Home Styles 9100 Series User manual

Home Styles ConsumerAssistance: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Part List
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occurring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Hardware List
88 9100 104C
Black Granite Top
9100 Series
Top Assembly Instructions
M6x30
Head Cap Bolt
6 pcs. (+1 extra)
V.
Support Top
2 pcs.
W.
Top
1 pc.
9100 Series
V
.
Support Top

STEP 3
Attach Pull Handles to Doors (N) and
(O) using Machine Screws.
(See Figure 1)
Attach Doors (N) and (O) by sliding
door lift hinges into the side panel lift
hinges.(See Figure 2)
Slide Drawers (T) and (U) into place.
9100 Series TopAssembly Instructions
T
O
N
T
W
V
Figure 2
STEP 1
Put back end of Top Supports (V) into the
pre-drilled holes in unit and attach with
Head Cap Bolts.
STEP 2
Place Top (W) onto the unit and then tighten all
Head Cap Bolts.
U
T
V
Figure 1
Head Cap Bolt
Head Cap Bolt

IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
Home Styles ConsumerAssistance: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
W.
Top
1 Pc.
88 9100 104C
Black Granite Top
9200 Series
Top Assembly Instructions

9200 Series TopAssembly Instructions
STEP 1
Remove the drawers from the unit.
Place Top (W) onto the unit and attach it to the body with the Steel Plate Connectors,
Flat Washers, Spring Washers and Head Cap Bolts (short). (See Figure 1)
Slide the drawers into place.
Steel Plate
Connector
Flat Washer
Spring Washer
Head Cap Bolt
(short)
B
W
Figure 1
