Hettich ROTANTA 460 Robotic User manual

2010 Andreas Hettich GmbH & Co. KG AH5680-01EN
Serial communication and
PC parameters
ROTANTA 460 Robotic
ROTANTA 46 RSC ROBOTIC
EN
Operating Instructions................................................... 3

2/70
Andreas Hettich GmbH & Co. KG
Föhrenstraße 12, D-78532 Tuttlingen / Germany
Phone [phone] / 705-0
Fax [phone] / 705-125
[email protected], serv[email protected]
www.hettichlab.com
© 2010 by Andreas Hettich GmbH & Co. KG
All rights reserved. No part of this publication may be reproduced without the prior written permission of the copyright
owner.
Änderungen vorbehalten! , Modifications reserved!
AH5680-01EN / 2010

EN
3/70
Contents
1.1 Robotic functions..........................................................................................................................................................5
1.2 Operating modes..........................................................................................................................................................5
1.2.1 Normal robotic operation ......................................................................................................................................5
1.2.2 Adjusting / teaching operation and handling of the centrifuge without serial interface ........................................5
2Communication with Hettich centrifuges..............................................................................................................................6
2.1 Definition:......................................................................................................................................................................6
2.2 General description ......................................................................................................................................................6
2.2.1 Setting of serial interface ......................................................................................................................................6
2.2.2 Control characters and abbreviations...................................................................................................................6
2.2.3 Used telegrams.....................................................................................................................................................6
2.2.4 Additional explanation for the protocol: ................................................................................................................7
2.3 Time behaviour for serial operation..............................................................................................................................7
2.3.1 Time for one ENQUIRY-Telegram........................................................................................................................7
2.3.2 Time for one SELECT-Telegram ..........................................................................................................................7
2.3.3 Rhythm of request ................................................................................................................................................7
2.4 Examples for Telegrams ..............................................................................................................................................8
2.4.1 Example for an ENQUIRY-Telegram:...................................................................................................................8
2.4.2 Example for a SELECT-Telegram: .......................................................................................................................8
2.5 Address of the Centrifuge / Change the address.........................................................................................................9
2.6 Principle for serial communication ...............................................................................................................................9
2.6.1 Detection of the “Generation 2” ............................................................................................................................9
2.6.2 General information for positioning and hatch commands:............................................................................... 10
2.7 General format of parameter content ( V = VAL = Value )........................................................................................ 10
2.8 Synopsis of the parameters....................................................................................................................................... 12
2.9 Short introduction of positioning with the ”new” communication of Generation 2..................................................... 13
2.9.1 Parameter 00524 (definition of the target):........................................................................................................ 13
2.9.2 Parameter 00526 (control commands for positioning and hatch) ..................................................................... 14
2.9.3 Parameter 00528 (information about positioning and hatch state) ................................................................... 14
2.9.4 Parameter 00521 (control commands for centrifugation).................................................................................. 15
2.9.5 Special functions: ACK, NAK and SIOF ............................................................................................................ 15
2.10 Detailed description of the parameters.................................................................................................................. 16
2.10.1 Parameters for "Generation 2" (only valid / possible with / for Generation 2)............................................... 16
2.10.2 Parameters for Generation 1 and Generation 2 ............................................................................................ 29
2.11 Additional features of communication with ”Generation 2” ................................................................................... 43
2.11.1 Serial communication and visual detection of the communication................................................................ 43
2.11.2 Software-Lock ................................................................................................................................................ 43
2.11.3 Checking values for validity (value has to be inside the allowed range)....................................................... 43
2.11.4 Limitations...................................................................................................................................................... 43
2.11.5 Query of actual values ................................................................................................................................... 43
2.11.6 Hatch and positioning commands.................................................................................................................. 44
2.11.7 Bit of modification........................................................................................................................................... 44
2.12 State of the centrifuge after power on and general operating states. ................................................................... 44
3Cookbook for serial control of “Generation 2”................................................................................................................... 46
3.1 Open the hatch.......................................................................................................................................................... 46
3.2 Close the hatch.......................................................................................................................................................... 47

