ORiNG RES-P3242GCL SERIES User manual

Industrial IEC 61850-3
Management Ethernet Switch
RES-P3242GCL SERIES User’s Manual
Version 2.0
JUN, 2012
ORing Industrial Networking Corp.
Website: www.oring-networking.com
E-mail: [email protected]

RES-P3242GCL SERIES User’s Manual
1
Table of Content
Getting to Know Your Switch............................................................................................................4
1.1About the RES-P3242GCL SERIES Industrial Switch..................................................4
1.2Software Features ..............................................................................................................4
1.3Hardware Features.............................................................................................................4
Hardware Overview .............................................................................................................................0
2.1Front Panel..........................................................................................................................0
2.2Power Panel........................................................................................................................1
2.3Rack mount kit assembly...................................................................................................2
Cables.....................................................................................................................................................3
3.1Ethernet Cables..................................................................................................................3
3.1.1100BASE-TX/10BASE-T Pin Assignments.....................................................................3
3.2SFP.......................................................................................................................................5
3.3Console Cable.....................................................................................................................5
WEB Management ...............................................................................................................................6
4.1Configuration by Web Browser.........................................................................................6
4.1.1About Web-based Management........................................................................................6
4.1.2System Information ..........................................................................................................8
4.1.3Basic setting......................................................................................................................9
4.1.3.2Admin Password .....................................................................................................9
4.1.3.3IP Setting...............................................................................................................10
4.1.3.4SNTP (Time).........................................................................................................11
4.1.3.5LLDP.....................................................................................................................14
4.1.3.6Backup & Restore.................................................................................................14
4.1.3.7Upgrade Firmware ................................................................................................16
4.1.3.8Broadcast storm filter............................................................................................16
4.1.3.9Aging Time ...........................................................................................................17
4.1.3.10Jumbo Frame.........................................................................................................17
4.1.4Redundancy....................................................................................................................17
4.1.4.1O-Ring...................................................................................................................17
4.1.4.2OPEN-Ring...........................................................................................................18
4.1.4.3O-RSTP.................................................................................................................19
4.1.4.4RSTP.....................................................................................................................20
4.1.4.5MSTP....................................................................................................................23

RES-P3242GCL SERIES User’s Manual
2
4.1.5Multicast.........................................................................................................................28
4.1.5.1IGMP Snooping.....................................................................................................28
4.1.5.2MVR .....................................................................................................................29
4.1.5.3Multicast Filter......................................................................................................29
4.1.6Port Setting.....................................................................................................................31
4.1.6.1Port Control...........................................................................................................31
4.1.6.2Port Status .............................................................................................................31
4.1.6.3Port Alias...............................................................................................................32
4.1.6.4Rate Limit .............................................................................................................32
4.1.6.5Port Trunk .............................................................................................................33
4.1.6.6Loop Guard...........................................................................................................35
4.1.7VLAN.............................................................................................................................36
4.1.7.1VLAN Setting .......................................................................................................36
4.1.7.2VLAN Setting – Port Based..................................................................................38
4.1.8Traffic Prioritization .......................................................................................................40
4.1.9DHCP Server..................................................................................................................42
4.1.9.1DHCP Server – Setting..........................................................................................42
4.1.9.2DHCP Server – Client List....................................................................................43
4.1.9.3DHCP Server – Port and IP bindings ....................................................................43
4.1.10SNMP ........................................................................................................................44
4.1.10.1SNMP –System Setting.........................................................................................44
4.1.10.2SNMP –Trap Setting .............................................................................................45
4.1.10.3SNMP – SNMPv3 Setting.....................................................................................46
4.1.11Security......................................................................................................................49
4.1.11.1Access Control List...............................................................................................49
4.1.11.2IP Security.............................................................................................................50
4.1.11.3Static MAC Forwarding........................................................................................51
4.1.11.4MAC Blacklist ......................................................................................................52
4.1.11.5802.1x....................................................................................................................52
4.1.12Warning......................................................................................................................55
4.1.12.1System Alarm........................................................................................................56
4.1.13Monitor and Diag.......................................................................................................60
4.1.13.1System EventLog..................................................................................................60
4.1.13.2MAC Address Table..............................................................................................61
4.1.13.3Port Overview.......................................................................................................62
4.1.13.4Port Counters.........................................................................................................63
4.1.13.5Port Monitoring.....................................................................................................65

RES-P3242GCL SERIES User’s Manual
3
4.1.14Save Configuration ....................................................................................................66
4.1.15Factory Default ..........................................................................................................66
4.1.16System Reboot...........................................................................................................67
Command Line Interface Management ........................................................................................68
5.1About CLI Management.................................................................................................68
5.2Commands Set List—System Commands Set................................................................73
5.3Commands Set List—Port Commands Set.....................................................................75
5.4Commands Set List—Trunk command set.....................................................................77
5.5Commands Set List—VLAN command set....................................................................79
5.6Commands Set List—Spanning Tree command set........................................................80
5.7Commands Set List—QoS command set........................................................................82
5.8Commands Set List—IGMP command set.....................................................................83
5.9Commands Set List—MAC/Filter Table command set ..................................................84
5.10Commands Set List—SNMP command set....................................................................84
5.11Commands Set List—Port Mirroring command set .......................................................85
5.12Commands Set List—802.1x command set....................................................................86
5.13Commands Set List—TFTP command set......................................................................88
5.14Commands Set List—SYSLOG, SMTP, EVENT command set.....................................89
5.15Commands Set List—SNTP command set.....................................................................91
5.16Commands Set List—O-Ring command set...................................................................92
Technical Specifications..................................................................................................................93

RES-P3242GCL SERIES User’s Manual
4
Getting to Know Your Switch
1.1 About the RES-P3242GCL SERIES Industrial
Switch
RES-P3242GCL SERIES are powerful managed industrial switches for power station
applications which have many features. RES-P3242GCL SERIES pass the IEC 61850-3 and
IEEE 1613 certification. They can be managed by WEB, TELNET, Console or other
third-party SNMP software as well. Besides, these switches can be managed by a useful
utility that we called Open-Vision.
Open-Vision is powerful network management software. With its friendly and powerful
interface, you can easily configure multiple switches at the same time, and monitor switches’
status.
1.2 Software Features
World’s fastest Redundant Ethernet Ring (Recovery time < 10ms over 250 units
connection)
Supports Ring Coupling, Dual Homing, RSTP over O-Ring
Supports SNMPv1/v2/v3 & RMON & Port base/802.1Q VLAN Network Management
Event notification by Email, SNMP trap and Relay Output
Web-based ,Telnet, Console, CLI configuration
Enable/disable ports, MAC based port security
Port based network access control (802.1x)
VLAN (802.1Q ) to segregate and secure network traffic
SNMPv3 encrypted authentication and access security
RSTP (802.1w)
Quality of Service (802.1p) for real-time traffic
Port configuration, status, statistics, mirroring, security
1.3 Hardware Features
Isolation redundant power inputs with 12 ~ 36VDC or 36 ~ 72VDC or 100 ~ 240VAC
power supply range
Operating Temperature:: -40 to 85oC
Operating Humidity: 5% to 95%, non-condensing
8 x 10/100Base-T(X) Ethernet ports

RES-P3242GCL SERIES User’s Manual
5
2 x 10/100/1000Base-T(X) and 1000Base-X SFP ports on combo port
1 x Console Port
Dimensions(W x D x H) : 443.7 mm(W)x 262.7 mm( D )x 44 mm(H)
19 inches rack mountable

Hardware Overview
2.1 Front Panel
The following table describes the labels that stick on the RES-P3242GCL SERIES.
Port Description
10/100 RJ-45 fast
Ethernet ports
24 x 10/100Base-T(X) RJ-45 fast Ethernet ports support
auto-negotiation.
Default Setting :
Speed: auto
Duplex: auto
Flow control : disable
Gigabit port 2 x 10/100/1000Base-T(X) Gigabit ports (combo)
Fiber port 2 x 1000Base-X on SFP ports (combo)
Console Use RS-232 cable to manage switch
1. Power inputs .
2. LED Status :
P1 LED for PWR1. When the PWR1 links, the green led will be light on.
P2 LED for PWR2. When the PWR2 links, the green led will be light on.
Status LED for System Status. When the system is ready, the green led will be light on.

