INSTRUCTION SHEET
S4565/S4575/S4585 SERIES
IGNITION CONTROLS FOR COMBINED VALVE AND IGNITION SYSTEM
EN1R--9161 0006R10--NE
”Old”-- style ”New”-- style
APPLICATION
The Combined Valve and Ignition system (CVI) has specially
been developed for application in gas fired appliances with
either intermittent pilot or direct burner ignition.
For this system, the VK41../VK81.. series gas controls have
been designed to have the S4565/S4575/S4585 series
ignition controls attached directly onto the valve.
The combined system then provides programmed safe light
up, flame supervision and regulation of gas flow to the main
burner and/or pilot burner of the appliance.
DESCRIPTION
The S4565/S4575 ignition controls provide automatic ignition
for direct gas burner applications and for intermittent pilot gas
burner applications with safety timer.
The S4565/S4575 ignition controls are not intended for direct
exposure to flame envelope.
The S4585 ignition controls provide automatic ignition for
intermittent pilot gas burner applications without safety timer.
The S4565/S4575/S4585 ignition controls are designed to
meet the european standards:
EN 298: Automatic gas burner control systems.
EN 60730--1: Automatic electrical controls for house hold
and similar use.
The S4565/S4575/S4585 ignition controls can be used in
appliances according European standard for household
electrical requirements EN 60335 series.
The S4565/S4575 ignition controls are approved on the North
American standard ANS Z21.20 Automatic Ignition Systems.
NOTE: S4565SD is not an ignition control but an ignition
circuit and rectifier only
Contents
Page
Dimensional drawing 2................................
Features 3...........................................
S4565A,B,P,Q 3.......................................
S4565C,D,R,T 4.......................................
S4565AD,BD,CD,DD,PD,QD,RD,TD “1000” series 7......
S4565AD,BD,CD,DD,PD,QD,RD,SD,TD “2000” series 13..
S4565AF,BF,CF,DF,EF,PF,QF, RF, TF 18..................
S4575A,B,C,D,P,Q,R,T 23..............................
S4585D 26...........................................
General considerations 27.............................
Electrical connections 28..............................
Subject to change without notice. Printed in the Netherlands.

2
EN1R--9161 0006R10--NE
Ignition
72
115
60
50
113
Mounting hole Ø 3.2
Flame detection
30
29
19
Connector pins suitable for
Molex 3001 female connectors
Note: specific housings may deviate from drawing
Fig. 1. Dimensional drawing “new style” housing in mm
111 Connector pins suitable
f
or
Molex 3001 female connectors
62
Mounting hole Ø 3.2
69
29
19
18.5
69
110
Ignition
Flame detection
Note: specific housings may deviate from drawing
Fig. 2. Dimensional drawing “old style” housing in mm

3EN1R--9161 0006R10--NE
FEATURES IGNITION CONTROLS
Flame supervision.
Built--in 2.5 ... 60 Hz ignition.
Internal or external reset and alarm.
Accurate safety timer.
Supply voltages of 220 ... 240 V in a single product.
Full operating sequence after flame loss.
Extended spark time.
Optional phase neutral independent operation, flame
sensing independent of safety ground potential for
S4565AD ... TD “2000” series and S4575.
Safety time triggered by Air Pressure Switch (APS) for
S4565AD ... TD “2000” series and S4575.
Optional safe separation flame relay output or opto
coupler.
Optional main burner interrupt for S4565 BF, DF, QF, TF.
Volatile or non volatile lock--out according EN 298.
EMC filter optional
Protective impedance flame rod
Under voltage protection
SPECIFICATIONS DIRECT BURNER IGNITION CONTROL S4565A, B, P, Q
Model
Suffix A: atmospheric, direct burner ignition
Suffix B: atmospheric, direct burner ignition, flame relay output
Suffix P: as A except volatile lock--out
Suffix Q: as B except volatile lock--out
Supply voltage
220 ... 240 Vac, 50/60 Hz
Power consumption
4VA
Humidity
90% RH max. at 40 _C
Ambient temperature
0 ... 60 _C
--15 ... 60 _C (optional)
Electrical rating (see also note 2.)
Alarm: 220 ... 240 Vac, 50/60 Hz, 1 A, cos ♥>0.6 or
1mAmax.
Flame relay contact: 220 ... 240 Vac, 50/60 Hz,
1A,cos♥>0.6
Flame opto coupler: +5 V, 10 kτ
Electrical connection
High voltage spark: 2.8 mm spade terminal
Flame sensing: 4.8 mm spade terminal
PCB connectors: Molex 3003 series suitable for Molex 3001
female cable connector
Housing (degree of protection)
See page 29
Timing (depending on O.S. number)
Self check time (Tc): 1.5 s
Waiting time (Tw): 0 ... 30 s
Safety time (Ts): 3.5 ... 55 s
Extended spark ignition time: 0 ... Ts
Flame sensing
Min flame current: 0.9 ←A
Response time on: > 0.2 s
Response time off (TFR): < 1 s
(optionally other values available)
Ignition
Spark voltage: >12 kV at 40 pF load
Repetition rate: 2.5 ... 60 Hz (depending on O.S. number)
Max. spark gap: 3.5 mm
Length flame sensing cable
1mmax.
Length ignition cable
0.5 m max.
Length of wiring for external components
1mmax.
Remark
Optional integrated flame relay available with safe separation
or opto coupler with safe separation.
N.C. contact of flame relay has no safe separation.
WARNING
Opto coupler interface needs a debounce time > 20
ms in order to prevent noise caused by transients on
mains.
Side connections
9865
L
10 12
N
7
Optional **
12
LM RS
3
Optional
411
Optional
All versions
LM -- Limiter
RS -- Reset switch
*See note 2.
** See page 10 fig. 17.
*
Fig. 3. Connection diagram S4565A, B, P, Q

4
EN1R--9161 0006R10--NE
SYSTEM OPERATION
General
Lock- out reset
The S4565 ignition control can be reset by either depressing
the internal/external reset button (suffix A and B) or by
interrupting the permanent life (suffix P and Q).
NOTE 1.: If during normal use the reset button is pressed,
the gas valves drop out and the S4565 ignition
control starts a new sequence after releasing the
reset button.
NOTE 2.: If permanent alarm output:
neon indicator with integral resistor >150 kτ
Εmax 1 mA)
NOTE 3.: If an return high limit thermostat is used, the high
limit switch in the application needs a longer return
time than the trial for ignition time of the control.
This in order to provide non volatile lock out.
Suffix A, B, P and Q (see fig. 4.)
When there is a call for heat a self check period (Tc)plus
waiting period (Tw) elapse before built--in igniter and gas valve
are switched on.
The ignition spark ignites gas and resulting flame is detected
by the flame rod.
Ignition is switched off after extended ignition time and flame
establishment.
If flame is not established within the safety time (Ts), the
S4565 ignition control locks out.
If the flame is lost during normal run, the S4565 ignition
control repeats start sequence.
Tc+TwTs
Thermostat
Alarm
Ignition
Gas valve
Flame rod
Legend
Tc+Tw TFR
Fig. 4. Functional diagram S4565A, B, P, Q
SPECIFICATIONS IGNITION CONTROL S4565C, D, R, T
Model
Suffix C: fan assisted, direct burner ignition
Suffix D: fan assisted, intermittent pilot burner ignition
including safety timer
Suffix R: as C except volatile lock--out
Suffix T: as D except volatile lock--out
Supply voltage
220 ... 240 Vac, 50/60 Hz
Power consumption
4VA
Humidity
90% RH max. at 40 _C
Ambient temperature
0 ... 60 _C
--15 ... 60 _C (optional)
Electrical rating (see also note 5.)
Alarm: 220 ... 240 Vac, 50/60 Hz, 1 A, cos ♥>0.6 or
max 1 mA
Fan: 220 ... 240 Vac, 50/60 Hz, 1 A, cos ♥>0.6
LPG outdoor valve: 220 ... 240 Vac, 50/60 Hz, 1 A,
cos ♥>0.6
External ignition transformer: 220 ... 240 Vac, 50/60 Hz,
1A,cos♥>0.6
Electrical connection
High voltage spark: 2.8 mm spade terminal
Optional:
External mains voltage ignition transformer with
2.8 mm spade terminal
Flame sensing: 4.8 mm spade terminal or 2.8 mm spade
terminal for combined high voltage
spark/flame sensing
PCB connectors:Molex 3003 series suitable for Molex 3001
female cable connector
Housing (degree of protection)
See page 29
Timing (depending on O.S. number)
Self check time (Tc): 0, 1.5 or 2 s
Prepurge time (Tp): 0 ... 30 s
Safety time (Ts): 3.5 ... 55 s
Extended spark ignition time and stabilisation time: 0 ... Ts
(dependent on elaps of safety time)
Flame sensing
Min flame current: 0.9 ←A
Response time on: > 0.2 s
Response time off (TFR): < 1 s
(optionally other values available)

