE certification, and will further complete the certification of other national standards.
Contact us
If you have any questions when using the products of Qingdao Hantek Electronics Co., Ltd., you can
obtain services and support through the following ways:
Mail box: serv[email protected] ，[email protected]
Website: http://www.hantek.com

EN
Copyright©Qingdao Hantek Electronics Co.,LTD HT360 series user manual
I
Catalog
Catalog............................................................................................................................................. I
Illustrations List............................................................................................................................IV
List of Tables.................................................................................................................................. I
1Safety requirements.............................................................................................................1
1.1 General security issues.............................................................................................................1
1.2Safety terms and symbols.........................................................................................................2
1.3 Working environment.................................................................................................................2
1.4 Maintenance and cleaning........................................................................................................4
1.5 Environmental precautions .......................................................................................................5
2Product features....................................................................................................................6
3Document Overview.............................................................................................................8
4Quick Start..............................................................................................................................9
4.1 General inspection......................................................................................................................9
4.2 Appearance and dimension......................................................................................................9
4.3 D-type impact device...............................................................................................................10
4.4 Profiled impact device.............................................................................................................10
4.5 Preparation before use...........................................................................................................12
4.5.1 Measurement...................................................................................................................................13

EN
HT360 series user manual Copyright©Qingdao Hantek Electronics Co.,LTD
II
4.5.2 Adjusting the support......................................................................................................................14
4.5.3 Charge...............................................................................................................................................15
4.5.4 Set System Language....................................................................................................................15
4.6Product introduction.................................................................................................................16
4.6.1 Front panel........................................................................................................................................16
4.6.2 Side panel.........................................................................................................................................18
4.6.3 Top panel..........................................................................................................................................18
4.6.4 User interface...................................................................................................................................18
4.7 Battery.........................................................................................................................................19
4.7.1 Battery storage ................................................................................................................................19
4.7.2 Battery replacement .......................................................................................................................19
4.8 Safety lockhole .........................................................................................................................21
5Function introduction..........................................................................................................23
5.1 Measuring interface.................................................................................................................23
5.2 System settings........................................................................................................................24
5.3 Measurement............................................................................................................................24
5.4 Save............................................................................................................................................25
5.5 Information.................................................................................................................................26
5.6 Calibration..................................................................................................................................26

EN
Copyright©Qingdao Hantek Electronics Co.,LTD HT360 series user manual
III
5.7 Printing........................................................................................................................................26
5.8 Firmware upgrade....................................................................................................................27
6Windows software ..............................................................................................................28
6.1 Software download and installation.....................................................................................28
6.1.1 Software function.............................................................................................................................28
7Troubleshooting..................................................................................................................30
8Attached table......................................................................................................................31
8.1 Attached table 1........................................................................................................................31
8.2 Attached table 2........................................................................................................................32
8.3 Attached table 3........................................................................................................................33
8.4 Attached table 4........................................................................................................................35
9Appendix...............................................................................................................................36
9.1 Appendix A: Accessories and Options................................................................................36
9.2 Appendix B: Warranty Summary..........................................................................................37

EN
HT360 series user manual Copyright©Qingdao Hantek Electronics Co.,LTD
IV
Illustrations List
Figure 3.1 Model....................................................................................................................8
Figure 4.1 Front view and side view .................................................................................9
Fig. 4.2 D-type impact device...........................................................................................10
Fig. 4.3 Profiled impact device.........................................................................................10
Fig. 4.4 Output signal of impact device..........................................................................11
Figure 4.5 Curved sample face........................................................................................12
Figure 4.6 Loading..............................................................................................................13
Figure 4.7 Adjusting the support......................................................................................15
Figure 4.8 Front Panel .......................................................................................................16
Figure 4.9 Side Panel.........................................................................................................18
Figure 4.10 Top panel.........................................................................................................18
Figure 4.11 User Interface.................................................................................................18
Figure 4.12 Opening the support.....................................................................................20
Figure 4.13 Installing the Battery.....................................................................................21
Figure 4.14 Safetyt Lockhole............................................................................................22
Figure 5.1 Measurement Interface..................................................................................23
Figure 5.2 Printer.................................................................................................................26
Figure 5.3 Printing Paper...................................................................................................27
Figure. 6.1 Connection diagram.......................................................................................28
Figure. 6.2 Upper computer user interface....................................................................29

EN
Copyright©Qingdao Hantek Electronics Co.,LTD HT360 series user manual
I
List of Tables
Table 4.1 Display error and repeatability .......................................................................11
Table 4.2 Measurement .....................................................................................................14
Table 4.3 User Interface.....................................................................................................19
Table 5.1 System menu functions....................................................................................24
Table 5.2 Measurement menu functions........................................................................25
Table 5.3 Storage menu functions...................................................................................26
Table 5.4 Print menu functions.........................................................................................27