EN
4/70
3.3 Set rotor position ....................................................................................................................................................... 48
3.4 Start centrifugation .................................................................................................................................................... 49
3.5 Stop centrifugation..................................................................................................................................................... 49
3.6 How to store and recall programs ............................................................................................................................. 50
3.6.1 Recall program to edit:....................................................................................................................................... 50
3.6.2 Recall program and set this program active:..................................................................................................... 50
3.6.3 Store program: ................................................................................................................................................... 50
3.6.4 Store program and set this program active: ..................................................................................................... 50
3.6.5 Write a new program and store it in the machine memory (EEPROM)............................................................. 51
3.6.6 Recall and activate an already stored program................................................................................................. 52
3.7 Protocol Examples..................................................................................................................................................... 52
3.7.1 Sequence after starting PC communcation....................................................................................................... 53
3.7.2 Cyclic enquiry during standstill and positioning:................................................................................................ 54
3.7.3 Change the Nominal Values in stand still or during the run .............................................................................. 55
3.7.4 The PC writes a program which will be stored in the centrifuge........................................................................ 56
3.7.5 The PC recalls and activates a program ........................................................................................................... 56
3.7.6 Open the hatch .................................................................................................................................................. 57
3.7.7 Set Rotor target rotor position 1......................................................................................................................... 57
3.7.8 Set target rotor position 4 .................................................................................................................................. 58
3.7.9 Close the hatch .................................................................................................................................................. 58
3.7.10 Recall Program No 6...................................................................................................................................... 58
3.7.11 Start centrifugation......................................................................................................................................... 59
3.7.12 Stop centrifugation ......................................................................................................................................... 59
3.7.13 Wait for standstill and the automatical position 1 and terminate positioning................................................. 60
3.8 Rotor cycles commands ............................................................................................................................................ 60
3.8.1 General description............................................................................................................................................ 60
3.8.2 Cycle counter ..................................................................................................................................................... 60
3.8.3 Check the general information about the "conditions" of rotor cycle counter.................................................... 61
4Comparison between the serial communication Generation 1 and Generation 2 ............................................................ 63
4.1 The serial protocol (hardware, settings and telegrams) remain constant. ................................................................ 63
4.2 Brief introduction of the differences:.......................................................................................................................... 63
4.3 List of parameters:..................................................................................................................................................... 63
5Communication with Generation 2 according to the still valid communication of Generation 1....................................... 67
5.1 Open the hatch .......................................................................................................................................................... 67
5.2 Go to position 1 and check the reached position ...................................................................................................... 67
5.3 Go to position 2 and check the reached position ...................................................................................................... 67
5.4 Go to position 3 and check the reached position ...................................................................................................... 68
5.5 Go to position 4 and check the reached position. ..................................................................................................... 68
5.6 Close the hatch.......................................................................................................................................................... 68
5.7 Start the centrifuge! ................................................................................................................................................... 69
5.8 STOP per PC = Emergency stop .............................................................................................................................. 69
5.9 Cancel Software-lock LOCK 4 or LOCK 5................................................................................................................. 69
5.10 Change the Nominal Values in stand still or during the run .................................................................................. 70
5.11 Recall (RCL) a program stored in the control panel, ready to start....................................................................... 70
5.12 Change and store the values of a program ........................................................................................................... 70

EN
5/70
1.1 Robotic functions
The loading hatch is placed in the centrifuge lid. The hatch is opened by a motor.
The rotor is positioned and hold under the hatch.
1.2 Operating modes
1.2.1 Normal robotic operation
The key-operated switch (Key-Lock) has to be in position LOCK 2 (right key position, turn clockwise).
The key must be pulled off.
Additionally in the complete arrangement the centrifuge has to be protected against unauthorized penetration and
manipulation.
1.2.2 Adjusting / teaching operation and handling of the centrifuge without serial interface
It is only allowed for skilled maintenance staff to work in the adjusting and initializing operation.
After the adjusting and initializing operation the key-operated switch has to be in position LOCK 2
(right key position) and the key must be pulled off.
To protect the key against unauthorized access keep it in a save place.
- Teaching of position 1
Please refer to the operation instruction chapter 30 “Setting rotor position 1”
- Close and open the hatch by the hatch motor drive
Only possible in key-operated switch position TEACH (left key position, the display shows "TEACH").
OPEN the hatch Press key
CLOSE the hatch Press
RPM
key
Notice: The hatch drive acts as long as the key is pressed.
The functions of the following keys are depending to key-operated switch position.
- STOP-key
The
OPEN / STOP
(Generation 1
STOP
) key on the control panel is always active.
- START-key
The
START
key on the control panel is normally active.
But the key function can be blocked / locked via the PC with the command LOCK 5
(see Parameter 00520 or 00633 / 00635).