5EN1R--9161 0006R10--NE
Ignition
Spark voltage: >12 kV at 40 pF load
Repetition rate: 2.5 ... 60 Hz (depending on O.S. number)
Max spark gap: 3.5 mm
Length flame sensing cable
1mmax.
Length ignition cable
0.5 m max.
Length of wiring for external components
1mmax.
P -- Air proving switch
LM -- Limiter
RS -- Reset switch
*See note 5.
** Alternative side connection for models with combined flame
detection/high voltage. See page 5 fig. 6.
P
10 3
71
L
11
N
Side connections** 824
569
LM
RS
12
Optional
*¯
N
LPG
¯
N
¯
Fig. 5. Connection diagram S4565C, D, R, T
Special applications
input
ignition control
N
L
21
Ph1
Ph2
AT7030
Fig. 6. Alternative side connection for models with
combined flamedetection/high voltage.
Side connection
230 Vac N
Ignition transformer
Fig. 7. Alternative side connection for models with flame
sense input + 230 Vac output for external ignition
transformer

6
EN1R--9161 0006R10--NE
SYSTEM OPERATION
General
Lock- out reset
The S4565 can be reset by either depressing the
internal/external reset button (suffix C and D) or by
interrupting the permanent life (suffix R and T).
NOTE 4.: If during normal use the reset button is pressed,
he gas valves close and the S4565 ignition control
starts a new sequence after releasing the reset
button.
NOTE 5.: If permanent alarm output:
neon indicator with integral resistor >150 kτ
Εmax 1 mA)
Suffix C and R (see fig. 8.)
When there is a call for heat the fan starts running through the
no air position of the air proving switch.
If an external LPG valve is connected, this will be energized.
When sufficient air flow is proven by the air proving switch, a
self check period (Tc) and prepurge period (Tp) elapse before
the gas valve and built--in ignition or external ignition
transformer (optional) are switched on.
The ignition spark ignites gas and resulting flame is detected
by the flame rod.
Internal or external ignition is switched off.
After flame establishment a predetermined, extended ignition
time can be included.
If flame is not established within the safety time (Ts), the
S4565 ignition control locks out.
If the flame is lost during normal run, the S4565 ignition
control repeats the start sequence with prepurge.
If no air is proven by the air proving switch within the prepurge
time (Tp), the ignition control stays in waiting mode with fan
running.
Suffix D and T (see fig. 9.)
When there is a call for heat the fan starts running through the
no air position of the air proving switch.
If an external LPG valve is connected, this will be energized.
When sufficient air flow is proven by the air proving switch, a
self check period (Tc) and prepurge period (Tp) elapses before
the pilot gas valve and built--in ignition or external ignition
transformer (optional) are switched on.
The ignition spark ignites pilot gas and resulting flame is
detected by the flame rod.
Internal or external ignition is switched off.
After flame establishment a predetermined, extended ignition
time can be included and flame establishment and the main
valve is switched on.
If flame is not established within the safety time (Ts), the
S4565 ignition control locks out.
If the flame is lost during normal run, the S4565 ignition
control repeats start sequence at prepurge.
If no air is proven by the air proving switch within the prepurge
time (Tp), the ignition control stays in waiting mode with fan
running.
WARNING
Do not interchange air proving switch wiring in order to
prevent malfunctioning
Tc+Tp
P
P
¯
Thermostat
Fan
Air proving switch
Ignition
Main valve
Flame rod
Legend
Ts
Alarm
Tc+Tp TFR
Fig. 8. Functional diagram S4565C, R

