YCanvas Office Landscape®In-Line Beam Connector
Installation and Disassembly for Recycling Instructions
Parts Included:
Coupler Assembly (2)
Hex Socket Button
Head Screw (16) Hex Nut (16)
Ganging Plate (1 or 2)
A
BC
DHardware Pack
Hardware Pack
Pan Head
Screw (16)
E
Tools Required:
Rachet Wrench 1/2” Hex Socket Torque Wrench 3/16 Allen Wrench
Safety Glass

Z
2
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b6y34 rev B.
1. Mate 2 Beam Frames together on Floor.
2. Insert Coupler(A) into Frames with groove side down.
3. Install 8 Hex Socket Button Head Screws(B) and 8 Hex Nuts(C) per Coupler.
4. Place straight edge on top op beam at joint. If there is a gap between straight
edge and top of beam then place shims under beam until frame is at or has
a slight crown.
5. Tighten Screws to 30 ft/lbs.
Shim Here If
Needed
AC
C
A
B
B

Z
3
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b6y34 rev B.
Support
6. Install Coupler onto ajoining Frame Assembly, then supported Frame
Assembly.
7. Place straight edge on top of Frame at joint. Adjust levelers on Supports until
frames are at or has slight crown.
8. Tighten screws to 30 ft/lbs.
C
C
A
A
B
B
9. After Work Surfaces have been
placed into position onto beam,
align adjoining edges.
10. Place Ganging Plates(D) under
Work Surfaces. Install 8 Pan Head
Screws(E) per Plate.
D
E

Z
4
© 2013 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Zand Canvas Office Landscape are among the registered trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
Part no. 1b6y34 rev B.
Disassembly and Recycling:
Materials Identication and Segregation:
Where possible, plastic components are marked with ASTM recycling codes. Use
these codes to identify material type for recycling. Non marked components should
be treated as mixed plastic. Ferrous metals can be identied using a small magnet
for recycling. Non-ferrous metals should be separated and recycled separately.
To disassemble product, reverse steps 10 through 1 and also do the following:
