HID DTC1000M User manual

15370 Barranca Parkway
Irvine, CA 92618-2215
USA
DTC1000 / DTC1000M / DTC4000 User Guide
P/N: L001398, Revision 1.5

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
2
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (Rev. 1.5), © 2012 property of HID
Global Corporation. All rights reserved.
Exclusive permission is granted to authorized resellers of HID Global products to reproduce and
distribute this copyrighted document to authorized HID Global customers, who have signed a no
disclosure agreement regarding the restricted, proprietary use of said document.
The revision number for this document will be updated to reflect changes, corrections, updates and
enhancements to this document.
Revision Control
Number
Date
Document Title
Revision 1.5
March 2012
DTC1000/DTC1000M/DTC4000
Card Printer/Encoder User Guide
DTC1000M
Revision 1.4
Xxxx 2011
DTC1000/DTC4000
Card Printer/Encoder User Guide
#44 Flipper Table Level (Troubleshooting
with the Error Message Table)
Added Connecting the Printer power
Power Supply Efficiency Level V
minimum (Regulatory Compliances)
Revision 1.3
January 2011
DTC1000/DTC4000
Card Printer/Encoder User Guide
Revision 1.2
August 2010
DTC1000/DTC4000
Card Printer/Encoder User Guide
Trademarks and Disclaimers
HID, HID Global, and Fargo are the trademarks or registered trademarks of HID Global Corporation in the U.S. and other
countries.
The information contained in this document is provided AS IS without any warranty.
HID Global hereby disclaims all warranties and conditions with regard to the information contained herein, including all implied
warranties of merchantability, fitness for a particular purpose, title and non-infringement.
In no event shall HID Global be liable, whether in contract, tort or otherwise for any indirect, special or consequential damages
arising from the use of the information contained in this document.
Any questions regarding changes, corrections, updates or enhancements to this document should be forwarded to:
Hid Global-Support Services
6533 Flying Cloud Drive
Eden Prairie, MN 55344 (USA)
[phone] Ext #6
FAX: [phone]
www.hidglobal.com

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
3
Table of Contents
DTC1000 / DTC1000M / DTC4000 User Guide ________________________________________________ 1
Section 1: Specifications___________________________________________________________________ 5
Regulatory Compliances ___________________________________________________________________________ 5
Agency Listings__________________________________________________________________________________6
United States__________________________________________________________________________________ 6
Canada ______________________________________________________________________________________6
Environmental Protection (China-RoHS) ______________________________________________________________7
Traditional Chinese RF Emissions and Safety Statements _______________________________________________7
Simplified Chinese _____________________________________________________________________________ 8
Safety Messages (review carefully)___________________________________________________________________9
Technical Specifications __________________________________________________________________________ 10
Functional Specifications__________________________________________________________________________ 14
Printer Components: Print Ribbons _______________________________________________________________ 14
Ribbon Types/Count Table ________________________________________________________________________ 15
Printer Components: Blank Cards ________________________________________________________________ 16
Section 2: Setup and Installation Procedures _________________________________________________ 17
Choosing a Good Location ________________________________________________________________________17
About Moisture Condensation ___________________________________________________________________17
Unpacking and Inspection_______________________________________________________________________17
Installing the Print Ribbon Cartridge (DTC1000/DTC1000M, and DTC4000) ________________________________ 18
Installing the Ribbon___________________________________________________________________________ 19
Installing Blank Cards into the Card Hopper (DTC1000, DTC1000M, and DTC4000) __________________________ 21
Setting the Card Size for CR79 and CR80 __________________________________________________________ 23
Connecting the Printer power ____________________________________________________________________ 27
Section 3: Print Driver Installation _________________________________________________________ 28
Driver Installation Instructions _____________________________________________________________________ 29
Swift ID Installation Instructions____________________________________________________________________31
Installing Swift ID _______________________________________________________________________________33
Printer Installed On Network ____________________________________________________________________ 34
Printer Connected Via USB Connection ______________________________________________________________ 36
Option No. 1 _________________________________________________________________________________ 36
Option No. 2 _________________________________________________________________________________ 36
Uninstalling Swift ID __________________________________________________________________________ 37
Additional Swift ID Rules ______________________________________________________________________ 37
Section 4: Printer Preferences Tab Functions ________________________________________________ 38
Using the Card tab_______________________________________________________________________________ 38
Using the Toolbox Options ________________________________________________________________________ 40
Using the Configuration tab _____________________________________________________________________ 41
Using the Event Monitoring Group Box____________________________________________________________ 41
Using the Calibrate Ribbon tab___________________________________________________________________ 42
Using the Clean Printer tab______________________________________________________________________ 43
Using the Advanced Settings tab _________________________________________________________________ 45
Using the Device Options tab ______________________________________________________________________ 54
Using the Image Color tab_________________________________________________________________________ 58
Using the Image Calibrate tab ______________________________________________________________________ 61
Using the Magnetic Encoding Tab __________________________________________________________________ 62

