Honeywell SILENT KNIGHT Farenhyt Series User manual

Installation and
Operations Manual
MODEL
RPS-1000
Intelligent Power Module
ECN: 11-0317
Document 151153
Rev: L
151153:L ECN: 15-0644
Farenhyt™Series

Contents
151153 1
Contents
Section 1
Overview ...................................................................................................................................................... 1-1
1.1 RPS-1000 Description ..............................................................................................................1-1
1.1.1 Maximum Number of SBUS Modules ................................................................................1-2
1.2 Agency Requirements ..............................................................................................................1-5
1.3 About This Manual ...................................................................................................................1-5
1.4 How to Contact Silent Knight ....................................................................................................1-5
Section 2
Before You Begin Installing ............................................................................................... 2-1
2.1 What’s in the Box? ...................................................................................................................2-1
2.2 Environmental Specifications ...................................................................................................2-1
2.3 Preventing Water Damage .......................................................................................................2-1
2.4 RPS-1000 Board and Terminal Strip Description .....................................................................2-2
2.5 Earth Fault Resistance .............................................................................................................2-4
2.6 Calculating Current Draw and Standby Battery ........................................................................2-5
2.6.1 Worksheet Requirements ..................................................................................................2-5
2.6.1.1 Maximum Battery Standby Load ..............................................................................2-6
2.6.2 Current Draw Worksheet ...................................................................................................2-7
2.7 Wiring Specifications ................................................................................................................2-8
2.7.1 Length Limitations ..............................................................................................................2-8
2.7.2 Calculating Wiring distance for SBUS modules .................................................................2-8
2.7.3 Wire Routing ....................................................................................................................2-11
Section 3
Hardware Installation .................................................................................................................. 3-1
3.1 AC Power .................................................................................................................................3-1
3.2 Battery Connection ...................................................................................................................3-3
3.3 Connecting the RPS-1000 to the FACP ...................................................................................3-4
3.3.1 Setting the Device ID .........................................................................................................3-6
3.4 Connecting SBUS Modules to the RPS-1000 ..........................................................................3-7
3.5 Flexputs™ I/O Circuits .............................................................................................................3-9
3.5.1 Conventional Notification Appliance ..................................................................................3-9
3.5.2 Releasing Operations ........................................................................................................3-9
3.5.2.1 Class B Notification Wiring .......................................................................................3-9
3.5.2.2 Class A Notification Wiring .....................................................................................3-11
3.5.3 Conventional Initiation Circuits .........................................................................................3-12
3.5.3.1 Class B Inputs ........................................................................................................3-12
3.5.3.2 Class A Inputs ........................................................................................................3-12
3.5.4 Installing 2-Wire Smoke Detectors ...................................................................................3-13
3.5.5 Installing 4-Wire Smoke Detectors ...................................................................................3-15
3.5.6 Auxiliary Power Configuration ..........................................................................................3-16

Contents
151153 2
3.5.6.1 Door Holder Power .................................................................................................3-17
3.5.6.2 Constant Power ......................................................................................................3-17
3.5.6.3 Resettable Power ...................................................................................................3-17
3.6 Conventional Relay Installation ..............................................................................................3-17
Silent Knight Fire Product Warranty and Return Policy
Manufacturer Warranties and Limitation of Liability

