HISENSED90TechnicalSpecifications CONFIDENTIAL
Technical Specifications
of
CDMA & GSM Dual Mode
Mobile Handset
Model: D90
Version 1.0
2008-06-03
Qingdao Hisense Communications Co., Ltd.

HISENSED90TechnicalSpecifications CONFIDENTIAL
ProprietaryInformationofHisense
All rights reserved, Page 1 of 10
Table of Contents
1. Product Introduction..............................................................................................2
2. General Features....................................................................................................2
3. Appearance...........................................................................................................2
4. Hardware Specification...........................................................................................3
5. Software Specification............................................................................................4
6. Technical Specifications..........................................................................................8
7. Accessories............................................................................................................9
8. A Complete Set of Product......................................................................................9
9. Criterion and Standard Regarding Green Environmental Protection Handset Materials10

HISENSED90TechnicalSpecifications CONFIDENTIAL
1. Product Introduction
D90 CDMA2000 1X digital mobile handset is a CDMA2000 1X digital mobile terminal
product developed by Hisense itself. D90 is based on Qualcomm QSC6020 and MTK6223
chipset and works at CDMA: 800MHz and GSM: 900/1800/1900MHz frequency bands,
D90 is also compatible with the IS-95A/B, CDMA2000 1X and GSM network environment.
D90 is a bar type handset, dual network mode, touch panel, multi-media and camera
functionsareprovided;
The feature highlights of D90 are dual network standby simultaneously, data service and
charming metal style design.
2. General Features
Product Model HS-D90
Form Factor Bar Type with built-in Antenna
Dimensions（H×W×D）113.4*54.8*17.2mm
Weight Standard Approx 120g
Appearance Color Black
Product Orientation Mid-End
Target Market Global Market
3. Appearance
This ID is only for reference, the products are subject to finally evaluated and confirmed
appearance.
ProprietaryInformationofHisense
All rights reserved, Page 2 of 10

HISENSED90TechnicalSpecifications CONFIDENTIAL
ProprietaryInformationofHisense
All rights reserved, Page 3 of 10
4. Hardware Specification
Network CDMA+GSM
Frequency Band CDMA: 800MHz
GSM: 900/1800/1900 MHz
Solution CDMA: Qualcomm QSC6020
GSM: MTK MT6223
Working Mode R-UIM
Vocoder 8K EVRC
Peak Data Rate 153.6kbps
Main Processor ARM9Processor Multi-Processor C627
ROM 256Mbits NAND for CDMA, 64Mbits for
GSM
RAM 64Mbits SDRAM+32Mbits SDRAM
Memory
Available User Memory Space TBD
Removable Memory
Card Micro SD card
Physical Dimension 2.4”(AA)
Resolution QVGA
Color Depth 256K
Type TFT
Main LCD
Touching Screen Type Yes, resistance
Sub-LCD No
Backlight Type LED
Keypad Area 23Number of Keystroke Side key 4
Keystroke Backlight Yes, blue
Sensor of Saving
Energy No
Ring Chipset No
Camera Yes,1.3M
Flash Lamp No
Infra-Red No
Bluetooth Yes, voice
Power off Clock Yes
Vibrator Motor Yes
FM No
Data Port 5 Pin Mini USB
Power Supply Port 5 Pin Mini USB
Antenna Built-in
Vehicle Power Adapter No
Indicator No

HISENSED90TechnicalSpecifications CONFIDENTIAL
ProprietaryInformationofHisense
All rights reserved, Page 4 of 10
Speaker 2 Speakers
Headset Yes, Stereo
Lanyard Hole No
Type Li-IonBattery Capacity Standard 1400mAh
Slot 3 (UIM, SIM , Micro SD card)
Charging Time <180 Minutes Subject to finally test result
Standby Time 100 Hours
Talking Time 180 Minutes
5. Software Specification
Basic Specification
Operating System REX
EnglishLanguage Others as customers’ requirements
Polish input mode (word by word)
Polish input mode (Character by character)
English
ABC
Numeral
Punctuation
Input Solutions
Handwriting and Virtual Qwerty Keypad
Copy
Paste
English Phrase
Text Editing Assistant Tools
Expression Punctuation
Contacts
Capacity 1000
VCARD Yes
Name
Phone Number 1
Phone Number 2
Home Number
Office Number
E-Mail
Website Address
Remark
Group
Content of Items
Ringtone
Group Numbers 20
Group Rings Identification Yes

HISENSED90TechnicalSpecifications CONFIDENTIAL
ProprietaryInformationofHisense
All rights reserved, Page 5 of 10
Rings Priority Individual Rings>Group Rings>Common Rings
Phone Number Length 32 digits
Extension Input P/T
By Initial Letters
By Name
By Group
Inquiry Method
Proximity Search
Delete Single EntryDelete Entries Optional Delete
Entries Copy Yes, between phone and card, card and card.
View Memory Status Yes
Calling
Voice Dialing No
IP Dialing Yes, 5
Speed Dialing Yes, 20
Name
Number
Incoming Call Display
Network
Name
Number
Outgoing Call Display
Network
Incoming Call Mute Yes
Call Restriction Yes
Hands Free Yes
Talk Time Display Yes
Talk Time Record Yes
Record Voice during Talking No
Record Voice when Standby Yes
Voice Message Yes
DTMF Dialing during Talking Yes
Pressing “answer key”Answer Mode Any key
Auto-answer by headset Yes
Call WaitingSupplementary Service
CDMA Call Forwarding
Call Waiting
Call Forwarding
GSM Network Service
Call Restriction
Dialed 100
Received 100
Call Records
Missed 100
SMS