7EN1R--9161 0006R10--NE
Tc+Tp
P
P
¯
Thermostat
Fan
Air proving switc
h
Ignition
Pilot valve
Flame rod
Legend
Ts
PV
MV
Main valve
PV
MV
Alarm
Tc+TpTFR
Fig. 9. Functional diagram S4565D, T
SPECIFICATIONS DIRECT BURNER IGNITION CONTROL
S4565AD, BD, CD, DD, PD, QD, RD, TD “1000- SERIES”
Model
Suffix AD: atmospheric, direct burner ignition
Suffix BD: as AD but with flame relay output
Suffix CD: fan assisted, direct burner ignition
Suffix DD: as CD but with flame relay output
Suffix PD: as AD except volatile lock--out
Suffix QD: as BD except volatile lock--out
Suffix RD: as CD except volatile lock--out
Suffix TD: as DD except volatile lock--out
Supply voltage
220 ... 240 Vac, 50/60 Hz
Power consumption
4VA
Humidity
90% RH max. at 40 _C non condensing
Ambient temperature
0 ... 60 _C
--15 ... 60 _C (optional)
Electrical rating (see also note 8.)
Alarm: 220 ... 240 Vac, 50/60 Hz, 1 A, cos ♥> 0.6 or max 1mA
Fan: 220 ... 240 Vac, 50/60 Hz, 1 A, cos ♥>0.6
Flame relay contact: 220 ... 240 Vac, 50/60 Hz, 1 A,
cos ♥>0.6
Flame opto coupler: +5 V, 10 kτ
LPG valve: 220 ... 240 Vac, 50/60 Hz,1 A max, cos ♥>0.6
Electrical connection
High voltage spark: 2.8 x 0.5 mm spade terminal
Flame sensing: 4.8 x 0.8 mm spade terminal
PCB connectors: Molex 3003 series suitable for Molex 3001
female cable connector
Housing (degree of protection)
See page 29
Timing (depending on O.S. number)
Self check time (Tc): 1.5 s
Waiting time (Tw): 0 ... 30 s
Safety time (Ts): 3.5 ... 25 s
Extended spark ignition time: 0 ... Ts
(dependent on elaps of safety time)
Flame sensing
Min flame current: 0.9 ←A
Response time on: > 0.2 s
Response time off (TFR): < 1 s
Ignition
Spark voltage: >12 kV at 40 pF load
(depending on O.S. number)
Repetition rate: 2.5 ... 60 Hz (depending on O.S. number)
Max. spark gap: 3.5 mm
Optional external ignition circuit: 220 ... 240 V (at no load),
single phase rectified, max 2 VA
Length flame sensing cable
1mmax.
Length ignition cable
0.5 m max.
Length of wiring for external components
1mmax.

8
EN1R--9161 0006R10--NE
Remark
Optional integrated flame relay available with safe separation
or opto coupler with safe separation.
N.C. contact of flame relay has no safe separation.
WARNING
Opto coupler interface needs a debounce time > 20
ms in order to prevent noise caused by transients on
mains.
9865
L
10 12
N
712
LM
3
Optional
411
RS
Side connections **
*
LM -- Limiter
RS -- Reset switch
*See note 8.
** See page 10 fig. 16.
*** See page 10 fig. 17.
Optional ***
Fig. 10. Connection diagram S4565AD and BD
9865
L
10 12
N
712
LM
3
Optional
411
RS
Side connections **
*
*See note 8.
** See page 10 fig. 16.
*** See page 10 fig. 17.
Optional ***
Optional
Fig. 11. Connection diagram S4565BD and QD “1000” series for gas/air application

9EN1R--9161 0006R10--NE
9865
L
10 12
N
712
LM
3
Optional
411
RS
N
P
¯
Side connections **
*
P -- Air proving switch
LM -- Limiter
RS -- Reset switch
*See note 8.
** See page 10. fig. 16.
*** See page 10 fig. 17.
NC
NO
C
Optional ***
Fig. 12. Connection diagram S4565CD and DD
9865
L
10 12
N
712
LM
3
411
N
Side connections
*
LM -- Limiter
RS -- Reset switch
*See note 8.
*** See page 10 fig. 17.
+--
Optional ***Optional
Fig. 13. Connection diagram S4565QD with external ignition circuit
98 65
L
10 12
N
712
LM
3
Optional
411
Side connections **
*
LM -- Limiter
*See note 8.
** See page 10. fig. 16.
*** See page 10 fig. 17.
Optional ***
Fig. 14. Connection diagram S4565PD and QD

