Hirschmann SPIDER Premium Line User manual

Installation SPIDER-PL
Release 03 08/2016
Technical support
https://hirschmann-support.belden.eu.com
User Manual
Installation
Industrial Ethernet Rail Switch
SPIDER Premium Line

The naming of copyrighted trademarks in this manual, even when not specially indicated, should
not be taken to mean that these names may be considered as free in the sense of the trademark
and tradename protection law and hence that they may be freely used by anyone.
© 2016 Hirschmann Automation and Control GmbH
Manuals and software are protected by copyright. All rights reserved. The copying, reproduction,
translation, conversion into any electronic medium or machine scannable form is not permitted,
either in whole or in part. An exception is the preparation of a backup copy of the software for
your own use.
The performance features described here are binding only if they have been expressly agreed
when the contract was made. This document was produced by Hirschmann Automation and
Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right
to change the contents of this document without prior notice. Hirschmann can give no guarantee
in respect of the correctness or accuracy of the information in this document.
Hirschmann can accept no responsibility for damages, resulting from the use of the network
components or the associated operating software. In addition, we refer to the conditions of use
specified in the license contract.
You can get the latest version of this manual on the Internet at the Hirschmann product site
(www.hirschmann.com).
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
Tel.: [phone]
SPIDER-PL

Installation SPIDER-PL
Release 03 08/2016 3
Contents
Safety instructions 5
About this Manual 10
Key 10
1 Description 11
1.1 General device description 11
1.2 Device name and product code 12
1.3 Device view 14
1.3.1 Front view 14
1.4 Power supply 16
1.5 Ethernet ports 16
1.5.1 Pin assignments 17
1.6 Display elements 18
1.6.1 Device state 18
1.6.2 Port state 19
2 Configuration interface 20
2.1 USB interface 20
3 Signal contact 21
4 Installation 22
4.1 Checking the package contents 22
4.2 Mounting the device 23
4.2.1 Installing the device onto the DIN rail 23
4.2.2 Mounting on a flat surface 24
4.3 Grounding the device 25
4.4 Installing an SFP transceiver (optional) 26
4.5 Connecting the terminal block 27
4.6 Operating the device 28
4.6.1 Installing terminal blocks, switching on the supply
voltage 28
4.6.2 Connecting data cables 28

4Installation SPIDER-PL
Release 03 08/2016
5 Configuration (optional) 29
5.1 Configuration readout 33
6 Monitoring the ambient air temperature 34
7 Maintenance and service 35
8Disassembly 36
8.1 Removing an SFP transceiver (optional) 36
8.2 Removing the device 37
9 Technical data 38
A Further Support 51

Installation SPIDER-PL
Release 03 08/2016 5
Safety instructions
General safety instructions
You operate this device with electricity. Improper usage of the device
entails the risk of physical injury or significant property damage. The
proper and safe operation of this device depends on proper handling
during transportation, proper storage and installation, and careful
operation and maintenance procedures.
Before connecting any cable, read this document, and the safety
instructions and warnings.
Operate the device with undamaged components exclusively.
The device is free of any service components. In case of a damaged
or malfunctioning the device, turn off the supply voltage and return the
device to Hirschmann for inspection.
Certified usage
Use the device solely for the application cases described in the
Hirschmann product information, including this manual.
Operate the device solely according to the technical specifications.
See “Technical data” on page 38.
Installation site requirements
When you are selecting the installation location, make sure you
observe the climatic threshold values specified in the technical data.
Operate the device at the specified ambient temperature (temperature
of the ambient air at a distance of 2 inches (5 cm) from the device) and
at the specified relative humidity exclusively.
Use the device in an environment with a maximum pollution degree
that complies with the specifications in the technical data.
Install the device in a fire enclosure according to EN 60950-1.
Qualification requirements for personnel
Only allow qualified personnel to work on the device.
Qualified personnel have the following characteristics:
Qualified personnel are properly trained. Training as well as practical
knowledge and experience make up their qualifications. This is the
prerequisite for grounding and labeling circuits, devices, and systems
in accordance with current standards in safety technology.
Qualified personnel are aware of the dangers that exist in their work.
Qualified personnel are familiar with appropriate measures against
these hazards in order to reduce the risk for themselves and others.
Qualified personnel receive training on a regular basis.

