HiB Trim Curve 40 User manual

Fitting Instructions
Thank you for purchasing this HiB product.
Please read through these instructions carefully and refer back to
them during installation to ensure that your product is fitted safely
and that it retains its high quality finish.
FI#01 036 R210706 Ver No. 1.0 Oct 2021
TRIM
Trim Curve 40 Black: Art No 62010000
Trim Curve 40 Brushed Brass: Art No 62020000
Trim Curve 50 Black: Art No 62030000
Trim Curve 50 Brushed Brass: Art No 62040000
Trim Round 60 Black: Art No 62050000
Trim Round 60 Brushed Brass: Art No 62060000
Trim Round 80 Black: Art No 62060000
Trim Round 80 Brushed Brass: Art No 62070000
Trim Round
Trim Curve

2
Warnings for Safe Use
• This product is intended for Domestic Use only
• Please read the instructions and warnings carefully before installing the product
and ensure this document is kept with the product for future reference to ensure
product longevity and in the interest of safety.
• If you give the product to another person, please give them this manual as well.
• If any modification is made it will invalidate the warranty and may render the
product unsafe.
• It is not suitable for use in saunas, steam rooms and shower cubicles.
• When drilling use appropriate eye protection.
• The use of a Residual Current Device (RCD) is advised for any power tools used
during the installation of this product.
• Take suitable precautions when handling glass.
• Do not use if glass is broken or unsafe.
• Beware of hidden cables or pipes. Take care if drilling on tiled surfaces in case the
drill slips.
• It is recommended that this product is installed by a person who is able to meet
the level of competence required in order to comply with relevant regulations. If
in doubt consult a qualified tradesperson.
• This product is designed for installation into a brick or masonry block wall, if
mounting onto other substrate ensure appropriate fixing and batons (if required)
are used and the load bearing of the wall is sufficient.
• It is recommended that this product is installed by two people.
• Avoid leaving excessive standing and surface water on the product for prolonged
periods of time.
• Dispose of packaging in accordance to local authority regulations.
• At end of life dispose of item according to local authority regulations.
Caution
We recommend that you place this mirror on a so flat surface to ensure no
breakages. We also recommend that you leave corner protectors on until
final fitting.
CAUTION

3
hib.co.uk
What’s in the Box?
Tools Required
Pencil Spirit Level Drill Drill bit Screwdriver
• Trim Mirror
• Fittings pack
Installation
It is recommended that this product is installed by two people.
1. Position the mirror in a suitable location.
2. Carefully mark the position of the mirror using a so pencil ensuring it is level.
Remove the mirror and mark the mounting points, see Fig. 1 overleaf. Please
ensure that all marked mounting points accurately match up with the
fixing points on the mirror.
3. Using a suitable drill bit, drill holes in the marked positions to a suitable
depth. If drilling through tile, use a ceramic drill bit.
4. Insert wall plugs level with the surface of the wall. If fitting to a tiled surface,
wall plugs should be inserted below the tile surface to avoid cracking. NB.
For plasterboard walls, specialist fixings should be purchased, available
from any DIY or hardware store.
5. Screw supplied fixings into wall plugs.
6. Hang the mirror in position.

©HiB Copyright: No part of this document may be reprinted or duplicated without HiB consent. All sizes and measurements are approximate, but we do try
and make sure they are as accurate as possible. In the interest of continuous product development, HiB reserves the right to alter specifications as necessary.
E & OE.
T: [phone] F: [phone] E: [e-mail] hib.co.uk
Building 3, North London Business Park, Oakleigh Road South, New Southgate, London. N11 1GN
Figures
A = Mounting Points
A
A
A
Fig 1. - Mounting points
Care
Aftercare
In the unlikely event that this product should fail please contact the retailer
from which the item was purchased.
To preserve the high quality finish of your HiB product, please ensure you
regard the following care and cleaning recommendations:
• Use only a so damp cloth.
• Wipe off all water spillages as soon as possible.
• Do not use any abrasives or solvents.
WEEE compliance
Must not be mixed with
general household waste