10
EN1R--9161 0006R10--NE
9865
L
10 12
N
712
LM
3
Optional
411
P
¯
NC
NO
C
Side connections **
*
P -- Air proving switch
LM -- Limiter
RS -- Reset switch
*See note 8.
** See page 10. fig. 16.
*** See page 10 fig. 17.
Optional ***
Fig. 15. Connection diagram S4565RD and TD
Side connections
Fig. 16. Alternative side connection if sparking to ground
5V
+--
21
10k
Flame
output
Fig. 17. Connection for opto coupler output

11 EN1R--9161 0006R10--NE
SYSTEM OPERATION
General
The S4565AD, BD, CD, DD, PD, QD, RD, TD ignition control
can provide both closed--loop sparking and sparking to
ground.
If the S4565AD, BD, CD, DD, PD, QD, RD, TD will be used in
sparking to ground applications, the upper spark tab has to be
grounded.
Lock- out reset
The S4565 can be is reset by either depressing the
internal/external reset button (suffix AD, BD, CD and DD) or
by interrupting the permanent life (suffix PD, QD, RD and TD).
NOTE 6.: When first starting, the inition control can be in the
lock--out condition; reset the ignition control.
After a reset an extended waiting time will occur.
NOTE 7.: If during normal use the reset button is pressed,
the gas valves close and the S4565 ignition
control starts a new sequence after releasing the
reset button.
NOTE 8.: If permanent alarm output:
neon indicator with integral resistor >150 kτ
Εmax 1 mA)
Suffix AD and PD (see fig. 18.)
When there is a call for heat a self check period (Tc)plus
waiting period (Tw) elapses before the built--in igniter and gas
valve are switched on.
The ignition spark ignites gas and resulting flame is detected
by the flame rod.
After flame establishment a predetermined, extended ignition
time can be included.
If flame is not established within the safety time (Ts), the
S4565 ignition control locks out.
If the flame is lost during normal run, the S4565 ignition
control repeats start sequence.
Suffix BD and QD (see fig. 19.)
As AD and PD except flame relay contact or opto is closed
after flame detection.
Suffix CD and RD (see fig. 20.)
When there is a call for heat the fan starts running through the
no air position of the air proving switch after a self check
period (Tc) plus waiting period (Tw). When sufficient air flow is
proven by the air proving switch, the built--in igniter and gas
valve are switched on.
The ignition spark ignites gas and resulting flame is detected
by the flame rod.
After flame establishment a predetermined, extended ignition
time can be included.
If flame is not established within the safety time (Ts), the
S4565 ignition control locks out.
If the flame is lost during normal run, the S4565 ignition
control repeats start sequence.
If no air is proven by the air proving switch within the safety
time (Ts), the ignition control locks out.
Suffix DD and TD (see fig. 21.)
As CD and RD except flame relay contact or opto is closed
after flame detection.
Gas/air application
For gas/air application without dynamic aircheck, the
S4565AD, BD, PD or QD can be used.
In this application the fan is connected between pin 4 and 5
and will start when a call for heat is present. The waiting
period now acts as a prepurge time.
When the call for heat disappears or when the ignition control
goes in lock--out, the fan will be switched off.
Tc+TwTs
Thermostat
Alarm
Ignition
Gas valve
Flame rod
Legend
Tc+Tw
TFR
Fig. 18. Functional diagram S4565AD, PD

12
EN1R--9161 0006R10--NE
Ts
Thermostat
Alarm
Ignition
Gas valve
Flame rod
Legend
Flame relay contact
Tc+Tw Tc+TwTFR
LPG valve
LPG
LPG
Fig. 19. Functional diagram S4565BD, QD
P
P
Thermostat
Fan
Air proving switch
Ignition
Gas valve
Flame rod
Legend
Ts
Alarm
Tc+Tw Tc+TwTFR
Fig. 20. Functional diagram S4565CD, RD