6Installation SPIDER-PL
Release 03 08/2016
Device casing
Only technicians authorized by the manufacturer are permitted to open
the housing.
Never insert pointed objects (narrow screwdrivers, wires, etc.) into the
device or into the connection terminals for electric conductors. Do not
touch the connection terminals.
Keep the ventilation slits free to ensure good air circulation.
See “General technical data” on page 38.
Install the device in the vertical position.
At ambient temperatures > 140 °F (60 °C):
The surfaces of the device housing may become hot. Avoid touching
the device while it is operating.

Installation SPIDER-PL
Release 03 08/2016 7
Requirements for connecting electrical wires
Before connecting the electrical wires, always verify that the
requirements listed are complied with.
General requirements for connecting electrical wires
The following requirements apply without restrictions:
The electrical wires are voltage-free.
The cables used are permitted for the temperature range of the application case.
Relevant for North America:
Use 60/75 or 75 °C copper (Cu) wire only.
Requirements for connecting the signal contact
The following requirements apply without restrictions:
The voltage connected complies with the requirements for a safety extra-low voltage
(SELV) as per IEC/EN 60950-1.
The connected voltage is limited by a current limitation device or a fuse.
Observe the electrical threshold values for the signal contact.
See “General technical data” on page 38.
Requirements for connecting the supply voltage
The following requirements apply without restrictions:
All of the following requirements are complied with:
The supply voltage corresponds to the voltage specified on the type plate of the device.
The power supply conforms to overvoltage category I or II.
The power supply has an easily accessible disconnecting device (e.g., a switch or a plug).
This disconnecting device is clearly identified. So in the case of an emergency, it is clear
which disconnecting device belongs to which power supply cable.
The power supply cable is suitable for the voltage, the current and the physical load.
Hirschmann recommends a wire diameter of 0.5 mm² to 0.75 mm² (AWG20 up to AWG18).
The following requirements apply alternatively:
Relevant when the device is supplied via 1 voltage input:
Alternative 1 The power supply complies with the requirements for a limited power source
(LPS) as per EN 60950-1.
Alternative 2 Relevant for North America:
The power supply complies with the requirements as per NEC Class 2
Alternative 3 All of the following requirements are complied with:
The power supply complies with the requirements for a safety extra-low
voltage (SELV) as per IEC/EN 60950-1.
Supply with DC voltage:
A fuse suitable for DC voltage is located in the plus conductor of the power
supply.
The minus conductor is on ground potential. Otherwise, a fuse is also
located in the minus conductor.
Regarding the properties of this fuse:
See “General technical data” on page 38.
Supply with AC voltage:
A fuse is located in the outer conductor of the power supply.
The neutral conductor is on ground potential at both voltage inputs.
Otherwise, a fuse is also located in the neutral conductor.
Regarding the properties of this fuse:
See “General technical data” on page 38.

8Installation SPIDER-PL
Release 03 08/2016
National and international safety regulations
Verify that the electrical installation meets locally or nationally applicable
safety regulations.
CE marking
The labeled devices comply with the regulations contained in the following
European directive(s):
2011/65/EU (RoHS)
Directive of the European Parliament and of the Council on the restriction
of the use of certain hazardous substances in electrical and electronic
equipment.
2014/30/EU (EMC)
Directive of the European Parliament and the council for standardizing the
regulations of member states with regard to electromagnetic
compatibility.
In accordance with the above-named EU directive(s), the EU conformity
declaration will be at the disposal of the relevant authorities at the
following address:
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Tel.: [phone]
The device can be used in the industrial sector.
Interference immunity: EN 61000-6-2
Emitted interference: EN 55022
Warning! This is a class A device. This device can cause interference in
living areas, and in this case the operator may be required to take
appropriate measures.
Note: The assembly guidelines provided in these instructions must be
strictly adhered to in order to observe the EMC threshold values.
LED or laser components
LED or LASER components according to IEC 60825-1 (2014):
CLASS 1 LASER PRODUCT
CLASS 1 LED PRODUCT

