HOMCOM B31-391 Installation guide

EN
1-Protection class I: The fitting has an earthing connection: The earth wire (yellow /green ) has to be connected to the clip
marked with .
2-This fitting should only be installed in rooms where direct contact with water is impossible.
3-Consumption in w, according to the speed of the motor.
4-May be operated with a remote control.
WARNINGS
•Read entire booklet carefully before beginning installation and save these instructions.
•To reduce the risk of personal injury, attach the fan directly to the support structure of the building according to these
instructions, and use only the hardware supplied.
•To avoid possible electrical shock, before installing your fan, disconnect the power by turning off the circuit breakers to
the outlet box and associated wall switch location.
•All wiring must be in accordance with national and local electrical codes. If you are un-familiar with wiring, you should use
a qualified electrician.
•To reduce the risk of personal injury, do not bend the blade attachment the system when installing, balancing or cleaning
the fan. Never insert foreign objects between rotating fan blades.
•To reduce the risk of fire, electrical shock or motor damage, do not lift or carry the fan by the lead wires.
•Ensure that when mounting the ceiling fan that the fixing can support the moving weight of the fan which is 15.8kg(35lb)
minimum.
•The fan blades cannot be installed lower than 2.3m from the floor.
NOTE:
The important precautions, safeguards and instructions appearing in this manual are not meant to cover all possible
conditions and situations that may occur. It must be understood that common sense, caution and carefulness are factors
which cannot be built into this pro- duct. These factors must be supplied by the person(s) installing, caring for and
operating the unit.
1

IMPORTANT SAFETY PRECAUTIONS
To ensure the success of installation, Be sure to read instructions and check parts for completeness before starting.
NOTE:
To reduce the risk of personal injury, only use the mounting kit provided with this ceiling fan.
TOOLS REQUIRED
Be sure to turn off the power before preparing for installation
2
Hardware List
Ax2pcs Bx2pcs Cx1pc Dx2pcs
Φ6X40 ST4. 8*38 M4*12 SM4*20
Hardware

PREPARING FOR MOUNTING
1. Remove the canopy from the mounting bracket, install the mounting bracket to the ceiling. (please ensure the fixing is
able to support minimum moving weight of the fan which is 15.8kg=35Lb)
2. Remove the nylon ball from the down rod and push the pin and clevis from the motor assembly, pass the wires through
the down rod and reinsert the pin and clevis, tighten the screw holding the down rod in place.
3
A x 2PCS
B x 2PCS

3. Put the yoke cover and canopy through the down rod, reinsert the nylon ball, pin and screw on the down rod.
4. Lift the fan up and place the nylon ball onto the bracket, Make sure the guide pin of the bracket fits into the slot of the
ball.
5. put the remote receiver into the middle of the bracket and connect the wires. (connect the wires according to the wiring
instructions)
4
The antenna don’t need be left outside the
outlet

power supply from ceiling (230V/50Hz)
6. Remote control connection diagram.
5
Subtitle:
1: AC IN N (Blue)
2: AC IN L (Brown)
3: Live wire for fan L (Brown)
4: Live wire for Lamp Control LA (Red)
5: Common zero line output N (Blue)
MOTOR
RECEIVER

7. Install the light kit pan to the motor assembly by tighten the screws.
8. Connect two plugs to connect the LED plate to the entire motor. Place the LED in the center of the panel.
9. Turn the acrylic bowl clockwise until it stops.
10. Assemble the canopy with the bracket again and using the fixing screws to tighten the canopy, make sure that the
canopy is secured and that you have not trapped any wires.
6

REMOTE CONTROL
IMPORTANTE
1. When the transmitter cannot control the receiver, please check whether the battery switch contact is normal, whether
the positive and negative poles are placed correctly, and whether the battery is sufficient. If the battery voltage is too
low, it will affect the transmitting intensity and cause remote control failure. Please replace the battery in time.
2. When the transmitter cannot control the receiver, please check if there are similar products nearby. The simultaneous
transmission of radio waves by the same kind remote control products will cause interference to each other and affect
the receiving effect.
3. The battery will decrease in power over time. Please replace the battery before it leaks to avoid damage to the
transmitter. Please handle the used battery properly. Keep the battery out of the reach of children.
4. If you do not use it for a long time, please remove the batteries from the transmitter.
7
1- Fan ON/OF
2- Fast speed
3- Middle speed
4- Low speed
5- 1 Hours delay
6- 2 Hours delay
7- 4 Hours delay
8- Light kit ON/OF
Using 1pcs of 12V-23A batteries.