13 EN1R--9161 0006R10--NE
P
P
Thermostat
Fan
Air proving switch
Ignition
Gas valve
Flame rod
Legend
Ts
Flame relay contact
Alarm
Tc+Tw Tc+TwTFR
Fig. 21. Functional diagram S4565DD, TD
SPECIFICATIONS DIRECT BURNER IGNITION CONTROL
S4565AD, BD, CD, DD, PD, QD, RD, SD, TD “2000” SERIES
Model
Suffix AD: atmospheric, direct burner ignition
Suffix BD: as AD but with flame relay output
Suffix CD: fan assisted, direct burner ignition
Suffix DD: as CD but with flame relay output
Suffix PD: as AD except volatile lock--out
Suffix QD: as BD except volatile lock--out
Suffix RD: as CD except volatile lock--out
Suffix SD: ignition circuit and rectifier only
Suffix TD: as DD except volatile lock--out
Supply voltage
230 ... 240 Vac, 50/60 Hz
Power consumption
4VA
Humidity
90% RH max. at 40 _C
Ambient temperature
0 ... 60 _C
--15 ... 60 _C (optional)
Electrical rating (see also note 8.)
Alarm: 230 ... 240 Vac, 50/60 Hz, output max 1mA
(e.g. neon light with internal resistor > 150 kτ)
Fan: 230 ... 240 Vac, 50/60 Hz, max 1 A, max cos ♥>0.6
Hour counter: 230 ... 240 Vac, 50/60 Hz, max 1 A, cos ♥>0.6
Flame relay contact: 230 ... 240 Vac, 50/60 Hz, max 1 A,
cos ♥>0.6
Flame opto coupler: +5 V, 10 kτ
Electrical connection
High voltage spark: 2.8 mm spade terminal
optional: 4 mm round terminal in spark to ground
application
Flame sensing: 4.8 mm spade terminal
PCB connectors: Molex 3003 series suitable for Molex 3001
female cable connector
Housing (degree of protection)
See page 29
Timing (depending on O.S. number)
Self check time (Tc): 0 ... 2 s
Waiting time (Tw): 0 ... 30 s
Safety time (Ts): 3.5 ... 55 s
Extended spark ignition time: 0 ... Ts
(dependent on elaps of safety time)
Flame sensing
Min flame current:
for optional phase independent systems: 0.5 ←A
for phase dependent systems: 0.9 ←A
Response time on: > 0.2 s
Response time off (TFR): < 1 s
(optionally other values available)
Ignition
Spark voltage: > 12 kV at 40 pF load
Repetition rate: 2.5 ... 60 Hz (depending on O.S. number)
Max. spark gap: 3.5 mm
Length flame sensing cable
1mmax.

14
EN1R--9161 0006R10--NE
Length ignition cable
0.5 m max.
Length of wiring for external components
1mmax.
Remark
Optional integrated flame relay available with safe separation
or opto coupler with safe separation.
N.C. contact of flame relay has no safe separation.
WARNING
Opto coupler interface needs a debounce time > 20
ms in order to prevent noise caused by transients on
mains.
9865
L
10 12
N
712 3
Optional
411
RS
Side connections *
LM -- Limiter
RS -- Reset switch
h -- Hour counter
*See page 16. fig. 28.
** See page 10 fig. 17.
h and RS and alarm are optional
Optional **
h
LM
Fig. 22. Connection diagram S4565AD and BD “2000 “series
9865
L
10 12
N
712 3
Optional
411
RS
Side connections *
LM -- Limiter
RS -- Reset switch
*See page 16. fig. 28.
** See page 10 fig. 17.
RS and alarm are optional
Optional **
LM
LM output
Fig. 23. Connection diagram S4565AD and BD “2000 “series (optional )

15 EN1R--9161 0006R10--NE
9865
L
10 12
N
712 3
Optional
411
RS
Side connections *
LM -- Limiter
RS -- Reset switch
P -- Air pressure switch
*See page 16. fig. 28.
** See page 10 fig. 17.
RS and alarm optional
Optional **
LM
P
Fig. 24. Connection diagram S4565CD and DD “2000”series
9865
L
10 12
N
712 3
Optional
411
Side connections *
LM -- Limiter
h -- Hour counter
*See page 16. fig. 28.
** See page 10 fig. 17.
h is optional
Optional **
h
LM
Fig. 25. Connection diagram S4565PD and QD “2000”series
9865
L
10 12
N
712 3
Optional
411
Side connections *
LM -- Limiter
P -- Air proving switch
*See page 16. fig. 28.
** See page 10 fig. 17.
Optional **
LM
P
Fig. 26. Connection diagram S4565RD and TD “2000”series