RES-P3242GCL SERIES User’s Manual
1
R.M LED for Ring master. When the LED light on, it means that the switch is the ring
master of O-Ring.
Ring LED for Ring. When the LED light on, it means the O-Ring is activated.
Fault LED for Fault Relay. When the fault occurs, the amber LED will be light on.
3. RS-232 Console Port. Set connection at 9600bps, 8N1.
4. 10/100Base-T(X) Ethernet ports.
5. LED for Ethernet ports Link status.
6. LED for Ethernet portsACT status.
7. LED for Combo SFP ports Link / ACT status.
8. 1000Base-X fiber port in SFP socket.
9. 10/100/1000Base-T(X) Ethernet port.
10. LED for Combo Copper ports Link /ACT status.
11. LED Status
P1 LED for PWR1. When the PWR1 links, the green led will be light on.
P2 LED for PWR2. When the PWR2 links, the green led will be light on.
Status LED for System Status. When the system is ready, the green led will be light on.
R.M LED for Ring master. When the LED light on, it means that the switch is the ring
master of O-Ring.
Ring LED for Ring. When the LED light on, it means the O-Ring is activated.
Fault LED for Fault Relay. When the fault occurs, the amber LED will be light on.
12. LED for Combo SFP ports Link / ACT status.
13. LED for Combo Copper ports Link /ACT status.
2.2 Power Panel
RES-P3242GCL SERIES are power redundant switches, supports two power inputs.
Note :
RLY COM– Relay Com
RLY NO – Relay Normal Open
RLY NC – Relay Normal Close

RES-P3242GCL SERIES User’s Manual
2
2.3 Rack mount kit assembly
You can find the rack mount kit and the screws in the packing box. Please assembly the rack
mount kit on the switch with screws as below picture.

RES-P3242GCL SERIES User’s Manual
3
Cables
3.1 Ethernet Cables
RES-P3242GCL SERIES switches have standard Ethernet ports. According to the link
type, these switches use CAT 3, 4, 5,5e UTP cables to connect to any other network device
(PCs, servers, switches, routers, or hubs). Please refer to the following table for cable
specifications.
Cable Types and Specifications
Cable Type Max. Length Connector
10BASE-T Cat.3, 4, 5 100-ohm UTP 100 m (328 ft) RJ-45
100BASE-TX Cat.5 100-ohm UTP UTP 100 m (328 ft) RJ-45
1000BASE-T Cat.5/Cat.5e 100-ohm UTP UTP 100 m (328ft) RJ-45
3.1.1 100BASE-TX/10BASE-T Pin Assignments
With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and
pins 3 and 6 are used for receiving data.
10/100 Base-T RJ-45 Pin Assignments
Pin Number Assignment
1 TD+
2 TD-
3 RD+
4 Not used
5 Not used
6 RD-
7 Not used
8 Not used

RES-P3242GCL SERIES User’s Manual
4
1000 Base-T RJ-45 Pin Assignments
Pin Number Assignment
1 BI_DA+
2 BI_DA-
3 BI_DB+
4 BI_DC+
5 BI_DC-
6 BI_DB-
7 BI_DD+
8 BI_DD-
The RES-P3242GCL SERIES switches support auto MDI/MDI-X operation. You can
use a straight-through cable to connect PC to switch. The following table below shows
the 10BASE-T/ 100BASE-TX MDI and MDI-X port pin outs.
10/100 Base-T MDI/MDI-X pins assignment
Pin Number MDI port MDI-X port
1 TD+(transmit) RD+(receive)
2 TD-(transmit) RD-(receive)
3 RD+(receive) TD+(transmit)
4 Not used Not used
5 Not used Not used
6 RD-(receive) TD-(transmit)
7 Not used Not used
8 Not used Not used
1000 Base-T MDI/MDI-X pins assignment
Pin Number MDI port MDI-X port
1 BI_DA+ BI_DB+
2 BI_DA- BI_DB-
3 BI_DB+ BI_DA+
4 BI_DC+ BI_DD+
5 BI_DC- BI_DD-
6 BI_DB- BI_DA-
7 BI_DD+ BI_DC+
8 BI_DD- BI_DC-
Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair.