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
4
Using the Magnetic Encoding Tab –ISO Standards___________________________________________________ 63
Using the Magnetic Encoding Tab –Custom Encoding or Raw Binary Encoding Mode ______________________ 65
Reviewing the ISO Track Locations_______________________________________________________________ 66
Reviewing the Sample String ____________________________________________________________________67
Sending the Track Information ___________________________________________________________________ 68
Reviewing the ASCII Code and Character Table _____________________________________________________ 69
Using the Overlay / Print Area tab___________________________________________________________________ 71
Using the K Panel Resin tab _______________________________________________________________________ 74
Using the Printer Info tab _________________________________________________________________________ 77
Section 5: Selecting the Fluorescent Panel Ribbon Type (DTC4000 only) __________________________ 78
Creating a Custom Fluorescent Image (using the YMCFKO Ribbon) _______________________________________ 78
Configuring Fluorescent Data (F-Panel for YMCFKO Ribbon) using the Application __________________________ 80
Section 6: System Overview- Troubleshooting ________________________________________________ 84
Reviewing the DTC1000/DTC1000M/DTC4000 Sequence of Operations____________________________________ 84
Section 7: Troubleshooting ________________________________________________________________ 86
Printer Error Button and Display Message Table _______________________________________________________ 86
Using the Error Message Table _____________________________________________________________________88
Troubleshooting with the Error Message Table_________________________________________________________ 89
Printer Specific Tools (DTC1000/DTC4000) __________________________________________________________ 97
Additional Printer Specific Tools _________________________________________________________________ 99
Section 8: Cleaning _____________________________________________________________________ 101
Safety Messages (review carefully)_________________________________________________________________ 101
DTC1000, DTC1000M , and DTC4000 Card Printer/Encoders Cleaning Kit ________________________________ 102
Supplies (included with the Cleaning Kit) _________________________________________________________ 102
Printhead Cleaning _____________________________________________________________________________103
Cleaning the Platen and the Card Feed Rollers______________________________________________________ 104
Cleaning the Printer’s Exterior ____________________________________________________________________ 108
Section 9: Firmware Upgrades____________________________________________________________ 109
Upgrade the Printer Firmware _____________________________________________________________________ 109
Section 10: HID Global Technical Support__________________________________________________ 112
Reading the Serial Numbers on a Fargo Printer _______________________________________________________ 113
Appendix A ____________________________________________________________________________ 114
Using the Defined Area Option ____________________________________________________________________114
Configuring Fluorescent Data (F-Panel for YMCFKO Ribbon) using the Workbench _________________________ 115

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
5
Section 1: Specifications
The purpose of this section is to provide you with specific information on the Regulatory Compliances,
Agency Listings, Technical Specifications and Functional Specifications for the
DTC1000/DTC1000M/DTC4000 Card Printer User Guide.
Regulatory Compliances
Term
Description
UL
The Card Printer is listed under UL 60950-1 (2nd edition)
INFORMATION TECHNOLOGY EQUIPMENT
Note: This product is intended to be supplied by a Listed Power
Unit marked Class 2 and rated for 24 V dc, 3.3A minimum
CSA
(cUL)
The Printer manufacturer has been authorized by UL to
represent the Card Printer as CSA Certified under CSA
Standard C22.2 IEC 60950-07 2nd edition
File Number: E145118
FCC
The Card Printer complies with the requirements in Part 15 of
the FCC rules for a Class A digital device.
CE
The Card Printer has been tested and complies with EN300-
330-1, EN300-330-2, EN301-489-1, and EN60950-1:2006 +
All:2009
(Note: Based on the above testing, the Printer manufacturer
certifies that the Card Printer complies with the following
directives of the European Community and has placed the CE
mark on the Card Printer.)
LVD 2006/95/EC, EMC 2004/108/EC, R+TTE 1999/5/EC,
ROHS 2002/95/EC
Environmental
Power supply Efficiency level V minimum. RoHS, China RoHS

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
6
Agency Listings
Term
Description
Emissions
Standards
FCC Part 15 Class A, RSS-GEN, RSS 210, CNS 13438, CNS
14336, EMC 2004/108/EC, R&TTE 1999/95/EC,GB9254-2008, GB
17625
Safety Standards
UL IEC 60950-1 (2nd edition), CSA C22.2 No. 60950-1-07 LVD
2006/95/EC, GB4943
Additional Agency
Listings
CCC, BSMI, KCC
United States
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference; in which case, you will be required
to correct the interference at his own expense.
Canada
This Class A digital apparatus complies with Canadian ICES-003.
C‟et appareil numerique de la classe A est comforme a la norme NMB-003 du Canada.
Caution: Changes or modifications not expressly approved by the party responsible for
compliance could void the user‟s authority to operate the equipment.