Overview 151153
1-1
Section 1
Overview
1.1 RPS-1000 Description
The RPS-1000 Intelligent Power Module provides additional power and circuits to the
IFP-2000, IFP-1000, IFP-1000ECS, IFP-100 or IFP-100ECS FACPs. The RPS-1000
can power all IFP-2000, IFP-1000, IFP-1000ECS, IFP-100 or IFP-100ECS
compatible modules, including SLC devices (via a Model 5815XL SLC Expander),
remote annunciators (RA-1000); notification appliances, auxiliary power modules,
and all other compatible modules.
Note: The IFP-100 does not use 5815XL SLC expanders.
The RPS-1000 has six Flexputs™ and two programmable relays. Outputs are rated
3.0 A (6.0 A total for each RPS-1000). Relays are Form C rated at 2.5 A @ 24 VDC.
Outputs and relays are fully programmable.
The RPS-1000 is optically isolated, providing ground loop isolation and transient
protection. It functions as an SBUS repeater which conditions the RS-485 signal and
allows the module to drive up to 6,000 feet of additional SBUS wiring.
The RPS-1000 is housed in a metal cabinet that is identical in size to the IFP-1000/
IFP-1000ECS FACP cabinet. This cabinet is large enough to house two 17 AH
batteries. Like the IFP-1000/IFP-1000ECS cabinets, the RPS-1000 cabinet provides
mounting studs for two Model 5815XL SLC Expander modules.
The RPS-1000 communicates to the main IFP-1000 or IFP-1000ECS FACP via the
SBUS. Each RPS-1000 provides an additional 6,000 feet of SBUS wiring length to
the main panel. As the drawings on the next pages illustrate, this allows you to
distribute modules, SLC devices, and outputs throughout an extremely large facility.
As well as expanding the wiring length capabilities of IFP-1000 or IFP-1000ECS, the
RPS-1000 also expands IFP-1000’s power capabilities by an additional 6.0 A of
current.

Overview 151153
1-2
1.1.1 Maximum Number of SBUS Modules
The chart below shows the maximum number of compatible modules that can be
used in an IntelliKnight installation. Modules can be distributed among the main panel
SBUS and each additional RPS-1000 SBUS in virtually any combination.
Figure 1-1 Example RPS-1000 Installation Overview
Module or Device Maximum Number
RPS-1000 Intelligent Power Module 8 per IFP-1000 or IFP-1000ECS installation
RA-1000 Remote Annunciator 8 per IFP-1000 or IFP-1000ECS installation
5815XL SLC Expander 2 per IFP-1000 or IFP-1000ECS installation
5824 Serial/Parallel Modules 8 per IFP-1000 or IFP-1000ECS installation
Outputs 6 per IFP-1000 or IFP-1000ECS / RPS-1000
Conventional Relays 2 per IFP-1000 or IFP-1000ECS / RPS-1000

Model RPS-1000 Installation Manual 151153
1-3
Figure 1-2 Example RPS-1000 Installation Overview (Details Added)

Overview 151153
1-4
1.2 Agency Requirements
The RPS-1000 has the same requirements as the main control panel. These
requirements are listed in the IFP-1000 Installation Manual (PN 151139) or IFP-
1000ECS Installation Manual (PN 151460).
1.3 About This Manual
This manual covers installation of RPS-1000 hardware. Software configuration
information is contained in the IFP-1000 Installation Manual (PN 151139) or IFP-
1000ECS Installation Manual (PN 151460).
1.4 How to Contact Silent Knight
If you have a question or encounter a problem not covered in this manual, contact
Silent Knight Technical Support at 800-446-6444.
To order parts, contact Silent Knight Sales at 800-328-0103 or [phone].

Before You Begin Installing 151153
2-1
Section 2
Before You Begin Installing
2.1 What’s in the Box?
The Model RPS-1000 ships with the following hardware:
• A cabinet with all hardware assembled
• Two keys for the front door
• Ten 4.7K ohm end-of-line resistors
Note: For UL installations Model 7628 4.7kend-of-line resistor (ordered separately) must be used.
• A battery cable for batteries wired in series
2.2 Environmental Specifications
It is important to protect the RPS-1000 control panel from water. To prevent water
damage, the following conditions should be AVOIDED when installing the units:
• Do not mount directly on exterior walls, especially masonry walls (condensation)
• Do not mount directly on exterior walls below grade (condensation)
• Protect from plumbing leaks
• Protect from splash caused by sprinkler system inspection ports
• Do not mount in areas with humidity-generating equipment (such as dryers, production
machinery)
When selecting a location to mount the RPS-1000, the unit should be mounted where
it will NOT be exposed to temperatures outside the range of 0°C-49°C (32°F-120°F)
or humidity outside the range of 10%-93% at 30°C (86°F) non-condensing.
2.3 Preventing Water Damage
Water damage to the fire system can be caused by moisture entering the cabinet
through the conduits. Conduits that are installed to enter the top of the cabinet are
most likely to cause water problems. Installers should take reasonable precautions to
prevent water from entering the cabinet. Water damage is not covered under
warranty.