16
EN1R--9161 0006R10--NE
9865
N
10 12 712 3
411
Side connections
Not
used
L
valves
L
ignition
Void
Fig. 27. Connection diagram S4565SD “2000” series
Side connections
Fig. 28. Alternative side connection if sparking to ground
Side connection
Fig. 29. Alternative side connection in case of single rod
SYSTEM OPERATION
General
The S4565AD, BD, CD, DD, PD, QD, RD, TD ignition control
can provide both closed--loop sparking and sparking to
ground.
The S4565SD ignition circuit and rectifier provides
closed--loop sparking.
Lock- out reset
The S4565 can be is reset by either depressing the
internal/external reset button (suffix AD, BD, CD and DD) or
by interrupting the permanent life (suffix PD, QD, RD and TD).
NOTE 9.: If during normal use the reset button is pressed,
the gas valves close and the S4565 starts a new
sequence after releasing the reset button.
Suffix AD and PD (see fig. 30.)
When there is a call for heat a self check period (Tc)plus
waiting period (Tw) elapse before the built--in igniter and gas
valve are switched on.
The ignition spark ignites gas and resulting flame is detected
by the flame rod.
After flame establishment a predetermined, extended ignition
time can be included.
If flame is not established within the safety time (Ts), the
S4565 ignition control locks out.
If the flame is lost during normal run, the S4565 ignition
control repeats start sequence.
Suffix BD and QD (see fig. 31.)
As AD and PD except flame relay contact or opto is activated
after flame detection.
NOTE 10.: The hour counter is energized when the valve is
energized. It can be used as an output signal.
Suffix CD and RD (see fig. 32.)
When there is a call for heat, self check period (Tc)plus
waiting period (Tw) elapse when the air proving switch is in the
no air position.
After Tc+T
wthe fan starts running.
When sufficient air flow is proven by the air proving switch, the
built--in igniter and gas valve are switched on.
The ignition spark ignites gas and resulting flame is detected
by the flame rod.
After flame establishment a predetermined, extended ignition
time can be included.
If flame is not established within the safety time (Ts), the
S4565 ignition control locks out.
If the flame is lost during normal run, the S4565 ignition
control repeats start sequence.

17 EN1R--9161 0006R10--NE
If no air is proven by the air proving switch, the ignition control
stays waiting (optional lock out on no air can be included).
Suffix DD and TD (see fig. 33.)
As CD and RD except flame relay contact or opto is activated
after flame detection.
Suffix SD (see fig. 27.)
If line voltage is applied between pin 5 (line valves) and
pin 9 (N), the gas valve is switched on.
If the line voltage is applied between pin 4 (line ignition) and
pin 9 (N) the build in igniter is switched on.
The igniter circuit is fed during the negative half wave of the
mains.
Pin 8 is present but not intended for use. It is connected with a
resistor (100 τ)topin5.
Ignition circuit must be on shorter than 10 s in an application
with single ignition trial.
Gas/air application
For gas/air application without dynamic aircheck, the
S4565AD, BD, PD or QD can be used.
In this application the fan is connected between pin 4 and 5
and will start when a call for heat is present. The waiting
period now acts as a prepurge time.
When the call for heat disappears or when the ignition control
goes in lock--out, the fan will be switched off.
Tc+TwTs
Thermostat
Alarm
Ignition
Gas valve
Flame rod
Legend
Tc+Tw
TFR
Fig. 30. Functional diagram S4565AD, PD “2000”series
Ts
Thermostat
Alarm
Ignition
Gas valve
Flame rod
Legend
Flame relay contact
Tc+Tw Tc+TwTFR
Fig. 31. Functional diagram S4565BD, QD “2000”series

