QuickShifter easy
Supplementary Manual
Kawasaki ZX-10R 2004-2005 (iQSE-1 + QSH-P4A)
www.healtech-electronics.com 1/4
Remove the passanger seat.
Remove the cover between the seats.
Remove the main seat.

QuickShifter easy
Supplementary Manual
Kawasaki ZX-10R 2004-2005 (iQSE-1 + QSH-P4A)
www.healtech-electronics.com 2/4
Remove the frame covers below the fuel
tank and the main seat.
Remove the fuel tank.
Remove the airbox.

QuickShifter easy
Supplementary Manual
Kawasaki ZX-10R 2004-2005 (iQSE-1 + QSH-P4A)
www.healtech-electronics.com 3/4
Plug the QSH connectors in-line with the
ignition coil connectors.
(Black, 2-pole connectors below the airbox)
Connect the QSH Black wire terminal to
the chassis ground.
Mount the QSE sensor.
(Replace the bolt with the one supplied.
Place the conical washers at the two sides
of the sensor like this: (0). Tighten the bolt
in this position by about 6 Nm. If you do not
have torque wrench, tighten the bolt until
the shift arm is tight on the gearbox shaft.)

QuickShifter easy
Supplementary Manual
Kawasaki ZX-10R 2004-2005 (iQSE-1 + QSH-P4A)
www.healtech-electronics.com 4/4
Typical position for the QuickShifter easy.
Secure the unit properly.
