C-TCB-5_INST_9-07
INSTALLATION INSTRUCTIONS
C-TCB-5 TELESCOPING COMPUTER BASE
1997-2008 FORD EXPEDITION
TOOLS REQUIRED:
3/16” Allen wrench
Standard socket set
Torx bit set
Power drill w/ 3/8” drill bit
Ratcheting wrench
Open-end wrench set
MATERIAL LIST
KEY# QTY DESCRIPTION PART #
1 1 Pole support assembly CM93071-5W
2 1 Telescoping pole assembly CM93072-3
3 1 Under floor plate with threaded hole CM93132
HARDWARE LIST
KEY# QTY DESCRIPTION PART #
4 1 3/8” x 1” Hex head bolt GSM33028
5 1 3/8”Flat washer GSM31007
Under floor
plate
Pole support
assembly
Telescoping
pole assembly

C-TCB-5_INST_9-07
Always!
 Read all instructions before installing any Havis-Shields Equipment Corp products.
 Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
 Use hardware provided with install kit
 For product support, visit the Install Instructions Section of our website at
http://havis.com/Installation/Installation.html, email [email protected] or call
1-800-524-9900.
INSTALLATION:
1. Remove front passenger seat bolts. Loosen, but do not remove, the two rear passenger
seat bolts.
2. Place base of the pole support assembly underneath of the seat base brackets.
3. Align the holes of the seat base, the pole support assembly, and the floor holes. Replace
the front seat bolts. Firmly tighten all four seat bolts without over tightening.
4. Making sure the pole is level; drill a 3/8” hole through the floor pan at the end of brace.
Hold the threaded under the floor plate underneath and through-bolt the base using the
supplied screw.
Pole support
assembly
Under floor plate (Not shown)
Telescoping
pole assembly