Before You Begin Installing 151153
2-2
2.4 RPS-1000 Board and Terminal Strip Description
Figure 2-1 shows the RPS-1000 circuit board including location of terminals, the DIP
switch for setting module ID, and the LED.
Figure 2-1 The RPS-1000 Board Layout

Model RPS-1000 Installation Manual 151153
2-3
* Regulated/special application when used for releasing.
Table 2-1: Terminal Strip Description and Electrical Ratings
Terminal # and Label Description Rating
Voltage Current
1 L AC input (hot) 120/240 VAC,
50/60 Hz 2.7 A 1.4 A
2 G Earth ground N/A N/A
3 N AC input (neutral) 120/240 VAC,
50/60 Hz 2.7 A 1.4 A
4 X I/O 6* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
5 O 100 mA Initiation Circuits
6 X I/O 5* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
7 O 100 mA Initiation Circuits
8 X I/O 4* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
9 O 100 mA
Initiation Circuits
10 XI/O 3* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
11 O100 mA Initiation Circuits
12 X I/O 2* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
13 O 100 mA Initiation Circuits
14 XI/O 1* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
15 O100 mA Initiation Circuits
16 B SBUS OUT SBUS communication 5 VDC 100 mA
17 A
18 + SBUS power 24 VDC 1.0 A
19 -
20 BSBUS IN Used for Class A installations
21 A
22 +
23 -
24 N.C. RELAY 2 General Purpose Relay 2 24 VDC 2.5 A
25 C
26 N.O.
27 N.C. RELAY 1 General Purpose Relay 1 24 VDC 2.5 A
28 C
29 N.O.
30 B SBUS IN/
OUT RPS-1000 communication with main panel or to controlling
RPS-1000 if daisy-chained
5 VDC 100 mA
31 A
32 + MAIN RPS-1000 SBUS power (from
IFP-1000 or IFP-1000ECS) 24 VDC 10 mA
33 -

Before You Begin Installing 151153
2-4
2.5 Earth Fault Resistance
Table 2-2 lists the earth fault resistance detection for each applicable terminal on the
FACP.
Table 2-2: Earth Fault Resistance Values by Terminal
Function Terminal
Number
Terminal Label Low Biased High Biased
(Values in kohms) High
Trip High Restore Low Trip Low Restore
Flexput™
Notification
Circuits
4 X I/O 6 - - 0 0
5O 00 - -
6 X I/O 5 - - 0 0
7O 00 - -
8 X I/O 4 - - 0 0
9O 00 - -
10 X I/O 3 - - 0 0
11 O 0 0 - -
12 X I/O 2 - - 0 0
13 O 0 0 - -
14 X I/O 1 - - 0 0
15 O 0 0 - -
SBUS
Communication 16 B SBUS OUT -- 00
17 A - - 0 0
SBUS Power 18 + 0 0 - -
19 - - - 0 0
Used for Class
A Installations 20 B SBUS IN - - 0 0
21 A - - 0 0
22 + 0 0 - -
23 - - - 0 0