EN
6/70
2 Communication with Hettich centrifuges
2.1 Definition:
"Generation 2" is the updated communication for ROTANTA 460 ROBOTIC type 5680
"Generation 1" is the original communication for ROTANTA 46 RSC Robotic type 4815 / 4816 / 4817
The centrifuges of "Generation 2" (ROTANTA 460 ROBOTIC type 5680) accept mostly the original communication
according to the definitions of "Generation 1".
Please find a more detailed description in chapter 4 and 5
2.2 General description
2.2.1 Setting of serial interface
- 9600 Bit/s
- Format: - 1 start-bit
- 7 data bits
- 1 parity-bit (even parity)
- 1 stop-bit
2.2.2 Control characters and abbreviations
STX = 02 hex: Start of text
ETX = 03 hex: End of text
EOT = 04 hex: End of transmission
ENQ = 05 hex: Enquiry of data
ACK = 06 hex: Acknowledge
NAK = 15 hex: Not acknowledged
ADR = Address of the centrifuge; Range : 'A' to 'Z' and '[' , '\' and ']'
C = CODE = Parameter-Address -> 5 Byte ASCII (always 5-digits)
= = 3D hex: spacer between CODE and VAL
V = VALUE (VAL) = Value -> 4 Byte ASCII (always 4-digits)
BCC = Block Code Check = Checksum of the relevant data in hex.
(EXOR – summary of the with BCC marked bytes)
2.2.3 Used telegrams
2.2.3.1 ENQUIRY-Telegram (transmission request)
Data link to the addressed centrifuge establishment to transmit the value (V=VAL)
of the parameter (C=CODE)
PC EOT ADR C C C C C ENQ
BCC-base
Centrifuge ADR STX C C C C C = V V V V ETX BCC
2.2.3.2 SELECT-Telegram (transmission of data or command)
Data transmission of value V to the parameter C of the addressed centrifuge.
BCC-base
PC EOT ADR STX C C C C C = V V V V ETX BCC
Centrifuge ADR ACK or ADR NAK
The characters are transmitted hexadecimal coded.
For a better readability here these characters are always displayed as ASCII-Symbols!

EN
7/70
2.2.4 Additional explanation for the protocol:
ADR = centrifuge-address (see also section "Address of the Centrifuge")
C= Parameter-Code (Parameter-Address)
5 digit CODE, the first two HEX digits are always 0
e.g.: Parameter-Address of the target speed
0 0 6 0 3 (send) 30 30 36 30 33 (all in hex)
V= Parameter-Value
4-digits VAL, VALUE which displays the contents.
e.g.: 500 RPM
0 1 F 4 (send) 30 31 46 34 (all in hex)
Hexadecimal coded characters are transmitted!
2.3 Time behaviour for serial operation
2.3.1 Time for one ENQUIRY-Telegram
ENQUIRY from
PC
Reaction time Answer of the centrifuge
8
digits
14
digits
approx. 9 ms 5...150 ms approx. 16 ms
PC
Centrifuge
2.3.2 Time for one SELECT-Telegram
Command for PC Reaction time
centrifuge
Answer
centrifuge
15
digits
2
digits
approx. 17 ms 20...150 ms approx. 2 ms
PC
Centrifuge
The reaction time of the centrifuge depends on the respective working order.
A busy centrifuge, e.g. during a centrifugation or positioning, uses more computing time and so the reaction time is
up to 150 ms. If there is no answer from the centrifuge after 150 ms, it can be assumed that there is a serial Error.
In case of an error the telegram should be repeated 2 times.
That means: If there is still no answer after the third transmission attempt, the telegram has to be cancelled to
examine the cause of the error.
2.3.3 Rhythm of request
We suggest the following communication timing:
During centrifugation: Parameter 00634
During positioning: Parameter 00634 once per second and parameter 00640 (Generation 1) or parameter 00528
(Generation 2) twice per second. Please refer also to chapter 2.11.5 "Query of actual values"

EN
8/70
2.4 Examples for Telegrams
2.4.1 Example for an ENQUIRY-Telegram:
PC transmits to address 29: “What is” the content of parameter 00604 (actual speed).
EOT ADR C C C C C ENQ schematic
EOT ] 0 0 6 0 4 ENQ ASCII
04 5D 30 30 36 30 34 05 HEX
Centrifuge with address 29 will answer: the content of parameter 00604 (actual speed) = 500
BCC
ADR STX C C C C C = V V V V ETX BCC schematic
] STX 0 0 6 0 4 = 0 1 F 4 ETX ASCII
5D 02 30 30 36 30 34 3D 30 31 46 34 03 7F HEX
2.4.2 Example for a SELECT-Telegram:
PC transmits to address 29, Parameter 00603; "set the speed" to 1500 RPM:
BCC
EOT ADR STX C C C C C = V V V V ETX BCC schematic
EOT ] STX 0 0 6 0 3 = 0 5 D C ETX BCC ASCII
04 5D 02 30 30 36 30 33 3D 30 35 44 43 03 09 HEX
Centrifuge answers:
ADR ACK or ADR NAK schematic
] ACK or ] NAK ASCII
5D 06 or 5D 15 HEX

EN
9/70
2.5 Address of the Centrifuge / Change the address
Each centrifuge that is being communicated with must have its own address.
The PC uses this address to communicate with the centrifuge.
This serial address can be compared with the name of a person.
Each address in a system can only be given ONCE. The Hettich-BUS system manages up to 29 centrifuges.
Address range:
1. Address A = 41hex
2. Address B = 42hex
to
26. Address Z = 5Ahex
and
27. Address [ = 5Bhex
28. Address \ = 5Chex
29. Address ] = 5Dhex Default address
Default address / factory settings address is ‘]’ = 29.
Change the address of the centrifuge using the control panel
• Keep the
PROG
key held down for 8 seconds.
After 8 seconds,  Machine Menu  appears in the display.
• Press the
PROG
- key as often as necessary until the ->Settings is displayed.
• Press the
START
- key , the
PROG
- key as often as necessary until the ->PC Address = ] is displayed .
• Use the adjusting knob to setup the desired PC Address .
• Press the
START
- key, Store Settings … and then ->Settings is displayed .
• Press the
OPEN / STOP
(Generation 1
STOP
) - key twice to leave the *** Machine Menu ***.
2.6 Principle for serial communication
The PC requires an available RS 232 interface.
The key-operated switch has to be in position LOCK 2 (right key position).
The centrifuge accept commands from PC only in position LOCK 2
Centrifuges are terminals (slaves) and answer only if they receive an ENQURIY - or SELECT - telegram.
2.6.1 Detection of the “Generation 2”
Send an ENQUIRY telegram with address”$” to parameter 00600 (centrifuge identification).
The robotic centrifuge of Generation 1 (type 4815 to 4817 will return: [ADR] : NAK
The robotic centrifuge of Generation 2 (type 5680) will return “1234”
Please refer to chapter 2.10, parameter 00600
Example (Centrifuge with default address “]” is connected:
PC EOT $ 0 0 6 0 0 ENQ
Cent ] STX 0 0 6 0 0 = 1 2 3 4 ETX DC
Please refer to chapter 2.8, "Parameter-No.: 00600"

EN
10/70
2.6.2 General information for positioning and hatch commands:
The centrifuge acknowledges the transmission of the command with "ACK" when a positioning or hatch
command was sent and executes the command.
Important information for the positioning:
Centrifuges of “Generation 2” (software 01.xx):
During the executing of a positioning command (the rotor moves) ALL OTHER positioning
commands will be ignored.
The centrifuge will acknowledge the additional positioning commands with ACK but the command
will be ignored. The centrifuge does not execute the second command during processing of the first
command). The additional commands will be flushed.
Therefore please wait with the next positioning command until the ongoing positioning is finished.
Centrifuges of “Generation 1” (software 4.xxx):
During the executing of a positioning command (the rotor moves) the ongoing positioning will
immediately be cancelled and the last sent positioning command will be executed.
You can use
• parameter 00640 to handle position 1, 2 3 and 4 with 2-place or 4-place rotors
(using the protocol of "Generation 1"),
• parameter 00524 and 00526 to handle ALL positions with ALL rotors
(using the protocol of "Generation 2").
Time-out:
Each rotor position (1 ... 48) is fixed (held in position) for maximum 20 minutes.
After 20 minutes the fixed position (electronical positioning and the electromagnetic brake) is automatically
deactivated. If the position is needed again please send the command for this position again.
Software-Lock via serial interface
To avoid complications with START commands (by pressing the START-key at the control panel), the software
provide the feature LOCK 5. Then the
START
- key is locked, only the
OPEN / STOP
(Generation 1
STOP
) -key is
active.
Please refer to chapter 2.10.1 (Parameter-No.: 00520) and chapter 2.10.2 (Parameter-No.: 00633)
2.7 General format of parameter content ( V = VAL = Value )
V V V V
MSD LSD MSD LSD
Lowbyte = LSB
Highbyte = MSB
Bit 3...0 3...0 3...0 3...0 = 4 digit
Bit 7....... ........0 7...... .........0 = 2 byte
Bit 15...........................................0 = 1 word
Explanation: MSD/LSD: Most/Least significant Digit (Digit = Nibble = half byte)
MSB/LSB: Most/Least significant Byte
MSb/LSb: Most/Least significant Bit
Values are sent or received in principle as 4 –digit characters.
Each digit has a range: from 30 hex = ‘0’ to 39 hex = ‘9’
and from 41 hex = ‘A’ to 46 hex = ‘F’.
The information (VAL) of one parameter can cover the range 0000 hex to FFFF hex
(0 up to 65535) with one transmission.

EN
11/70
The following parameters are hexadecimal (numeral) coded:
• Time 00500, 00501, 00502, 00503, 00504, 00505, 00533,
00601, 00602, 00613, 00614, 00615 and 00616
• Speed 00420,00422,00603, 00604, 00605 and 00617
• RCF 00606, 00607 and 00608
• Radius 00620
• Temperature 00618, 00619 (with scale, to prevent negative values)
• Software-Version 00636
• Positioning 00524
• Rotor cycle commands 00560,561,562,563,564,565,566,567,568
• Nr. of centrifugation starts 00569,570
Some parameters are bit coded, partial bit and partial numeral coded
e.g. parameter 00634, 00635, 00640, 00685 etc.
Control by serial interface:
Almost all functions, offered by the control panel, can be called up via the interface.
In chapter 3 is a cookbook, in chapter 3.7 are examples, where the most important commands and inquiries are
presented:
• START and STOP
• Open and close the hatch
• Move rotor to position X
48 positions are possible, the permitted positions are depending to the installed rotor
• Call up already stored programs

EN
12/70
2.8 Synopsis of the parameters
Para-
meter Content Compatible to
Access:
R = read
RW = read/write
Generation 1 Generation 2
00420 Actual rotor speed (speed of the rotor tacho)
in RPM Use only to calculate the slippage!
X R
00422 Motor field rotating speed X R
00470 External operating hours (High Word) X R
00471 External operating hours (Low Word) X R
00472 Internal operating hours (High Word) X R
00473 Internal operating hours (Low Word) X R
00500 Set runtime (hours) X RW
00501 Actual runtime (hours) X R
00502 Set runtime (minutes) X RW
00503 Actual runtime (minutes) X R
00504 Set runtime (seconds) X RW
00505 Actual runtime (seconds) X R
00512 Show RCF or RPM mode in the display X RW
00513 Dual Timing Mode ,
timing begins at start or on end of acceleration
RW
00518 Actual program number X R
00519 Program info X R
00520 Software lock command X RW
00521 Control command X W
00522 Enable the active/current program block X W
00523 Program command X W
00524 Target position X RW
00526 Positioning and hatch command X W
00528 Positioning and hatch state X R
00533 Positioning timeout R
00537 Centrifuge type and version X R
00563 Actual cycles of the actual rotor (High Word) R
00564 Actual cycles of the actual rotor (Low Word) R
00565 Preset cycles of the actual rotor (High Word) R
00566 Preset cycles of the actual rotor (Low Word) R
00567 Total cycles of the actual rotor (High Word) R
00568 Total cycles of the actual rotor (Low Word) R
00569 Number of centrifugation starts (High Word) R
00570 Number of centrifugation starts (Low Word) R
00600 Centrifuge ID X R
00601 Set run-time X X RW
00602 Actual run-time X X R
00603 Set speed X X RW
00604 Actual speed X X R
00605 Maximum rotor speed X X R
00606 Set-RCF X X RW
00607 Actual-RCF X X R
00608 Maximum-RCF of rotor X X R
00609 ∫RCF/RZB-actual 1.word MSW X X R
00610 ∫RCF/RZB-actual 2.word LSW X X R
00611 Run-up ( acceleration ) X X RW
00612 Run-down ( brake ) X X RW