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
7
Environmental Protection (China-RoHS)
Environmental Protection Use Period is based on the product being used in an office environment.
Traditional Chinese RF Emissions and Safety Statements

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
8
Simplified Chinese

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
9
Safety Messages (review carefully)
Symbol
Critical Instructions for Safety purposes
Danger:
Failure to follow these installation guidelines can result in death
or serious injury.
Information that raises potential safety issues is indicated by a
warning symbol (as shown to the left).
To prevent personal injury, refer to the following safety
messages before performing an operation preceded by this
symbol.
To prevent personal injury, always remove the power cord prior
to performing repair procedures, unless otherwise specified.
To prevent personal injury, make sure only qualified personnel
perform these procedures.
Caution:
This device is electrostatically sensitive. It may be damaged if
exposed to static electricity discharges.
Information that raises potential electrostatic safety issues is indicated
by a warning symbol (as shown to the left).
To prevent equipment or media damage, refer to the following
safety messages before performing an operation preceded by this
symbol.
To prevent equipment or media damage, observe all
established Electrostatic Discharge (ESD) procedures while
handling cables in or near the Circuit Board and Printhead
Assemblies.
To prevent equipment or media damage, always wear an
appropriate personal grounding device (e.g., a high quality wrist
strap grounded to avoid potential damage).
To prevent equipment or media damage, always remove the
Ribbon and Cards from the Printer before making any repairs,
unless otherwise specified.
To prevent equipment or media damage, take jewelry off of
fingers and hands, as well as thoroughly clean hands to remove
oil and debris before working on the Printer.

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
10
Technical Specifications
Term
Function
Print Method
Dye Sublimation / Resin Thermal Transfer
Print resolution
300 dpi (11.8 dots/mm); continuous tone
Colors
Up to 16.7 million colors / 256 shades per pixel
Print Ribbon
Options
Full-color with resin black and overlay panel, YMCKO*, 250
prints
Full-color half-panel with resin black and overlay panel,
YMCKO*, 350 prints
Full-color with two resin black panels and overlay panel,
YMCKOK*, 200 prints
Full-color with fluorescing, two resin black panels and overlay
panel, YMCFKO*, 200 prints
Full-color with fluorescing, two resin black panels and overlay
panel, YMCFKOK*, 175 prints
Resin black and overlay panel, KO*, 500 prints
Dye-sublimation black and overlay print, BO*, 500 prints
Resin black (standard and premium), 1000 prints
Resin green, blue, red, white, silver and gold, 1000 prints
Rewrite technology –No ribbon is required
* Indicates the Ribbon type and the number of Ribbon panels
printed where Y=Yellow, M=Magenta, C=Cyan, K=Resin Black,
O=Overlay, F=Fluorescing Resin

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
11
Technical Specifications
Term
Function
Print Speed
7 seconds per card (K*)
12 seconds per card (KO*)
24 seconds per card (YMCKO*)
31 seconds per card (YMCKOK*)
Print speed indicates an approximate batch print speed and
is measured from the time a card feeds into the Printer to the
time it ejects from the Printer.
Print speeds do not include encoding time or the time
needed for the PC to process the image.
Process time is dependent on the size of the file, the CPU,
amount of RAM and the amount of available resources at the
time of the print.
* Indicates the Ribbon type and the number of Ribbon panels
printed where Y=Yellow, M=Magenta, C=Cyan, K=Resin Black,
O=Overlay, F=Fluorescing Resin
Card Size and
Types Supported
CR-80 (3.375"L x 2.125"W / 85.6mmL x 54mmW)
CR-79 (3.313”L x 2.063”W / 84.1mmL x 52.4mmW
Accepted Standard
Card Sizes
CR-80 edge-to-edge (3.36"L x 2.11"W / 85.3mmL x
53.7mmW)
CR-79 (3.3”L x 2.04”W / 83.8mmL x 51.8mmW)
Accepted Card
Thickness
.009” - .040” / 9 mil – 40 mil / .229mm –1.016mm
Accepted Card
Types
PVC or polyester cards with polished PVC finish; monochrome
resin required for 100% polyester cards; optical memory cards
with PVC finish; rewrite

