HiB Globe 45 User manual

T: [phone] F: [phone] E: [e-mail] hib.co.uk
Building 3, North London Business Park, Oakleigh Road South, New Southgate, London. N11 1GN
©HiB Copyright: No part of this document may be reprinted or duplicated without HiB consent. All sizes and measurements are approximate, but we do try and make sure they are as accurate as possible. In the
interest of continuous product development, HiB reserves the right to alter specifications as necessary. E & OE.
This product is suitable for installation in zones:
FI#01 002 R150909 Ver No. 1.0 Jan 2016
2 &Outside Zone
All installations must comply with guidelines which are based on a zonal
concept. The diagram above illustrates this concept and must be followed
to ensure the safe installation of electrical appliances in the bathroom.
These regulations apply to domestic installations only. Installations must be
made in accordance with the current IEE wiring regulations and relevant
building regulations. HiB recommends that all electrical bathroom
products should only be fitted by a suitably qualified, Part P registered
electrician.
Thank you for purchasing this HiB product.
Please read through these instructions carefully and refer back to them
during installation to ensure that your product is fitted safely and that it
retains its high quality finish.
Please retain this leaflet for future reference.
Before installation, ensure the domestic electrical mains supply to
which the mirror is to be connected is turned off. Before drilling,
ensure that there are no hidden cables or pipes in the wall.
(Fig. 1)
NB. These products must be installed with a minimum distance of 150mm
between the infra-red sensor switch and any adjacent wall or object to
ensure correct operation of the sensor.
Mounting Points Diagram (Fig. A)
Illuminated Mirrors
Globe 45 Art No. 78400000 / Globe 50 Art No. 78500000
Globe 60 Art No. 78600000 / Globe 120 Art No. 78700000
Sonic Art No. 77430000 / Orb 50 Art No. 78550000
Orb 60 Art No. 78650000 / Zircon 50 Art No. 77600000
Zircon 60 Art No. 77610000 / Zircon 80 Art No. 77620000
Fleur Art No. 77440000 / Fahrenheit 50 Art No. 77480000
Fahrenheit 60 Art No. 77490000
Fahrenheit 80 Art No. 77500000
Care Instructions
Do not use abrasives or solvents when cleaning this product.
Wipe off all water spillages as soon as possible using a so, damp cloth.
Aercare Service
In the unlikely event that this product should fail please contact HiB
customer services, details shown below.
Installation
1. Position the mirror in a suitable location (according to the zonal
diagram - Fig. 1), ensuring that the domestic electrical mains
supply is within reach of the electrical entry point of the product.
2. Carefully mark the position of the mirror using a so pencil
ensuring it is level. Remove the mirror and mark the mounting
points. Please ensure that all marked mounting points
accurately match up with the fixing points on the mirror.
3. Using a suitable drill bit, drill holes in the marked positions to a
suitable depth. If drilling through tile, use a ceramic drill bit.
4. Insert wall plugs level with the surface of the wall. If fitting to a
tiled surface, wall plugs should be inserted below the tile surface
to avoid cracking. NB. For plasterboard walls, specialist fixings
should be purchased, available from any DIY or hardware store.
5. Screw supplied fixings into wall plugs.
6. Ensure the domestic electrical mains supply to which the
mirror is being connected is turned off. Connect the domestic
mains supply to the terminal box according to the wiring diagram
overleaf (Fig. B).
7. Hang the mirror in position.
8. Switch the domestic electrical mains supply for the mirror back
on.
Operation Instructions
To turn illumination on or off, wave hand under the sensor switch
located at the bottom of the mirror.
Heated Pad is only on when mirror is illuminated.
Globe 45
Globe 50
Globe 60
Globe 120
Orb 50
Orb 60
Sonic
Fleur
Fahrenheit 50
Fahrenheit 60
Fahrenheit 80
Zircon 50
Zircon 60
Zircon 80
mounting points
REAR VIEW
mounting points
REAR VIEW
Hanging Portrait
Hanging landscape

T: [phone] F: [phone] E: [e-mail] hib.co.uk
Building 3, North London Business Park, Oakleigh Road South, New Southgate, London. N11 1GN
©HiB Copyright: No part of this document may be reprinted or duplicated without HiB consent. All sizes and measurements are approximate, but we do try and make sure they are as accurate as possible. In the
interest of continuous product development, HiB reserves the right to alter specifications as necessary. E & OE.
live
earth
neutral
MAINS SUPPLYLUMINAIRE
Wiring Diagram
Live supply can be Red or Brown
Earth supply is Green and Yellow
Neutral supply can be Blue or Black
Live is Brown
Earth is Green and Yellow
Neutral is Blue
Caution
How to Isolate the sensor so you can switch ON & OFF with a mains switch (Fig. 2)
live
earth
neutral
How the mirror is wired.
Charger socket/transformer
Sensor switch controller
LED driver
Heated mirror pad
INOUT
live
earth
neutral
How to isolate the sensor.
Charger socket/transformer
Sensor switch controller
LED driver
Heated mirror pad
INOUT
Rewire the mirror as shown in the diagram above. HiB recommends that all electrical bathroom products should only be fitted by a suitably
qualified, Part P registered electrician.
For further assistance on isolating the sensor please contact us at:
Tel: [phone]
Email: [e-mail]
Please do not li the product by the plastic diffusers as
this may cause damage to your product.
We recommend that you place this mirror on a so flat surface to ensure
no breakages. We also recommend that you leave corner protectors on
until final fitting
Wiring Diagram (Fig. B)
WEEE compliance
Must not be mixed with general household waste