Safety requirements
EN
Copyright©Qingdao Hantek Electronics Co.,LTD HT360 series user manual
1
1 Safety requirements
1.1 General security issues
Read the following safety precautions carefully to avoid injury and to prevent damage to
this product or any product connected to this product. To avoid possible hazards, be
sure to use this product as prescribed.
Only professionally authorized personnel should perform maintenance.
Check all terminal ratings.
To avoid fire or shock from excessive current, check all ratings and symbols on the
product. Consult the product manual for rating details before connecting the
product.
Do not operate with the cover open.
Do not run the product with the outer cover or panel open.
Do not operate the product when you suspect it is faulty.
If you suspect this product has been damaged, ask a qualified repairman to
inspect it.
Maintain proper ventilation.
Do not operate in a humid environment.
Do not operate in a flammable or explosive environment.
Please keep the product surface clean and dry.
Antistatic protection.
Static electricity may cause damage to the instrument. Test in an anti-static area
as far as possible. Before connecting the cable to the instrument, the inner and
outer conductors should be grounded briefly to release static electricity.
Use the batteries properly.
If batteries are provided, do not expose the batteries to high temperature or fire.
Keep batteries away from children. Replacing the battery incorrectly can cause an
explosion (warning: lithium-ion batteries). Only use batteries specified for this
product.
Warning:

Safety requirements
EN
HT360 series user manual Copyright©Qingdao Hantek Electronics Co.,LTD
2
Devices that meet Class A requirements may not provide adequate protection for
broadcast services in the residential environment.
1.2 Safety terms and symbols
Safety terms in this manual:
Danger:
Indicate that you may cause immediate damage if you perform this operation.
Warning:
Indicate that it may not cause immediate damage to you if you perform this
operation.
Note:
Indicate that you may cause damage to this product or other properties if you
perform this operation.
Safety symbols on the product:
Warning
1.3 Working environment
Temperature
Operating temperature: 0 ℃- 45 ℃
Storage temperature: -20 ℃- 60 ℃
Humidity
≤+104 °F (≤+40 °C): relative humidity ≤ 90%

Safety requirements
EN
Copyright©Qingdao Hantek Electronics Co.,LTD HT360 series user manual
3
106 °F ~ 122 °F (+41 °C~45 °C): relative humidity ≤ 60%
The surrounding environment is free of vibration, strong magnetic field, corrosive
medium and serious dust.
Warning:
To avoid the risk of short circuit or electric shock in the internal circuit, do not
operate in a humid environment.
Altitude
When operating and not operating: 3000m (10000 feet).
Random vibration: 0.31 g RMS at 50Hz to 500Hz, 10 minutes per axial direction.
When not operating: 2.46g RMS from 5Hz to 500Hz, 10 minutes per axial direction.
Installation (overvoltage) category
This product is powered by a main power supply conforming to installation (overvoltage)
category II.
Warning:
Ensure that no over-voltage (such as lightning) reaches the product. Otherwise,
operators may be exposed to electric shock.
Definition of install (overvoltage) category
Installation (overvoltage) class I is the signal level that applies to the measuring
terminal of the device connected to the source circuit, where measures have been
taken to limit the instantaneous voltage to a correspondingly low level.
Installation (overvoltage) class II refers to the local distribution level, which is applicable
to devices connected to the mains (AC power supply).
Degree of pollution
2 class
Definition of pollution level
Pollution Level 1: No pollution, or only dry non-conductive pollution. This level of
contamination has no effect. Examples: clean rooms or office with air conditioning.
Pollution level 2: Generally only dry non-conductive pollution occurs. Temporary
conduction due to condensation may sometimes occur. Examples: general indoor

Safety requirements
EN
HT360 series user manual Copyright©Qingdao Hantek Electronics Co.,LTD
4
environments.
Pollution level 3: Conductive pollution occurs, or dry non-conductive pollution
becomes conductive due to condensation. Examples: sheltered outdoor
environment.
Pollution Level 4: Permanent conductive contamination through conductive dust,
rain or snow. Examples: outdoor sites.
Security level
Level 1 - Grounded product
1.4 Maintenance and cleaning
Maintenance:
Do not expose the LCD to direct sunlight for a long time when storing or placing the
hardness tester.
Cleaning:
Check the instrument frequently according to the requirements of operating conditions,
and clean the external surface according to the following steps:
1) Use a lint free rag to remove the floating dust on the outside of the hardness tester.
Be careful to avoid scratching the bright filter material of the display.
2) Clean the hardness tester with a soft cloth soaked in water. For more thorough
cleaning, use a 75% isopropyl alcohol water solvent.
Note:
To avoid damaging the surface of the instrument, do not use any corrosive reagents or
chemical cleaning reagents.
Warning:
Before reenergizing, please make sure that the instrument is dry to avoid electrical
short circuit or personal injury caused by moisture.