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
12
Technical Specifications
Term
Function
Input Hopper Card
Capacity
100 cards (.030” / .762.mm) DTC1000, DTC1000M, DTC4000
200 cards (.030” / .762 mm) DTC4000 (Dual Hopper)
Output Hopper Card
Capacity
100 cards (.030” / .762.mm) DTC4000
30 cards (.030” / .762.mm) DTC1000
Reject Hopper Card
Capacity
100 cards (.030” / .762.mm) –same-side Input/Output Card
Hopper (required)
Card Cleaning
Card cleaning roller integrated into the Ribbon Cartridge.
A new cleaning roller is included with each Ribbon Cartridge.
Printer Memory
32MB RAM
Software Driver
Windows® XP / Vista™ (32 bit & 64 bit) / Server 2003 & 2008 /
Windows® 7 (32 bit & 64 bit) / Linux®
Interface
USB 2.0 and Ethernet with internal print server
Operating
Temperature
65 degrees to 80 degrees F / 18 degrees to 27 degrees C
Humidity
20-80% non-condensing
Dimensions
Here are the dimensions for the DTC1000:
Single-Sided Printer: 8.8˝H x 13.7˝W x 7.9˝D / 224mmH x
348mmW x 201mmD (DTC1000M)
Dual-Sided Printer: 9.8˝H x 18.7˝W x 9.2˝D / 249mmH x
475mmW x 234mmD
Here are the dimensions for the DTC4000:
Single-Sided Printer: 9.8˝H x 18.1˝W x 9.2˝D / 249mmH x
460mmW x 234mmD
Dual-Sided Printer: 9.8˝H x 18.7˝W x 9.2˝D / 249mmH x
475mmW x 234mmD
Weight
Single-Sided: 8 lbs. / 3.63 Kg; Dual-Sided: 10 lbs. / 4.54 Kg
Agency Listings
Safety: UL 60950-1, CSA C22.2 (60950-1), and CE; EMC; FCC
Class A, CRC c1374, CE (EN 55022 Class A, EN 55024), CCC,
BSMI, KCC

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
13
Technical Specifications
Term
Function
Supply Voltage
100-240 VAC, 1.6 A
Supply Frequency
50 Hz / 60 Hz
Warranty
Printer –Two years; Printhead –Two years, unlimited pass with
UltraCard™
Encoding Options
Supported
125kHz (HID Prox) reader
13.56 MHz (iCLASS, MIFARE, ISO 14443 A/B, ISO 15693)
read/write encoder
Contact Smart Card Encoder reads from and writes to all
ISO7816 1/2/3/4 memory and microprocessor smart cards
(T=0, T=1) as well as synchronous cards
ISO Magnetic Stripe Encoding, dual high- and low-coercivity,
Tracks 1,2 and 3
Options
Single Wire Ethernet and USB 2.0 Interface for inline printing
and encoding
Single wire Ethernet encoding is only available for iCLASS
and Contact Smart Card encoding)
Dual-Sided Printing Module –Upgradable
Dual Input Card Hopper –Upgradable (DTC4000)
Same-Side Input / Output Card Hopper –Upgradable
(DTC4000)
Smart Card Encoding (contact / contactless) –Upgradable
Magnetic Stripe Encoding –Upgradable
Printer Clearing Kit
Software
Swift ID™Embedded Badging Application, FARGO Workbench
Diagnosis Utility
Display
Color changing status buttons (DTC1000, DTC4000)
Graphical Display (DTC4000)

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
14
Functional Specifications
This Card Printer utilizes two different, yet closely related printing technologies to achieve its remarkable
direct-to-card print quality for dye-sublimation and resin thermal transfer.
Printer Components: Print Ribbons
The Card Printer utilizes both dye-sublimation and/or resin thermal transfer methods to print images
directly onto blank cards. Since the dye-sublimation and the resin thermal transfer print methods each
provide their own unique benefits, Print Ribbons are available in resin-only, dye-sublimation-only and
combination dye-sublimation/resin versions.
To make it easier to remember which Print Ribbons are which, a letter code has been developed to
indicate the type of Ribbon panels found on each Ribbon. This letter code is as follows:
= Dye-Sublimation Yellow Panel
= Dye-Sublimation Magenta Panel
= Dye-Sublimation Cyan Panel
= Resin Black Panel (Premium unless otherwise stated)
= Clear Protective Overlay Panel
= Fluorescing Panel