EN
13/70
Para
meter Content Compatible to
Access:
R = read
RW = read/write
Generation 1 Generation 2
00613 Minimum run-up time X X R
00614 Maximum run-up time X X R
00615 Minimum run-down time X X R
00616 Maximum run-down time X X R
00617 Brake switch off speed X X RW
00618 Set temperature X X RW
00619 Actual value of temperature X X R
00620 Radius X X RW
00630 Program-Info X X 1*) R
00631 Program-command from PC X X 1*) RW
00633 Control command X X RW
00634 Centrifuge state 1 X X R
00635 Centrifuge state 2 X X R
00636 Software version X X R
00639 Clear errors , teaching of position 1 X X RW
00640 Positioning X X RW
00685 SIOF (serial input output failure state) X X R
1*) The parameter is compatible with the exception of Lowbyte bit 6 and 7
2.9 Short introduction of positioning with the ”new” communication of Generation 2
This chapter shows only a short introduction. All details will be described in chapter 2.10.
Please find in chapter 3 a cookbook of the procedures and examples for serial operation.
2.9.1 Parameter 00524 (definition of the target):
Highbyte: even number of rotor positions , 2 up to 48 , depending on the rotor .
7 (not relevant)
6 (not relevant)
5 MSb
4
3
2
1
0 LSb
6-bit digit,
which indicates the maximum number of rotor positions ,
only even numbers (i.e. 2 , 4 , 6..48) can be used .
Lowbyte: target position ( maximum = Highbyte )
7 (not relevant)
6 (not relevant)
5 MSb
4
3
2
1
0 LSb
6-bit digit,
which indicates number of the target rotor position ,
from 1 to the possible rotor positions (maximum number of rotor positions).

EN
14/70
2.9.2 Parameter 00526 (control commands for positioning and hatch)
Lowbyte: Positioning command
01h: move to position slow ,
02h: move to position fast ,
40h: cancel positioning (i.e. if the positioning fails, the current positioning should be deactivated or
the current positioning is disabled with "timeout")
60h: open hatch
70h: close hatch
80h: terminate positioning
The positioning mode will be terminated automatically
(like the command 00526 = 0080) by:
− closing of the hatch
− switching the key-switch from LOCK 2 to LOCK 3
− switching the key-switch from LOCK 2 to LOCK 1 (TEACH-mode)
− starting the centrifugation
2.9.3 Parameter 00528 (information about positioning and hatch state)
Highbyte: General settings (bit 7) hatch state (bit 0 to 6)
7 1 = magnetic brake implemented
6 1 = hatch timeout (pos error 42 is set )
5 1 = hatch open
4 1 = hatch closed
3 1 = lid lock of hatch is closed
2 1 = hatch is moving , general information during opening or closing the hatch
1 1 = hatch is opening , bit is set during hatch is opening also bit 2 is set .
0 1 = hatch is closing , bit is set during hatch is closing also bit 2 is set .
Lowbyte: Position state
7 1 = command " positioning end " is given
6 1 = command " positioning stop " is given
5 1 = magnetic brake is active
4 1 = positioning error
3 1 = positioning timeout (warning )
2 1 = position reached
1 1 = position mode is active (description see chapter " operating states ")
0 1 = command "goto target position " is active , rotor is moving