HISENSED90TechnicalSpecifications CONFIDENTIAL
ProprietaryInformationofHisense
All rights reserved, Page 6 of 10
Inbox 300Capacity Outbox 100
Max Length English 160
Long SMS Yes
Auto Concatenate Yes
Voice Message Yes
Max 20 entriesSMS Group Sending Delivery Report
Contacts Team Group
Sending Yes
Delete Single EntrySMS Delete Optional Delete
Reserved Phrase Yes
Message Restriction Yes
PhoneDefault Memory Setting UIM Card
View Memory Status Yes
MMS No
PIM
Alarm Clock Yes, Power off Alarm Clock
Stopwatch Yes
Scheduler Yes
Notepad Yes
Calculator Yes
Calendar Yes
World Time Yes
Converter Yes
Reminding Yes
State Number Search No
Puzzle box
Tetris
Games
Gobang
Multi-Media Yes 1.3 M
Format JPG
Digital Zoom Yes
Brightness Adjustment Yes
Effect Yes
Frame No
Self Shoot Yes
Sequence mode Yes
Camera
Quality Normal/Fine/Super
Video Shoot Format Mp4, 3GP

HISENSED90TechnicalSpecifications CONFIDENTIAL
ProprietaryInformationofHisense
All rights reserved, Page 7 of 10
Size 240*192
Time According to memory space
Frame Rate Max 15fps
Brightness Yes
Focal length Yes
Audio Play Mp3, MIDI
Video Play MPEG4, 3GP
Multi-Media Player Yes
Data Service
BREW No
Modem Yes
WAP WAP 2.0
JAVA No
Display Information
Power on/off Animation Yes
Standby Time Display Yes/Optional
Provider Info. Display Yes/Optional
Static Pic 4Wallpapers Display Optional Pic BMP
Customization Interface Theme Yes
Function Display Yes
CDMA Signal Strength
GSM Signal Strength
In Talking
Keypad Lock/Phone Lock
Roaming CDMA
Roaming GSM
1X Icon
WAP Service Icon
WAP Push Icon
Micro SD card
Bluetooth
SMS
Voice Message
Profile Mode
Alarm Clock
Icon Indicating
Battery
No. of Inte
g
rated Rin
g
Tones 15
No. of Polyphonics 64
Format Mp3/MIDI
Incoming Rings
SMS Prompt
Ring tone Setting
Keystroke

HISENSED90TechnicalSpecifications CONFIDENTIAL
ProprietaryInformationofHisense
All rights reserved, Page 8 of 10
Ring tonesVolume Adjustment Receiver
Power on/off Rings On/Off
Personal Ring Yes
Group Ring Yes
Priority Group>Common
Rings
Vibration
Alert Mode
Rings+Vibration
Warning in low battery Yes
Standard
Quiet
In Meeting
Profile Modes
In Out Door
Security Setting
Phone Lock Yes
PIN Setting Yes
Others
Auto Power on/off Yes
Keypad Lock Yes
Emergency Call Yes
Reset Yes
U-disk Yes
PC Sync Software Yes
6. Technical Specifications
Communication Protocols and Technical Indices
Mode of Access CDMA(Code Division Multiple Access)
CDMA Protocol IS-2000, CDMA 2000 1X
Transmitting Frequency 824～849MHz
Receiving Frequency 869～894MHz
Receiving Sensitivity ≤-104dBm
Communication Protocols and Technical Indices
Mode of Access GSM
Transmitting Frequency 890～915MHz, 1710~1785MHz, 1850~1910MHz
Receiving Frequency 935～960MHz, 1805~1880MHz, 1930~1990MHz
Receiving Sensitivity ≤-102dBm
Power Consumption
Item Standard
Talking Time ≤180 Minutes

HISENSED90TechnicalSpecifications CONFIDENTIAL
ProprietaryInformationofHisense
All rights reserved, Page 9 of 10
Standby Time ≤100 Hours
Charging Time ≤3 Hours
Standby Current
(both CG standby)
≤12mA
Working Condition
Item Description
Working Temperature -20 ℃～+60 ℃
Storage Temperature -30 ℃～+70 ℃
Humidity 5%~95%
7. Accessories
Travel Charger Voltage AC 100~240VInput Frequency 50~60Hz
Voltage 5V Output Max. current 730mA
59.5*27.24*42.1mmSize Approx 60g
Input Plug Type –A (others as requested)
Humidity 5%~95%
Battery
Item Description
Type Li-Ion
Capacity 1400mAh
Rated Voltage 3.7V
8. A Complete Set of Product
No. Name Qty. Remark
1 Mobile Phone Body 1 Without battery
2 Battery 1
3 Travel Charger Head 1 Form a charger with data cable
4 Data Cable 1
5 Headset 1
6 Driver Disk 1
7 User Manual 1

HISENSED90TechnicalSpecifications CONFIDENTIAL
ProprietaryInformationofHisense
All rights reserved, Page 10 of 10
9. Criterion and Standard Regarding Green Environmental Protection Handset
Materials
2002/95/EC The Europe Union Parliament and Council Promulgate the Restriction of the
use of certain hazardous substances in electrical and electronic equipment
SN/T2004.1-2005 Hg’s content measuration in Electrical and electronic product
SN/T2004.2-2005 Pb, Cd, Cr’content measuration in Electrical and electronic product
SN/T2004.3-2005 Cr6+ content measuration in Electrical and electronic product
SN/T2005.2-2005 PBBs, PBDEs’ content measuration in Electrical and electronic product