RES-P3242GCL SERIES User’s Manual
5
3.2 SFP
The RES-P3242GCLSERIES has fiber optical ports with SFP connectors. The fiber optical
ports are in multi-mode (0 to 550M, 850 nm with 50/125 µm, 62.5/125 µm fiber) and
single-mode with LC connector. Please remember that the TX port of Switch A should be
connected to the RX port of Switch B.
SwitchA SwitchB
3.3 Console Cable
RES-P3242GCL SERIES switches can be management by console port. The DB-9 to
RJ-45 cable can be found in the package. You can connect them to PC via a RS-232 cable
with DB-9 female connector and the other end (RJ-45 connector) connects to console port of
switch.
PC pin out (male) assignment RS-232 with DB9 female connector DB9 to RJ 45
Pin #2 RD Pin #2 TD Pin #2
Pin #3 TD Pin #3 RD Pin #3
Pin #5 GD Pin #5 GD Pin #5
Fiber cord

RES-P3242GCL SERIES User’s Manual
6
WEB Management
4.1 Configuration by Web Browser
This section introduces the configuration by Web browser.
4.1.1 About Web-based Management
Inside the CPU board of the switch, an embedded HTML web site resides in flash memory.
It contains advanced management features and allows you to manage the switch from
anywhere on the network through a standard browser such as Microsoft Internet Explorer.
The Web-Based Management supports Internet Explorer 5.0. It is based on Java Applets
with an aim to reduce network bandwidth consumption, enhance access speed and present an
easy viewing screen.
Note: By default, IE5.0 or later version does not allow Java Applets to open sockets. You need to explicitly modify
the browser setting in order to enable Java Applets to use network ports.
Preparing for Web Management
The default value is as below:
IPAddress: 192.168.10.1
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.10.254
User Name: admin
Password: admin
System Login
1. Launch the Internet Explorer.
2. Type http:// and the IP address (default is 192.168.10.1) of the switch. Press
“Enter”.

RES-P3242GCL SERIES User’s Manual
7
3. The login screen appears.
4. Key in the username and password. The default username and password is
“admin”.
5. Click “Enter” or ”OK” button, then the main interface of the Web-based
management appears.
Login screen
Main Interface
Main interface

RES-P3242GCL SERIES User’s Manual
8
4.1.2 System Information
System Information interface
System Information will display the configuration of Basic Setting / Switch Setting page.
The following table describes the labels in this screen.
Label Description
System Name Display the system name of switch.
System
Description Display the description of switch.
System Location Display the location of switch.
System Contact Display the name of contact person or organization
Firmware Version Display the switch’s firmware version
Kernel Version Display the kernel software version
MAC Address Display the unique hardware address assigned by manufacturer
(default)

RES-P3242GCL SERIES User’s Manual
9
4.1.3 Basic setting
4.1.3.1 Switch Setting
Switch setting interface
The following table describes the labels in this screen.
Label Description
System Name Assign the name of switch. The maximum length is 64 bytes
System
Description Display the description of switch.
System Location Assign the switch physical location. The maximum length is 64 bytes
System Contact Enter the name of contact person or organization
4.1.3.2 Admin Password
Change web management login username and password for the management security
issue
Admin Password interface
The following table describes the labels in this screen.
Label Description
User name Key in the new username(The default is “admin”)
New Password Key in the new password(The default is “admin”)