Installation SPIDER-PL
Release 03 08/2016 9
FCC note:
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference; (2) this device must accept any interference received,
including interference that may cause undesired operation.
Appropriate testing has established that this device fulfills the
requirements of a class A digital device in line with part 15 of the FCC
regulations.
These requirements are designed to provide sufficient protection against
interference when the device is being used in a business environment.
The device creates and uses high frequencies and can also radiate these
frequencies. If it is not installed and used in accordance with this
operating manual, it can cause radio transmission interference. The use
of this device in a residential area can also cause interference, and in this
case the user is obliged to cover the costs of removing the interference.
Recycling note
After usage, this device must be disposed of properly as electronic waste,
in accordance with the current disposal regulations of your county, state,
and country.

10 Installation SPIDER-PL
Release 03 08/2016
About this Manual
The “Installation” user manual contains a device description, safety
instructions, a description of the display, and the other information that you
need to install the device.
Key
The symbols used in this manual have the following meanings:
Listing
Work step
Subheading

Installation SPIDER-PL
Release 03 08/2016 11
1 Description
1.1 General device description
The SPIDER-PL devices are designed for the special requirements of
industrial automation. They meet the relevant industry standards, provide
very high operational reliability, even under extreme conditions, and also
long-term reliability and flexibility.
The devices allow you to set up switched industrial Ethernet networks that
conform to the IEEE 802.3 standard.
You have numerous options of combining the device characteristics. You can
determine the possible combinations using the configurator which is
available in the Belden E-Catalog (www.e-catalog.beldensolutions.com) on
the web page of the device.

12 Installation SPIDER-PL
Release 03 08/2016
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.
Item Characteristic Characteri
stic value
Description
1 ... 9 Product SPIDER-PL SPIDER Premium Line
10 (hyphen) –
11 Data rate 2 10/100 Mbit/s
4 10/100/1000 Mbit/s
12 Power over Ethernet
(PoE)
0 without PoE support
13 (hyphen) –
14 ... 17 Number
Twisted pair ports
01T1
04T1
05T1
06T1
07T1
08T1
18 ... 19 Optical fiber port 1 M2 DSC multimode socket for
100 Mbit/s F/O connections
S2 DSC singlemode socket for
100 Mbit/s F/O connections
M4 ST multimode socket for
100 Mbit/s F/O connections
O6 SFP slot for
100/1000 Mbit/s F/O connections
Z6 SFP slot for
100 Mbit/s F/O connections
99 without
20 ... 21 Optical fiber port 2 M2 DSC multimode socket
for 100 Mbit/s F/O connections
S2 DSC singlemode socket
for 100 Mbit/s F/O connections
Z6 SFP slot for
100 Mbit/s F/O connections
99 without
22 ... 23 Optical fiber port 3 Z6 SFP slot for
100 Mbit/s F/O connections
99 without
24 Temperature range T Extended −40 °F ... +158 °F
(−40 °C ... +70 °C)
Deratinga
E Extended
with Conformal
Coating
−40 °F ... +158 °F
(−40 °C ... +70 °C)
Table 1: Device name and product code

Installation SPIDER-PL
Release 03 08/2016 13
25 ... 26 Certificates and
declarations
Z9 CE, FCC, EN61131
Y9 Z9 + cUL61010
WV WU + EN50121-4 + E1
WW WU + IEC61850, IEEE1613 + EN50121-4
27 ... 28 Customer-specific
version
HH Hirschmann standard
HK Voltage terminal with spring
29 ... 30 Configuration HH Hirschmann standard
HV Extended voltage range
(48 V DC, 24 V AC)
a. For device variant SPIDER-PL-20-06T1Z6Z6Z6TZ9HHHH, the maximum permitted
ambient air temperature has to be reduced to 140 °F (60 °C).
Item Characteristic Characteri
stic value
Description
Table 1: Device name and product code

