Introduction
This manual is covers all of the WinTV models based on the “PCI
Push” technology for displaying TV on your PC’s VGA screen. It covers,
but is not limited to, the following models:
WinTV-Go
WinTV-Express
WinTV-dbx
WinTV-radio
WinTV-pci
WinTV-primio
WinTV-Theater
References to the WinTV apply to all models. The Windows driver for
all of the WinTV boards will be referred to as the WinTV driver, and
the installation CD-ROM will be referred to as the WinTV Installation
CD-ROM.
For models which have particular features (such as the chapter on the
Radio application), we will note which models these features are avail-
able on.
For a description of how the WinTV boards display video on your VGA
screen, see the chapter entitled How WinTV Works.

WinTV Installation and Reference Manual
v

Installing the WinTV boards
The WinTV boards are Plug-and-Play devices designed for
WindowsXP. Plug-and-Play simplifies the installation and hardware
setup of WinTV by having hardware settings assigned by Windows,
instead of needing to set jumpers. This chapter describes how to install
these boards and how the automated Plug-and-Play installation proce-
dure works .
Installation overview
To install WinTV under WindowsXP, you will follow these steps:
✓Install the WinTV board in your PC
✓After booting Windows, you will install WinTV’s Windows device
driver from the WinTV Installation CD-ROM
✓After the Windows driver is installed, you will then install the WinTV
application software from the WinTV Installation CD-ROM
✓Finally, if necessary, an updated Windows Direct Draw Driver can be
installed from the WinTV Installation CD-ROM
WinTV board diagram
The following diagram shows the main functions and connectors of the
WinTV board. Since there are several different models with different
features and functions, your board may not have all of the components
installed.
Board connections
FM: FM radio antenna connection (some models)
TV: TV antenna or cable TV connection
Audio LineOut: Audio output 1/8” minijack (connects to sound
card LineIn jack)
Video In: VideoInput jack (S-Video on some models)
Audio Line In: Audio input 1/8' minijack J2, left/right channel
Remote Control: Minijack J3 (optional on some models)
1-1

*
Installing the WinTV board in your PC
Before installing the WinTV board, turn off the power to your PC and
remove the cover. Since the WinTV board is sensitive to static electrici-
ty, we recommend that before you remove it from its protective anti-stat-
ic bag, you touch the chassis with your hand to discharge any static
electricity.
Once the cover is removed, plug the WinTV board into any free PCI
slot.
Now connect the Audio Cable between the WinTV board and your
PC’s sound card. Plug one end of the audio cable into the Audio
LineOut jack of the WinTV. The other end (a 1/8” audio jack) then
1-2
WinTV Installation and Reference Manual
*Note: not available on all models.
Note: this outline may not reflect the current revision of your WinTV board. For the most up to
date information, see the WinTV QuickInstall Guide provided with your WinTV board.
*
Audio LineOut
* Video In
Audio LineIn
Remote

plugs into the LineIn jack of your sound card.
Most sound cards have three round jacks on the out-
side of the PC. They are: Microphone Input, Audio
Output and Line Input. The Audio Output would go to
your speakers, while the Microphone input might go to
a microphone (if you are using one). The LineIn jack is normally a
blue connector, and is indicated on the sound card by the words IN
or LineIn stamped into the metal bracket on the outside of your PC.
This is where you would plug your WinTV Audio cable.
Installing the WinTV driver under WindowsXP
When the Found New
Hardware Wizard appears,
insert the WinTV
Installation CD-ROM in
your PC’s CD-ROM drive
and make sure Install the
software automatically
(Recommended) is
checked.
Then click NEXT.
If the Hardware Installation dialog
box opens, click Continue Anyway.
WinTV Installation and Reference Manual
1-3

Click Finish.
After the video driver is
installed, the Found New
Hardware Wizard will detect
the WinTV audio driver.
Click Next, then Continue anyway
and then Finish to complete the audio
driver installation.
Primary Surface
It is sometimes useful to force WinTV to use a mode of operation of your
VGA card known as Primary Surface mode. This can be helpful in
eliminating VGA compatibility problems.
To force WinTV to use Primary Surface mode, run the program "PRI-
MARY", which is installed with the WinTV application. Click Start/
Programs and then WinTV. Double click on Primary.EXE. Click on Force
1-4
WinTV Installation and Reference Manual

Primary then close the program by clicking on the X.
The Primary program simply makes a setting in the Windows Registry
that tells the WinTV application to always use the Primary mode of oper-
ation. This can be changed at any time to "Allow Overlay" by re-running
Primary and clicking
Allow Overlay .
When using Primary Surface mode, you will not be
able to view live Closed Caption data overlaid on your
TV Window.
Connecting the WinTV board to a VCR, Video
Camera or Camcorder
Most VCR’s or camcorders have a female RCA jack labeled “Video
Out”. Most also have a jack labeled “Audio Out”. Most video cameras
simply have one output connection labeled "Video Out".
To connect the video to the WinTV board, use shielded video cables
(not supplied) with male RCA connectors on both ends:
- connect from the “Video Out” jack on your video camera, VCR
or camcorder to the Composite Video input jack on the
WinTV board.
Note: Some WinTV models have a yellow RCA jack on the back
panel bracket. Others have a high-quality S-Video input jack, which
requires a supplied S-Video to Composite video adapter to connect
to your camcorder.
To connect the audio from your VCR or camcorder to the WinTV, use a
1/8” stereo minijack extension cable (1/8” male minijacks on each end)
and:
- connect the “Audio Output” 1/8” minijack on the VCR or camcorder
to the Audio LineIn jack on the WinTV board.
Note: Some camcorders use RCA connectors instead of 1/8” mini-
jacks to connect the audio. If so, you will need an female RCA to
1/8” minijack adapter. These adapters can be found at most Radio
Shack stores.
WinTV Installation and Reference Manual
1-5

