Aluminium Cabinets - Fixing Instructions
Thank you for purchasing this HiB product. Please
read through these instructions carefully and refer
back to them during installation to ensure that your
product is fitted safely and that it retains its high
quality finish.
Please retain this leaflet for future reference.
Electrical Safety Information
Before drilling, ensure there are no hidden cables or
pipes in the wall.
Jupiter Art no.43600 Mars Art no. 43500
Care Instructions
To preserve the high quality finish of your HiB
product, please ensure you regard the following
care and cleaning recommendations:
-
-
-
-
wipe off all water spillages as soon as
possible
mirrors and glass can be cleaned with a
proprietary cleaner using a soft cloth, taking
care not to get excessive cleaner behind
the mirror
all other surfaces should be cleaned with
diluted detergent, i.e. washing up liquid,
and a soft cloth
scourers and scouring agents should not
be used, as these may cause damage to
the surface of the product.
Mercury Art no.43700

1) Position the cabinet in a suitable location and
carefully mark the position of the top of the cabinet
using a soft pencil.
2) Remove the cabinet from the wall and using a
spirit level, mark a horizontal line 50mm below the
original pencil mark. Hold the mounting bracket in
place with the holes corresponding with the marked
line. Ensure the bracket is central, and mark the
position of the holes.
3) Before drilling, ensure there are no hidden cables
or pipes behind the mounting points. Drill the
required holes in the marked positions. If drilling
through tile, use a ceramic drill bit. Insert the wall
plugs level with the surface of the wall. If fitting
to a tiled surface, wall plugs should be inserted
below the tile surface to avoid cracking. NB. For
plasterboard walls, specialist fixings should be
purchased, available from any DIY or hardware
store. Fix the bracket to the wall using the screws
provided.
6) Hang the cabinet on the wall ensuring that it
is firmly located on the mounting bracket. Align
doors according to the diagram above.
8) Starting with the top shelf, insert the shelf
supports in the desired position and fit the shelf.
7) Drill a hole in the wall at the marked position
using a 6mm drill bit and insert a rawl plug.
Replace the cabinet and fix to the wall using
the screw, washer and cover supplied.
door adjustment shelf assembly
attaching brackets
fixing preparation
wall mounting
Final Assembly