Care and Cleaning
Troubleshooting
Problem
Solution
The fan will not
start.
 Check the main and branch circuit fuses or breakers.
 Check the line wire connections to the fan and switch wire connections in the switch
housing.
The fan is noisy.
 Ensure all motor housing screws are snug.
 Ensure the screws that attach the blade bracket to the motor hub are tight.
 Ensure the wire nut connections are not rattling against each other or the interior wall of
the switch housing.
 Allow a 24-hour “breaking in” period. Most noises associated with a new fan disappear
during this time.
 If you are using the Ceiling Fan light kit, ensure the screws securing the glassware are
tight. Check that the light bulbs are also secure.
 Ensure the canopy is a short distance from the ceiling. It should not touch the ceiling.
 Ensure your outlet box is secure and rubber isolator pads were used between the
mounting plate and outlet box.
The fan wobbles.
 Check that all blade and blade arm screws are secure.
 Most fan wobble problems are caused when blade levels are unequal. Check this level
by selecting a point on the ceiling above the tip of one of the blades. Measure from a point on
the center of the blade to the point on the ceiling. Rotate the fan until the next blade is
positioned for measurement, and measure from the same point on each blade to the ceiling.
Repeat for each blade. Any measurement deviation should be within 1/8 in. Run the fan for
ten minutes. If the minutes. If the fan continues to wobble please contact Customer Service
and a balancing kit will be sent to you at no charge.
EN：This product contains a light source of energy efficiency class <F>.
8
WARNING: Make sure the power is off
before cleaning your fan.
 Because of the fan’s natural movement, some connections may become loose. Check the support connections,
brackets, and blade attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from
the ceiling.
 Clean your fan periodically to help maintain its new appearance over the years. Do not use water when cleaning,
as this could damage the motor, or the wood, or possibly cause an electrical shock. Use only a soft brush or Iint-free
cloth to avoid scratching the finish. The plating is sealed with a lacquer to minimize discoloration or tarnishing.
 You can apply a light coat of furniture polish to the wood for additional protection and enhanced beauty. Cover
small scratches with a light application of shoe polish.
 You do not need to oil your fan. The motor has permanently-lubricated sealed ball bearings.

ES
1-Clase de protección I: El accesorio cuenta con una conexión a tierra: El cable de tierra (amarillo / verde) debe ser
conectado al clip marcado con señal de .
2- Solo coloque o instale el ventilador en una habitación seca, manténgalo alejado de las sustancias húmedas.
3- El consumo es en vatios por la velocidad del motor.
4- Se puede operar el ventilador con un control remoto.
ADVERTENCIAS
• Lea todo este manual cuidadosamente antes de instalar el ventilador, y guárdelo bien para las referencias futuras.
• Por motivo de reducir el riesgo de lesiones, conecte el ventilador a la estructura de soporte del edificio directamente seg
ún estas instrucciones. Solo utilice el hardware suministrado.
•Por motivo de evitar descargas eléctricas, antes de instalar el ventilador, apaque los disyuntores de la caja de salida y
los interruptores de pared para desconectar la alimentación.
• Todo el cableado debe estar de acuerdo con los códigos eléctricos nacionales y locales. Si usted no está familiarizado
con el cableado, póngase en contacto con un electricista calificado.
• Por motivo de reducir el riesgo de lesiones personales, no pliegue las hojas del ventilador al realizar la instalación y la
limpieza. Nunca inserte objetos entre las hojas giratorias del ventilador.
• Por motivo de reducir el riesgo de incendio, descarga eléctrica o daños al motor, no levante ni transporte el ventilador
tirando de los cables directamente.
• Al instalar el ventilador, asegúrese de que el techo pueda soportar el peso mínimo de 15,8 kg (35 libras).
•No se pueden instalar las hojas del ventilador a menos de 2,3 m del piso.
NOTA:
Las precauciones, salvaguardas e instrucciones importantes descritas en el manual no pueden cubrir todas las
condiciones y situaciones posibles que puedan ocurrir. Debe usar el sentido común y tener en cuenta la precaución y el
cuidado. Debe(n) considerar dichos factores la (s) persona(s) que instalan, realizan el mantenimiento y operan el
ventilador.