RES-P3242GCL SERIES User’s Manual
10
Confirm
password Re-type the new password.
Apply Click “Apply” to set the configurations.
4.1.3.3 IP Setting
You can configure the IP Settings and DHCP client function through IP configuration.
IP Configuration interface
The following table describes the labels in this screen.
Label Description
DHCP Client To enable or disable the DHCP client function. When DHCP client
function is enabling, the switch will be assigned the IP address from
the network DHCP server. The default IP address will be replaced by
the IP address which the DHCP server has assigned. After clicking
“Apply” button, a popup dialog shows up to inform when the DHCP
client is enabling. The current IP will lose and you should find a new
IP on the DHCP server.
IP Address Assign the IP address that the network is using. If DHCP client
function is enabling, you do not need to assign the IP address. The
network DHCP server will assign the IP address for the switch and it
will be display in this column. The default IP is 192.168.10.1
Subnet Mask Assign the subnet mask of the IP address. If DHCP client function is
enabling, you do not need to assign the subnet mask
Gateway Assign the network gateway for the switch. The default gateway is

RES-P3242GCL SERIES User’s Manual
11
192.168.10.254
DNS1 Assign the primary DNS IP address
DNS2 Assign the secondary DNS IP address
Apply Click “Apply” to set the configurations.
4.1.3.4 SNTP (Time)
The SNTP (Simple Network Time Protocol) settings allow you to synchronize switch clocks
in the Internet.
SNTP Configuration interface
The following table describes the labels in this screen.
Label Description
SNTP Client Enable or disable SNTP function to get the time from the SNTP server.
Daylight Saving
Time
Enable or disable daylight saving time function. When daylight saving
time is enabling, you need to configure the daylight saving time period.
UTC Time zone Set the switch location time zone. The following table lists the
different location time zone for your reference.
Local Time Zone Conversion from UTC Time at 12:00 UTC
November Time Zone - 1 hour 11 am
Oscar Time Zone -2 hours 10 am

RES-P3242GCL SERIES User’s Manual
12
ADT -Atlantic Daylight -3 hours 9 am
AST - Atlantic Standard
EDT - Eastern Daylight -4 hours 8 am
EST - Eastern Standard
CDT - Central Daylight -5 hours 7 am
CST - Central Standard
MDT - Mountain Daylight -6 hours 6 am
MST - Mountain Standard
PDT - Pacific Daylight -7 hours 5 am
PST - Pacific Standard
ADT - Alaskan Daylight -8 hours 4 am
ALA - Alaskan Standard -9 hours 3 am
HAW - Hawaiian Standard -10 hours 2 am
Nome, Alaska -11 hours 1 am
CET - Central European
FWT - French Winter
MET - Middle European
MEWT - Middle European
Winter
SWT - Swedish Winter
+1 hour 1 pm
EET - Eastern European,
USSR Zone 1 +2 hours 2 pm
BT - Baghdad, USSR Zone
2 +3 hours 3 pm
ZP4 - USSR Zone 3 +4 hours 4 pm
ZP5 - USSR Zone 4 +5 hours 5 pm
ZP6 - USSR Zone 5 +6 hours 6 pm
WAST - WestAustralian
Standard +7 hours 7 pm
CCT - China Coast, USSR
Zone 7 +8 hours 8 pm

RES-P3242GCL SERIES User’s Manual
13
JST - Japan Standard,
USSR Zone 8 +9 hours 9 pm
EAST - EastAustralian
Standard GST
Guam Standard, USSR
Zone 9
+10 hours 10 pm
IDLE - International Date
Line
NZST - New Zealand
Standard
NZT - New Zealand
+12 hours Midnight
Label Description
SNTP Sever IP
Address Set the SNTP server IP address.
Daylight Saving
Period
Set up the Daylight Saving beginning time and Daylight Saving ending
time. Both will be different each year.
Daylight Saving
Offset Set up the offset time.
Switch Timer Display the switch current time.
Apply Click “Apply” to set the configurations.