Connecting the WinTV board to a Sound Card
The WinTV board's audio output should be connected to a sound card
using the supplied Audio Cable:
- plug one end of the Audio Cable into the jack marked LineOut
(Audio Line Out jack) on the back panel bracket of the WinTV
board
- plug the other end of the Audio Cable into your soundcard’s
LineIn jack.
Most sound cards have three round jacks on the out-
side of the PC. They are: Microphone Input, Audio
Output and Line Input. The Audio Output would go to
your speakers, while the Microphone input might go to a micro-
phone (if you are using one). The LineIn jack is normally a blue
connector, and is indicated on the sound card by the words IN or
LineIn stamped into the metal bracket on the outside of your PC.
This is where you would plug your WinTV Audio Cable.
Adjusting the Audio Volume
Once the audio cable is connected to your Sound Card, the WinTV
application can change the audio volume coming from the WinTV
board by adjusting the LineInput sound volume of the
VolumeControl program in Windows.
The VolumeControl program is normally installed with Windows or
by the sound card installation program, and allows the control of vol-
ume from the various sound sources. If you cannot hear sound when
running the WinTV application, you might need to check the volume
level of LineInput in VolumeControl.
The VolumeControl application is started by clicking either:
Programs/Accessories/Multimedia/VolumeControl
or
Start/Programs/Accessories/Entertainment/VolumeControl
1-6
WinTV Installation and Reference Manual

If LineIn is muted, unmute it to hear audio from the WinTV.
You should see Line-In balance as one of the selections. If not, then
click on Options/Properties and under Show the following vol-
ume controls check Line-In. Then click OK.
You should now see a selection for Line-In. Make sure the Select
box is checked, then raise the volume to about 1/2 of the way to the
top. This should be a good starting point for the volume control.
In the WinTV application under the Configure/Audio menu, the Mixer
ID should be set at Line-In.
As you adjust the audio volume in the WinTV application, you should
see the slide bar in the VolumeControl window rise and fall.
WinTV Installation and Reference Manual
1-7

1-8
WinTV Installation and Reference Manual

Checking the WinTV Plug-and-Play
Setup
After the WinTV board has been installed, you can find out what memo-
ry range and interrupt have been assigned by Windows Plug-and-Play
by looking at the configuration in the Control Panel. Plug-and-Play will
not let you change the Interrupt it has assigned, but you can, if neces-
sary, change the Memory Address chosen by Windows.
Open up Control Panel by clicking on Start/Settings/ControlPanel.
Now open up the System properties setup by double clicking on its
icon, then click on the Device Manager folder:
Then select Sound, video and game controllers, then click on
Hauppauge WinTV and then Properties:
2-1

Click on Resources to see which resources Windows has assigned to
the WinTV. Remember: the Interrupt setting cannot be changed (since
it is assigned by Windows Plug-and-Play) but the Memory Address can.
To see which versions of drivers are being used, click on Drivers:
2-2
WinTV Installation and Reference Manual

Click the Details tab to see the configuration of the WinTV driver
This window will show the type of TV tuner, the serial number and revi-
sion of your WinTV board.
WinTV Installation and Reference Manual
2-3

2-4
WinTV Installation and Reference Manual

The WinTV2000 Application
To run the WinTV2000 application for watching TV and for recording videos,
double click the WinTV2000 icon.
Scanning for channels
When running WinTV for the first time, you will need to scan for your TV chan-
nels. If you are using Cable TV, in the Broadcast/Cable box select Cable (or
Cable HRC)
. Otherwise select Antenna .
Choose the Video Format for your geographic region:
North America uses NTSC M
Europe uses PAL B/G
the U.K. uses PAL I
in South America, either PAL M or PAL N is used
3-1
Snap
Snapshot
Button
Freeze
video
CFG
Configure
Snapshot
Pref
Preferences
menu
Menu
Setup Menu
Always-on-top
Full screen TV
Remove toolbars
"no toolbar" mode
Minimize
Record
open the record
controls
Channel surf
Video source select
Channel down
Channel up
Previous channel
Close
WinTV
Snapshot viewer
window
Double click on
each "thumbnail" to
see image full size.
Click and hold your
right mouse button
to see image
options.
Current TV channel
or video source
Click your right mouse
button here to see the
channel selector
Remove toolbars
Click your right mouse button in the TV
window to remove toolbars.
Click again to restore toolbars.
RC: Software remote control
One Touch
Record