Model RPS-1000 Installation Manual 151153
2-5
2.6 Calculating Current Draw and Standby Battery
This section is for helping you determine the current draw and standby battery needs
for your installation.
2.6.1 Worksheet Requirements
The following steps must be taken when determining RPS-1000 current draw and
standby battery requirements.
Filling in the Current Draw Worksheet, Table 2-4 (Section 2.6.2)
1. For the RPS-1000, the worst case current draw is listed for the panel, addressable devices,
and SLC expanders. Fill in the number of addressable devices and expanders that will be
used in the system and compute the current draw requirements for alarm and standby.
Record this information in Table 2-4 at Line A.
2. Add up the current draw for all auxiliary devices and record in the table at Line B.
3. Add up all notification appliance loads and record in the table at Line C.
4. For notification appliances and auxiliary devices not mentioned in the manual, refer to the
device manual for the current ratings.
5. Make sure that the total alarm current you calculated, including current for the panel itself,
does not exceed 6.0 A. This is the maximum alarm current allowable.
6. Complete the remaining instructions in Table 2-4 for determining battery size require-
ments.
2.6.1.1 Maximum Battery Standby Load
Table 2-3 shows the maximum battery standby load for the RPS-1000 based on 24
and 60 hours of standby. The standby load calculations of line G in the Current Draw
Calculation Worksheet (Table 2-4) must be less than the number shown in Table 2-3
for the battery size used and standby hours required.
Note: 33AH max battery size for Fm (Factory Mutual) installations
Table 2-3: Maximum Battery Standby Load
Rechargeable
Battery Size Max. Load for 24 hrs. Standby, 5 mins. Alarm *Max. Load for 60 hrs. Standby, 5 mins. Alarm
7 AH 270 mA 105 mA
12 AH 475 mA 190 mA
17 AH 685 mA 270 mA
33 AH 1370 mA 540 mA
* Required for NFPA 72 Auxiliary Protected Fire Alarm systems for Fire Alarm Service (City Box)
and Remote Station Protected Fire Alarm systems (Polarity Reversal) and Digital Alarm Com-
municator/Transmitter (DACT).

Before You Begin Installing 151153
2-6
2.6.2 Current Draw Worksheet
For each RPS-1000* in the installation, use this worksheet to determine current
requirements during alarm/battery standby operation. (Copy this page if additional
space is required.)
*Use a separate worksheet for each RPS-1000.
Table 2-4: Current Draw Calculations
Device Number of
Devices Current per Device Standby
Current Alarm Current
For each device use this formula: This column X This column = Current per number of
devices.
RPS-1000 Intelligent Power Module
(Current draw from battery) 1* Standby: 40 mA 40 mA
Alarm: 160 mA 160 mA
Additional RPS-1000
(Daisy-chained to this module) (7 max.) Standby: 10 mA
Alarm: 10 mA
Addressable Devices (381 max.) Standby: 0.55 mA
Alarm: 0.55 mA
5815XL SLC Expander (2 max.) Standby: 55 mA mA
Alarm: 55 mA mA
RA-1000 or RA-100 Remote Fire
Alarm Annunciator (8 max.) Standby: 20 mA mA
Alarm: 25 mA mA
5824 Serial / Parallel Module (2 max.) Standby: 45 mA mA
Alarm: 45 mA mA
5865-4 LED Annunciator
(with reset and silence switches) (8 max.) Standby: 35 mA mA
Alarm: 145 mA mA
5865-3 LED Annunciator Standby: 35 mA mA
Alarm: 145 mA mA
5880 Generic LED Driver Module Standby: 35 mA mA
Alarm: 200 mA mA
ATotal System Current
**Auxiliary Devices Refer to devices manual for current rating.
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
BAuxiliary Devices Current
Alarm: mA mA
Alarm: mA mA
Alarm: mA mA
Alarm: mA mA
CNotification Appliances Current mA
D Total current ratings of all devices in system (line A + line B + C) mA mA
E Total current ratings converted to amperes (line D x .001): A A
F Number of standby hours (24 or 60 for NFPA 72, chapter 1, 1-5.2.5): H
G Multiply lines E and F. Total standby AH AH
H Alarm sounding period in hours. (For example, 5 minutes = .0833 hours) H
I Multiply lines E and H. Total alarm AH AH
J ***Add lines G and I. Total ampere hours required AH

