HiBoost Mini Series User manual

Mini Series
Installation Guide
Dot 2.0

Package Contents
Signal Booster Outdoor Cable Outdoor Antenna Indoor Whip Antenna
Power Supply waterproof tape
Accessories for main parts
Dot 2.0
01
are all provided to protect connections
49.2ft NM-SMAM
Alarm(ISO) Bluetooth Wi-Fi
Booster Light Patterns
LED STATUSINDICATORS
Bluetooth LED
Wi-Fi LED solid blue wifi disconnected
slow flashing blue wifi connected
ALARM(ISO)
solid blue normal
slow flashing blue slight loopback
quick flashing blue loopback
quick flashing red
slow flashing blue
quick flashing blue
bluetooth disconnected
bluetooth connected
booster automatically shut off due to
strong loopback/overload

Step 1
Connect the Power Supply to the Booster
02
Signal BoosterPower Supply
Step 2
Connect the Booster with the App
Getting Started
Register an ID first and log in.
Add the booster to the device list.
Bands contained in the Gauges on Signal Supervisor
Gauge Band Uplink Downlink
12/17 698-716MHz 728-746MHz
13 776-787MHz 746-757MHz
5 824-849MHz 869-894MHz
LTE700
CELL800
Please focus on the gauge that contains the band you are using

Download NetWork Cell Info Lite in the Google store and open it.
It can be seen from the example picture that the frequency band is band 13.
(According to the form before, you need to pay attention to Gauge LTE700)
Then click MAP. You can see your phone connecting to a tower, and you can try
aiming your outdoor antenna at it. But sometimes this is not accurate. You could also
move to Step 3.2 to find the tower
Note: Please take screenshots at this stage.
03
Step 3
Find the cell tower & Determine the outdoor antenna’s position
3.1 Find the band you are using
For Android

04
(1) Dial *3001#12345#*
(2) Follow the instructions, take the screenshots as required.
(1) Enter cellmapper.net
(2) Choose your own carrier and band here.
3.2 Find the cell tower
For ios
AT&T AT&T

05
(3) Then enter the coordinate of where you are trying to install the signal booster, and press
Enter key.
(In fact when you open Cellmapper, the map on the right will automatically locate your area
if you've given the site permission to access your location. If you found tower sites not even
displayed on the map, it might because the app intercepts the locations for security
reasons.)
(4) After the map jumps to the location, you can scroll the mouse pulley and zoom it out,
then you will see the tower near the location. It would be better to take a screenshot of this
page to guide the following installing steps. Should you have any questions, please contact
our tech support.
Note: If you need help finding the tower, please contact our tech support and provide your
carrier, band and screenshots taken in the last steps.

06
Signal BoosterOutdoor CableOutdoor Antenna
49.2ft SMAM-NM
Step 4
Connect the outdoor antenna with the booster
3.3 Determine the outdoor antenna’ s position
The outdoor antenna is usually placed at one of the 4 ends of the roof.
Please choose the position according to the tower’ s location. Make sure there are no barriers
between the antenna and the tower.
Note：At this stage, don’ t connect the indoor antenna to the booster.

07
Step 5
Adjust and fix the Outdoor Antenna
Step 6
Connect the indoor antenna with the booster
Step 7
Adjust the indoor antenna
Place the signal booster on a table and make sure
the booster is within the coverage area.
Have your outdoor antenna pointed to the cell tower
you found before and observe the reading on the
app. Adjust the outdoor antenna accordingly.
Notes:
(1) The output power should be the higher the better.
(2) The full output power for Dot is 10dBm. And the full
gain is 60dB.
Make sure that the gain reaches about 60dB. If not,
please increase the vertical and horizontal
distance between the two antennas or add some
barriers.

08
OVERLOAD
DL GAIN OUTPUT POWER REASON SOLUTIONLED LIGHT PATTERN
<60dB >=8dBm
Outdoor signal is too strong
<60dB >=8dBm
LTE700
CELL800
4 Regular Problems and 1 normal status
Iftheboosterisworkingnormally,nofurtheradjustmentisrequired
Step 8
Signal quality test
You could do the following:
(1)First make sure the signal gauge value is unchanged from that during
the outdoor antenna installation.
(2)Do speed tests with the booster on and off, and make a comparison.
(3)Check if the number of signal bars increases.
(4)Make a phone call or send messages and check if the voice and
streaming are better.
Have your outdoor antenna
pointed slightly away from the
cell tower
ISO（Alarm）light
blinking red
LOOP BACK
DL GAIN OUTPUT POWER REASON SOLUTIONLED LIGHT PATTERN
<60dB <8dBm
<60dB <8dBm
LTE700
CELL800
1、Increase vertical and
horizontal distance.
2、Add barriers(e.g. walls)
Please try these solutions until
the gain reaches or is over 60dB.
Inadequate separation
of the indoor and
outdoor antennas
ISO（Alarm）light
blinking blue or red
POOR SIGNAL
DL GAIN OUTPUT POWER REASON SOLUTIONLED LIGHT PATTERN
>=60dB --/NEGATIVE
>=60dB --/NEGATIVE
LTE700
CELL800
1、Try adjusting the outdoor
antenna to the best direction
2、Try adjusting the outdoor
antenna to another cell tower
3、Try increasing the height of
the outdoor antenna and make
sure there are no barriers
between the tower and the
outdoor antenna
Please try these solutions until
the output power reaches or is
over -5dBm.
Input signal is too weak
ISO（Alarm）light
solid blue

Note:
Some customers have some misunderstandings about boosters, and we would like to clarify
it here:
If you can't even get a stable 1 bar outside the house or on the roof, then we suggest you
return it as it won't work in areas with very weak signal, the same is true of all boosters on the
market.

Technical Specifications
NORMAL
DL GAIN OUTPUT POWER REASON SOLUTIONLED LIGHT PATTERN
>=60dB >=-5dBm
>=60dB >=-5dBm
LTE700
CELL800
ISO（Alarm）light
solid blue
Normal but No Boosted Signal
DL GAIN OUTPUT POWER REASON SOLUTIONLED LIGHT PATTERN
>=60dB >=-5dBm
>=60dB >=-5dBm
LTE700
CELL800
Check the band you are using
again. If it stays at band66,get
into the 'detail'/'setting' of
gagues on Signal Supervisor
and switch off RF switch of
AWS2100, then adjust the
outdoor antenna again. It would
be better if there are two
persons and one can stay near
the indoor antenna to check if
the signal is boosted.
1、The band is not
supported
2、The Signal is from
other carriers
ISO（Alarm）light
solid blue
Working Band
UL Frequency Range(MHz)
DL Frequency Range(MHz)
Supported Standards
Max. Gain
Max. output power
MGC (Step Attenuation )
I/O Port
Impedance
Environment Conditions
Dimensions
Weight
Power Supply
824-849/698-716/776-787
869-894/728-746/746-757
Band 5 / Band 12 / Band 13
60 dB
UL 18 dBm,DL 10dBm
≥ 25 dB / 1 dB step
50 ohm
IP40
6.77*4.41*0.75in
≤ 3.3 lbs / 1.5 kg
Input AC100~240 V, 50/60 Hz, Output DC 5 V / 3 A
CDMA, LTE
Dot
Model No.
SMA-Female
09

Download Signal Supervisor or enter our website.
a. You can download the specific user manual.
b. You can reach our technical support for help.
For more information
www.hiboost.com.
10