EN
15/70
2.9.4 Parameter 00521 (control commands for centrifugation)
Parameter 00521 is responsible for centrifugation.
Lowbyte:
7
6
5
4
3
not relevant
not relevant
not relevant
not relevant
not relevant
2 Not relevant
1 1= start centrifugation
0 1= stop centrifugation
• START
Requirement: Key-switch is in position Lock 2
SELECT-Command: 00521 = 0002 (start centrifugation).
• STOP
SELECT-Command: 00521 = 0001 (stop centrifugation).
2.9.5 Special functions: ACK, NAK and SIOF
• If a centrifuge is answering with NAK to a telegram, the SIOF parameter (00685) has to read –out. The enclosed
Info-bit will be reset with the read-out of the parameter.
• Only with deleted bits in SIOF, the centrifuge will accept an order by SELECT.
• SIOF-Bits will be set:
• after "switch on" the centrifuge (mains reset)
• by ENQUIRY a non existent parameter
• by SELECT a non existent parameter
• by SELECT a "read only" parameter
• by SELECT non valid values
• With read-out SIOF ENQUIRY-Telegram to parameter 00685):
• a SIO - error can be detected.
• enables serial interface for SELECT-telegrams.
• with SIOF-enquiry all SIOF-Error-bit will be reset by the centrifuge.

EN
16/70
2.10 Detailed description of the parameters
Used abbreviations:
Gen. 1 Generation 1: Machines of family
ROTANTA 46 RSC (Types 4815, 4816 and 4817)
The parameter is possible for the “old” families.
Gen. 2 Generation 2: Machines of family
ROTANTA 460 ROBOTIC (Type 5680)
The parameter is only possible for these machines
Gen. 1 + 2 Generation 1 and 2:
The parameter is possible for BOTH families.
ROTANTA 46 RSC AND ROTANTA 460 ROBOTIC
The parameter is 100% compatible.
Gen. (1) + 2 Generation 1 (not to 100%) and Generation 2:
The parameter is subtotal / to 100% compatible.
Please read the detailed description
Access: R Read: Parameter access is “read only”; A SELECT telegram will cause a NAK
Access: W Write: Parameter access is “write only”; An ENQUIRY telegram will cause a NAK
Access: RW ReadWrite: Parameter access is “read” and “write”.
The centrifuge accepts SELECT-telegrams only in Key-Lock position "LOCK 2",
therefore the key-operated switch has to be in position LOCK 2 (right key-position).
ENQUIRY-telegrams are always possible, independent of the Key-Lock position.
2.10.1 Parameters for "Generation 2" (only valid / possible with / for Generation 2)
2.10.1.1 Speed parameters
Parameter-No.: 00420 Actual rotor speed Gen. 2 Access: R
Speed of the rotor tacho in RPM; Use only to calculate the slippage
Structure:
MSD LSD MSD LSD
Actual rotor speed LSB
Actual rotor MSB
Display: RPM = revolutions per minute
Range: 50 up to 20 000 RPM

EN
17/70
Parameter-No.: 00422 Motor field rotating speed Gen. 2 Access: R
Structure:
MSD LSD MSD LSD
Actual set rotation speed LSB
Actual set rotation speed MSB
Display: RPM = revolution per minute
Range: 50 up to 20 000 RPM
Slippage = Motor field rotating speed (00420) - Actual rotor speed (00422)
2.10.1.2 Parameters for operating time and operting cycle
The operating hours are stored as "long value" in seconds.
Calculation : Value in seconds = (High Word * 65536) + Low Word
Parameter-No.: 00470 External operating hours (High Word) Gen. 2 Access: R
The operating hours are “sum up” into the "internal" and the "external" operating hours.
Internal operating hours: Total time that the device was switched on (power-on time).
External operating hours: Total time of centrifugation (centrifugation time).
Structure:
MSD LSD MSD LSD
Lowbyte : External operating hours
Highbyte: External operating hours
External operating hours (High Word)
Range: 0000H…FFFFH
Parameter-No.: 00471 External operating hours (Low Word) Gen. 2 Access: R
Structure:
MSD LSD MSD LSD
Lowbyte: External operating time
Highbyte: External operating time
External operating hours (Low Word)
Range: 0000H…FFFFH
Parameter-No.: 00472 Internal operating hours (High Word) Gen. 2 Access: R
Structure:
MSD LSD MSD LSD
Lowbyte: Internal operating hours
Highbyte: Internal operating hours
Internal operating hours (High Word)
Range: 0000H…FFFFH