14 Installation SPIDER-PL
Release 03 08/2016
1.3 Device view
1.3.1 Front view
Front view using example of device variants SPIDER-PL-40...
SPIDER-PL-40-08T1...
1 LED display elements for device status
2 6-pin, pluggable terminal block for power supply and signal contact
3 ... 6 4 × RJ45 socket for 10/100/1000 Mbit/s Twisted Pair connections
7USBinterface
8 Rail lock gate for DIN rail mounting
9 ... 12 4 × RJ45 socket for 10/100/1000 Mbit/s Twisted Pair connections
SPIDER-PL-40-05T1...
1 LED display elements for device status
2 6-pin, pluggable terminal block for power supply and signal contact
3 ... 7 5 × RJ45 socket for 10/100/1000 Mbit/s Twisted Pair connections
8USBinterface
9 Rail lock gate for DIN rail mounting
SPIDER-PL-40-01T1...
1 LED display elements for device status
2 6-pin, pluggable terminal block for power supply and signal contact
3 LED display elements for port status
4 RJ45 socket for 10/100/1000 Mbit/s Twisted Pair connections
5 SFP slot for 100/1000 Mbit/s F/O connections
6 Rail lock gate for DIN rail mounting
2
3
4
5
6
2
3
4
5
6
7
8
1
9
SPIDER-PL-40-05T1... SPIDER-PL-40-01T1...
1
7
2
3
4
5
6
8
SPIDER-PL-40-08T1...
1212
1111
1010
9
1

Installation SPIDER-PL
Release 03 08/2016 15
Front view using example of device variants SPIDER-PL-20...
SPIDER-PL-20-08T1...
(depending on the device variant)
1 LED display elements for device status
2 6-pin, pluggable terminal block for power supply and signal contact
3 LED display elements for port status
4 depending on device variant
DSC multimode socket for 100 Mbit/s F/O connections
DSC singlemode socket for 100 Mbit/s F/O connections
5 ... 6 2 × RJ45 socket for 10/100 Mbit/s twisted pair connections
7 USB interface
8 Rail lock gate for DIN rail mounting
9 ... 14 6 × RJ45 socket for 10/100 Mbit/s twisted pair connections
SPIDER-PL-20-06T1...
1 LED display elements for device status
2 6-pin, pluggable terminal block for power supply and signal contact
3, 5, 7 LED display elements for port status
4, 6, 8 SFP slot for 100 Mbit/s F/O connections
9 USB interface
10 Rail lock gate for DIN rail mounting
11 ... 16 6 × RJ45 socket for 10/100 Mbit/s twisted pair connections
SPIDER-PL-20-04T1...
1 LED display elements for device status
2 6-pin, pluggable terminal block for power supply and signal contact
3 ... 6 4 × RJ45 socket for 10/100 Mbit/s twisted pair connections
7 depending on device variant
ST multimode socket for 100 Mbit/s F/O connections
DSC multimode socket for 100 Mbit/s F/O connections
DSC singlemode socket for 100 Mbit/s F/O connections
8 USB interface
9 Rail lock gate for DIN rail mounting
SPIDER-PL-20-06T1... SPIDER-PL-20-04T1...
SPIDER-PL-20-08T1...
1010
9
14
14
13
12
12
1111
1
7
2
3
4
5
6
8
1
1616
1515
1414
1313
1212
1111
9
2
4
5
6
7
8
1010
3
2
3
4
5
6
7
8
9
1