Model RPS-1000 Installation Manual 151153
2-7
** If you are using door holders, you do not need to consider door holder current for alarm/battery standby,
because power is removed during that time. However, during normal operation, door holders draw current
and must be included in the 6.0 A total current that can be drawn from the panel.
*** Use next size battery with capacity greater than required.
2.7 Wiring Specifications
2.7.1 Length Limitations
This section contains information on calculating SBUS wire distances and the types
of wiring configurations (Class A and B).
2.7.2 Calculating Wiring distance for SBUS modules
The following instructions will guide you in determining the type of wire and the
maximum wiring distance that can be used with SBUS accessory modules.
To calculate the wire gauge that must be used to connect SBUS modules to the
panel, it is necessary to calculate the total worst case current draw for all modules on
a single 4-conductor bus. The total worst case current draw is calculated by adding
the individual worst case currents for each module. The individual worst case values
are shown in the table below.
Note: Total worst case current draw on a single SBUS cannot exceed 1 amp. If a large number of
accessory modules are required, and the worst case current draw will exceed the 1 amp limit,
then the current draw must be distributed using RPS-1000 Power Expanders. Each RPS-1000
Power Expander provides an additional SBUS, with an additional 1 amp of SBUS current. Wiring
distance calculations are done separately for eachRPS-1000, and separately for the panel itself.
After calculating the total worst case current draw, Table 2-5 specifies the maximum
distance the modules can be located from the panel on a single wire run. The table
insures 6.0 volts of line drop maximum. In general, the wire length is limited by
resistance, but for heavier wire gauges, capacitance is the limiting factor.
Model Number Worst Case Current Draw
RA-1000 Fire Annunciator .100 amps
RA-100 Remote Annunciator .100 amps
5824 Parallel/Serial Interface .040 amps
5880 LED IO Expander .250 amps
5865 LED Fire Annunciator .200 amps
RPS-1000 Intelligent Power Supply .010 amps
5496 Intelligent Power Module .010 amps

Before You Begin Installing 151153
2-8
These cases are marked in the chart with an asterisk (*). Maximum length can never
be more than 6,000 feet, regardless of gauge used. (The formula used to generate
this chart is shown in the note below).
Note: The following formulas were used to generate the wire distance chart:
Table 2-5: Wire Distances Per Wire Gauge
Wiring Distance: SBUS Modules to Panel
Total Worst Case
Current Draw (amps) 22 Gauge 18 Gauge 16 Gauge 14 Gauge
0.100 1852 ft. 4688 ft. * 6000 ft. * 6000 ft.
0.200 926 ft. 2344 ft. 3731 ft. 5906 ft.
0.300 617 ft. 1563 ft. 2488 ft. 3937 ft.
0.400 463 ft. 1172 ft. 1866 ft. 2953 ft.
0.500 370 ft. 938 ft. 1493 ft. 2362 ft.
0.600 309 ft. 781 ft. 1244 ft. 1969 ft.
0.700 265 ft. 670 ft. 1066 ft. 1687 ft.
0.800 231 ft. 586 ft. 933 ft. 1476 ft.
0.900 206 ft. 521 ft. 829 ft. 1312 ft.
1.000 (Max) 185 ft. 469 ft. 746 ft. 1181 ft.
Maximum Resistance (Ohms) = 6.0 Volts
Total Worst Case Current Draw (amps)
Maximum Wire Length (Feet) =
(6000 feet maximum) Maximum Resistance (Ohms) * 500
Rpu
where: Rpu = Ohms per 1000 feet for various Wire Gauges (see table below)
Table 2-6: Typical Wire Resistance Per 1000 ft.
Wire Gauge Ohms per 1000 feet (Rpu)
22 16.2
18 6.4
16 4.02
14 2.54

