1x Schraubensatz: 1x Screw kit:
1
2 allen screw M8 x 55
2 filister head screw M6 x 70
2 filister head screw M8 x 70
2 filister head screw M6 x 25
2 spacer Ø15 x Ø 7 x 14 mm
2 spacer Ø18 x Ø 9 x 14 mm
4 allen screw M6 x12
4 allen screw M6 x 20
6 washer ø6,4
2 body washer ø6,4 x 20
6 washer ø8,4
4 special washer 20 x 20 x ø6,4
4 self-lock nut M6
2 self-lock nut M8
2 Zylinderschrauben M8 x 55
2 Linsenkopfschrauben M6 x 70
2 Linsenkopfschrauben M8 x 70
2 Linsenkopfschrauben M6 x 25
2 Aludistanzen Ø15 x Ø 7 x 14 mm
2 Aludistanzen Ø18 x Ø 9 x 14 mm
4 Zylinderschrauben M6 x12
4 Zylinderschrauben M6 x 20
6 U-Scheibe ø6,4
2 Karosseriescheibe ø6,4 x 20
6 U-Scheibe ø8,4
4 Viereck-Scheiben 20 x 20 x ø6,4
4 Selbstsichernde Mutter M6
2 Selbstsichernde Mutter M8
080410/180416/030220
1 700007280 Alurack Adapter links
1 700007281 Alurack Adapter rechts
1 700003703 Versteifungsadapter links
1 700003704 Versteifungsadapter rechts
1 700007280 alu-rack adapter left
1 700007281 alu-rack adapter right
1 700003703 frame adapter left
1 700003704 frame adapter right
Bei Bestellung eines Aluracks zusätzlich:
1x 799.901HB Alu-Rack
1x 799.902HB TC-Bügel für Alu-Rack
1x 799.903HB Abdeckplatte für Rack
Bei Bestellung eines Easyracks zusätzlich:
1x 700008650 Easyrack
1x 700008647 Abdeckblende links
1x 700008648 Abdeckblende rechts
When ordering a Alurack:
1x 799.901HB alu-rack
1x 799.902HB bow for Alu-rack
1x 799.903HB plastic cover for rack
When ordering a Easyrack:
1x 700008650 Easyrack
1x 700008647 plastic cover left
1x 700008648 plastic cover right
SUZUKI GSX 1400
ab Baujahr 2005 / from date of manufacture 2005
Easyrack Alurack
SUZUKI GSX 1400
bis Baujahr 2004 / up to date of manufacture 2004
661329 01 01 schwarz/black 650329 01 01 schwarz/black
6613507 01 01 schwarz/black 6503507 01 01 schwarz/black
INHALT
CONTENTS
Easyrack - Symbol
Alurack - Symbol
Unbedingt zuerst die Versteifungsadapter montieren, um den Rahmen für die Aufnahme einer Gepäckbrücke zu verstärken !
Folgende Teile demontieren:
Sitzbank, Heckbügel und Heckverkleidung. Blinker lösen und nach außen herausziehen
(Blinkerkabel müssen nicht getrennt werden). Beide Gepäckhaken samt Schrauben demontieren, sie entfallen.
Dismantle first:
Seat, handle bar and rear cover. Loose and pull out the blinkers (cables must not be disconnected).
Dismantle luggage hooks - they are obsolete.
Preparing of the Alurack:
Fix the bow to the rack with allen screws M6 x 12.
NOTICE:
The bow is needed in use with a Hepco & Becker topcase only .
Vorbereitung des Aluracks:
Den beiliegenden TC-Bügel mit den Zylinderkopf-
schrauben M6 x 12 hinten unter dem Alurack
verschrauben.
HINWEIS:
Der TC-Bügel ist nur bei Anbringung eines Hepco & Becker
Topcases erforderlich.
2
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
WICHTIG
IMPORTANT
VORBEREITUNG
PREPARING
4x
First mount the frame adapters. They are essential to enforce the frame for fastening a rear rack !