Safety requirements
EN
Copyright©Qingdao Hantek Electronics Co.,LTD HT360 series user manual
5
1.5 Environmental precautions
The following symbols indicate that this product complies with the requirements of
WEEE Directive 2002/96/EC.
Equipment recycling:
The production of this equipment requires the extraction and use of natural resources. If
the product is discarded improperly, some substances contained in the equipment may
be harmful to the environment or human health. In order to avoid releasing harmful
substances into the environment and reduce the use of natural resources, it is
recommended to adopt appropriate methods to recycle this product to ensure that most
materials can be reused correctly.

Product features
EN
HT360 series user manual Copyright©Qingdao Hantek Electronics Co.,LTD
6
2 Product features
Product features
Apply Leeb hardness measurement principle to measure various metal materials,
including steel and cast steel, alloy tool steel, stainless steel, gray cast iron, ductile
iron, cast aluminum alloy, copper zinc alloy, copper tin alloy, pure copper, forged
steel, etc;
Realize the mutual conversion between seven kinds of hardness scales: Leeb
(HL), Brinell (HB), Rockwell B (HRB), Rockwell C (HRC), Rockwell A (HRA),
Vickers (HV) and Shore (HS);
Support tests in 5 different directions, including vertical downward, oblique
downward, horizontal, oblique upward and vertical upward;
Equipped with D-type impact device, which supports DC, DL, D+15, G and other
types of impact devices;
Support Windows connection, equipped with USB Type-C interface, which can
easily and quickly exchange data with PC;
Adopt 2.8-inch color display which can provide informative and intuitive content;
The instrument is powered by rechargeable lithium battery, which can work
continuously for no less than 80 hours. The long-life and environmentally-friendly
battery has power saving functions such as backlight time adjustment and
automatic shutdown;
Chinese and English display, which is simple and convenient;
Large capacity memory, which can store 500 data of single measurement value of
the host, including measurement value, average value, measurement date, impact
direction, times, materials, hardness system and other information;
Applicable to quality control of heat treated workpieces, rapid inspection of
workpieces with small test space such as installed mechanical or permanent
assembly parts and mold cavities, rapid inspection of multiple parts of large
workpieces, failure analysis of pressure vessels, steam turbine generators and
other equipment, the material differentiation of bearing and other parts production
lines, metal material warehouses, production line of bearing and other
components, material differentiation of metal material warehouse, and hardness
testing of machine tool guides and automobile chassis.
HT360 series portable hardness tester adopts Leeb hardness measurement principle to
detect metal hardness, which can measure various metal materials including steel and
cast steel, alloy tool steel, stainless steel, gray cast iron, ductile iron, cast aluminum
alloy, copper zinc alloy, copper tin alloy, pure copper, forged steel, etc; Realize the
mutual conversion between seven hardness scale, including Leeb (HL), Brinell (HB),
Rockwell B (HRB), Rockwell C (HRC), Rockwell A(HRA), Vickers (HV) and Shore (HS).
Adopt streamlined ergonomic structure design, equip with a support, and adopt 2.8 inch
high-definition display screen, which can display rich and intuitive information; Equip
with a large capacity memory, which can store up to 500 data. Support the optional

Product features
EN
Copyright©Qingdao Hantek Electronics Co.,LTD HT360 series user manual
7
Bluetooth printer, which is convenient for users to output test results; Support Windows
program control connection to facilitate the storage, export and printing of computer
data.

Document Overview
EN
HT360 series user manual Copyright©Qingdao Hantek Electronics Co.,LTD
8
3 Document Overview
This document is used to guide users to quickly understand the front panel, side panel,
user interface and basic operation methods of HT360 series Leeb hardness tester.
Tips:
The latest version of this manual can be accessed at (http://www.hantek.com).
Software version:
Software upgrade may change or add product features. Please follow the Hantek
website for the latest version.
Document format convention:
Key
Use icons to represent the front panel buttons. For example, represents the
"Scale" button.
1 Menu
Use "menu text (bold)+color (blue)" to indicate a menu option. For example, Measure
means clicking the "Measure" option on the current operation interface to enter function
configuration menu of “Measure”.
2 Operating Steps
Use the arrow ">" to indicate the next operation. For example, Print>Connect means
click Print and then click Connect.
Document content convention:
HT360 series Leeb hardness tester includes the following models. Unless otherwise
specified, this manual takes HT360C as an example to explain HT360 series and its
basic operation.
Model
Bluetooth
HT360
No
HT360C
Yes
Figure 1 Model