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
15
Ribbon Types/Count Table
Ribbon type and count used in each Printer.
Ribbon
DTC1000
DTC4000
DTC1000M
YMCKO –Full Color/Resin
Black/Overlay
250
250
YMCKO Half Panel –Full
Color (1/2)/Resin
Black/Overlay
350
350
YMCFKO - Full Color/UV
Fluorescing/Resin
Black/Overlay
200
YMCKK - Full Color/2 Resin
Black
YMCKOK - Full Color/2
Resin Black/Overlay
200
200
YMCFKOK - Full Color/UV
Fluorescing/2 Resin
Black/Overlay
175
K –Standard Resin
1000
1000
1000
K –Premium Resin
1000
1000
1000
Colored Resin
1000
1000
1000
KO - Premium Black
Resin/Overlay
500
500
500
BO - Dye-Sub Black/Overlay
500
500
500
None –Rewritable
Supported
Supported
Supported

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
16
Printer Components: Blank Cards
Type
Description
Card Size
The Card Printer accepts standard CR-79 and CR-80 sized cards.
Card
Surface
Suitable cards must have a polished PVC surface free of fingerprints, dust
or any other types of embedded contaminants. In addition, cards must
have a completely smooth, level surface in order for the Printer to achieve
consistent color coverage.
Certain types of Proximity cards have an uneven surface that will
inhibit consistent color transfer.
Certain types of smart card chips are raised slightly above the cards
surface which also results in poor color transfer.
UltraCard™
Brand
Cards
The UltraCard product line, available exclusively as part of HID's Global's
Fargo brand secure card issuance solutions, has a long standing
reputation among dealers and end-Users for consistent quality in
construction.
In addition to blank stock, the UltraCard line is available in a variety of
configurations for magnetic stripe, custom holograms and other
additional anti-counterfeiting feature
UltraCard™ Premium is the preferred card for Direct-to-Card (DTC®)
applications that require a higher quality card. The UltraCard
Premium‟s composite material construction provides for maximum
durability, flexibility and card life, with optimal resolution print quality
for lamination and fluorescent panel Ribbon printing applications.
UltraCard™ PVC cards are medium-durability cards for a glossy,
photo quality finish. These cards are manufactured to ensure clean,
scratch-free cards for high-quality prints and extended Printhead life.

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
17
Section 2: Setup and Installation Procedures
This section describes the setup and installation for the DTC1000, DTC1000M, and the DTC4000
Card Printers.
Choosing a Good Location
Follow these guidelines:
Place the unit in a location with adequate air circulation to prevent internal heat build up.
Use the Printer's dimensions as a guideline for the minimum clearances to the unit. (Note: Allow for
adequate clearance in front of the unit to accommodate the unit with its Covers open.)
Do not install unit near heat sources such as radiators or air ducts or in a place subject to direct
sunlight, excessive dust, mechanical vibration or shock.
About Moisture Condensation
If the unit is brought directly from a cold to a warm location or is placed in a very damp room, moisture
may condense inside the unit. Should this occur, print quality may not be optimum.
Leave the unit unplugged in a warm, dry room for several hours before using. This will allow the moisture
to evaporate.
Caution: For safety purposes, Ethernet is not intended for a direct connection outside of the
building.
Unpacking and Inspection
While unpacking your Printer, inspect the carton to ensure that no damage has occurred during shipping.
Make sure that all supplied accessories are included with your unit.
Check that the following items are included:
Power Supply
US / EU Power Cable
USB cable (2.0)
Software Installation CD
Card Printer User Guide
Warranty Statement, Compliancy Document

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
18
Installing the Print Ribbon Cartridge (DTC1000/DTC1000M,
and DTC4000)
Fargo Card Printers requires highly specialized supplies to function properly.
The Fargo DTC1000, DTC1000M, and DTC4000 Card Printers use a one-piece, disposable Ribbon
Cartridge load system.
To maximize Printer life, reliability, printed card quality and durability, you must use only Fargo-
certified supplies.
For this reason, your Fargo warranty is void, where not prohibited by law, if you use non-Fargo-
certified supplies.
Printer cleaning is recommended with each Ribbon change to ensure quality printed cards.
Resin-only Print Ribbons consist of a continuous roll of a single resin color. No protective overlay
panel (O) is provided since resin images do not require the protection of such an overlay.

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
19
Installing the Ribbon
Step
Procedure
1
Insert the Print Ribbon Cartridge into the Printer.
DTC1000/DTC1000M
DTC4000 with Flipper Module

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
20
Installing the Ribbon
Step
Procedure
2
Close the Front Cover.
DTC1000/DTC1000M
DTC4000 with Flipper Module