16 Installation SPIDER-PL
Release 03 08/2016
1.4 Power supply
You have the following options to supply your device with voltage:
Power supply via a 6-pin terminal block
A 6-pin terminal block is available for the power supply to the device.
You will find more information here:
See “Installing terminal blocks, switching on the supply voltage” on
page 28.
1.5 Ethernet ports
You can connect end devices and other segments to the device ports using
twisted pair cables or optical fibers (F/O).
You find information on pin assigments for making patch cables here:
“Pin assignments” on page 17
10/100/1000 Mbit/s twisted pair port
This port is an RJ45 socket.
The 10/100/1000 Mbit/s twisted pair port offers you the ability to connect
network components according to the IEEE 802.3 10BASE-T/100BASE-
TX/1000BASE-T standard.
This port supports:
Autonegotiation
Autopolarity
Autocrossing (if autonegotiation is activated)
1000 Mbit/s half duplex, 1000 Mbit/s full duplex
100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode
10 Mbit/s half-duplex mode, 10 Mbit/s full duplex mode
10/100 Mbit/s twisted pair port
This port is an RJ45 socket.
The 10/100 Mbit/s twisted pair port offers you the ability to connect
network components according to the IEEE 802.3 10BASE-T/100BASE-
TX standard.
This port supports:
Autonegotiation
Autopolarity
Autocrossing (if autonegotiation is activated)
100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode
10 Mbit/s half-duplex mode, 10 Mbit/s full duplex mode

Installation SPIDER-PL
Release 03 08/2016 17
100/1000 Mbit/s F/O port
This port is an SFP slot.
The 100/1000 Mbit/s F/O port offers you the ability to connect network
components according to the IEEE 802.3 100BASE-FX/1000BASE-
SX/1000BASE-LX standard.
This port supports:
1000 Mbit/s full duplex when using a Gigabit Ethernet SFP transceiver
100 Mbit/s half duplex, 100 Mbit/s full duplex when using a Fast
Ethernet SFP transceiver
100 Mbit/s F/O port
The 100 Mbit/s F/O port offers you the ability to connect network
components according to the IEEE 802.3 100BASE-FX standard.
This port supports:
100 Mbit/s half-duplex mode, 100 Mbit/s full duplex mode
State on delivery:
100 Mbit/s, full duplex
1.5.1 Pin assignments
RJ45 Pin 10/100 Mbit/s 1000 Mbit/s
MDI mode
1 TX+ BI_DA+
2TX−BI_DA−
3 RX+ BI_DB+
4 — BI_DC+
5— BI_DC−
6RX−BI_DB−
7 — BI_DD+
8— BI_DD−
MDI-X mode
1 RX+ BI_DB+
2RX−BI_DB−
3 TX+ BI_DA+
4 — BI_DD+
5— BI_DD−
6TX−BI_DA−
7 — BI_DC+
8— BI_DC−
1
2
3
4
5
6
7
8

18 Installation SPIDER-PL
Release 03 08/2016
1.6 Display elements
After the supply voltage is switched on, the device performs a self-test.
During this process, various LEDs light up.
1.6.1 Device state
These LEDs provide information about conditions which affect the operation
of the whole device.
LED Display Color Activity Meaning
Power Supply voltage — None Supply voltage is too low
Yellow Lights up Device variants with redundant power
supply:
Supply voltage 1 or 2 is on
Green Lights up Device variants with redundant power
supply:
Supply voltages 1 and 2 are on

Installation SPIDER-PL
Release 03 08/2016 19
1.6.2 Port state
These LEDs display port-related information.
SP
(data rate)
Color Activity Meaning
— None Device detects an invalid or missing
link
Yellow Flashes 1 time a period 10 Mbit/s connection
Yellow Flashing 2 times a
period
100 Mbit/s connection
Yellow Flashes 3 times a
period
1000 Mbit/s connection
LS/DA
(link status/data)
Color Activity Meaning
— None Device detects an invalid or missing
link
Green Lights up Device detects a valid link
Green flashing Device is transmitting and/or
receiving data
yellow/gre
en
Flashing alternately Update of the configuration via the
USB interface
SPSP
LS/DALS/DA

20 Installation SPIDER-PL
Release 03 08/2016
2 Configuration interface
2.1 USB interface
The USB interface allows you to connect the a storage medium. This is for
transfering configuration data.
The USB interface has the following properties:
Connectors: type A
Supports the USB master mode
Supports USB 2.0
Supplies current of max. 500 mA
Voltage not potential-separated
1234
Pin
1
2
3
4
Function
VCC (VBus)
- Data
+ Data
Ground (GND)