Quick Start
EN
Copyright©Qingdao Hantek Electronics Co.,LTD HT360 series user manual
9
4 Quick Start
4.1 General inspection
Check the transport package
After receiving the hardness tester, users should check the equipment according to the
following steps: check whether there is any damage caused by transportation: if the
packaging carton or foam plastic protective pad is seriously damaged, please keep it
until the whole machine and accessories pass the electrical and mechanical tests.
Check the accessories
The details of the accessories provided are described in "Appendix A: Accessories and
Options" at the end of this manual. If the accessories are found missing or damaged,
please contact the dealer responsible for this business.
Check the whole machine
If the appearance of the instrument is damaged, the instrument does not work properly,
or fails to pass the performance test, please contact the dealer in charge of this
business.
4.2 Appearance and dimension
Figure 41 Front view and side view

Quick Start
EN
HT360 series user manual Copyright©Qingdao Hantek Electronics Co.,LTD
10
4.3 D-type impact device
Fig. 2 D-type impact device
1 Supporting ring
5 Conduit
2 Impact body
6 Loading set
3 Coil
7 Release button
4 Conductor
4.4 Profiled impact device
Fig. 43 Profiled impact device
Working principle
Impact the sample surface with an impact body with specified mass at a certain speed

Quick Start
EN
Copyright©Qingdao Hantek Electronics Co.,LTD HT360 series user manual
11
under the effect of elastic force, and calculate the hardness value with the ratio of the
rebound speed and impact speed of the punch at a distance of 1mm from the sample
surface. The calculation formula is as follows:
HL=1000 * VB/VA
Where: HL - Leeb hardness value
VB -- Rebound speed of impact body
VA - Impact velocity of impact body
The output signal of the impact device is shown in the following diagram:
Fig. 4 Output signal of impact device
Technical characteristics
Serial
No
Impact
device type
Hardness value of
standard Leeb
hardness block
Indication
error
Repeatability
of indication
1
D
760±30HLD
530±40HLD
±6 HLD
±10 HLD
6 HLD
10 HLD
2
DC
760±30HLDC
530±40HLDC
±6 HLDC
±10 HLDC
6 HLD
10 HLD
3
DL
878±30HLDL
736±40HLDL
±12 HLDL
12 HLDL
4
D+15
766±30HLD+15
544±40HLD+15
±12
HLD+15
12 HLD+15
5
G
590±40HLG
500±40HLG
±12 HLG
12 HLG
6
E
725±30HLE
508±40HLE
±12 HLE
12 HLE
7
C
822±30HLC
590±40HLC
±12 HLC
12 HLC
Table 41 Display error and repeatability
This series of hardness tester meets the following standards
1. GB/T 17394. 1-2014 Leeb Hardness Test for Metallic Materials Part 1: Test Method
2. GB/T 17394. 2-2012 Leeb Hardness Test for Metallic Materials Part 2: Verification
and Calibration of Hardness Tester

Quick Start
EN
HT360 series user manual Copyright©Qingdao Hantek Electronics Co.,LTD
12
3. GB/T 17394.3-2012 Leeb Hardness Test for Metallic Materials Part 4: Calibration of
Standard Hardness Blocks
4. GB/T 17394. 4-2014 Leeb Hardness Test for Metallic Materials Part 4: Standard
Value Conversion Table
5. Design basis and standard: Technical Conditions for Leeb Hardness Tester JB/T
9378-2001
4.5 Preparation before use
Preparation of sample surface
When preparing the sample surface, the influence of heating and cold working on the
sample surface hardness shall be avoided as far as possible.
If the measured surface is too rough, measurement error will be caused. Therefore, the
tested surface must show metallic luster and be flat, smooth and free of oil stain.
Curved surface: The test surface is better to be flat. When the curvature radius R of the
tested surface is less than 30mm (type D, DC, D+15, C, E, DL impact devices) and less
than 50mm (type G impact devices), small support rings or profiled support rings should
be used for testing.
Figure 4 Curved sample face
Support of sample
1. No support is required for heavy samples;
2. For medium-sized samples, they must be placed on a flat and firm plane. The
samples should be placed stably without any shaking;
3. The sample shall have sufficient thickness, and the minimum thickness of the sample
shall comply with Table 3;
4. For the samples with surface hardening layer, the depth of hardening layer shall
comply with Table 3.
Coupling
1. For the light sample, it must be tightly coupled with the solid support, the two
coupling surfaces must be flat and smooth, the amount of coupling agent must not be
too much, and the test direction must be perpendicular to the coupling plane;
2. When the sample is a large area plate, long rod or bending piece, if the weight and
thickness are too large, it may cause distortion and instability of the sample, leading to
