Wireless external card and keyfob reader. The device is designed to
work with the Hikvision and Pyronix wireless access control systems
operating in the 868 MHz band.
Cards support: MIFARE 13.56 MHz
Reading distance of prox-keys: max. 8 cm
Autonomous operation:
Keyboard built-in:
Doorbell button:
Communication: Wireless
Tamper protection:
Frequency range: 868 MHz
Radio communication range (at open area): 800 m
Power supply: 4 x 1.5V, type AAA/LR03 battery (not included)
Backup time: 5 years (standby)
Operation temp: -20 °C ... 60 °C
Permissible relative humidity: 10 ... 90 % (non-condensing)
Housing: Plastic
Color: Black
"Index of Protection": IP65

User Manual
Code: DS-PTA-WL-868(BLACK)
WIRELESS PROXIMITY READER DS-PTA-WL-868(BLACK) Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: [email protected]; tel: +(48) 61 864 69 60
2021-07-04 DS-PTA-WL-868(BLACK) 3/5
Weight: 0.08 kg
Dimensions: 91 x 91 x 16 mm
Manufacturer / Brand: Hikvision
SAP Code: 302401383
Guarantee: 3 years
Front panel view:
Internal view of the housing:
