Honeywell Lynx Plus Series User manual

Ê800-13471)Š
800-13471 12/12 Rev A Part 1
2 Corporate Center Drive, Suite 100
P.O. Box 9040, Melville, NY 11747
Copyright © 2012 Honeywell International In
c.
www.honeywell.com/security
LYNX Plus
Testing the System
Using the Test mode allows each detection point to be checked for
proper operation. Testing should be conducted weekly to
ensure proper operation.
The keypad sounds a single beep about every 45 seconds as a
reminder that the system is in the Test mode.
Alarm messages are not sent to your Central Station during testing.
If a problem is experienced with any detection point (no confirming
sounds, no display), call for service immediately.
1. Disarm the system and close all protected windows, doors, etc.
The ready indicator LED should be lit if all zones are intact.
2. Enter your User Code and depress the TEST key. The control
emits a single long beep and “System Test” is displayed.
3. Listen. The sounder should beep one time and “Test In Progress”
should be displayed. The control sounds a single beep every 45
seconds while the test is in progress. If the sounder does not
sound, CALL FOR SERVICE.
4. Fault zones. Open each protected door and window in turn and
listen for three beeps from the keypad followed by the zone’s
voice descriptor. Each faulted detection point should appear on
the display. The display clears when the door or window is closed.
5. Walk in front of any interior motion detectors (if used) and listen
for three beeps. Each detector should appear on the display when
it is activated. The display clears when no motion is detected. Note
that if wireless motion detectors are used, there is a 3-minute
delay between activations to conserve battery life.
6. Test all smoke detectors, following the manufacturer's instructions.
7. When all detection points have been checked and are intact
(closed), there should be no zone numbers displayed.
8. Exit test mode by entering your User Code and depressing the
OFF key.
Setting the Time and Date
NOTE: The system must be disarmed before time/date can be set.
You can set the time and date by doing the following:
1. Enter + FUNCTION + 63
(Master Code)
2. The system enters the Voice Prompt Calendar Setting mode.
Follow the prompts to set the Date and Time. Enter the ADD
key to advance to the next field or ESCAPE key to return to
the previous field.
Enter the 2 –digit hour and depress the ADD key.
Enter 1 (PM) OR 0 (PM) and depress and depress the ADD key.
Enter the 2 –digit minute and depress the ADD key.
Enter the 2 –digit month and depress the ADD key.
Enter the 2 –digit day and depress the ADD key.
Enter the 2 –digit year and depress the ADD key. The system
beeps 4 times and exits the Calendar Setting mode.
AUX Function
The AUX key may have been programmed to either perform a
predefined function or to send a preset message to a pager/“Follow
Me” system phone number. Refer to the full version User Guide to
program an AUX function.
Follow Me Announcements
If the “Follow Me” Announcement feature has been programmed
your system will automatically dial a telephone number and deliver a
voice message. The two different types of “Follow Me” messages
include system and reminder announcements. Refer to the full
version User Guide for additional information regarding this feature.
Function Press these Keys …
Program OR
Delete “Follow
Me” Reminder
Phone number
+ FUNCTION + 65
(Master Code)
Follow the prompts to program/delete the
Follow Me” Reminder Phone number
System/Zone Status
A "beeping" at the control, indicates a trouble condition in the
system and requires your attention. Determine if the zone(s)
displayed are intact and make them so if they are not. If the display
persists, CALL FOR SERVICE.
To silence the beeping for these conditions, press any key.
Primary System Status Announcements
Disarmed–Ready to Arm [check system]
Disarmed [not ready to arm]
Armed [away] [stay] [instant] [check system] [exit now]
NOTE: The phrases shown in brackets are variable, and are announced
only if appropriate in the current state of the system.
Secondary System Status Announcements
Fire Alarm + zone voice descriptor
Alarm + zone voice descriptor
Carbon Monoxide Alarm + zone voice descriptor
Carbon Monoxide Fault + zone voice descriptor
Fire Fault + zone voice descriptor
Fault + zone voice descriptor
Alarm + zone voice descriptor
Low Battery + zone voice descriptor
System Low Battery
Check System
AC Loss
Zones Bypassed
Chime
See the full User Guide for additional details.
Record a Message
Your system can record brief single or multiple messages. The total
available recording time is 85 seconds.
Function Press these Keys… What happens …
Record a
Message FUNCTION + RECORD
(Select OFF key when
recording is complete)
Keypad Displays
“Record Press Off to
Stop”.
When recording is
complete the keypad
beeps two times and
“Msg” is displayed.
Play and
Delete
Messages FUNCTION + PLAY
System plays and then
deletes the recorded
message.
Delete all
Messages
FUNCTION + PLAY
then enter
FUNCTION + DELETE
System plays and then
deletes ALL recorded
messages.
Speaker Phone Mode
Your system can be used as a Speaker Phone.
Function Press these Keys…
Make a Call #+ AUX and dial desired number
Answer a call #+ AUX
End a call OFF
Servicing Information
Your local Honeywell dealer is the person best qualified to service
your alarm system. Arranging some kind of regular service
program with him is advisable. Your local Honeywell dealer is:
Name:
Address:
Phone:
LYNX PLUS SECURITY SYSTEM
Quick Guide to User Functions
Full User Guide Available Online: This Quick Guide describes the most frequently used features and functions of your system. For full details of
all user functions, please see the system’s User Guide located online at: http://www.security.honeywell.com/hsc/products (see LYNX Plus
Security System User Guide P/N 800-03858V2 or higher). The full version User Guide is also available from your installer upon request.
Congratulations on your ownership of a Honeywell Security System. This system provides:
Three forms of detection: burglary, fire and emergency (see your installer for which forms of detection are installed)
At least one keypad which provides control of system and displays system status
Various sensors for perimeter and interior burglary detection
Optional smoke or combustion detectors designed to provide early warning in case of fire.
Your system may also be programmed to automatically send alarm and status messages to a Central Monitoring Station.
System Basics
The following is a list of some of the most common features and
functions of your system:
Several modes of burglary detection: Stay, Away, Instant.
Bypass feature lets you bypass selected zones while leaving the
rest of the system armed.
Chime mode alerts you to the opening of protected doors and
windows while the system is disarmed.
Fire and carbon monoxide detection are always active (if
installed) and an alarm sounds if a fire or carbon monoxide
condition is detected.
Panic keys (if programmed) let you manually initiate fire, police
and medical alarms using the keypad.
4-digit security codes are used in conjunction with keypad
commands to perform system functions.
Each user (up to 8 can be assigned a different security code.
The system sensing devices have been assigned to various
“zones,” which are specific areas of detection (e.g., front door,
kitchen window, etc.).
Zone numbers (points of detection) are displayed at the keypad
when an alarm or trouble condition occurs.
Message Center allows recording and play-back of brief voice
messages (up to 85 seconds).
Speaker Phone allows the control to be used for hands free
telephone conversation. See the full User Guide for details.
Two-way Voice allows the Central Station to listen, talk or
conduct a two-way conversation with in individuals at the
premises. See the full User Guide for details.
Follow me reminder announcements allow the panel to dial a
number and deliver system status messages. See the full User
Guide for details.
A Scheduling feature can be programmed to automatically
perform certain functions (e.g., arm the system) at a
predetermined time each day. See the full User Guide for details.
Entry/Exit Delays
Entry Delays give you time to disarm the system when you
enter through the designated entrance door.
You must disarm the system before the entry delay period ends,
or an alarm will occur (keypad beeps during the entry delay
period, reminding you to disarm the system).
Exit delay gives you time after arming the system to leave
through the designated exit door(s) without setting off an alarm.
If programmed, a slow beeping will sound during the exit delay
period until the last 10 seconds, which then changes to fast
beeping (alerting you to the end of exit delay). If you cannot
leave within this delay time period, you should stop, disarm the
system, and start over to avoid a false alarm.
See your installer for your delay times. See the full User Guide
for details on Exit Error alarms.
Notes on Burglary Detection
The system must be armed before the burglary detection can
sense intrusions.
To arm your system, enter your security code and depress the
STAY or AWAY key.
To arm your system, if the Quick Arm feature is enabled,
depress the STAY or AWAY key for at least 2 seconds. You do
not need to enter your security code.
To disarm the system, enter your security code and depress
the OFF key.
When an alarm occurs, the control sounds and displays the
zone(s) causing the alarm. An external sounder may also
sound, if installed.
If your system is connected to a Central Monitoring Station, an
alarm message is also sent (delayed 30 seconds by default to
reduce false alarms).
To stop the alarm sounding, simply disarm the system.
Memory of Alarm: When an alarm condition occurs, the
keypad displays the number(s) of the zone(s) that caused the
problem, and displays the type of alarm. Clear the Memory of
Alarm display by entering another “Off” sequence.