18
EN1R--9161 0006R10--NE
P
P
Thermostat
Fan
Air proving switch
Ignition
Gas valve
Flame rod
Legend
Ts
Alarm
Tc+Tw Tc+TwTFR
Fig. 32. Functional diagram S4565CD, RD “2000”series
P
P
Thermostat
Fan
Air proving switch
Ignition
Gas valve
Flame rod
Legend
Ts
Flame relay contact
Alarm
Tc+Tw Tc+TwTFR
Fig. 33. Functional diagram S4565DD, TD “2000”series
SPECIFICATIONS IGNITION CONTROL S4565AF, BF, CF, DF, PF, QF, RF, TF
Model
Suffix AF: atmospheric, direct burner ignition
Suffix BF: atmospheric, intermittent pilot burner ignition
including safety timer
Suffix CF: fan assisted, direct burner ignition
Suffix DF: fan assisted, intermittent pilot burner ignition
including safety timer
Suffix PF: as AF except volatile lock--out
Suffix QF: as BF except volatile lock--out
Suffix RF: as CF except volatile lock--out
Suffix TF: as DF except volatile lock--out
Supply voltage
220 ... 240 Vac, 50/60 Hz
Power consumption
4VA

19 EN1R--9161 0006R10--NE
Humidity
90% RH max. at 40 _C
Ambient temperature
0 ... 60 _C
--15 ... 60 _C (optional)
Electrical rating (see also note 12.)
Alarm: 220 ... 240 Vac, 50/60 Hz, 1 A, cos ♥>0.6or
max 1mA
Fan: 220 ... 240 Vac, 50/60 Hz, 1 A, cos ♥>0.6
LPG outdoor valve: 220 ... 240 Vac, 50/60 Hz, 1 A,
cos ♥>0.6
Electrical connection
High voltage spark: 2.8 mm spade terminal
Optional: 4 mm round terminal
Flame sensing: 4.8 mm spade terminal or 2.8 mm spade
terminal for combined high voltage
spark/flame sensing
PCB connectors:Molex 3003 series suitable for Molex 3001
female cable connector
Housing (degree of protection)
See page 29
Timing (depending on O.S. number)
Self check time (Tc): 1.5 s
Waiting time (Tw): 0 ... 30 s
Safety time (Ts): 3.5 ... 55 s
Extended spark ignition time and stabilisation time: 0 ... Ts
(dependent on elaps of safety time)
External main burner interrupt
Max open contact voltage 24 V, max current 15 mA
A low voltage relay is suitable.
An opto coupler e.g. CNY17--3 is also possible
A flame indicating series LED (see connection diagram) will
conduct min 0.85 mA if the contact is open and minimal
3.5 mA if the contact is closed.
Flame sensing
Min flame current: 0.9 ←A
Response time on: > 0.2 s
Response time off (TFR):<1s
Ignition
Spark voltage: > 12 kV at 40 pF load
Repetition rate: 2.5 ... 60 Hz (depending on O.S. number)
Max spark gap: 3.5 mm
Length flame sensing cable
1mmax.
Length ignition cable
0.5 m max.
Length of wiring for external components
1mmax.
Side connections** 10 3
71
L
11
N
824 569
LPG
LM G
RS
12
*
P -- Air proving switch
LM -- Limiter
RS -- Reset switch
*See note 12.
** Alternative side connection for models with combined flame
detection/high voltage. See page 5 fig. 6.
Optional
Fig. 34. Connection diagram S4565AF, BF, PF, QF

20
EN1R--9161 0006R10--NE
P -- Air proving switch
LM -- Limiter
RS -- Reset switch
*See note 12.
** Alternative side connection for models with combined flame
detection/high voltage. See page 5 fig. 6.
10 3
71
L
11
N
Side connections** 824
569
LM
P
¯
RS
12
Optional
*
Fig. 35. Connection diagram S4565CF, DF, RF, TF
P -- Air proving switch
LM -- Limiter
RS -- Reset switch
*See note 12.
** Alternative side connection for models with combined flame
detection/high voltage. See page 5 fig. 6.
10 3
71
L
11
N
Side connections** 824
569
LM
RS
12
Optional
*
CNY 17--3
P
22 K
Fig. 36. Connection diagram S4565DF, TF with external main burner interrupt
SYSTEM OPERATION
General
Lock- out reset
The S4565 can be is reset by either depressing the
internal/external reset button (suffix AF, BF, CF and DF) or by
interrupting the permanent life (suffix PF, QF, RF, and TF).
NOTE 11.: If during normal use the reset button is pressed,
the gas valves close and the S4565 ignition
control starts a new sequence after releasing the
reset button.
NOTE 12.: If permanent alarm output:
neon indicator with integral resistor >150 kτ
Εmax 1 mA)