EN
18/70
Parameter-No.: 00473 Internal operating hours (Low Word) Gen. 2 Access: R
Structure:
MSD LSD MSD LSD
Lowbyte: Internal operating time
Highbyte: Internal operating time
Internal operating hours (Low Word)
Range: 0000H…FFFFH
The operating hours are stored as "long value" in seconds.
Calculation : Value in seconds = (High Word * 65536) + Low Word
Parameter-No.: 00474 Number of centrifugation starts Gen. 2 Access: R
Structure:
MSD LSD MSD LSD
Lowbyte: Number of starts
Highbyte: Number of starts
The value is the totally number of centrifugation runs, the range is: 0000H…FFFFH (0 – 656535)
2.10.1.3 Time parameters
The time parameters of the “Generation 2” :
- set time ( 00500, 00502 and 00504 )
- actual time ( 00501, 00503 and 00505 )
are alternative to the parameters of the “Generation 1”
- set time ( 00601 )
- actual time ( 00602 ).
Note:
- The value range of the 005xx time parameters is up to 99 hours, 59 minutes and 59 seconds
- The value of the parameters 00601 and 00602 are restricted to 59999 seconds
(16 hours 39 minutes and 59 seconds).
Please refer also to parameter 00513 (Dual Timing Mode)
Parameter-No.: 00500 Set runtime (hours) Gen. 2 Access: RW
Structure:
MSD LSD MSD LSD
Lowbyte: Set runtime hours
Highbyte: Always 00
Input: set runtime hours
Range: 0000H…0063H ( = 0d .. 99d) hours

EN
19/70
Parameter-No.: 00501 Actual runtime (hours) Gen. 2 Access: R
Structure:
MSD LSD MSD LSD
Lowbyte: Actual runtime hours
Highbyte: Always 00
Range: 0000H…0063H ( = 0d ..99d) hours
Parameter-No.: 00502 Set runtime (minutes) Gen. 2 Access: RW
Structure:
MSD LSD MSD LSD
Lowbyte: Set runtime minutes
Highbyte: Allways 00
Input: set runtime minutes
Range: 0000H…003DH ( = 0d ..59d) minutes
take notice to Parameter 00513 (Dual Timing Mode)
Parameter-No.: 00503 Actual runtime (minutes) Gen. 2 Access: R
Structure:
MSD LSD MSD LSD
Lowbyte: Actual runtime minutes
Highbyte: Allways 00
Parameter-No.: 00504 Set runtime (seconds) Gen. 2 Access: RW
Structure:
MSD LSD MSD LSD
Lowbyte: Set runtime seconds
Highbyte: Allways 00
Input: set runtime
Range: 0000
hex to 003D hex = 0 dec to 59 dec in seconds
Parameter-No.: 00505 Actual runtime (seconds) Gen. 2 Access: R
Structure:
MSD LSD MSD LSD
Lowbyte: Actual runtime seconds
Highbyte: Allways 00
Parameter 00500 to 00505 are used if the runtime is higher than 16 hours.
Otherwise parameter 00601 (runtime in sec from 0...59999) can be used.
Advantage of parameter 00601: Only one parameter is needed

EN
20/70
2.10.1.4 Miscellaneous parameters part 1
Parameter-No.: 00512 Show RCF or RPM mode in the display Gen. 2 Access: RW
Structure:
MSD LSD MSD LSD
Lowbyte: RCF / RPM mode
Highbyte: Not relevant
Lowbyte : RCF / RPM mode
7
6
5
4
3
2
1
not relevant
not relevant
not relevant
not relevant
not relevant
not relevant
not relevant
0 1 = rcf mode 0 = rpm mode
If the radius (parameter 00620) is changed, the display will automatically show the RCF mode.
If the set speed (parameter 00603) is changed, the display will automatically show the RPM mode.
Parameter-No.: 00513 Dual Timing Mode Gen. 2 Access: R
Structure:
MSD LSD MSD LSD
Lowbyte: Dual timing mode on/off
Highbyte: Not relevant
Lowbyte : Dual timing mode
7
6
5
4
3
2
1
not relevant
not relevant
not relevant
not relevant
not relevant
not relevant
not relevant
0 1 = dual timing mode on 0 = dual timing mode off
Dual timing mode on means : Running time counter starts when set speed is reached.
Dual timing mode off means : Running ting time counter starts at start of centrifugation