IMPORTANT
If you return to the premises and the burglary sounder is
on, or the keypad beeps rapidly upon entering the
premises, it indicates that an alarm has occurred during
your absence and an intruder may still be on the
premises. LEAVE IMMEDIATELY and CONTACT THE
POLICE from a nearby safe location.
Notes on Fire and CO Detection
Your fire alarm system (if installed) is on 24 hours a day, for
continuous detection. In the event of an emergency, the
smoke and heat detectors sound their alarms, triggering a
loud, interrupted pulsed sound from the control and any
external sounder(s) (if installed).
Carbon monoxide (CO) detectors, if installed, provide
continuous detection. If a high level of carbon monoxide is
detected, an interrupted pulsed alarm sound occurs at the
control and the detector(s). Immediately move to a spot
where fresh air is available, preferably outdoors. From a safe
area, call your security service provider for further
instructions. To silence the control sounding, enter 4 digit User
Code followed the Off key. To silence the detector, see its
instructions.

Checking Open Zones o
r
System Status
Checking Zones: Before arming your system, all protected doors, windows and other
detection zones must be closed or bypassed; otherwise the keypad displays “Disarmed Not
Ready.”
Function Press these keys… What happens
Check General
System Status
Zones STATUS Announces general system status.
Check Specific
System Status
STATUS (2 times)
(second depression must be
made within 10 seconds)
Displays system status and announces zone
faults.
Arming the System
Before arming, close all perimeter doors and windows and make sure the “Ready to Arm”
message is displayed. Enter the 4-digit Security Code and select the desired key. The system
will beep three times to confirm the arming and will display the armed status.
After arming, leave the premises through an entry/exit door during the exit delay period and
be sure the door is reclosed to avoid causing an alarm.
Mode Press these keys… When to use an arming mode
and what happens
Stay User Code + STAY
Used to arm the system when persons are staying
inside (or if you have pets that are moving
throughout the premises).
Arms perimeter zones; interior zones left
disarmed.
An alarm sounds if any protected window or non-
entry/exit door is opened.
Instant Stay User Code + STAY +
NO DELAY
Used when staying inside and you do not expect
anyone to use an entry/exit door.
Same as Stay mode, except entry delay is Off.
An alarm sounds same as Stay mode, and sounds
upon opening entry/exit doors.
Away User Code + AWAY
Used when premises is vacant (including pets).
Arms the entire system (interior and perimeter).
An alarm sounds if a protected window or any
door is opened, or if any movement is detected.
Quick
Arming STAY OR AWAY
(for at least 2 seconds)
If programmed, you can press the Quick Arm
button in place of your security code when arming
the system
Disarming the System and Silencing Alarms
The OFF key is used to disarm the system, silence alarm and trouble sounds, and clear
memory of alarm displays. Enter the 4-digit Security Code and select the OFF key.
Mode Press these keys … What happens
Disarm &
Silence
Alarms
User Code + OFF
OR User Code
(If Quick Disarm is active)
System is disarmed and alarm sounding is
silenced.
To clear the memory of alarm display (if present),
enter a second Off Sequence.
Bypassing Zones
Select the BYPASS key when you want to arm your system with one or more zones
intentionally unprotected. The system must be disarmed first.
Mode Press these keys… What happens
Bypass
Individual
Zone(s)
User Code + BYPASS
+ 2-digit zone number
(s)
When finished, the keypad will provide a
confirmation beep and “Bypass” will be displayed
along with each bypassed Zone Number.
When armed, the arming message is displayed
with “Bypass.”
Bypassed zones are unprotected and will not
trigger an alarm if violated.
Fire zones cannot be bypassed.
Bypasses are automatically removed when the
system is disarmed.
Bypass all
Open Zones User Code + BYPASS +
FUNCTION
All open (faulted) zones are bypassed (if
programmed).
Display
Bypassed
Zones
User Code + BYPASS
+ wait
“Bypass” will be displayed along with each
bypassed Zone Number
1000-300-013-V0
ARMED READY
BYPASS
NO DELAY
RECORD
TEST
FUNCTION
STATUS
VOLUME PLAY
CODE
LIGHTS ON
LIGHTS OFF CHIME
ESCAPE
ADD
DELETE
SELECT
13
2
4
5
6
9
1 2
0
OFF
AWAY
STAY
AUX
9
3
6
8
7
4 5
17
19
21
18
20
16
15 10
11
13
1414 12
7
8
Index
Item Description
1 Display Window Liquid Crystal Display (LCD). Displays protection point identification ,
system status, messages, and user instructions.