Model RPS-1000 Installation Manual 151153
2-9
Wiring Distance calculation example:
Suppose a system is configured with the following SBUS modules:
2 - RA-1000 Fire Annunciator
1 - RPS-1000 Intelligent Power Expander
1 - 5865 LED Fire Annunciator
1 - 5824 Parallel/Serial Interface
The total worst case current is calculated as follows:
Using this value, and referring to the Wiring Distance table, it can be found that the
available options are:
370 feet maximum using 22 Gauge wire
938 feet maximum using 18 Gauge wire
1493 feet maximum using 16 Gauge wire
2362 feet maximum using 14 Gauge wire
RA-1000 Current Draw = 2 x .100 amps = .200 amps
RPS-1000 Current Draw = 1 x .010 amps = .010 amps
5865 Current Draw = 1 x .200 amps = .200 amps
5824 Current Draw = 1 x .040 amps = .040 amps
Total Worst Case Current Draw = .450 amps

Before You Begin Installing 151153
2-10
2.7.3 Wire Routing
You must follow power-limited wiring techniques, which includes maintaining one-
quarter inch spacing between power-limited and nonpower-limited circuits and
separating high and low voltage circuits.
Figure 2-2 Wire Routing Example
RPS-1000 Board

Hardware Installation 151153
3-1
Section 3
Hardware Installation
RPS-1000 installation involves the following steps:
• AC power (Section 3.1) and backup battery connection (Section 3.2).
• Physical connection to the IFP-1000 or IFP-1000ECS FACP to the controlling RPS-1000
(see Section 3.3).
• Setting an ID for the RPS-1000 (Section 3.3.1).
• Physical connection of SBUS modules that will be powered by this RPS-1000 (Section
3.4).
• Physical connection of any outputs (conventional relays, notification appliances, auxiliary
power modules, and so on) that will be powered by this RPS-1000. See Section 3.5.1 for
notification appliance wiring information. Refer to the IFP-1000 Installation Manual (PN
151139) or IFP-1000ECS Installation Manual (PN 151460), for software configuration
information and other information about installing outputs.
3.1 AC Power
At installation, connect the AC terminals to 120 VAC source as shown in Figure 3-1. It
may be necessary for a professional electrician to make this connection.
The AC terminals are rated as 120 VAC, 50 or 60 Hz, 2.7 A (for the RPS-1000) or 240
VAC, 50 or 60 Hz, 1.4A (for the RPS-1000HV).
Figure 3-1 AC Power Connection
To 120 VAC
Power Source
White
Green
Black
For RPS-1000 For RPS-1000HV
To 240 VAC
Power Source
Earth
(Ground)
Note: RPS-1000HV
models are labeled.

Hardware Installation 151153
3-2
3.2 Battery Connection
The RPS-1000 battery charge capacity is 7.0 to 33.0 AH. Use 12V batteries of the
same AH rating. Determine the correct AH rating as per your current load calculation
(see Section Table 2-4).
Note: When your backup batteries requirements use backup batteries that are to large to fit into the
RPS-1000 cabinet. The AB-33 cabinet holds batteries up to the 33 AH size. (Refer to IFP-1000
Installation manual PN 151139 or IFP-1000ECS Installation manual PN 151460 for AB-33 instal-
lation instructions.
Wire batteries in series to produce a 24-volt equivalent. Do not parallel batteries to
increase the AH rating.
Figure 3-2 Battery Connection
3.3 Connecting the RPS-1000 to the FACP
1. Connect the RPS-1000 to the appropriate SBUS. The RPS-1000 can be connected directly
to the IFP-1000 / IFP-1000ECS FACP or can be daisy-chained to another RPS-1000. Fig-
ure 3-3 and Figure 3-4 show both connections.
2. Use on-board DIP switch to assign an ID#. (See Section 3.3.1) Figure 2-1 shows the loca-
tion of the DIP switches on the RPS-1000 board.
Red
To Panel
Black
UL Listed 12V Battery
UL Listed 12V Battery
Battery Jumper
(P/N 140694)
Replace batteries every 5 years.
Gell Cell Gell Cell
