Quick Reference Guide

Why Buy Harbor Breeze Ceiling Fans
●3-Speeds(Low,MediumorHigh)
●ReversibleMotorforYear-RoundComfortandEnergySavings
●TripleCapacitorSpeedControlForQuietOperation
●SiliconSteelMotor-HighestQualitySteelAvailable-ProducesLess
Heat for Longer Life
●ConcealedHardwareforEnhancedAppearance
●Double-SealedBearingsNeverNeedLubrication
●3/4”Downrod(InsideDiameter)
●PrecisionBalancedBladesandBladeArmsforWobble-FreeOperation
●ExtraSwitchCoverIncludedforUse with or without a Light Kit.
●LightKitAdaptable

●Quiet Operation
●Larger Housing
●Larger Motor (172 x 14mm or 188 x 12mm)
●Triple Capacitor Speed Control
●Die Cast Ball/Hanger Bracket for Safe Installation of Heavier Fans
●54” Lead Wires- No Splicing in Downrods up to 48”
●14 Degree Blade Pitch (Steeper Pitch for MoreAir Movement)
●“Quick and Easy” BladeAssembly
●Triple Step Heavy Duty Capacitors for Silent Operation
●54” Lead Wires- No Splicing in Downrods up to 48”
●Insulator Pad Between Motor and BladeArms
●14 Degree Blade Pitch
●Larger Motor for Longer Life
●Energy Star Rated and Labeled Ceiling Fans MoveAir 15 to 20% More
●Efficiently than a Typical Ceiling Fan
Lifetime Warranty Ceiling Fans
Lifetime Warranty Outdoor Ceiling Fans
Lifetime Warranty Builder’s Best Ceiling Fans
●Stainless Steel Hardware
●ABS Plastic Blades
●Rubber Gaskets on Switches and Downrod
●Powder Coated Paint on Inside and Outside of Motor Housing
R
●Quiet Operation
●Silicon Steel Motor
●Triple Capacitor Speed Control
●18” Lead Wire - Dual Mount Only (8” for Hugger Styles)
15 Year Warranty Ceiling Fans

4 Easy Steps Help You Choose The Most
Efficient Ceiling Fan For Your Needs
1.The size of the room determines the fan size you need (see below).
2. Select the proper mounting option:
a. For low ceilings, choose a Closemount Fan
b. For more mounting options choose the Dualmount System
3. Decide whether you need a Light Kit and how much light you require
4. Choose a style and finish to enhance your room’s décor.
Fan Sizing Guide

Fan Mounting Systems
●The Dualmount System Gives You
Three Installation Options
1. Closemount for additional clearance
in rooms with normal to low ceilings
2. Downrod for standard ceiling
3. Downrod for vaulted ceilings. Longer
downrods for vaulted ceilings are
available at Lowe’s.
●Flushmount fans are excellent for
installation in rooms with low ceilings.
Ceiling Height
For optimum performance, fan blades should be 7 to 9 feet from the floor.
Fans with blades lower than 7 feet from the floor can be a safety hazard.
The blades in standard mounts are 12 inches from the ceiling and 9
inches from the ceiling for huggers. Fans with downrods move more air
than huggers because there is more air to move between the ceiling and
the blades.

Year-Round Comfort &
Energy Savings Are A Breeze
Energy Savings
Reversible Operated Motor Gives Upward and
Downward Air Flow Providing DesiredAir Circulation
Inwarmweatheroperate
thefanCOUNTERCLOCKWISE.
Thiscreatesadowndraftwhichgivesa
windchilleffectto improvetheefficiency
ofyourairconditioner.
Incoolweatheroperatethefan
CLOCKWISE.Thiscreatesanupdraft
whichcirculatesthehotairtrappedatthe
ceilingandpushesit downto provide
even,comfortableheat.
All Harbor Breeze Ceiling Fans
Have a 3-Speed Reversible Motor
for Year Round Comfort
Look for this Logo on Select Ceiling Fans

Accessories Let You Get
The Most Out Of Your Ceiling Fan
Item # 43147
Model # RC103L
Universal Remote Control
3-Speeds, Variable Light
Control, Instant Off Button
Item # 103186
Model # TRC100L
Universal LCD Remote Control
Control ByTimer,Thermostat Or
Manually, Variable Light Control
Item # 103185
Model # WC100L
Wall Command Remote Control
Uses 2 Wires, 3-Speeds, Dimmer,
Instant Off Button
Item # 130622
Model # WM-7WWL
4-Speed Fan Control, Slider Style
Buttons, Variable light Control
(requires 3 wires in wall)
Accessories Are Available To Allow You To Enhance
The Beauty Of Your Harbor Breeze FanAnd Adapt It To Your Home.
●Light Kits
●Fan Hangers
●Down Rods
●Fan Speed/Light Controls
●Pull Chains/Tassels
●Ceiling Medallions
●Replacement Glass
●Fan Light Bulbs

For Customer Service, Technical Support,
and Replacement Parts Call: 1-800-444-6742
For Special Orders Call:
1-800-527-1292 ext. 210
For Litex Store Service Call:
1-800-223-6156