2 ARMED (Red)
LED Indicator ON = System is armed (Stay or Away)
OFF = System is disarmed
Blinking = System is armed, and not ready to be armed (an alarm has
occurred)
Blinking once per second = AVM (VOX or Talk) or speaker phone mode is
active
3 READY (Green)
LED Indicator ON = system is ready to be armed
OFF = System is armed
Blinking = System is disarmed, and not ready to be armed (a fault exists)
Blinking once per second = AVM (VOX or Talk) or speaker phone mode is
active
4 PLAY key Play a recorded message or increase volume of voice messages.
5 STAY/DELETE
key Arms the perimeter burglary protection, (but not the
motion sensor)
or to
delete messages.
6 AUX/Select key Program/perform a predefined function or to send a preset message to a
pager or “Follow Me” system phone number.
7 BYPASS key Bypasses individual protection zones or to decrease volume of voice
messages.
8 CHIME key Turns the Chime mode On or Off.
9 FUNCTION key Allows alternate key functions or as a “repeat” key during Clock/Calendar
setting.
10 Microphone Used to record personal messages via the Message Center, and for two-
way voice and speaker phone operation.
11 NO DELAY key Used with STAY or AWAY function to bypass the entry delay
12 CODE key Allows entry of User Codes for additional system users
13 STATUS key Use to display all open zones and announce system status when system is
disarmed
14 LIGHTS ON key Turns lights or other devices On, if programmed by the installer
15 TEST key Tests the system and alarm sounder
16 LIGHTS OFF key
Turns lights or other devices Off, if programmed by the installer
17 Speaker Source of alarms, audible internal warning and confirmation sounds, status
announcements, as well as alarms (Refer to the full User Guide for details)
18 AWAY/ADD key Completely arms perimeter and interior burglary protection or to accept
entries in specific programming modes.
19 OFF/ESCAPE key
Disarms the burglary portion of the system, silences alarms and audible
trouble indicators, and clears alarm trouble display after the problem has
been corrected. Also used to exit/abort “Follow Me” phone number and
Clock/Calendar mode.
20 RECORD key Activates the recording function to record personal messages.
21 0 -9 keys Used to enter your individual security access code(s).
System Settings
Your system settings including volume level (message playback, system announcements,
and status beeps). Additionally, you can turn On/Off the Chime, Telephone Ringer and/or
System Voice Announcements.
Note: To enable or disable the Chime mode the system must be disarmed.
Mode Press these Keys… What happens
Mute System
Announcements
FUNCTION + VOLUME
+ OFF
Disables the Voice announcement of
system status.
Restore System
Announcements
OR
Adjust Volume
FUNCTION + VOLUME
+ 3 OR 6
Enables the Voice announcement of system
status.
Adjusts the volume of the Voice
announcements.
Chime
Mode
FUNCTION + CHIME
Alerts you to the opening of a perimeter
door or window while the system is
disarmed.
Open (faulted) zone information is
displayed.
Three tones sound at the keypad whenever
a perimeter door or window is opened
(faulted interior zones do not produce a
tone).
Ringer Mode # + VOLUME + AUX Enables or disables the Telephone Ringer.
Security Codes
Your installer assigned a master code that is used to perform all system functions.
In addition, security codes can be assigned for up to 6 users. Only the Master User can
assign security codes to users. Note that User No. 07 is assigned to the Babysitter Code and
User No. 08 is the Duress Code.
To Add/Edit/Delete User Codes:
Follow the steps below:
Function Perform the following…
Add User Code Enter Master User Code + CODE + User Number (03-08) + User Code
(Keypad beeps once confirming User Code addition)
Delete User
Code Enter Master User Code + CODE + User Number (03-08) (Keypad beeps once confirming User Code deletion)
Change Master
User Code
Enter Master User Code + CODE + Master User Number (02) + New
User Code (2 times)
(Keypad beeps 3 times confirming Master User Code change)
Panic Keys
Your system may have been programmed to use special keys to manually activate
emergency (panic) functions.
To activate a Panic Function:
Press and hold down the both keys of the Panic key pair for at least 2 seconds.
* All panic functions send signals to the Central Monitoring Station, if connected.
The functions that might be programmed are listed below. See your installer for the
function(s) that may have been programmed for your system. Your Installer should note the
functions that are active in your system.
Keys Zone Sends this Signal*
1 and 95
3 and # 96
and # 99