SUZUKI GSX 1400
ab Baujahr 2005 / from date of manufacture 2005
Easyrack Alurack
SUZUKI GSX 1400
bis Baujahr 2004 / up to date of manufacture 2004
661329 01 01 schwarz/black 650329 01 01 schwarz/black
6613507 01 01 schwarz/black 6503507 01 01 schwarz/black
Ratsche/Ratchet
Verlängerung/extension
Set
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
3
Fastening of the adapters left and right:
Put spacer Ø15xØ7x14mm in the free
front borings and spacer Ø18xØ9x14
mm in the rear borings.
For fixing, use filister head screw M 6x70
with washers Ø6,4 front .
Filister head screw M8x70 with washers
Ø8,4 at the rear side
2
1
2x
Montage der Halteadapter links und
rechts:
In die nun freien Bohrungen vorne
die Aludistanzen Ø15xØ7x14mm
hinten die Aludistanzen Ø18xØ9x14
mm einstecken.
Die Befestigung der Halteadapter erfolgt
zusammen mit dem Heckbügel.
Vorne mit der Linsenkopfschraube
M6x70,und U-Scheibe Ø6,4.
Hinten mit der Linsenkopfschraube
M8x70, und U-Scheibe Ø8,4
verschrauben.
2x
2x
2x
2x
Montage der Versteifungsadapter:
Die Versteifungsadapter werden links und
rechts jeweils von außen auf den Rahmen
aufgeschoben und am Rahmenende in den
Bohrungen der Gepäckhaken verschraubt.
Vorne mit den Linsenkopfschrauben
M6x25 und Karosseriescheiben ø6,4x20.
Hinten mit Zylinderschrauben M8x55,
U-Scheiben ø8,4 und selbstsichernden
Muttern M8.
Folgende Teile demontieren:
Sitzbank, Heckbügel und Heckverkleidung. Blinker lösen und nach außen herausziehen
(Blinkerkabel müssen nicht getrennt werden). Beide Gepäckhaken samt Schrauben demontieren, sie entfallen.
Fastening of the frame adapter:
Push the frame adapter to the frame
and fix it.
Front fixing point use filister head screws
M6x25 and body washer ø6,4x20.
Rear fixing point use allen screws M8x55,
washers ø8,4 and self lock nuts M8.
2x
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
SUZUKI GSX 1400
ab Baujahr 2005 / from date of manufacture 2005
Easyrack Alurack
SUZUKI GSX 1400
bis Baujahr 2004 / up to date of manufacture 2004
661329 01 01 schwarz/black 650329 01 01 schwarz/black
6613507 01 01 schwarz/black 6503507 01 01 schwarz/black
4
Als weiteres Zubehör lieferbar:/ Also available:
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: [email protected]
www.hepco-becker.de
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren ! Abgebaute Teile
wieder montieren. Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the
dismanteled parts. Please notice our enclosed service information.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
Alurack:
Easyrack:
3
Fastening of the Alurack/Easyracks:
On the rack adapters.
Use allen screws M6 x 20 and special washer
20x20xø6,4. Secure with washers ø6,4 and
self-lock nuts M6. Mount the plastic cover.
Montage des Aluracks/Easyracks:
Das Rack wird mit den Zylinderschrauben
M6x20,den Viereck-Scheiben 20x20xø6,4,
den U-Scheiben ø6,4 und den selbst-
sichernden Muttern M6 an den Gepäck-
brückenhalter verschraubt. Anschließend
die Kunststoffabdeckung montieren.
4x 4x
4x
4x
SUZUKI GSX 1400
ab Baujahr 2005 / from date of manufacture 2005
Easyrack Alurack
SUZUKI GSX 1400
bis Baujahr 2004 / up to date of manufacture 2004
661329 01 01 schwarz/black 650329 01 01 schwarz/black
6613507 01 01 schwarz/black 6503507 01 01 schwarz/black
Kofferträger schwarz / Side carrier, black
Motorschutzbügel schwarz / Engine guard, black
