HOMCOM 824-049V80 User manual

ASSEMBLY INSTRUCTION
INcjh017_US
READ AND SAVE THIS INSTRUCTION FOR FUTURE USE
120V~60Hz 45W
TOWER FAN
824-049V80

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL,
OPERATE OR MAINTAIN THE PRODUCT DESCRIBED. PROTECT
YOURSELF AND.OTHER BY OBSERVING ALL SAFETY INFORMA-
TION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT
IN PERSONAL INJURY AND/OR PROPERTY DAMAGE!
IMPORTANT SAFETY INFORMATION
1. Read all instructions carefully before using the FAN.
2. Use this FAN only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electrical shock, or
injury to persons.
3. Remove the package and ensure that the FAN is undamaged. In case
of doubt do not use FAN and contact with your supplier.
4. Do not let children play parts of package.
5. Before use the FAN, check if the voltage marked on the rating label
corresponds to the mains in your home.
6. Extreme caution is necessary when the FAN is used by or near
children or Invalids and whenever the FAN is left operating unattended.
7. Avoid using extension cord as the extension cord may overheat and
cause a risk of fire.
8. Do not pull the power cord to disconnect with power source. Always
grasp the plug to pull out.
9. Do not insert any objects into the FAN as it may cause an electric
shock or injure or damage to the FAN. Do not block or tamper with the
FAN in any manner while it is in operation.
10. Do not leave the FAN unattended. Always unplug FAN when not in
use.
11. This FAN is not intended for use in wet or damp locations. Never
locate a FAN where it may fall into a bathtub or other water container.
12. Do not use FAN outdoors.
13. Disconnect the fan from the mains power when not in use, and
before servicing or performing any maintenance.
-2-

WARNING : The Main Power Switch and the On/Off switch should not be used
as the sole means of disconnecting power. Always unplug the power cord
before servicing or moving the unit.
WARNING : To avoid danger of electric shock, unplug from outlet when not in
use and before cleaning. If the supply cord is damaged, it must be replaced by
the manufactory or it’s service agent or a similarity qualified person in order to
avoid a hazard.
14. Always disconnect the fan from the power supply when moving it
from one location to another.
15. Keep the fan clean and maintain in good condition (use an autho-
rized service agent).
16. Use recommended parts only (non genuine parts may be dangerous,
and will invalidate your warranty).
17. When not in use store in a safe, dry, childproof location.
18. If the supply cord is damaged, it must be replaced by the manufac-
ture, its service agent or similarly qualified persons in order to avoid a
hazard.
19. This appliance can be used by Children aged from 8 years and
above and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and under-
stand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
-3-

The base of the tower fan comes in two parts, which fit around the
oscillation base. Both parts fit easily together. The back half is the one
with cut-outs for the power supply cord.
1. First attach the front half of the base, aligning the holes in base with
the screw holes in the oscillation base, and leading the power cord
through the centre hole.
2. Then snap the back half of the base to the front half and secure with
the four screws (supplied)
PARTS NAME
ASSEMBLY
-4-

3. Thread the power supply cord through the two cut-outs at the bottom
of the base.
REMOTE CONTROL
1. Included a button cell battery (the type of battery CR2025). The
Remote Control Power button is labeled as such. All the functions
performed with the Remote Control work identically to the Manual
Controls.
The FAN may be operated by the manual controls located on the FAN
(as shown in FIGURE 3) or by your remote control (shown in FIGURE
2).
(Figure 1)
(FIGURE2)
OPERATION
824-049V80
-5-

1. Place the FAN on a stable flat surface. Plug the cord set into a
220-240V~A.C. electrical outlet.
2. POWER: Turn the FAN on by pressing the ‘POWER’ button; Turn the
FAN off by pressing the ‘POWER’ button again.
3. SPEED: You can adjust the fan speed to the desired level: low,
medium, or high by pressing ’SPEED’. The speed setting is displayed on
the LED screen (shown in FIGURE 4).
4. MODE: Pressing the’ MODE’ button will set the FAN into NORMAL,
NATURAL, and SLEEP mode.
5. TIMER: The fan is equipped with a timer that allows you to set it's
length of operation from 1 hour to 12 hours（834-004/834-005）, and
from 0.5 hour to 7.5hours （834-003）.
6. OSC: Pressing the ‘OSC’ button will start and stop the oscillation
function.
The symbol is displayed on the LED screen.
7. TEMP: Once the unit plug into the power socket or switch on, the FAN
will show the room temperature, and the ‘TEMP’ will change to ‘TIMER’
when the timer is set.
8. Power save mode: when the ‘sleep’ mode or the ‘timer’ is on, the main
display will be off after 30 seconds, and you can press any keys to turn
on the display again.
(FIGURE 3)
-6-

9.DISPLAY LED- can be switched off temporarily by pressing the DIS-
PLAY button on the remote control or by pressing and holding the
SPEED button on the control panel from more than 3 seconds,the
display will light up again once any control button is activated.
MAINTENANCE
1. This can only be done by an authorized service agent such as your
local Sealer dealer or any agent qualified to undertake electrical repairs.
2. If the unit requires external cleaning make sure it is switched off and
unplugged from the mains supply. Use a soft tissue or cloth for general
cleaning. To remove more persistent dirt or grime wipe down with a cloth
that has been dampened with warm soapy water. Do not use any
solvents ( such as thinners ) as these may damage the plastic casing.
Notice
1. This appliance is not intended for use by persons (including children)
with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with
appliance.
3. If the supply cord is damaged, it must be replaced by the manufac-
ture, its service agent or similarly qualified persons in order to avoid a
hazard.
824-049V80 FIGURE 4
